Much More Water BlueBox 1200 RORS User manual

PURE WATER – ANYTIME – ANYWHERE
BlueBox 1200 RORS
Operating manual

2PURE WATER – ANYTIME – ANYWHERE
BlueBox 1200 RORS
Post-chlorination and UV-disinfection features

3
C
L
E
A
N
W
A
T
E
R
R
A
W
W
A
T
E
R
I
N
L
E
T
F
L
U
S
H
W
A
T
E
R
O
U
T
L
E
T
C
L
E
A
N
W
A
T
E
R
R
A
W
W
A
T
E
R
I
N
L
E
T
F
L
U
S
H
W
A
T
E
R
O
U
T
L
E
T
1Affix the three coupling hoses
on the outside of the container.
2Press red blue and black
hoses onto the quick
couplings.
Follow the colour codes:
Red sign = red hose
Blue sign = blue hose
Black sign = black hose
3Prepare the floating device.
The floating position can be
adjusted with water. The more
water, the deeper it will sink.
4Affix the float filter as shown.
PART 1 BEFORE USING THE BLUEBOX
ill. 1
ill. 2
ill. 4
ill. 3
Flush water
outlet
(Red hose)
Raw
water inlet
(Black hose)
Clean
water outlet
(Blue hose)

4
C
L
E
A
N
W
A
T
E
R
R
A
W
W
A
T
E
R
I
N
L
E
T
F
L
U
S
H
W
A
T
E
R
O
U
T
L
E
T
START
STOP
Main Power
Switch
START
STOP
Main Power
Switch
1Mount correct electrical plug
to the supplied mains wire.
Connect the unit to a 230 V
power supply.
2Before starting the pump, the
blue pressure valve must be
opened by turning it all the way
counter-clockwise.
IMPORTANT
The BlueBox must not be
started with pressure on.
3Turn the black power switch
clockwise to the ON position.
4Start the pump by pressing
the green start button.
PART 2 STARTING THE BLUEBOX (electrical version)
ill. 5
ill. 6
ill. 8
ill. 7
Start
Electrical cabinet
Electrical cabinet
On
Pressure valve

5
C
L
E
A
N
W
A
T
E
R
R
A
W
W
A
T
E
R
I
N
L
E
T
F
L
U
S
H
W
A
T
E
R
O
U
T
L
E
T
365
5Let the pump run for 1-2
minutes until no more bubbles
are detected from the red hose.
6Turn the blue pressure valve
clockwise until pressure is
approximately 8 bars.
7Open the grey electrical cabinet
and check that the UV display
unit is active and that the
display shows the number of
days left.
The UV light must be changed
after 365 days of operation.
Please see maintenance
section.
8Non-potable (not suitable for
drinking) water will come out
of the red hose (Flush water
outlet).
Drinking water can be tapped
from the blue hose (Clean
water).
The flow meter shows the
volume of clean water.
WARNING!
Never drink the water from the
blue fresh-water tube before the
BlueBox has been working for at
least 3-5 minutes!
Flush water
outlet
(Red hose)
Raw
water inlet
(Black hose)
Clean
water outlet
(Blue hose)
ill. 11
ill. 9
ill. 10
Wait 3-5
minutes
Pressure valve
Electrical cabinet
UV display
Air filter

6
Stop
START
STOP
Main Power
Switch
START
STOP
Main Power
Switch
START
STOP
Main Power
Switch
1Carefully turn the blue pressure
valve counter-clockwise until
the pressure reads 0 bar.
2Drain the system fully by
opening the drain valve,
situated at the bottom of
the BlueBox unit, next to the
electrical cabinet.
Run the BlueBox for 1 minute
without pressure and without
feed water intake.
3Stop the pump by pressing the
red Stop button.
Close the drain valve.
4Turn the black switch counter-
clockwise to turn off the
BlueBox.
WARNING!
Never stop the BlueBox
with pressure on.
PART 3 AFTER USING BLUEBOX (electrical version)
0 bars
ill. 12
ill. 13
ill. 14
Off
Electrical cabinet
Electrical cabinet
Drain
valve
ill. 15

7
Daily
1Cleaning of the float-filter:
Screw off the red balloon and
plastic top. Remove the nylon
and metal filters. Rinse them
in clean water with a brush.
Insert the filters and check that
the crude filter is placed on top.
2Cleaning of the three filters
cartridges:
a) Unmount the three cylinders
containing the filters.
b) Remove the filter from the
housing and rinse both with
clean water.
IMPORTANT
The filters must NOT be wrought
or squeezed.
3Reinstall the used or new filter cartridges in the housings and mount back onto the
corresponding bracket.
4The filters should be changed when plant pressure is becoming too high or when they are
judged to being too dirty. Max. 6 months operating time.
5The air filter mounted in the door of the electrical cabinet must be inspected every day ensuring
the filter is not clocked.
PART 4 MAINTENANCE
ill. 16
ill. 17
ill. 18

8
C
L
E
A
N
W
A
T
E
R
R
A
W
W
A
T
E
R
I
N
L
E
T
F
L
U
S
H
W
A
T
E
R
O
U
T
L
E
T
1
ill. 20
2
ill. 21
EVERY WEEK
Lubrication of the pump
The pump is lubricated with grease at the
indicated area. Remove the black plug on
the front of the BlueBox to reach the grease
point. Be generous. We recommend 3-4
squeezes with a grease tool (you cannot
overgrease the pump). Some grease might
run out of the pump if it is full, but this is not
damaging to the pump or the purifier.
EVERY MONTH
• Check that all the connections and clamps are tightened correctly.
• Ensure that filters cartridges, membranes and UV-light bulb are fittet correctly.
• Check that the drainage pipes in the container are not blocked.
• Check all hoses for holes, tears and other signs of damage and water leakage.
• Check the pump’s membrane. If there is water leaking out of the small hole at the bottom of
the pump, the membrane is not watertight and must be changed.
EVERY YEAR
We recommend that the UV glass tube is removed from the chamber and cleaned using a damp
cloth infused with a solution of a mild cleaning agent.
PUMP MAINTENANCE
The membranes must be renewed once a year.
1Remove the two bolts on top of the motor and replace filter.
2Remove the four bolts either side of each cylinder and replace filter.
3Assemble in reverse order.
IMPORTANT
The BlueBox 1200RORS must be started every 3 months in order to maintain flexibility in rubber
parts and to avoid build up of contaminants.
ill. 19
Plug for grease lubrication

9
After more than 14 days of standstill and before storing, the BlueBox 1200 must undergo a
complete cleaning process.
Please ensure that you have approximately 200 litres
of clean water available before you start the cleaning
process.
Cleaning procedure with Sodium
Hydroxide and Nitric Acid
(For example RoClean P303 and RoClean P111)
1Remove the three filter housings and pull out the
filter cartridges. Mount the filter housings back
onto the mounts without the filters in.
2Acid Cleaning (RoClean P303)
Dilute 1 kg of RoClean P303 in 50 litres of water.
Insert all three hoses into the container with the
cleaning fluid (Flush water outlet, Raw water
inlet and Clean water).
Start the BlueBox and let the system rinse without pressure (open the blue pressure valve) for
10 minutes.
3Turn the blue pressure valve clockwise to show approximately 8 bars of operating pressure.
Run the BlueBox at this setting for 30 minutes.
4Open the pressure valve all the way and run the system with clean water for 10 minutes
without pressure, and then again for 10 minutes with 8 bars of pressure.
5Alkali cleaning (RoClean P111)
Dilute 1 kg of RoClean P101 in 50 litres of water.
Insert all three hoses into the container with the cleaning fluid (Flush water outlet, Raw water
inlet and Clean water).
6Start the BlueBox and let the system rinse without pressure (open the blue pressure valve) for
10 minutes.
7Turn the blue pressure valve clockwise to show approximately 8 bars of operating pressure.
Run the BlueBox at this setting for 30 minutes.
8Open the pressure valve all the way and run the system with clean water for 15 minutes
without pressure, and then again for 15 minutes with 8 bars of pressure.
9Turn off the BlueBox, following the procedure in ‘PART 3 After using BlueBox’.
If the first filter, 25 micron, is not too damaged (clogged), it can be rinsed and brushed down
and reinstalled.
NOTE For a thorough cleaning, please repeat step 2, 3, 6 and 7, 2-3 times and/or let the
membranes soak for up to 4 hours.
Preservation of membranes during storage or period of stand-still.
If the unit is to be stored (not used) for longer than 14 days, the membranes must be treated with
a 20 % glycol solution or RoCide preservation mixture, which will also protect it against freezing
temperatures. Remember to run a cleaning process of the system before taking into use.
IMPORTANT
The cleaning fluid must not exceed 45 ºC
The pH value of the cleaning fluid must remain within 2-11 pH
ill. 22
PART 5 CLEANING

10
PART 6 UV-LAMP
UV Exposure Never illuminate UV Lamp outside of the UV Chamber.
Never look directly at illuminated UV Lamp, even when using protective gear.
Always use protective gear, including gloves and UV safety glasses.
If accidental exposure occurs, immediately cool affected area and consult physician.
Electrical Shock Disconnect power to system before performing any maintenance or repair.
There may be more than one source of power.
Impalement Never perform any physical inspection, repair or maintenance on UV Chamber unless UV chamber has
been isolated and depressurized.
Never service UV Lamps, Sleeves or associated hardware until depressurization of UV chamber has been
confirmed.
Hot chamber Allow UV Lamps, UV Chamber to cool for a minimum of 10 minutes before handling.
Cut or ingestion Ensure the quartz sleeve or lamp is not broken, cracked or damaged in any way when handling equipment.
Scald from water When there is no water flow, the water in the chamber will become hot.
To prevent scalding, allow the system to cool before draining the system.
Fire Do not store any combustible or flammable material close to the system.
Hg Exposure The UV lamp contains mercury. If the lamp breaks, then avoid inhalation or ingestion of the debris and
avoid exposure to eyes and skin. Never use a vacuum cleaner to clean up a broken lamp as this may
scatter the spilled mercury. Obey local regulations and guidelines for the removal and disposal of mercury
waste.
Water leak Use proper plumbing materials to avoid potential material degradation from UV exposure.
No power GFCI and/or breaker tripped.
Transient voltage surge suppressor (TVSS) damaged
Power supply damaged
Reset GFCI and/or breaker
Replace TVSS
Replace power supply and use a TVSS
GFCI or breaker
repeatedly trips
Connection between lamp and lamp plug is wet
Short-circuit in the electrical assembly
Clean and dry lamp pins and lamp plug, check unit
for leaks or condensation
Replace power supply
Leak at inlet or outlet Threaded pipe fittings are leaking Clean threads, reseal with Teflon tape and retighten
Leak detected from
area of UV chamber
Condensation of moist air on cold chamber
(slow accumulation)
O-ring damaged, deteriorated or incorrectly installed
Lamp/sleeve assembly not properly installed
(too tight or not tight enough)
Control humidity or relocate unit
Inspect and replace if deteriorated
Tighten assembly hand-tight
Leak detected
at sensor (if so
equipped)
UV sensor o-rings are damaged, deteriorated, or
incorrectly installed
Inspect and replace o-rings if deteriorated
Alarm See Display section See Display section
System is operating
but water tests
reveal bacterial
contamination
Equipment downstream of UV system is acting as
a breeding ground for pathogens
Pathogens are residing in the distribution lines
post-UV
Recontamination from pipe dead-ends
Ensure UV is the last piece of treatment equipment
Ensure all distribution lines have been disinfected
with chlorine
Remove any pipe dead-ends and flush with chlorine
Lamp timer does not
read anything
Unit is unplugged
No power at AC power outlet
Power cord is damaged
Power surge caused damage to electrical assembly
Plug unit into AC power outlet
Replace fuse or reset breaker
Replace power cord
Replace power supply and use a surge protector
Potential Hazard Safety Measures
Symptom Possible cause Possible solution

11
Lamp timer display Counts down from 365 days to show time for annual lamp replacement.
Lamp timer reset After installing a new lamp, press and hold for five seconds to reset Lamp timer to 365.
Alarm Press to silence audible alarm.
When the alarm is due to the lamp’s age, the mute button will silence the audible alarm for 7 days; this
may be repeated up to a maximum of 4 times. After that, the button will silence for only 24 hours.
When the alarm is due to any other issue, the mute button will silence the audible alarm for 24 hours.
Display
SLEEVE CLEANING & LAMP REPLACEMENT
Lamp replacement
Unplug the BlueBox from the electrical socket.
Let the unit cool for 10 minutes.
Remove the UV-lamp from the container.
Sleeve cleaning
Minerals in the water slowly form a coating on the sleeve. This coating must be removed because
it reduces the amount of UV light reaching the water, thereby reducing purification performance.
Equipment required
Clean cotton Latex or plastic gloves are preferred
Scale remover Vinegar or a citrus-based product
Cloth Must be soft, lint-free, and chemical-free. No clean-wipes must be used
Cotton swab
Lamp life
The amount of UV light created by the lamp decreases over time, requiring a replacement of the
lamp every 12 months. The controller displays the total lamp life remaining in days.
At 0 (zero) days, the controller will display ‘A3’ and supply an intermittent audible chirp (1 second
on, 5 seconds off), indicating the need to change the lamp.
NOTE
The UV system is designed to operate continuously and should not be shut
off for short periods of time, such as over a period of less than three weeks.
RESETTING LAMP LIFE
1Disconnect the lamp from the controller.
2Hold the ‘RESET’ button down while reapplying power to the Controller until you see ‘rSet’
on the display, then release.
3A 5 second delay will occur until your hear an audible tone and the display will once again
read ‘365’.

12
SPARE PARTS
Please contact [e-mail] for spare parts
Filter cartridges
E-XA004823309 Prefilter, 25 micron/19.5” (no.1) BB1200 RORS
E-XA004823291 Prefilter, 05 micron/19.5”. Melt blown (no.2) BB1200 RORS
E-70020146323 Activated Carbon. 7.75” cartridge filter (no.3) 2 pcs per housing = 19.5” RS1200 RORS
Filter housing
E-70020254895 SS filter housing 20”. Fitting Ø 3/4”
ACLOW34021 LOW3 4021 RO-Membrane for BB1200RORS
VE4021304BSP-BO Stainless Steel vessel 4” for RO-membrane
VECEC4BSPCLAMP-BOW Complete endcap for 4” vessel. BSP 1/2” x 1/2”
Modul_RO1200 Complete RO-membrane setup on frame
UV-disinfection system
14201-9105 UV-light bulb
14201-9205 UV quartz tube
Pump parts
750153 Hardi pump 603/7 membrane kit
210022 Bearings type 6205
60207 Bearings type 6007
Membrane rehabilitation detergents
7509846 RoClean P303, High PH cleaning granulate.
7509014 RoClean P111, Low PH cleaning granulate.
ROCSC RoCide, preservation granulate mixture.
Miscellaneous parts
0001014 Pressure gauge. 16 BAR. Glycol filled
703032 Suction wind chamber
334553 Membrane for suction wind chamber
Filter cartridge
8944502541 (25µ)
80105410000 (5µ)
871005906 (AC)
Filter Housing
E-70020254895
Float filter
841481
UV quartz tube
14201-9205
UV-light bulb
14201-9105
100 micron filters
165767

13
C
L
E
A
N
W
A
T
E
R
R
A
W
W
A
T
E
R
I
N
L
E
T
F
L
U
S
H
W
A
T
E
R
O
U
T
L
E
T
START
STOP
Main Power
Switch
365
Suction chamber
703032
Membrane
(kit of four filters)
750153
Bearings
6205 – 210022
6007 – 60207
Flush water outlet
(Red hose)
DH10008
Raw water inlet
(Black hose)
DH10009
Clean water outlet
(Blue hose)
DH10007
Electrical cabinet
Ballast
(UV display)
550910300
Air filter
5712014732

14
If any faults should occur…
SYMPTOM
Pump cannot
produce any
pressure
Clean water
capacity fails
UV-light bulb
gives no light
Beeping noise
There is water
coming out
from the bot-
tom of the
pump
REASON
Float-filter is clogged.
Absorption tube is not filled with water.
Contra vent in absorption tube is stuck.
Membranes in pump are defective.
Vent valves in pump Are defective or
clogged.
The pump is letting in air.
Check reasons in pump section.
The system must undergo a cleaning
process.
The system is not working at normal
work pressure.
The lifting height (max. 6 meters) has
been exceeded.
Clean water tube is blocked or clogged.
Plug for light is not connected.
UV-light bulb is not connected.
Defective bulb.
Transformer is defective.
Defective membrane -or membranes.
SOLUTION
Dismantle red float and clean net-filters with brush
(see ill. on page 7)
Dismantle black absorption hose and fill with water.
Take apart contra vent and clean inside.
Pump is dismantled by loosing the bolts –
membranes are loosened and changed.
(see Motor maintenance on page 8).
Pump is dismantled by loosening bolts and vents
are cleaned or changed.
Tubes are tightened on absorption side of pump.
Check solutions in pump section.
Follow the cleaning guide.
(see Part 5, ‘Every month’)
Adjust work pressure to 8 bars (see ill.) and check
that the manometer on main-block shows 8 bar.
The lifting height must be reduced to
under 6 meters.
Make sure that there is free passage in the blue
clean water hose and that the flow meter are not
clogged by obstacles.
Insert plug.
Dismantle UV-housing and tighten bulb in its socket.
Change bulb and check if the light
housing is tight (avoid looking directly at UV-light for
more than a couple of seconds).
Change transformer, please contact Much More
Water A/S or your local distributor for further
assistance.
Change membrane- or membranes.

15
IMPORTANT NOTE
Please be aware of the following:
• Make sure that the electricity supply is stable.
• The Reverse Osmosis membranes (RO filters) in the BlueBox system normally have to be changed
every 2 years depending on the working hours and quality of feed water.
• Please do not place the system in directly sunlight. Heat may affect the electronics in the switch
board box.
• As the UV-light contains glass, the system must not be affected by hard shock.
• The system must be free of dust and dirt.
• The system must not be exposed for frost. Temperatures below 0 ºC (zero degrees Celsius) can ruin
the RO membranes. E.g. during a long-haul flight, the BlueBox should be started with low pressure
for a while in order to defrost the membranes without damaging them. For long term storage in
freezing temperatures, please contact Much More Water at [e-mail].
• As an industrial standard for Reverse Osmosis, the output of the membranes decreases in
proportion with the temperature of the raw water: 3 % reduction per 1 ºC measured from 25 ºC.
• Beware of silt, humus and high levels of iron in the raw water. These compounds will eventually spoil
the membranes, since very small ‘plates’ from these compounds will fill up the membranes over
time. The only way to deal with this is to install an improved pre-filtration system.
• Beware of high content of iron/manganese. Especially coming from boreholes, high levels of iron
and manganese will clog the membranes and render them useless. It may be advisable to install an
improved pre-filtration system, using anti-scalants.

PURE WATER – ANYTIME – ANYWHERE
Much More Water A/S
Staerkendevej 43 •DK-4000 Roskilde
phone: [phone]
[e-mail]
www.MuchMoreWater.com
July 2017
