Munro SIMPLICITY User manual

munro
MU01R1 1121 © 2021 MUNRO COMPANIES INC., ALL RIGHTS RESERVED
OWNER’S MANUALOWNER’S MANUAL
MUNRO SIMPLICITY
Operation - Programming - MaintenanceOperation - Programming - Maintenance
1.800.942.42701.800.942.4270
[email protected][email protected]
www.munropump.comwww.munropump.com
®

1. System Operation Overview 2
2. Hand/OFF/Auto Mode Descriptions 2
3. Using the Digital Operator 4
4. Parameter List 6
5. Parameter Details 6
6. Faults & Alarms 10
7. Wiring Diagram 11
8. Pre-Start Up Checklist 12
9. Start Up Checklist 14
10. Maintenance Checklist 16
NOTES
TABLE OF CONTENTS
Page 1
Phone-in Start-up Assistance and Technical Support
Contact the Munro team to schedule and access
phone-in start up assistance and technical support.
1-800-942-4270 or [email protected]

The Munro Simplicity is a low-maintenance, self-contained pumping station with simple, user-friendly
controls. The system is controlled using a toggle switch and a digital keypad for modifying settings.
The small toggle switch on the front of the VFD labeled “HAND/OFF/AUTO” can be set to one of the three
positions: left= HAND, center= OFF, and right= AUTO.
• Hand Mode simply runs the pump at a constant speed.
• Auto Mode uses feedback from the pressure transducer to automatically start and stop the pump and
control the speed in order to maintain constant pressure in the system.
When in Auto Mode, the pump can be started using either the Pressure Start Method or the Clock Start Method.
• With Pressure Start, the pump starts when the pressure in the system drops below a set threshold.
• With Clock Start, an external run signal from an irrigation controller can be used to start and stop the system.
For information about modifying settings, refer to sections 3 and 4.
When in Hand Mode, the functions marked below are enabled:
OFF Mode:
• The VFD stops the pump using the stopping method set in parameter B1-03.
• The pump remains off until switch is moved from the OFF position.
Hand Mode:
• Sends a 24VDC signal to VFD terminals S3-S4.
• Forces the VFD into the “Run” state.
• The pump runs at the speed set in parameter D1-01.
• The Start Method and Sleep Function are ignored.
2. HAND/OFF/AUTO MODE DESCRIPTIONS
1. SYSTEM OPERATION OVERVIEW
Function Hand Mode
Sleep Function
Pid Control
Prime Loss Detection
Overload Detection
Clock Start
Pressure Start
P
P
Page 2

Auto Mode:
• Sends a 24VDC signal to VFD terminal S2.
• The VFD waits idly until the designated start conditions have been met.
• Utilizing feedback from the pressure sensor, the VFD uses PID control to adjust the speed of the pump
in order to achieve the pressure setpoint set in parameter B5-19.
• If using Clock Start, the pump runs until the external 24VAC signal is removed.
• If using Pressure Start, the pump runs until the conditions of the designated Sleep Type have been met
(see Figure 1).
• Pressure Start: the system pressure drops below the pressure set in parameter Q1-01.
• Clock Start: an external 24VAC signal is received across the wires in the external junction box
which closes the Time Clock Relay and sends a 24VDC signal to VFD terminal S1.
Frequency: the pressure setpoint has been achieved and the pump’s proportional speed
is less than the percentage set in parameter Q1-02 for the time set in parameter Q3-01.
Current: The pressure setpoint has been achieved and the pump’s proportional current is
less than percentage set in parameter Q1-02 for the time set in parameter Q3-01.
Figure 1 - Timing diagram of the Sleep Function illustrating both Sleep Types
When in Auto Mode, the functions marked below are enabled:
Page 3
Function Hand Mode
Sleep Function
Pid Control
Prime Loss Detection
Overload Detection
Clock Start
Pressure Start P
P
P
P
P
P
Note: Pump station is default programmed for pressure start. If 24VAC start is
required, connect 24VAC signal to red and black wires located in j-box (labeled
24VAC connection) outside station enclosure. Program parameter Q1-02 tu 001.00%.
VERY IMPORTANT
READ CAREFULLY

This section describes the basic settings for your Munro Simplicity pump station. Virtually all of the settings
that control the pump station are managed by the VFD parameters. The parameters can be modied directly
on the VFD using its buttons and digital display, or by using the much more user-friendly Yaskawa JVOP-
180 Digital Operator keybad included with your Munro Simplicity (see Figure 2). To use the Digital Operator,
simply connect it to the VFD using a Cat5e Networking Cable.
Figure 2 - Digital Operator Key Functions
3. USING THE DIGITAL OPERATOR
Yaskawa JVOP-
180 Digital
Operator
Key Pad to VFD
Connection
(see Figure 6)
No. Display Name Function
1
2
3
4
5
Function Key (F1, F2)
ESC Key
RESET Key
RUN Key
Up Arrow Key
The function assigned to F1 and F2 vary depending on the currently displayed menu
The name of each function appears in the lower half of the display window
• Returns to the previous display if there are no spaces to move to the left
• Moves the cursor one space to the left
• Pressing andholidng this button will return to the Frequency Reference display
• Moves the cursor to the right
• If an alarm is active, turns off alarm; When programming, resets the drive to factory
presets
Starts the drive
Scrolls up to display the next item, selects parameter numbers, and increments setting
values
6Down Arrow Key Scrolls down to display the previous item, selects parameter numbers, and decrements
setting values
7STOP Key1Stops drive operation
8ENTER Key • Enters parameter values and settings
• Selects a menu item to move between displays
9LO/RE Selection Key2Switches drive control between the operator (LOCAL) and an external source (REMOTE)
for the Run command and frequency reference
11 LO/RE Light Lit while the operator is selectted to run the drive (LOCAL mode). Refer to page 117 of
the Yaskawa V1000 manual for details
12 ALM LED Light Refer to ALARM (ALM) LED Displays on page 117 of the Yaskawa V1000 manual
10 RUN Light Lit while the drive is operating the motor. Refer to page 117 of the Yaskawa V1000
manual for details
1The STOP key has highest priority. Pressing the STOP key will always cause the drive to stop the motor, even if a RUN command is active at any
external RUN command source. To disable the STOP key priority, set parameter o2-02 to 0.
2The LO/RE key can only switch between LOCAL and REMOTE when the drive is stopped. To disable the LO/RE key to prohibit switching between
LOCAL and REMOTE, set parameter o2-01 to 0.
Page 4

No. Step Display/Result
1Turn on the power to the drive. The initial display appears.
2Press or until the Parameter Setting Mode screen appears,
Press or to select the C parameter group.
3
Press two times.
Press to enter the parameter menu tree.
4
Press or to select parameter C1-02.
6
Press and enter 0020.0.
9
Press or or until the desired number is selected “1” ashes.
8
Press to conrm the change.
10
5
Press to view the current setting value (10.0 s). The leftmost digit ashes.
7
Press as many times as necessary to return to the initial display.
The display automatically returns to the screen shown in Step 4.
11
12
To modify a parameter, follow the steps shown below in gure 3. This example explains
changing parameter C1-02 (Deceleration Time 1) from 10.0 seconds (default) to 20.0 seconds.
Figure 3 - how to modify a parameter using the Digital Operator
Page 5

No. Parameter Name Function Range Default
4. PARAMETER LIST
Q1-03
Q1-02
L6-02
D1-01
Q1-04
Q1-01
B5-19
Determines which Start Method is used for Auto
Mode.
0.00: Pressure Start Method: the VFD will start
the pump when the pressure drops below the level
set in Q1-01.
1.00: Clock Start Method: the VFD will start the
pump when it receives a 24VAC signal from an
external source.
Sets the value at which either the pump’s speed or
current (depending on Q1-04) must fall below in
order to activate the sleep mode. The value is set
as a percentage of either max speed (60Hz) or the
rated current of the VFD.
Sets the threshold for the Prime Loss Detection
Function. If the pump is running at 100% speed
(60 Hz) and the proportional current falls below
this value for the amount of time set in L6-03, the
VFD will shut off the pump to prevent it from being
damaged and display Fault Code UL5. This value
is set as a percentage of the rated output current
of the VFD.
Sets the speed the pump will run at while in Hand
Mode. This value is set as a percentage of the
maximum speed, 60Hz.
Determines if the VFD will monitor the pump’s
speed or current to trigger to sleep function.
0.00: Speed
1.00: Current
Sets the pressure that the system must fall below
for the pump to exit sleep mode. It is typically set
to 10 psi below the running pressure. The value is
set as a percentage of the range of the pressure
transducer.
Sets the operating pressure setpoint for Auto
Mode. The value is set as a percentage of the
range of the pressure transducer.
0.00
0.00
84%
43%
100%
35%
40%
0.00
or 1.00
0.00
or 1.00
0-100%
0-100%
0-100%
0-100%
0-100%
START METHOD
(Custom Parameter 3)
SLEEP THRESHOLD
(Custom Parameter 2)
PRIME LOSS
DETECTION LEVEL
(Torq Det 1 Lvl)
FREQUENCY
REFERENCE
(Reference 1)
SLEEP TYPE
(Custom Parameter 4)
START PRESSURE
(Custom Parameter 1)
RUNNING PRESSURE
(PID Setpoint)
5. PARAMETER DETAILS
The VFD parameters are organized with a numbering system using one letter and two numbers, e.g., “A0-00”.
The letter represents the parameter group, the rst number represents the sub-group, and the number after
the dash represents the specic parameter. This section covers the main, applicable parameters. The rest of
the parameters and their descriptions can be found in the V1000 Quick Start Guide*.
Page 6
*Find on “Other Info” tab www.munropump.com/simplicity-pump-stations

No. Parameter Name Digital Operator Display Range Default
B5-19 RUNNING PRESSURE PID Setpoint 0-100% 40%
Parameter B5-19 sets the pressure setpoint that the system tries to maintain when in Auto Mode. This value is
entered as a percentage of the range of the pressure transducer used in the system.
To calculate the value to enter for running Pressure, use the following equation or see Figure 4 for typical values.
EXAMPLE: If you want the system to maintain the pressure at 60 psi, substitute 60
into the above equation: 60+20 =40, enter 40 into parameter B5-19.
2
entered value=
2
desired pressure(psi) + 20
entered value=
2
desired pressure(psi) + 20
Parameter Q1-01 sets the pressure that will cause the pump to start when using the Pressure Start Method
in Auto Mode. If the pressure in the system falls below this setting, the VFD will exit sleep mode and run the
pump. It is typically set to 10 psi below the Running Pressure. This value is set as a percentage of the range of
the pressure transducer used in the system. To calculate the value to enter for Start Pressure, use the following
equation or see Figure 4 for typical values.
EXAMPLE: if you want the pump to start when the pressure drops below 50 psi, substitute
50 into the above equation 50+20 = 35, enter 35 into parameter Q1-01.
2
No. Parameter Name Digital Operator Display Range Default
Q1-01 START PRESSURE (Custom Param 1) 0-100% 35%
0-200 psi Transducer
40
45
50
55
60
65
70
75
80
85
90
95
100
30
35
40
45
50
55
60
65
70
75
80
85
90
30
32.5
35
37.5
40
42.5
45
47.5
50
52.5
55
57.5
60
25
27.5
30
32.5
35
37.5
40
42.5
45
47.5
50
52.5
55
Running Pressure
(psi)
Wake Pressure
(psi)
Q1-01
(%)
B5-19
(%)
Where “x” is a percentage of the range of the pressure
transducer and “r” is the range of the pressure transducer (in
psi). The Munro Simplicity uses a 0-200 psi, 1-11V Pressure
transducer, but the analog input on the VFD used for PID
feedback reads a 0-10V signal, so the 10% offset in the
equation compensates for the 1V difference. If the pressure
transducer is replaced with one with a different pressure
range, substitute the new range into the above equation to
calculate the correct values to enter into the parameters.
NOTE: The above equation used for the pressure parameters
is derived from the equation:
X=pressure(psi) + .1r *100
r
Figure 4 - A table showing typical Running and Start Pressures
and their corresponding parameter values.
Page 7

The Q1-03 parameter determines if the VFD will use the Pressure Start Method or Clock Start Method.
Parameter Q1-02 sets the threshold for the Sleep Function. The value entered in this parameter depends on the
setting of the SLEEP TYPE Parameter Q1-04:
Q1-04 =0: If the running pressure is being maintained and the proportional speed falls below this value for the
amount of time set in Q3-01, the VFD will activate the Sleep Function. This value is set as a percentage of the
maximum speed, 60Hz.
Q1-04 =1: If the running pressure is being maintained and the proportional current falls below this value for
the amount of time set in Q3-01, the VFD will activate the Sleep Function. This value is set as a percentage of
the rated output current of the VFD. The rated output current of the VFD is printed on the top of the VFD, near
the model number and serial number.
EXAMPLE: If you want the pump to go to sleep when the speed drops below 50Hz:
50Hz =84%, enter 84 into parameter Q1-02
60Hz
No. Parameter Name Digital Operator Display Range Default
Q1-02 SLEEP THRESHOLD (Custom Param 2) 0-100% 84%
EXAMPLE: If you want the pump to go to sleep when the current drops below 7A:
7A =40%, enter 40 into parameter Q1-02
17.5A
No. Parameter Name Digital Operator Display Range Default
Q1-03 START METHOD (Custom Param 3) 0.00-1.00 0
0.00: Pressure Start Method: When in Auto Mode, the VFD will start the pump when the pressure drops
below the level set in Q1-01.
1.00: Clock Start Method: When in Auto Mode, the VFD will start the pump when it receives a 24VAC signal
from an external source (e.g. an irrigation controller).
Page 8

The Q1-04 parameter determines if the VFD will monitor the pump’s speed or current to trigger the sleep function.
Parameter L6-02 sets the threshold for the Prime Loss Detection Function. If the pump is running at full speed
(60 Hz) and the proportional current falls below this value for the amount of time set in L6-03, the VFD will shut
off the pump to prevent it from being damaged and display Fault Code UL5.
The value is set as a percentage of the rated output current of the VFD. The rated output current of the VFD is
printed on the top of the VFD, near the model number and serial number. The Prime Loss Detection Level is set
and tested at the factory, so it is unlikely that it will need to be adjusted. This value is typically set at 43% (60%
of the pump’s FLA), in most systems. Increasing this value will make the system more sensitive to Prime Loss
Detection (see gure 5).
Parameter D1-01 sets the speed the pump will run while in Hand Mode.
This value is set as a percentage of the maximum speed, 60Hz.
0.00: Speed
1.00: Current
No. Parameter Name Digital Operator Display Range Default
No. Parameter Name Digital Operator Display Range Default
L6-03 PRIME LOSS DETECTION TIME (Torq Det 1 Time) 0.0 or 10.0 sec 10.0 sec
Q1-04 SLEEP TYPE (Custom Param 4) 0.00 or 1.00 0
No. Parameter Name Digital Operator Display Range Default
D1-01 FREQUENCY REFERENCE (Reference 1) 0-100% 100%
EXAMPLE: If you want the pump to run at 54 Hz while in Hand Mode:
54Hz =90%, enter 90 into parameter D1-01
60Hz
EXAMPLE: If you want the VFD to trigger a Prime Loss fault when the
pump is at max speed and the current drops below 8A:
8A = 45.67%, enter 45.7 into parameter L6.02
17.5A
Page 9

Figure 5 - Timing diagram of the Prime Loss Detection Function
Figure 6 - A photo showing where the rated output current is printed
on the VFD. The VFD shown here is rated for 30.0A/25.0A.
6. FAULTS & ALARMS
When the VFD has an active alarm, the “ALM” LED will blink red and the digital display (or the digital operator
if it’s connected) will display the alarm code. When the VFD has an active fault, the “ALM” LED will be solid
red and the digital display (or the digital operator if it’s connected) will display the fault code. Fault and Alarm
code descriptions can be found in the V1000 Quick Start Guide*.
To resolve a Fault or Alarm:
1. Move the HOA switch to the OFF position.
2. Connect the Digital Operator and identify the displayed fault/alarm.
3. Look up the fault/alarm code in the V1000 Quick Start Guide.
4. Resolve the issue triggering the fault/alarm.
5. Place the HOA switch in the OFF position.
6. Push the RESET button on the Digital Operator to reset the fault/alarm.
Page 10
*Find on “Other Info” tab www.munropump.com/simplicity-pump-stations

7. WIRING DIAGRAM
Page 11
Note: Pump station is default programmed for pressure start. If
24VAC start is required, connect 24VAC signal to red and black
wires located in j-box (labeled 24VAC connection) outside
station enclosure. Program parameter Q1-02 to 001.00%.
VERY IMPORTANT
READ CAREFULLY
Phone-in Start-up Assistance and Technical Support
Contact the Munro team to schedule and access
phone-in start up assistance and technical support.
1-800-942-4270 or [email protected]

8. PRE-START UP CHECKLIST
Page 12
PROJECT NAME
Scheduled Start up date
MECHANICAL INSTALLATION
Verify all mechanical components were received and installed properly.
Verify suction screens are properly attached to pumps and ush lines are connected.
Verify suction piping and foot valve installation.
Verify all fasteners are tight, including motor bolts, piping connections and panel supports.
Verify skid is properly leveled and secured.
ELECTRICAL INSTALLATION
Verify the electrical power is connected and installed per NEC, including grounding, bonding, and neutral.
Connect wiring to motors, when applicable.
Verify incoming power is +/- 10% of specied voltage.
Specied voltage
Phase A to Ground Phase B to Ground Phase C to Ground
A to B B to C A to C
Verify pump, skid, and pipes, are sufciently grounded to prevent electrolysis and premature wear. Use of
ground rods and/or CEE (Concrete Encased Electrode) is recommended.
Verify 24 VAC signal from clock is installed, as well as any other remote signal source, or monitor, when applicable.
HYDRAULIC INSTALLATION
Verify pump station has water.
Verify inlet water pressure is within spec.
Verify distribution system is ready to accept water. (Example: all sprinkler heads installed.)
PERSONNEL AVAILABILITY
If scheduling a start up with Munro, either in person or over the phone, please conrm that relevant
personnel are available at time of start up, including installer and end user personnel. Installer and end user
personnel are scheduled to be available on site during start up.
Pump station is installed and ready for start up. All listed checklist items have been completed and veried. I
understand that if Munro’s Authorized Service Provider arrives at the job site and nds that the pump station is
not ready to start up, any required subsequent visits will incur hourly fees (up to $150/hr.) and travel expenses.
Customer Name
Customer Signature Date
PHONE-IN START-UP ASSISTANCE AND TECHNICAL SUPPORT
Contact the Munro team to schedule and access phone-in start up
assistance and technical support.
1-800-942-4270 or [email protected]
Use the below checklist to prepare for a successful pump station start up. If scheduling a start up date
with Munro, either in person or over the phone, this document must be completed and returned
to Munro at least 48 hours prior to scheduled start up date.

Page 13
PROJECT NAME
Serial # Distributor
Contractor End User
Site Location
City State
Site Contact Phone
Date of pump station installation Requested start up date
Simplicity: Vertical Horizontal Submersible
Notes:
Station Orientation and Training Provided with In-Person Startups Only
If you elect to purchase an in-person start-up, the Munro Authorized Service Provider will provide training for the
end user. When training is provided, end-user maintenance personnel should be present for the last 2-3 hours of
station start up.
THIS DOCUMENT MUST BE COMPLETED AND RETURNED TO MUNRO IF YOU WOULD LIKE TO SCHEDULE
A PHONE-IN OR IN-PERSON START UP
Start up must be scheduled at least two weeks prior to requested start up date regardless of type of start. Dates
are not guaranteed until conrmed by Munro. Start ups requested with less than two weeks notice may not be
possible to accommodate and may incur additional expense.
Optional in-person start ups will incur additional charges if desired, please contact Service Manager at
970.270.0400 and provide PO# here:
Prior to start up date, job site must be ready to start up pump station. If Munro’s Authorized Service Provider
arrives at the job site and nds that the pump station is not ready to start up, any required subsequent visits will
incur hourly fees and travel expenses.

Page 14
9. START UP CHECKLIST
PROJECT NAME
Serial # Distributor
Contractor End User
Site Location
City State
Site Contact Phone
Start-Up Date
Pump Station Type: Boost Flooded suction Lift
Pump Station Warranty Period: 2 year 5 year - based on
Starting method: Clock/relay start Pressure start Irrigation controller model:
1. All bolts and hardware tightened
2. All panel wiring tight and correct according to schematic
3. All piping and equipment mounted securely, thrust blocking in place
4. Motor lugged and taped properly, and verify no wires are pinched under t-box cover
5. Service wire size =
6. Service protection size =
7. Voltage tested prior to start L1-L2 , L2-L3 , L1-L3
L1-gnd , L2-gnd , L3-gnd
8. Valved opened and system primed, air bled from top of pump stacks,
9. Direction of rotation correct DOR #1 gpm, psi, a
DOR #2 gpm, psi, a
10. Perform Autotune on all pumps with VFDs and note on back
11. Test run system under all expected site conditions (min and max ows)
12. Perform full load tests on each pump and note on back
13. Record set point, sleep speed/current, wake up level, and delay (on second page)
14. Check for leaks
15. Back-up parameters saved to key pad (03-01)
16. Start up date noted on sticker inside panel
17. Switches back in AUTO and site secured prior to leaving (do not leave doors unsecured)
Notes:
1. Record all other data (repairs/modications required, unusual/site conditions) on second page provided.
2. The pages of this form must be completed and submitted with invoicing in order to expedite payment.
3. Amps/horsepower rule of thumb if no name plate data:
• 3 PHASE: 1.2 amps/HP for 480 volt, 2.4 amps/HP for 230 volt
• 1 PHASE: 8.4 amps/HP for 120 volt, 4.2 amps/HP for 230 volt
INITIAL
Complete this helpful tool as a record of your start up. If Munro completes the start up, we will complete a start up checklist.

Page 15
Station Data gpm @ psi with , suction pressure (or lift ft), Using CP, or RS
Pump = hp, kw, a rpm, nla
100% deadhead = psi, hz, a Set LOP at % ( a)
40hz deadhead (Line Fill Speed) = psi, a Set FPL current at % ( a)
Stpt deadhead = psi @ hz & a Set Slp Spd at hz, or % ( a)
Using set point of % ( psi), Wake of % ( psi) with Wake Delay of s
Full load tests (note test conditions – example: Zone 1 = Hz, AMPS @ PSI)
AutoTune

These are basic guidelines for recommended maintenance. Quarterly maintenance is recommended.
Maintenance is not provided by Munro.
MOTOR:
Voltage unloaded
Voltage loaded
Amperages loaded
Megger readings (Not if attached to a VFD)
Check t-box connections
Check t-box gasket condition
Change oil
Grease bearings
PUMP:
Exercise valves
Inspect mechanical seals
Check ush lines
PANEL:
Check/tighten connections
Check Control voltage
Check/clear transducer port (insulating pressure transducer)
Check level sensors (low level safety transducer - probes)
VFD:
Check connections
Check fans/lters
Record user data, (runtime, bus voltage, fault history)
COOLING:
Check vents and remove any blockages
PRV:
Check valve operation/ setting. (25 PSI over setpoint)
Clean y-strainer
Exercise valves
FLOW METER:
Check connections
PUMP SKID:
Clean
Controls back in auto When in doubt, call
a licensed electrician.
High voltage can shock,
burn, or cause death.
10. MAINTENANCE CHECKLIST
Page 16
