Multitech - MTE-Series Cell Modem

Overview
The purpose of this article is to provide a quick guidance on how to configure Multitech MTE-Series cell modem to
connect it to a Swift Navigation Device and get corrections from Skylark or a third party RTK correction service.


Prerequisites
Ensure device is powered properly to the voltage level suggested by the manufacturer.
Steps
1. Before starting, check with the selected service provider :
a. SIM card APN information, to be used later during cell modem configuration
b. If data plan has been activated on the SIM card to be used.

2. Insert the SIM card on the SIM slot as instructed on the Multitech MTE-Series User Manual.

3. Connect your computer to the cell modem via ethernet cable and turn the device on.

4. On your computer, turn-off your wireless network and enable DHCP on the physical ethernet interface to be used.

5. Open your internet browser and type the following ip : 192.168.2.1
Note : If you are not able to establish connection with the cell modem, check your network settings on your
computer.

6. You will land into the Multitech default credentials screen. Please enter the default username and password as
indicated below:



www.swiftnav.com | [email protected]
©2018 Swift Navigation, Inc. All rights reserved | Version 2.1 | Swift Navigation, Inc. Proprietary



Username : admin
Password : admin


7. You will be directed to the main configuration menu screen


8. In order to configure your cell-modem, go to Status >> Networking and then click on the "edit" button the "Wan
Interface IPV4 Network Status" on the far right side of your screen.



9. In top section "Connection with SIM-A Card"


www.swiftnav.com | [email protected]
©2018 Swift Navigation, Inc. All rights reserved | Version 2.1 | Swift Navigation, Inc. Proprietary



a. Change Dial-up Profile from Auto-detection to Manual-detection.
b. Change Country to the corresponding one where SIM Card has been purchased, in our case we will select
the "USA".
c. Go to "Service Provider" and select the carrier that fit the one you have purchased.Ensure the information
matches with the information from your SIM and APN information. As soon as one service provider is
selected, it auto populates the rest of the configuration. No further modification are needed in this
section. For example, we have tested it with AT&T.

10. In lower section "3G/4G Connection Common Configuration":
a. Go to "IP Passthrough" and deactivate the checkbox.
b. Right after, ensure "NAT" is "Enable".

11. As mentioned before and for the purpose of this guide, we have selected USA as country and AT&T as service
provider. The configuration for this example will look like the following image:



12. Proceed to Save the configuration. The device will reboot and you will be ready to connect it to your Swift
Navigation Device via ethernet port.


Multitech MTE-Series product listing for this configuration
MTE-LAT2
Region
MTE-LAT2-B07-US
North America



www.swiftnav.com | [email protected]
©2018 Swift Navigation, Inc. All rights reserved | Version 2.1 | Swift Navigation, Inc. Proprietary



For technical support or questions in regards to the Multitech cell modem devices, please contact Multitech
Support at https://www.multitech.com/support







