INSTRUCTIONS:
GRATINGDISCCHANGEINBASKETASSEMBLY–ES500ANDES700

IMPORTANT:CLEANTHEBASKETASSEMBLYTHOROUGHLYBEFORECHANGINGDISCAND
HANDLEWITHCARE
STEPDESCRIPTION PHOTO
1
A13mmsocketwrenchisrequiredtochangethedisc.This
toolisreadilyavailableatanyhardwarestoreandmost
Maintenancestaffhasthistool.

2
Placethebasketassemblyupsidedownonaflatsurface.
Youwillseetheclutchdrivewithanutandwasher
attached.

3
Usethetubularboxwrenchtoloosenthenut.After
removing,youwillhaveatotalofsix(6)pieces:

1. Basket
2. Base
3. GratingDiscwithScrew
4. ClutchDrive
5. Washer
6. Nut
 

4
Makenoteofonesideofthecenterscrewthatisflat.This
mustalignwiththeflatsideoftheholeinthea)thebasket;
b)thebase;andc)thegratingdisc
 



5
Takethereplacementgratingdiscandplaceitinthebase
ofthebasket,aligningtheflatsideofthehole.Insertthe
specialscrew.

6
Assembletheflatsideofthebaseagainstthebottomof
thebasketassembly(outeredgeturneddown).

Holdingthenutintheupsidedownbasketwithonehand,
replacetheclutchdrive,washerandnut.

Tightenthenutwiththesocketwrench.










 
