J6000 SERIES BREAK CHECK VALVE
Installation Instructions
NOTE: The break check valve and wet barrel hydrant must be installed and maintained according to AWWA M17,
C503, C600, and applicable local codes.
Do not use this product on wet barrel fire hydrants that have an internal diameter greater than 6-5/8"
(see Danger Tag on product for more information). Do not use break-away bolts with Traffic Flange.
8"
6.75"
2.00"
BURY LINE
A. Upon receipt of shipment, inspect J-6000 valve assembly to ensure no damage or breakage occurred during shipment.
B. Install FLANGE GASKET onto BURY SECTION FLANGE. Set J-6000 FLANGE on BURY SECTION FLANGE; plumb, install
and tighten fasteners to pipe manufacturer specified torque.
C. Make sure the O-RING is in the O-ring groove on the traffic side of the J-6000, the Discs are vertical and ARMS are
in the J-6000 Body POCKETS.
D. Set hydrant on the J-6000 and orient the pumper to the desired direction.

J6000 SERIES BREAK CHECK VALVE
Installation Instructions
For more information about Jones water products, please visit joneswaterproducts.com or call Jones customer service at 1.800.423.1323.
Mueller refers to one or more of Mueller Water Products, Inc., a Delaware corporation (“MWP”), and its subsidiaries. MWP and each of subsidiaries are legally separate and independent entities when providing products
and services. MWP does not provide products or services to third parties. MWP and each of its subsidiaries are liable only for their own acts and omissions and not those of each other. MWP brands include Mueller®,
Echologics®, Hydro Gate®, Hydro-Guard®, HYMAX®, Jones®, Krausz®, Mi.Net®, Milliken®, Pratt®, Singer®, and U.S. Pipe Valve & Hydrant. Please see www.muellerwp.com/about to learn more.
Copyright © 2019 James Jones Company, LLC. All Rights Reserved. The trademarks, logos and service marks displayed in this document are the property of
Mueller Water Products, Inc., its affiliates or other third parties. Products above marked with a section symbol (§) are subject to patents or patent applications.
For details, visit www.mwppat.com. These products are intended for use in potable water applications. Please contact your Mueller Sales or Customer Service
Representative concerning any other application(s).
F 14160 10/19
NOTE: If a change in orientation of the pumper outlet is required after installation, loosen the Traffic
Flange Nuts, lift hydrant slightly and rotate using caution not to damage or displace the O-ring. Re-tighten
Traffic Flange Nuts to 70-90 ft-lb.
F. Test hydrant with line pressure before backfilling. Remove the cap from the top hydrant outlet. Slightly open
the top outlet valve and slowly open the service gate valve to restore water to the hydrant. When all air is
evacuated from the hydrant, water will begin to come out of the top nozzle. Firmly seat top valve. Completely
open gate valve and check for leaks at flanges and seals.
G. Install concrete thrust collar at or near the ground line. Recommended collar dimensions are 8 inches thick and
30” x 30” square. These dimensions are dependent upon soil conditions.
H. Flush the hydrant after installation to remove any foreign material and ensure J-6000 is set in the open
position (assure full flow is achieved)
HYDRANT / TRAFFIC FLANGE BOLT PATTERN
No. of Holes Bolt Hole Size Bole Circle Dia. Bolt Size Hydrant Flange Thickness Bolt Length
³₄˝  ³₈˝ ⁵₈˝ ¹₂˝  ³₄˝
˝  ¹₄˝
 or  ⁷₈ ˝  ¹₂˝ ³₄˝ ¹₂˝  ³₄˝
˝  ¹₄˝
* Additional Bolt Patterns may be available
E. Attach TRAFFIC FLANGE and Traffic Flange BOLTS/NUTS (see table below) as shown.
Torque bolts to approximately 70-90 ft-lb.
