MUNBYN IMP013 User manual

IMP013
Please read this Manual carefully before using the printer and keep it for future reference

9
9
7.1
7.2

About This Manual
Icons and Practices
Related Manual Information
Thank you for purchasing the mobile printer.
This manual can help you easily learn to use this product.Please read this Manual carefully before using the printer and
keep it properly so that everyone who uses this product can read it.
For your convenience,this manual uses the following symbols(icons)and practices:
warns that improper use may result in property damage, serious injury or death.
indicates that improper use may result in personal injury or property damage.
indicates that the information listed allows you to use the product better or extend the
service life of the product.
The illustrations and text used in this Manual may differ from the actual product.
Various manuals provide detailed instructions for various technical problems.

Do not disassemble the printer by yourself. Please read this Manual carefully before use.
Please turn off the power immediately in case of failure. When you notice smoke or odor coming from
the printer or power adapter, please unplug the power adapter and remove the battery immediately.
Please be careful not to get burnt.
Please do not use the printer near gas stations, fuel warehouses and other flammable materials.
During charging, the printer and power adapter must be placed in a ventilated place with the ambient
temperature of 0C-45°℃, and be sure to use the power adapter provided by the Company. The use of
unapproved power adapters may be hazardous and also violates our warranty policy.
When the printer is printing, please do not open the cover of the paper bin; otherwise, unpredictable
conditions may occur and the printer may even be damaged.
After printing, the print head is still at a high temperature. Do not touch it to avoid burns.
Please do not use dissolved matter(such as benzene thinner) to wipe the printer shell, and please
keep the printer away from corrosive chemicals. You can only gently wipe the printer with a clean soft
cloth.
Please use our original or approved printing paper; otherwise, it may lead to poor printing quality or
even damage to the printer mechanism.

If the printer is to be stored for a long time, be sure to remove the battery from the printer and store it
separately; otherwise, the battery may fail or even have leakage, which may damage the printer.
Make sure the printer is turned off before replacing the battery. If a power adapter is used, make sure
the power is cut off before replacing the battery.
The printer can work stably at an ambient temperature of 0C-40℃. Too high or too low ambient
temperature will lead to low printing quality.
The time that the printed text can be kept on the thermal printing paper is related to the paper quality.
To print documents that need to be kept for a long time, please use long-lasting thermal printing paper.
Please carefully read this Manual and symbols on the battery surface before use.
Please charge the battery in a cool and ventilated room. The high ambient temperature during
charging will cause the battery to heat up, emit smoke, burn, deform, or even explode.
There are special protective circuits and devices inside the battery. Please do not disassemble the
battery by yourself, or it will cause a short circuit or electrolyte leakage.
There is a risk of blindness if the electrolyte gets into the eye. In case of eye contact, rinse immediate-
ly with water and seek doctor's advice immediately.
Do not squeeze, mechanically vibrate or shake the battery, and short circuit of the battery is strictly
forbidden.

Please do not put the battery into water; otherwise, it may result in internal short circuit, which may
cause the battery to heat up, emit smoke, deform, damage or even explode.
Do not expose the battery to direct sunlight or put it in a place with excessive smoke and dust.
Do not use the battery in a high humidity environment, such as a bathroom.
Please replace the battery if it cannot meet the performance requirements.
Keep the battery out of reach of children to prevent danger.
If you notice any discoloration or deformation of the battery, stop using it immediately.
Do not disassemble or modify the power adapter. Do not use the power adapter if the power line is
damaged; otherwise, it may cause electric shock, fire and damage to the power adapter.
Do not touch the power adapter with wet hands. If the power adapter comes into contact with water or
other liquids, cut off the power supply immediately.
Please avoid short circuit, vibration or shaking of the power adapter.
Do not use the power adapter in a high humidity environment, such as a bathroom.
The equipment is not waterproof and must not be exposed to rain or moisture.
Hold the power adapter body when unplugging. Simply pulling the power line will damage the wires.
Keep the power adapter out of reach of children to prevent danger.

Standard Accessories
The pictures are for reference only. If any item is damaged or missing, please contact the supplier.

STATUS indicator
BATT indicator
ERROR indicator
Front cover
Cover opening
button
Main body
Battery
Power DC interface
USB interface
FEED button
Rubber roll gear
Rubber roll Thermal print head
POWER button

3.1 Battery Installation
This chapter describes the steps to prepare the printer, including battery
installation, battery charging, and printing paper loading.
The battery is installed in the printer before the
product leaves factory.
(1) Remove the protective film of battery contacts.
(2) Install the battery as shown in the figure above.
(3) Fasten the battery.

3.2 Battery Charging
For charging method
After the printer is used for a period of time, the battery will
run out. When the printer battery is about to run out, all BATT
indicators(Bluetooth) will go out, while the ERROR indica-
tor(red) will be on.
At this time, the user should charge the printer.
If the printer is automatically turned off during printing, it must
be charged before reuse.
If you use a power adapter not provided or approved
by us, the printer may be damaged.
You can print while charging.
The equipment supports fast charge function and can
continue to print after short-time charging.
Do not remove the battery while charging.
The battery cannot be charged with the adapter and
USB cable at the same time.
Insert the mains plug of the charger into a 220V,50HZ power outlet, then insert the charging plug into the printer's
charging outlet, and the printer will start charging. During the charging process, if the printer is turned on, the BATT
indicator(blue) will flash in turn from left to right until the battery is fully charged and the BATT indicator is always on.

3.3 Printing Paper Loading
1.Remove the seal of the paper roll.
2.Open the paper bin cover.
3.Put the paper roll into the paper bin as shown in the figure.
4.Put the paper roll in place and close the cover.
1. Paper specification used by the printer: Paper width:79.5±0.5mm, paper roll diameter:40mm.
2. Pay attention to the direction of paper roll. If it is placed in the wrong direction, it will lead to blank printing.

4.1 Power On
4.1 Power Off
During power-off state, press and hold the power button for
2 seconds to turn on the printer and enter working state.
At this time, the STATUS indicator(green) is always on.
4.3 Self-test
After getting the printer, the user can perform self-test
on the printer at any time to check the current settings
and status of the printer.
4.4 Paper Feeding(Manual Feeding)
Under normal working state of the printer, press
[FEED] button and the printer will start feeding paper.
The self-test method is as follows: Turn off the
printer(if the printer is on), press and hold the [FEED]
button, and then press the [POWER] button to turn on
the printer. At this time, the printer will print the self-test
page, including current state, settings and printing
sample.
If all BATT indicators(blue) are off and the ERROR
indicator(red) is always on, it means the printer battery is
about to run out. If you want to continue using it, please
replace the battery or charge it as soon as possible.
For charging method, refer to 3.2 Charging
During power-on state, press and hold the [POWER]
button for 2 seconds to turn off the printer and all indicators
will be off.

4.5 Indicator Description
After getting the printer, the user can perform self-test on the printer at any time to check the current settings and
status of the printer.
STATUS indicator
BATT indicator
ERROR indicator

Ⅴ. Driver Installation
5.1 USB to Serial Driver Installation
Driver download link: https://bit.ly/IMP013-Driver
Open the file
from the file: Driver CD.
Double click the installation icon
Then, it will show as below picture:
Select “Next”, it will show as below picture:
12

Click “Finish”, the USB to Serial Driver is installed.
Firstly, if you want to connect the Mobile Printer to computer, please connect the printer to computer by the
USB Data Wire. Turn on the computer power. Then you can see the COM number from the lower right
corner of the computer desktop. Then you can install the Windows Driver.
13

5.2 Windows Driver Installation
Double click the installation icon ,
Then, it will show as below picture:
Select the language, then click “OK”.
Then, it will show as below picture:
Then click “Install”. 14

Then, it will show as below picture:
Select the Printer Model and available computer port, such as "USB PORT" as the
picture, then, click “Install”.
15

And then, it will show as below picture:
Select “OK”, and then click “Exit”. Wait until it shows the below picture, it means, the printer driver has
been installed successfully.
16

Then click “Finish” to finish driver installation.
17
