Multitech MultiModem ZBA USB MT5634ZBA-USB User manual

Model MT5634ZBA-USB
Data/Fax Modem
User Guide

User Guide
Model MT5634ZBA-USB-Mac
P/N S0000002 Rev.A
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed
written permission from Multi-Tech Systems, Inc.
Copyright ©1999, by Multi-Tech Systems, Inc.
Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes in
the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such
revisions or changes.
Record of Revisions
Revision Date Description
A6/7/99 Manual released.All pages at RevisionA.
Trademarks
MultiModemZBA, Multi-Tech, and the Multi-Tech logo are trademarks of Multi-Tech Systems, Inc.
Macintosh, iMac, and G3 are trademarks ofApple Computer, Inc.
MNP and Microcom Network Protocol are trademarks of Microcom, Inc.
K56flex is a registered trademark of Rockwell International Corporation and Lucent Technologies Corporation.
Notice
Though these modems are capable of 56K bps download performance, line impairments, public telephone
infrastructure and other external technological factors currently prevent maximum 56K bps connections.
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, MN 55112 U.S.A
[phone] or [phone]
US.. Fax [phone]
Fax-Back Service [phone]
Technical Support [phone]
BBS [phone] or [phone]
InternetAddress http://www.multitech.com
Technical Writer: [email protected]

Contents
Chapter 1 - Introduction and Description
Introduction ................................................................................................................................................ 6
Product Description.................................................................................................................................... 6
Universal Serial Bus (USB) ........................................................................................................................ 6
What Is in Your Modem Package? ............................................................................................................. 7
Chapter 2 - Quick Start
Introduction .............................................................................................................................................. 10
What You Will Need ................................................................................................................................. 10
Safety Warnings ....................................................................................................................................... 10
Step 1:Assemble the Modem ...................................................................................................................11
Step 2: Install the Software ...................................................................................................................... 12
Step 3: Connect the Modem to Your System ........................................................................................... 13
Line Connection ................................................................................................................................. 13
Phone Connection ............................................................................................................................. 13
USB Connection ................................................................................................................................ 13
Step 4: Select the Modem ........................................................................................................................ 14
Step 5: Test Your Modem ......................................................................................................................... 14
Chapter 3 - Features
What Can You Do with Your Modem? ...................................................................................................... 16
Features ................................................................................................................................................... 16
Data ................................................................................................................................................... 16
Fax..................................................................................................................................................... 17
Required Equipment .......................................................................................................................... 17
Computer ........................................................................................................................................... 17
Telephone Line................................................................................................................................... 17
Communications Software ................................................................................................................. 17
Connections ............................................................................................................................................. 18
Connecting to the Computer (“USB”)................................................................................................. 18
Connecting to the Telephone Line (“LINE”)........................................................................................ 18
Connecting to a Telephone Set (“PHONE”) ....................................................................................... 18
Surge Protectors and Lightning ......................................................................................................... 18
Front Panel............................................................................................................................................... 19
Chapter 4 - AT Commands, S-Registers and Result Codes
AT Commands.......................................................................................................................................... 22
AT Command Summary ........................................................................................................................... 23
S-Registers .............................................................................................................................................. 32
Result Codes............................................................................................................................................ 35
Chapter 5 - Remote Configuration
Introduction .............................................................................................................................................. 38
Basic Procedure....................................................................................................................................... 38
Setup........................................................................................................................................................ 38
Changing the Setup Password .......................................................................................................... 38
Changing the Remote Escape Character .......................................................................................... 39
iii

Chapter 6 - Troubleshooting
Introduction .............................................................................................................................................. 42
None of the Indicators Light ............................................................................................................... 42
The Modem Does Not Respond to Commands ................................................................................. 42
The Modem Dials But Cannot Connect ............................................................................................. 43
The Modem Disconnects While Online..............................................................................................44
The Modem Cannot Connect WhenAnswering................................................................................. 44
The Modem Doesn’t Work with Caller ID ...........................................................................................44
Fax and Data Software Can’t Run at the Same Time ........................................................................ 44
Appendixes
AppendixA: Regulatory Compliance........................................................................................................ 46
Appendix B: Technical Specifications....................................................................................................... 50
Appendix C: Loopback Tests.................................................................................................................... 53
Appendix D: Warranty, Service, and Technical Support ........................................................................... 57
Index
iv

Chapter 1 - Introduction and Description

6
MT5634ZBA-USB User Guide
Introduction
Welcome to the world of data communications. You have acquired one of the finest
intelligent data and fax modems available today from one ofAmerica’s oldest and most
respected modem manufacturers: Multi-Tech Systems, Inc. This User Guide will help you
install, configure, test and use your modem as well as provide links to useful Web sites
and other resources.
Product Description
The MT5634ZBA-USB-Mac modem (hereafter MultiModemUSB) incorporates V.90™
technology, which enables Internet connections at data rates up to 53K bps* over
standard telephone lines. V.90 technology is able to send data downstream from the
Internet to your computer at these speeds because data on the telephone network
typically is converted from digital to analog only once before it reaches your modem.
Upstream transmissions, and transmissions between client modems, are limited to data
rates of 33.6K bps, as are downstream transmissions that are converted more than once
on the telephone network.
The MultiModemUSB comes with interactive automatic dialing and command mode
configuration. In standard mode, you can store up to two command lines or telephone
numbers of up to 40 characters each in the modem’s nonvolatile memory. The modem
pulse- or tone-dials, and recognizes dial tones and busy signals for reliable call-progress
detection. The modem can detectAT&T calling card tones, and also has Caller ID,
remote configuration and incorporates self-resetting lightning protection. The modem is
FCC-registered for connection without notification to the telephone company.
The MultiModemUSB is a full-duplex intelligent modem with V.42 error correction, V.42bis
data compression, and V.17 (14,400 bps), Class 1 and 2, Group 3 fax capabilities.
Universal Serial Bus (USB)
Universal Serial Bus (USB), defined by a consortium of industry leaders, permits
connection of multiple low-speed and medium speed computer peripheral devices such
as telephones, modems, printers, keyboards, mice, and scanners; all from a single port.
The specification, based on an open architecture is quickly becoming a standard feature
in new desktop and notebook computers. For more details on the Universal Serial Bus,
refer to the USB Public Web Board on the World Wide Web, at:
http://www.usb.org/
* Although V.90 technology is capable of downloads of up to 56K bps, FCC regulations
currently restrict ISP modems to downloads of 53K bps.

7
Chapter 1 - Introduction and Description
What Is in Your Modem Package?
Your modem package has several components. Make sure you have them all before
trying to operate your modem. Your package should include:
• One MT5634ZBA-USB-Mac modem
• One set of four plastic feet
• One modular telephone cable
• One USB cable
• One Installation CD
• This MT5634ZBA-USB User Guide (on Installation CD)
•MT5634ZBA-USB Quick Start Guide
If any of these items are missing, please contact Multi-Tech Systems or your dealer/
distributor (seeAppendix D for information on contacting Multi-Tech via telephone, fax or
the Internet).

8
MT5634ZBA-USB User Guide

Chapter 2 - Quick Start

10
MT5634ZBA-USB User Guide
Introduction
We know you are eager to get your Multi-Tech modem up and running, so we’ll skip the
features for now, and show you how to set it up and install it on your computer. For a
more detailed description of your modem’s features, please refer to the Chapter 3 -
Features.
What You Will Need
Before starting, please make sure you have everything you need:
We supply
•An MT5634ZBA-USB-Mac data/fax modem
•One set of four plastic feet
•One modular telephone cable
•One USB cable
•A Quick Start Guide
•An installation CD (which includes this User Guide)
You supply
•A computer with an unused USB port and Mac OS 8.5 or higher
•A nearby telephone line jack
If you are new to computers, see Chapter 3 - Features, for more information about the
requiredequipment.
Safety Warnings
Before you begin connecting your modem, please read through the following safety
instructions:
•This product is to be used with UL- and CUL-listed computers.
•Never install telephone wiring during a lightning storm.
•Never install a telephone jack in a wet location unless the jack is specifically
designed for wet locations.
•Never touch uninsulated telephone wires or terminals unless the telephone line has
been disconnected at the network interface.
•Use caution when installing or modifying telephone lines.
•Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electrical shock from lightning.
•Do not use the telephone to report a gas leak in the vicinity of the leak.
•To reduce the risk of fire, use only 26 AWG or larger telecommunication line cord.

11
Chapter 2 - Quick Start
Step 1: Assemble the Modem
The only assembly required is to mount the feet on the bottom of the modem. Simply
peel the four self-adhesive plastic feet off the backing strip and press them into the
recesses on the bottom of the modem.
Figure 2-1. Mounting the feet.

12
MT5634ZBA-USB User Guide
Step 2: Install the Software
Note: You must have Mac OS 8.5 or later to perform this installation. If you need to
upgrade, go to http://asu.info.apple.com/. Once you have done this, proceed with the
installation that follows.
Follow these steps to install the software on your computer.
1 Turn on your computer.
2 Insert the Installation CD. The Installation CD icon appears on the desktop.
3 Double click the CD icon.
4 Double click on Install MT5634ZBA-USB. The MT5634ZBA-USB Installation Script
dialog box appears.
5 Click Install.
Note: If you have other applications running a dialog message will be displayed
instructing you to close all other applications. If this is the case, click Continue to
close applications and continue with the installation.
6 When installation is finished, a dialog message will be displayed telling you that
installation was successful. Click Quit to complete the installation.

13
Chapter 2 - Quick Start
Step 3: Connect the Modem to Your System
Placing the modem in a convenient location, connect it to your computer’s USB port, to
the telephone line, and, optionally, to your telephone. Figure 2-2 shows the connections.
USB Ports
PHONE LINE
USB
Figure 2-2. MultiModemUSB Cabling (iMacTM)
Line Connection
Plug one end of the line cable into the modem’s LINE jack*, and the other end into a
phone line wall jack.
Phone Connection
For voice-only calls (optional), you can plug a telephone into the modem’s PHONE jack*.
* Note: The LINE jack is not interchangeable with the PHONE jack. Do not plug the
phone into the LINE jack or the line cable into the PHONE jack.
USB Connection
Plug the Type B (D-shaped) end of the USB cable into the USB connector on the
modem, and the Type A (flat) end into a USB port connector on your computer*. See
Figure 2-2.
* Note: Do not plug the modem into the USB port on you keyboard—this port is for low
power devices such as a mouse.
Once the USB cable is connected, the TR (Terminal Ready) indicator lights, indicating
the modem has been recognized by the computer.

14
MT5634ZBA-USB User Guide
Step 4: Select the Modem
1 Click Apple ( ) menu | Control Panels | Modem. The Modem dialog box is
displayed.
2 In the Connect via pull-down list, select MT5634ZBA-USB.
3 In the Setup group, select MT5634ZBA-USB from the Modem pull-down list.
4 Close the Modem dialog box, and click Save when prompted to save changes.
Step 5: Test Your Modem
If you already have an Internet account, the simplest way to test your modem is to try
logging on to the Internet. If the modem does not connect successfully, refer to Chapter 6
for troubleshooting tips, or toAppendix D for information on contacting Technical Support.

Chapter 3 - Features

16
MT5634ZBA-USB User Guide
What Can You Do with Your Modem?
Your Multi-Tech modem is the gateway to the exciting world of telecommunications.
You can use it to access commercial on-line information services such as CompuServe,
America Online, Genie, and Prodigy. These services provide access to databases,
encyclopedias, stock reports, news, weather, and shopping. They provide electronic mail
(e-mail) links to subscribers of the same and other services. Public message areas
called forums allow subscribers to trade information and opinions on a vast array of
topics fromA to Z, while vendor forums provide hardware and software support from
Multi-Tech and other manufacturers. Online services also allow you to upload and
download computer programs, data files, and updated software such as video and printer
drivers.
Your modem can also connect you to the Internet, an international computer network of
universities, libraries, businesses, and government agencies. Like the commercial online
services, the Internet provides e-mail services, public message areas, and access to
information and software, much of it easily accessed through the World Wide Web.
Other uses include direct links to colleagues with modems, to banks, and to service
bureaus. You can also telecommute with your fax modem—work at home while
communicating with the office by modem or fax.
And of course, you can use your modem to exchange faxes with any fax machine in the
world, enabling you to communicate quickly with businesses and organizations that do
not have direct data communications.
Features
• Compliance with major ITU-T, TIA, and EIAinternational standards to ensure
compatibility with other modems.
• Caller ID capability can identify a caller’s phone number (available only on U.S.
products).
• Limited warranty: Ten years
Data
• Supports the V.90 standard for data transmission speeds up to 56K bps while
maintaining compatibility with lower-speed modems.
• Supports the enhanced ITU-T V.34 standard, with data transmission speeds to 33.6K
bps.
• Supports asynchronous data rates at 56K, 33.6K, 31.2K, 28.8K, 26.4K, 24K, 21.6K,
19.2K, 16.8K, 14.4K, 12K, 9600, 4800, 2400, 1200, and 300 bps.
• Supports automatic fallback to slower speeds in noisy line conditions, and fall-
forward to faster speeds as conditions improve.
• ITU-T V.42 LAP-M and MNP Class 3 and 4 error correction.
• ITU-T V.42bis (4-to-1) and MNP 5 (2-to-1) data compression.
• Automatically disables data compression when transferring already-compressed
files.
• Autodial, redial, pulse (rotary) and touch-tone dial.
• Dial tone and busy signal detection for reliable call-progress reporting.
• Compatible with the standardAT command set used by most communication
programs.

17
Chapter 3 - Features
Fax
• Supports V.17, Group 3 fax communication standards, allowing it to communicate
with other fax modems as well as with fax machines.
• Responds to EIA/TIA Class 1 and 2 fax commands.
• Sends and receives faxes from your computer at 14,400 bps, 9600 bps, 7200 bps,
4800 bps, 2400 bps, or 300 bps.
Required Equipment
In addition to the contents of your modem package, you need the following equipment.
Computer
Your modem can only be connected to a computer with a USB port.
Telephone Line
You must have a telephone line with jack (connector) that accepts the cable that comes
with the modem. If you do not have a telephone jack near your computer, you should
install one before proceeding.
Do-it-yourself telephone extension kits and accessories are available wherever
telephones are sold. You may also hire an independent contractor or your local telephone
company to install an extension. If you want a separate line for your fax modem, you
must contact your telephone company.
Communications Software
To operate your modem, you must have data communications and fax communications
software. Data communications software simplifies control of the modem by guiding you
through the process of selecting your serial port, your port speed, and other variables,
and then storing your settings, including frequently called phone numbers, so they can be
recalled with the stroke of a key or the click of a mouse. Data communications software
must be set up (or configured) before you can use it.

18
MT5634ZBA-USB User Guide
Connections
To use your modem, you must connect it to your computer (“USB”), to a telephone line
(“LINE”), and optionally to a telephone set (“PHONE”).
PHONE LINE
USB
Figure 3-1. USB and communications connectors.
Connecting to the Computer (“USB”)
Using a USB cable, connect the USB connector on the modem to a USB connector on
the back of your computer*.
* Note: Do not plug the modem into the USB port on you keyboard—this port is for low
power devices such as a mouse.
Connecting to the Telephone Line (“LINE”)
Plug one end of the cable provided with the modem into the telephone jack in your home
or office. Plug the other end into the LINE jack on the modem.
Note: The LINE jack is not interchangeable with the PHONE jack. Do not plug the
telephone into the LINE jack or the line cable into the PHONE jack.
Note: The Federal Communications Commission (FCC), Industry Canada, and other
regulatory agencies impose certain restrictions on equipment connected to public
telephone systems. SeeAppendixAfor more information.
Connecting to a Telephone Set (“PHONE”)
If you wish to connect a telephone to the same line as the modem, you can plug it into
the modem’s PHONE jack. This connector is provided as a convenience; you can also
connect your telephone to a duplex jack inserted into your wall jack.
Note: The PHONE jack is not interchangeable with the LINE jack; do not plug the
telephone into the LINE jack or the line cable into the PHONE jack.
Surge Protectors and Lightning
Your modem has self-resetting lightning protection to protect it from electrical spikes on
the telephone line. During an electrical storm, your safest course is to unplug your
computer equipment from both the power outlet and the telephone line.

19
Chapter 3 - Features
Front Panel
Figure 3-3. Front panel
The MT5634ZBA-USB has 6 LED indicators on the front panel that indicate status,
configuration, and activity:
TD
Transmit Data. The TD LED flashes when the modem is transmitting data to another
modem.
RD
Receive Data. The RD LED flashes when the modem is receiving data from another
modem.
CD
Carrier Detect. The CD LED lights when the modem detects a valid carrier signal
from another modem. It is on when the modem is communicating with the other
modem and off when the link is broken.
OH
Off-Hook. The OH LED lights when the modem is off-hook, which occurs when the
modem is dialing, online, or answering a call. The LED flashes when the modem
pulse-dials.
TR
Terminal Ready. The TR LED lights when the computer detects and initializes the
modem.
Power. The PWR led lights when the system is applying power to the modem.

20
MT5634ZBA-USB User Guide
