Muddy MUD-RBI User manual

MUD-RBI
User Manual
R0
REMOTE BEACON ILLUMINATOR
www.gsmoutdoors.com
GSM, LLC
PO Box 535189, Grand Prairie, TX 75053-5189
Toll Free: 877-269-8490

INCLUDED ITEMS IC STATEMENT
1
1. Remote Beacon Illuminator (RBI) Unit
2. Remote Activator
3. Mounting Clamp
4. Clamp Spacers
5. User Manual
6. AA 1.5V Battery (x4, for RBI unit)
7. CR2032 3V Lithium Battery (in remote)
This device complies with Canada ICES-005(B)/NMB-005(B)
This device contains license-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s license-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux
RSS (RSS) d'Innovation, Sciences et Développement économique Canada. L'exploitation
est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radio électrique subi, même si
le brouillage est susceptible d'en compromettre le fonctionnement.
12

This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications to the device could void the warranty and the user’s authority to
operate the device.
RF warning statement: The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition without restriction.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC STATEMENT
2
ABOUT
The Remote Beacon Indicator (RBI) is intended to be mounted to
a tree stand to illuminate the tree stand steps for safety. It can
also assist in locating a well- hidden tree stand.
11

PRODUCT IDENTIFICATION
Warning! For California Customers: Proposition 65 Warning. This product
contains chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. www.p65warning.ca.gov
1. Battery Compartment
2. Clamp
3. Clamp Spacers
4. LED
5. Power/Pairing Button
WARNINGS & DISCLOSURES
3
10
PRODUCT IDENTIFICATION
1. Batteries included are not rechargeable. Trying to recharge can
cause damage to battery and unit.
2. If handled improperly, the battery may break or leak causing
possible corrosion of the device or clothes.
3. It is recommended that the same model battery is used for
battery replacement.
4. Batteries should not come into contact with other metal objects,
such as: keys, coins, etc. as this may cause the battery to
overheat or short circuit.
1
2
4
5

WARRANTY
This MUDDY product is covered by a one-year limited warranty.
This warranty covers product with manufacturer defects. Normal
wear & tear as well as product abuse are not covered by the
warranty. The warranty is valid only for the original owner of the
product purchased from an authorized retailer.
Tampering with or altering the unit will void the warranty. Any
unauthorized service will void the warranty. Original sales receipt
must be produced for any warranty service and a Return
Authorization (RA) number must be obtained from customer
service at 877-269-8490prior to returning the product.
For more information go to www.gomuddy.com
SETUP
9
4
Installing batteries
Remove battery cap by turning
the cap clockwise.
Insert the included AA batteries
in the proper orientation (refer
to (+) and (-) marks on the RBI).
Reinstall the battery cap by
turning clockwise.

REMOTE PAIRING
Pressing the button on the RBI remote will cause all paired RBI units
within range to illuminate.
The remote activator functions at a range of up to 150 yards.
The light on the RBI units will turn off automatically after 3 minutes.
Light may be tuned off manually by pressing the button on the RBI
unit.
The remote activator can be paired to additional RBI units by
following these steps:
1. With RBI unit OFF, press and hold the power button until main
light begins to flash.
2. Once flashing, press the button on the remote.
3. The light on the RBI unit will turn solid when paired.
(Note: 1 remote activator can be paired with multiple RBI units)
5
8
OPERATION

CLAMP ADJUSTMENT
The RBI is designed for installation on square tubing used on
MUDDY brand tree stands (¾” – 1”; 20-25mm)
The RBI will also clamp onto round tubing (¾” – 1”; 20-25mm)
Add or remove clamp spacers (included) as needed)
6 7
Adjustable clamp can be mounted on horizontal or vertical
tubing, with a wide range of adjustments possible in either
orientation.
Remove the center thumbscrew to change the orientation of the
clamp.
INSTALLATION
Clamp spacers
