Muratec MFX-1430 Manual

MFX-1430/
MFX-2030
Product Demonstration Kit
>
MK3139

MFX-1430/MFX-2030
CONFIGURATIONS & OPTIONS
CONFIGURATIONS
The MFX-1430 comes in a standard version (1430) and as a duplex model MFX-1430D
(1430D). The MFX-2030 (2030), with standard duplex, comes in one configuration.
PAPER OPTIONS
PRINTING/
COMMUNICATIONS/
CONSUMABLES
OPTIONS
Printing Options
PCL500
PCL print
controller kit
Communication/Fax Options
AL500
DA7663
Second
fax modem
32 MB
memory
Telephone handset
2030THK
Page Counter
DA7664
Consumable Options
Toner cartridge
TS2030
Drum cartridge
DK2030
1. MFX-1430 – 550 sheets 2. Second paper cassette
(2030CAS) – 500 sheets
Total = 1,050 sheets
3. Paper cabinet (2030CAB)
2. Second paper cassette
(2030CAS) – 500 sheets
Total = 1,050 sheets
3. Paper cabinet (2030CAB)
2. Second paper cassette
(2030CAS) – 500 sheets
Total = 1,050 sheets
3. Paper cabinet (2030CAB)
MFX-1430
1. MFX-1430D – 550 sheets
1. MFX-2030 – 550 sheets
MFX-1430D:
MFX-2030:
MFX-1430 MFX-1430D MFX-2030
Standard
80-sheet ADF • • •
33.6 Kbps fax modem • • •
(1) 500-sheet cassette • • •
50-sheet bypass tray • • •
Network Printing & Color Scanning • • •
Local USB Printing & Color Scanning • • •
Duplex Print Kit • •
Optional
Paper Cabinet (2030CAB) • • •
500-Sheet Cassette (2030CAS) • • •
32 MB Memory Upgrade (DA7663) • • •
Telephone Handset (2030THK) • • •
Page Counter (DA7664) • • •
PCL Print Controller (PCL500) • • •
2nd Phone Line (AL500) • • •
OfficeBridge Expansion Kit (OB450) • • •

WHY MURATEC?
3,000 independent
office technology dealers
can’t be wrong.
They voted Muratec the top secondary product line
manufacturer in the industry. Why? Muratec focuses on
building highly reliable business-level “fax” machines
and award-winning multifunction units perfect for the
desktop or small workgroup. What’s more, other
manufacturers around the world put their own brand
name on Muratec machines.
For more information on Muratec and its products,
please log on to www.muratec.com
MFX-2830
Cannata Report
Fax Manufacturer of the Year – 2005
Buyer’s Laboratory, Inc.
Muratec MFX-1700 – 2004 Pick of the Year
Muratec F-360 – 2002 Highly Recommended
Muratec F-320 – 2002 Highly Recommended
Muratec MFX-1200 – 2001 Recommended
Better Buys for Business
Muratec F-320 – 2002 Editor’s Choice
Muratec F-360 – 2002 Editor’s Choice
BERTL Digital Test Lab
OfficeBridge Pro – BERTL’s Best Award –
Innovation of the Year 2005
Muratec MFX-2830 – Recommended
Muratec MFX-1700 – 2003 BERTL’s Best
Awards: Best COHO/Satellite Office MFP
Muratec MFX-1700 – Recommended
Business Technology
Association
2003 & 2004 Channel’s Choice Award –
Top Secondary Product Line Manufacturer
F-520
MFX-2030

WHAT IS NGP?
What is NGP?
NGP is an acronym for Network Gateway Platform, a design
on which Muratec has adopted its next generation of segment 1 and
fax products. This design has led to the development of MFP devices
with a built-in affinity for the network, meaning products seamlessly
integrate into and maximize the full potential of a corporate network environment.
What functions can I perform on NGP-enabled devices?
NGP-enabled devices are capable of:
■Color scan to network (direct SMB scanning)
■Color scan to FTP (direct or shortcut)
■Color scan to e-mail (direct or shortcut)
■Internet faxing (T.37 compliant, not T.38)
■Desktop faxing
■Traditional walk-up faxing (33.6 Kbps high-speed modem)
Without adding any additional hardware or software…
Simplistic operation
NGP-enabled products are the first segment 1 and fax-centric products to utilize a touchscreen, which
allows for intuitive user operation.

GENERAL FEATURES
80-sheet automatic document feeder
■Enables faxing, copying or scanning of large jobs without having to split into multiple sets
Intuitive touchscreen operation
■A first in this segment!
■Large, back-lit touchscreen is easy to operate and significantly reduces customers learning curve
■Program keys allow for one-touch initiation of complex fax and copy commands
■The function keys on the default screen can be customized, making commonly used functions accessible
Flexible paper capacity
■Standard 500-sheet front loading tray is accessible and user adjustable
■Optional second 500-sheet cassette allows for the simultaneous use of letter and legal-sized papers
Multipurpose bypass tray
■50-sheet bypass tray can be used for unique media such as letterhead, envelopes, labels or overhead
projector sheets
Easy network installation
■DHCP compliant (Non-DHCP environments may still enter the network settings manually)
■Print drivers can be installed via server or individual client
Duplex printing (MFX-1430D & MFX-2030)
■Reduce paper consumption and day-to-day operational costs by utilizing duplex print, copy and fax
reception capabilities
Expandable memory
■Standard 8-MB memory can be upgraded to 40-MB, creating sufficient memory storage for large
applications
■72-hour memory back-up ensures that business critical documents are not lost in the event of an
extended power outage
Energy Star compliant
■When the machine is left idle for a set period it will enter Energy Save Mode, which will reduce energy
consumption to minimum levels
EEaassyyCChhaannggeeSSMMtoner system
■Front loading high-yield consumables can be quickly changed without the need for a service call
Refined print engine
■14 and 20-ppm print engines provide superior quality and clarity
■Redesigned paper path reduces jam frequency
■Side-access jam removal system allows for quick and painless troubleshooting
Department Codes
■Track up to 100 codes for cost accounting purposes
■Extra level of security, only authorized users have access to certain machine functions

FAX FEATURES
33.6 Kbps fax modem
■Standard fax modem transmits documents at the highest regulated speeds
■JBIG compression reduces the transmission packet allowing for shorter connection times
■Up to 2 spp transmission time
300 entry address book
■Each location can house a fax number, e-mail address and group location
■Up to 30 locations can be manually entered per transmission
■330 number broadcast capabilities (fax and e-mail addresses can be mixed)
■OfficeBridge Expansion Kit allows customers to have both personal & shared address books
■OfficeBridge Expansion Kit can expand the address book to 2000 locations (w/ optional 512 MB
memory)
■Supports vCard import from Microsoft Outlook
LDAP search capabilities
■Quickly and easily locate contacts on a corporate server (Active Directory, OpenLDAP, etc.)
■Up to 5 LDAP servers can be registered
■Contacts located during an LDAP search can be added to the internal address book
Delayed transmission
■Send documents during off-peak hours to reduce machine congestion
Batch transmission
■Group several fax transmissions into one, reducing connection requirements and phone charges
Standard Internet fax functionality
■T.37 compliant – most common standard on the market
Transmission confirmation reports
■Ensures that business-critical documents reached their intended destination
Optional second 33.6 Kbps fax modem
■Allows the simultaneous sending and receiving of fax documents
ITU-I sub-address routing
■Send and receive fax documents into confidential mailboxes

SCAN FEATURES
Standard network scanning
■Surf corporate networks with ease, delivering documents directly into network folders
■High-quality 600 dpi scanning
■Create up to 20 folder shortcut keys for one-touch scan initiation (shared w/FTP shortcuts)
■Broadcast documents to an e-mail address and network folder (archive)
■Windows log-in security parameters
■Supports color scanning
Scan to e-mail
■Intuitive QWERTY keypad allows for customized e-mail transmissions
■File Formats include TIFF, PDF or JPEG
■File name, subject line and text message can be added to each transmission (SPAM prevention)
■Any document stored on the network may be attached to a transmission (simple network browse)
■Supports color scanning
Scan to FTP
■Upload documents to an FTP server for sharing or storage
■Create up to 20 FTP shortcuts for one-touch scan initiation (shared w/folder shortcuts)
■Supports color scanning
Standard local color scanning via USB
■TWAIN compliant
■High-resolution color scanner offers easy digital transfer of hardcopy photos, charts and various office
documents

PRINT FEATURES
Flexible OS support
■Windows 98SE, 2000, Me, NT 4.0, XP
■Windows Server 2003
Standard GDI-based network printing
■High-speed 10/100 BaseT Ethernet connection is the perfect solution for a small to mid-sized
workgroup
■Supports TCP/IP protocols
■RJ-45 network connection
Optional PCL support
■PCL 5e & 6
■Does not require a separate network drop, the standard NIC card can handle both GDI and PCL
commands
■Can be installed by the factory or installed as a field upgrade
Standard local GDI printing via USB
■High-speed USB 2.0 connection
Intuitive print drivers
■Seamless output from popular applications
■Server or client-based installation
■Choose watermarks, paper sources, options, etc.
Duplex print output (MFX-1430D & MFX-2030)
■Up to 5 page-per-minute duplex production

COPIER FEATURES
14 (MFX-1430) and 20 (MFX-2030) page-per-minute print engine
■Print engine produces letter-sized documents at 14 and 20 pages per minute
■600-dpi output insures high-quality digital imaging
Get the job going!
■10 second (MFX-2030) and 12 second (MFX-1430) first-copy-out-times
■23 second warm-up time
Duplex printing (MFX-1430D & MFX-2030)
■Reduce paper consumption and day-to-day operational costs by utilizing duplex print, copy and fax
reception capabilities
■Manual duplex scanning allows for 1:2, 2:2 or 2:1 output
QuadAccessTM technology
■Unique to Muratec, the MFX-1430 and MFX-2030 can simultaneously perform four tasks at once
allowing users to fax, copy and print at the same time without machine slowdown
Card Copy Mode
■Copy both sides of a driver's license, insurance card or other card-size object quickly and easily
■Does not require you to lower the platen cover prior to scanning
■Check-size documents (both personal and business size) may be copied in this mode
Digital copy features
■2-in-1 & 4-in-1 image combination
■Mixed original detection
■Digital zoom (25-400%) and image adjustment
■Electronic sorting
Programmable Macro Keys
■Conveniently program lengthy copy job processes into a single executable command

DEMONSTRATION
ORIGINALS
Apply the enclosed
Demonstration Originals
when conducting a
demo on the MFX-1430
and/or MFX-2030.

COMBINE COPY
The MFX-1430 and MFX-2030
condenses up to 4 original
documents into one document,
reducing much needed storage
space and paper consumption.
Image Combination
Separate Originals
>>>

Copy two single-sided documents
onto one two-sided document.
The Duplex Print option allows
users to reduce hard-copy
storage requirements by printing
single-sided fax, print and copy
jobs into two-sided documents.
Original Front
Original Back
Duplexed Image
DUPLEX COPY (1:2 OR 2:2,
MFX-1430D AND MFX-2030 ONLY)
>>>

(Side 2 of Duplex Copy)

MIXED ORIGINALS
The Mixed Originals feature gives
the user the flexibility to copy both
letter and legal-sized documents.
With the optional second paper
cassette, users simply need to
load the corresponding paper
sizes in the cassettes.
Finished Copies
Mixed Originals Scan Documents Together
Through Document Feeder
>>>
>>>

COMBINE COPY
The MFX-1430 and MFX-2030
condenses up to 4 original
documents into one document,
reducing much needed storage
space and paper consumption.
Image Combination
Separate Originals
>>>

Copy two single-sided documents
onto one two-sided document.
The Duplex Print option allows
users to reduce hard-copy
storage requirements by printing
single-sided fax, print and copy
jobs into two-sided documents.
Original Front
Original Back
Duplexed Image
DUPLEX COPY (1:2 OR 2:2,
MFX-1430D AND MFX-2030 ONLY)
>>>

(Side 2 of Duplex Copy)

MIXED ORIGINALS
The Mixed Originals feature gives
the user the flexibility to copy both
letter and legal-sized documents.
With the optional second paper
cassette, users simply need to
load the corresponding paper
sizes in the cassettes.
Finished Copies
Mixed Originals Scan Documents Together
Through Document Feeder
>>>
>>>

CARD COPY
When in Card Copy mode, users
quickly capture the information
on the front and back of
insurance or identification cards.
This reduces a six-step process
into one easy step, without ever
having to close the top cover.
Original Insurance Card (Front and Back)
Card Copy Image
>>>

MFX-1430/MFX-2030
1
