Multimedia Standard QR-130 Assembly instructions

U
Us se er r M Ma an nu ua al l G Gu ui id de e
M
Mo od de el l Q QR R- -1 13 30 0
The Movie what you really wanted to watch
The Music which is your favorite
The Photos which has your happy memories
TV Drama which you would never miss
Relax yourself wherever and whenever so far
Ultimate Digital Multimedia Player “Movie Clip”

UserManualGuide Model: QR-130
2
CONTENTS
1. Introduction..............................................................................................................................4
2. Product Specification .............................................................................................................5
3. Descriptions & Product Contents..........................................................................................7
3-1 Description ......................................................................................................................... 7
3-2 Product Contents...............................................................................................................8
4. Remote Controller................................................................................................................... 9
5. SATA HDD Installation.........................................................................................................12
6. Partitioning and Formatting Hard Disk ...............................................................................14
6-1 Setting and Formatting on Windows 98/ME..................................................................14
6-2 Setting and Formatting on Windows 2000 / XP ............................................................18
6-3 Hard disk formatting and partition under Windows VISTA..........................................22
6-4 Use on Linux (Available on Linux 2.4 or later)..............................................................24
6-5 Use on Macintosh............................................................................................................25
7. Connecting QR-130...............................................................................................................26
7-1 TV Connection – A/V IN...................................................................................................26
7-2 TV Connection – A/V OUT...............................................................................................26
7-3 Connection with Y/Pb/Pr Component OUT ...................................................................27
7-4 Connection with HDMI OUT............................................................................................27
7-5 Power Connection ...........................................................................................................28
7-6 Ethernet Connection........................................................................................................28
7-7 WLAN Connection (by option)........................................................................................29
7-8 Connection with 2Ch of Normal Audio..........................................................................29
7-9 Connection with Optical output .....................................................................................30
7-10 First Time Usage............................................................................................................30
8. Getting Started.......................................................................................................................31
8-1 Selecting Video In-Live TV, Recording and Time Shift.................................................31
8-2 Selecting file copy function............................................................................................31
8-3 Selecting browser function............................................................................................. 31
8-4 Selecting Setup................................................................................................................32
8-5 Timer Rec..........................................................................................................................32
9. Setup Menu............................................................................................................................33
9-1 Changing System Settings .............................................................................................33
9-2 Changing Audio Settings................................................................................................ 35
9-3 Changing Video Settings ................................................................................................36
9-4 Changing Record Settings..............................................................................................38
9-5 Changing Network Settings............................................................................................39
10. Browser Menu......................................................................................................................45
10-1 Browsing All...................................................................................................................45
10-2 Browsing Music .............................................................................................................46
10-3 Browsing Photo .............................................................................................................46
10-4 Browsing Movie .............................................................................................................47
10-5 Browsing via Network ................................................................................................... 47
10-6 File Management............................................................................................................49

UserManualGuide Model: QR-130
3
10-6 Playlist ............................................................................................................................51
11. Media Recording.................................................................................................................53
11-1 Recording from Video-In Mode ..................................................................................53
11-2 Time Record Menu ....................................................................................................... 53
12. File Copy Menu....................................................................................................................56
13. Firmware Upgrade...............................................................................................................58
13-1 System information .......................................................................................................58
13-2 Firmware Upgrade .........................................................................................................58
17. Frequently Asked Questions..............................................................................................60
18. Caution.................................................................................................................................64

UserManualGuide Model: QR-130
4
1
1. . I In nt tr ro od du uc ct ti io on n
Thank you very much for purchasing this brand-new Multimedia Player QR130 with stronger function
support. In the digital era, this product is quite suitable to be a home entertainment partner. With her
outstanding designed features, you can enjoy movies and music, view photos of precious moments, and
record your favorite TV or movie programs to make up for your regret of not being able to enjoy them in
time. The editing function provides you with an easy way to save the essential part. It's also a good choice
to use this product as a portable storage device for its built-in HDD and high-speed USB 2.0.
This player has the following functionality:
-
supports one button recording and schedule recording in MPG
format, can easily record programs from TV, DVD player and DV,
and save as MPEG-2 (.mpg) format; also can edit the recorded
titles;
Video Recording
- Time shifting function;
Movie Playback - supports VOB (DVD), IFO (DVD), MPG (MPEG-2/1), AVI (MPEG-4 ASP: XviD), DAT (VCD), and MPEG-2 TS files; resolution up to
1080i;
- supports MP3, OGG, and WMA* files;
Music Playback - supports one button playlist music playback;
Photo Playback - supports digital camera JPEG, and BMP files;
Data Storage - works as a portable hard disk using USB 2.0 port;
Network Function - Ethernet & WLAN streaming playback (Wireless function supported
by the optional Wireless LAN USB Adapter);
HDMI - High-Definition Multimedia Interface transmits the highest quality digital video and audio via a single cable, simplifies cabling and
provides high quality home theater experience.
-
supports one button recording and schedule recording in MPG
format, can easily record programs from TV, DVD player and DV,
and save as MPEG-2 (.mpg) format; also can edit the recorded
titles;
Video Recording
- Time shifting function;
We hope that this product will bring you a lot of enjoyment. We are committed to apply multimedia
technology to work, entertainment, family, daily life, car and everywhere in the world. Welcome to be with
us. Thank you again for choosing our Home Multimedia Center.
NOTE WMA Pro & Advanced Profile and WMA with DRM are not supported.

UserManualGuide Model: QR-130
5
2
2. . P Pr ro od du uc ct t S Sp pe ec ci if fi ic ca at ti io on n
GENERAL
Dimensions 190.5(W) x 54(H) x 183.2(L)mm
Power Supply AC 100~240V 50~60Hz
Power Consumption Approx. 35 W
Operating Temperature +5°C to +35°C (+36°F to +95°F)
Operating Humidity 5% to 80% RH
Hard Disk SATA HDD SATA HDD
Net Weight Approx 1.5 kg
CONTENT FORMATS SUPPORTED
DAT/VOB/IFO/MPG/AVI/MPEG-2 TS
MP3/OGG/WMA
Compression rate: between 32 kbps and 320 kbps
Formats
JPEG/BMP
RECORDING FORMAT
Video HQ / SP / LP / EP / SLP mode : MPEG-2 MP@ML
Audio HQ / SP / LP / EP / SLP mode : MP2 2-channel
CODECS SURPORTED
Video MPEG-1 / MPEG-2 / MPEG-4 ASP: XviD
Audio MP2/MP3 /OGG Vorbis/WMA Standard
(DRM, Pro & Advanced Profile not supported) / PCM
VIDEO RECORDING MODE
Mode 80 GB HDD 120 GB HDD 160 GB HDD
HP 16hrs 24 hrs 33 hrs
SP 32 hrs 48 hrs 66 hrs
LP 48 hrs 72 hrs 99 hrs
EP 64 hrs 96 hrs 132 hrs
SLP 96 hrs 144 hrs 198 hrs

UserManualGuide Model: QR-130
6
VIDEO OUTPUT SPECIFICATION
Composite Output 1 Vpp 75 Ohm
Y:1 Vpp 75 Ohm
Cb:0.7 Vpp 75 Ohm
Components Output
Cr:0.7 Vpp 75 Ohm
HDMI Output HDMI (Version 1.1)
AUDIO PERFORMANCE
DA Converter 24-bit / 192kHZ
AD Converter 24-bit / 96kHZ
Signal-Noise (1kHZ) ≥95dB
Dynamic Range (1kHZ) ≥90dB
Channel ≥95dB
Separation Total Harmonic Distortion (1kHZ) ≤-85dB
SUBTITLE FORMATS SURPORTED
Formats SRT, SMI, SSA, IDX/SUB, SUB
RECORDABLE DEVICE SUPPORTED
Device Built in HDD / USB HDD
USB SUPPORTED
USB - USB HDD
- Other USB Mass Storage Devices
- USB 2.0 Interface
NETWORK FEATURE
Ethernet 10/100Mbps Auto-Negotiation
WLAN IEEE 802.11b/g, up to 54Mbps (supported by the optional WLAN USB Adapter)
NOTE The specifications and design of this product are subject to change without notice.

UserManualGuide Model: QR-130
7
3
3. . D De es sc cr ri ip pt ti io on ns s & & P Pr ro od du uc ct t C Co on nt te en nt ts s
3-1 Description
Front Panel
1 POWER
Indicator (red) turns on when the system turns on.
2 REC indicator
When Recording starts, this LED would shining in Blue.
3 HDMI
When HDMI interface was working, the HDMI Led would be shining in Blue
4 IR: Infrared receiver window
Receiving IR signals from the remote control.
5 HDD
When reading HDD files from HDD, the HDD LED would be shinning.

UserManualGuide Model: QR-130
8
Rear Panel
3-2 Product Contents
QR130 Remote Controller Battery A/V Cable
PowerAdapter PowerCable InstallCD UserGuide
SCART
Adapter
USB Cable
NOTE
The actual contents in the package might be different from the packing list in this manual
1. Air Flow
2. Audio OUT jack (Left Channel)
3. AUDIO OUT jack (Right Channel)
4. VIDEO OUT jack
5. AUDIO IN jack (Right and Left Channel)
6. VIDEO IN jack
7. RJ45 LAN port
8. USB SLAVE port (MINI USB)
9. Y/Pb/Pr OUT jack (Components Video)
10. S/PDIF Optical jack
11. HDMI jack
12. USB HOST port x 1
13. DC IN jack

UserManualGuide Model: QR-130
9
4
4. . R Re em mo ot te e C Co on nt tr ro ol ll le er r

UserManualGuide Model: QR-130
10
1 Power Press to enter standby mode or wake up
2 Numeric botton Press to enter channel numbers or numeric input when
changing settings.
3 GOTO Press to jump to a specific point on a title. Specify the point
using Title, Chapter and Time.
4 TV OUT Change player video output mode according to the following
order (NTSC Composite -> NTSC Component -> NTSC
HDMI -> PAL Composite -> PAL Component ->PAL HDMI)
5 AUDIO Press to select an audio track
6 VOLUME + volume up
7 SKIP BACKWARD fast reverse during video play /10 second rewind during mp3
play.
8 VOLUME -volume down
9 PAUSE Stop play.
10 RECORD button
Press to begin recording or to resume when recording has
been paused. Press repeatedly to set one touch recording
(OTR) length (30 MIN. / 60 MIN. / 90 MIN. / 120 MIN. / 180
MIN. / 240 MIN. / Off).
11 OK Press to select options in menus.
12 BROWSER Press to browse music, photo, and movie files on HDD, USB,
and NET
13 REPEAT ALL repeat all items when play video,mp3,ect.
14 REPEAT ONE repeat one item when play video,mp3,ect.
15 TIMER Press to enter the Timer Menu directly to add, edit and delete
recording schedules. See 5.1 Creating a New Schedule for
more details.
16 TIME SHIFT
While in Video In mode, press to activate the time shift
function, which allows you to pause live TV and resume the
program from the point you left it. While paused, the program
is recorded to the HDD or USB device, as long as space is
available. Press to activate TIME SHIFT function and wait for
the PLAY arrow to appear on the screen. Press and the
program will be paused. Press to resume viewing the
program. Time shift mode remains active until you press.

UserManualGuide Model: QR-130
11
17 SETUP Press to access the Setup Menu directly.
18 MUTE Press to mute audio output, and press again to resume
19 GUIDE Press to view the Guide menu, it is the player’s home page.
20 INFO Popup video information during Video Play.
21 SEARCH Popup random access OSD during Video Play
22 SKIP FORWARD Press to fast forward the current playback. Press repeatedly
to select speeds.
23 SEARCH Popup random access OSD during Video Play.
24 PLAY Press to begin playback of a media file or title
25 STOP Press to stop playback
26
NAVIGATION
BOTTON Press the arrow buttons to select menu options.
27 RETURN Press to return to the previous screen when navigating
menus
28 SUBTITLE Press to set subtitle option
29 DELETE Press to delete what you want to delete
30 CONFIRM Press to add the selected file to playlist
31 SELECT Press to select the file to be added to playlist
32 ZOOM Press to zoom in/out the image (photo or video)
33 COPY Press to enter the file copy menu
34 CM SKIP Press to forward 30 seconds when in playback or record
model
35 REPLAY Press to backward 10 seconds of current playback

UserManualGuide Model: QR-130
12
5
5. . S SA AT TA A H HD DD D I In ns st ta al ll la at ti io on n
Please install the player according to the following instructions.
SATA HDD Installation
1、press the bottom cover. 2、open the bottom cover. 3、pull away hard disk
bracket.
4、putharddiskin. 5、screw hard disk tightly 6、make sure all 6pcs
screws well .
7、Insert the bracket with HDD. 8、Connect SATA or IDE cable 9、Connect power cable
10、Insert bottom cover and close it. 11、Ok.

UserManualGuide Model: QR-130
13

UserManualGuide Model: QR-130
14
6
6. . P Pa ar rt ti it ti io on ni in ng g a an nd d F Fo or rm ma at tt ti in ng g H Ha ar rd d D Di is sk k
6-1 Setting and Formatting on Windows 98/ME
1. Install exclusive driver and then connect
QR130 to PC using USB cable
2. Select Window [Start>Program>MS-DOS]
to open and MS-DOS window.
3. Type fdisk command in MS-Dos window
and press the [Enter] key.
4. Say yes to enable large disk capacity by
typing “Y” and then press the [Enter] key.
Non-formatted hard disks are not detected by PC. If the hard disk is not formatted, please take the
following steps to format it. Newly purchased hard disks are not normally formatted
Caution In Windows 98SE, install and exclusive driver before proceeding to partition and
formatting. In windows ME/2000/XP, there is no need to install exclusive driver

UserManualGuide Model: QR-130
15
5. Among fdisk options, select options
5[change current fixed disk drive].
6. Type the hard disk number fro partitioning in
[Enter Fixed Disk Number] and press the
[Enter] key
7. Select [1.creat DOS partition or Logical DOS
Drive] in fdisk options by typing “1” and then
press the enter key
8. Select [1.Creat Primary DOS Partition] in
‘Create DOS Partition or Logical DOS Drive’
by typing “1” and then press the enter key.

UserManualGuide Model: QR-130
16
9. Wait for integrity check to be complete
as below
10. After integrity check, say yes to the message
‘Do you wish to use the maximum available
Size for a primary DOS partition and make the
Partition active( Y/N)?
By typing “Y” and press the enter key
11. Type in [capacity or % you want] and press the
enter key. If you want to use one disk
without partitioning. Type 100%.
12. Integrity check is started again. After it is
completed, Amessage saying Primary Dos
Partition was created, drive letter was modified
or added is displayed.
Then, press [ESC] to return to fdisk options
13. In fdisk option screen, press [ESC].
Then a message is displayed, saying that
your must restart your system.
Press [ESC] again.

UserManualGuide Model: QR-130
17
14. At hen C:\WINDOWS> prompt, type exit
and then press[ENER] to return to window
screen.
15. Disconnect QR130 from PC and then connect
it again to PC.
16. Drive letter s created in [My Computer] of
Windows Explorer.
Right-click the created drive letter and select
[Format].
17. When formatting is completed , you can use
QR130 as an external hard disk drive by connecting
it to Computer.(I change it based on my comprehension)
Caution
For some hard disks, power supply from USB port is not enough for operation, in this
case, connect a separate power supply using the adapter supplied in the package. Then,
no problem will be experienced in operating the device connected to a PC.
For recently released PCs, there is a USB port installed on the front side of the PC for
users’ convenience. However, this expanded USB port sometimes fail to recognize
devices sending and receiving data in high speed such as external hard disk. In this case,
use the USB port in the rear side of the PC

UserManualGuide Model: QR-130
18
6-2 Setting and Formatting on Windows 2000 / XP
1. Connect QR130 to a PC using a USB cable
2. Select [Start> Control Panel>management
Tool>Computer Management] and then
[Disk Management] under Computer Management
menu.
3. Click [Next] to continue when write Signature
and Disk Upgrade Wizard appears
4. Select the disks you want to write a disk signature to
and Click [Next] to continue
5. When Write Signature and Disk Upgrade Wizard
is completed, Click [Finish]
6. Right-click an [Unallocated] drive in Drive Management
and select [New Partition] from the menu that appears.
7. When the New partition Wizard is shown,
Click [Next] to continue
Non-formatted hard disks are not detected by PC. If the hard disk is not formatted, please take the
following steps to format it. Newly purchased hard disks are not normally formatted

UserManualGuide Model: QR-130
19
8. Select [Primary Partition(P)] and Click [Next]
to continue
9. Enter the desired partition size in [Partition size in MB]
and Click [Next] to continue.
10. When the [driver letter] is assigned, Click [Next]
11. In the format partition windows, select
[format this partition with the following settings] and
FAT32, and then check [Perform a quick format] box.
Click [Next] to continue.
12. When [Completing the New Partition Wizard]
appears, Click [Finish]

UserManualGuide Model: QR-130
20
13. A new NTFS partition was created.
14. Right-click an [Unallocated] drive in Drive
Management and select [New Partition] from
the menu that appears.
15. When the New partition wizard is shown
Click [Next] to continue.
16. Select [Primary Partition(p) and Click [Next]
to continue.
17. Leave the value for [Partition size in MB]
as if appears and Click [Next] to continue.
(The partition size shown is the remaining
hard disk size unallocated.)
18. When the [drive letter] is assigned,
Click [Next]
