Muratec MFX-2500 Installation and operation manual

MFX-2500
FIELD ENGINEERING MANUAL
North American version 1.0
(Febrary. 29 2000)
MURATA MACHINERY, LTD
COMMUNICATION EQUIPMENT DIV.

1
Safety Information
Laser Safety
This is a digital machine which prints by means of a laser. There is no possibility of danger from the laser,
provided the machine is operated according to the instructions in this manual.
Since radiation emitted by the laser is completely confined within protective housing, the laser beam
cannot escape from the machine during any phase of user operation.
This machine is certified as a Class 1 product. This means the machine does not produce hazardous laser
radiation.
CAUTION:The use of controls, adjustments or performance of procedures other than those specified
in this manual may result in hazardous radiation exposure. Because of this, Minolta
strongly recommends that you operate your copy machine only as described in this
documentation.
Internal Laser Radiation
Maximum Average Radiation Power: 36.7µW at laser aperture of the print head unit
Wavelength: 770-810nm
This product employs a Class IIIb Laser Diode that emits an invisible laser beam.
The Laser Diode and Scanning Polygon Mirror are incorporated in the print head unit.
The print head unit is NOT A FIELD SERVICE ITEM.
Therefore, the print head unit should not be opened under any circumstances.
Laser Aperture of the Print Head Unit
This figure shows the view inside the Right Side Door with the Imaging Unit removed.
For United States
CDRH regulation
This copier is certified as a Class 1 Laser product under the Radiation Performance Standard according to
the Food, Drug and Cosmetic Act of 1990. Compliance is mandatory for Laser products marketed in the
United States and is reported to the Center for Devices and Radiological Health (CDRH) of the U.S. Food
and Drug Administration of the U.S.
Department of Health and Human Services (DHHS). This means that the device does not produce
hazardous laser radiation.

2
The label shown on next page indicates compliance with the CDRH regulations and must be attached to
laser products marketed in the United States.
CAUTION: Use of controls, adjustments or performance of procedures other than those specified in
this manual may result in hazardous radiation exposure.
This is a semiconductor laser. The maximum power of the laser diode is 5mW and the wavelength is
770-810nm.
For Europe
CAUTION: Use of controls, adjustments or performance of procedures other than those specified in
this manual may result in hazardous radiation exposure.
This is a semiconductor laser. The maximum power of the laser diode is 5mW and the wavelength is
770-810nm.
For Denmark
ADVARSEL
Usynlig laserstråling ved åbning, når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
Klasse 1 laser produkt der opfylder IEC60825 sikkerheds kravene.
For Finland
LUOKAN 1 LASERLAITE
VAROITUS
Laitteen käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle näkymättömälle lasersäteilylle.
VARO
Avattaessa ja suojalukitus ohitettaessa olet alttiina näkymättomälle lasersäteilylle.
Älä katso säteeseen.
For Sweden
KLASS 1 LASER APPARAT
VARNING
Om apparaten används på annat sätt än i denna bruksanvisning specificerats, kan användaren
utsättas för osynlig laserstrålning, som överskrider gränsen för laserklass 1.
VARNING
Osynlig laserstråining när denna del är öppnad och spärren är urkopplad. Betrakta ej stråien.
For Norway
ADVERSEL
Dersom apparatet brukes på annen måte enn spesifisert i denne bruksanvisning, kan brukeren
utsettes för unsynlig laserstrålning, som overskrider grensen for laser klass 1.
Dette en halveder laser. Maksimal effekt till laserdiode er 5mW og bφlgelengde er 770-810nm.

Muratec MFX-1500E General Description
3
Laser Safety Label
A laser safety label is attached to the outside of the machine as shown below.
Laser safety label
ID Label
IC Label
Label inside copy machine
The following laser safety label will be attached inside the copy machine as shown below.
Please read the following for your own protection.
Caution
Opening the cover indicated by the Caution label may expose you to harmful laser radiation which could
cause damage or loss of eyesight. Do not open the cover when the power is on.

4
ALL Areas CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries accordingto the manufacturer’s instructions.
Muratec does not recommend the independent replacement of this battery.
The battery is sold only as a component part of the main control PCB and cannot be purchased
separately from Muratec.
Il y a un danger d'explosion s'il y a un remplacement incorrect de la batterie.
Remplacer uniquement avec une batterie du même type ou d'un type recommandé par le constructeur.
Mettre au rebut les batteries usagées conformement aux instructions du fabricant.
Germany only VORSICHT!
Explosinsgefahr bei unsachgemäßen austausch der batterie.
Ersatz nur durch denselben oder einen vom hersteller empfohlenen ähnlichen typ. Entsorgung
gebrauchter batterien nach angaben des herstellers.
Denmark only ADVARSEL!
Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering
Udskiftning må kun ske med batteri af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
Norway only ADVARSEL
Eksplosjonsfare ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten.
Brukte batterier kasseres i henhold til fabrikantens instruksjoner.
Sweden only VARNING
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren.
Kassera använt batteri enligt fabrikantens instruktion.
Finland only VAROlTUS
Paristo voi räjähtää, los se on virheellisesti asennettu.
Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin.
Hävitä Käytetty paristo valmistajan ohjeiden mukaisesti.
ALL Areas CAUTION
“Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used IC Package according to the manufacturer’s instructions.”
Germany only VORSICHT!
⇒”Austausch nur durch denselben oder einen vom Hersteller empfohlenen,
gleichwertigen typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers.

i
Table of Contents
Section 1 General Description
1.1 Product Description ..............................................................................................................................1-1
1.2 General specifications ..........................................................................................................................1-2
1.3 Scanning specifications........................................................................................................................1-5
1.4 Printer specifications.............................................................................................................................1-6
1.5 Memory specifications..........................................................................................................................1-7
1.6 G3 modem section................................................................................................................................1-8
1.7 V.34 HDX modem section ....................................................................................................................1-8
1.8 Features and Functions........................................................................................................................1-9
1.9 Supply Yields......................................................................................................................................1-13
1.10 Option...............................................................................................................................................1-14
Section2 Machine Composition
2.1 Interconnect Block Diagram (Scanner).................................................................................................2-1
2.2 Interconnect Block Diagram (Printer)....................................................................................................2-5
2.3 Scanning Section..................................................................................................................................2-9
2.4 Recording Section ..............................................................................................................................2-14
Section3 Software adjustment ................................................3-1
3.1 Field Service Program Modes ..............................................................................................................3-1
3.2 Machine Parameter Adjustment ...........................................................................................................3-2
3.3 Memory Switch Adjustment................................................................................................................3-79
3.4 Clear Programmed Data / User Settings............................................................................................3-96
3.5 All RAM Clear .....................................................................................................................................3-97
3.6 Setting Individual Autodialer Attributes...............................................................................................3-97
3.7 Unique Switch Adjustment................................................................................................................3-100
3.8 Print Program Mode List...................................................................................................................3-122
3.9 Test Modes.......................................................................................................................................3-122
3.10 Print Machine Parameters, Memory Switch and Unique Switch Settings.......................................3-125
3.11 Factory Functions...........................................................................................................................3-125
3.12 Line Tests.......................................................................................................................................3-131
3.13 Mirror Carriage Transfer Mode.......................................................................................................3-135
3.14 Consumable order sheet ................................................................................................................3-136
3.15 DRAM Clear....................................................................................................................................3-139
3.16 Clear Life Monitor ...........................................................................................................................3-140
3.17 Set Service Code............................................................................................................................3-140
3.18 Printer Trouble Reset......................................................................................................................3-141
3.19 Clear Optional Data ........................................................................................................................3-141
3.20 JP1, JP2 Battery Backup................................................................................................................3-141
3.21 Update the software........................................................................................................................3-142
Section4 Troubleshooting Procedures...................................4-1
4.1 Troubleshooting Outline........................................................................................................................4-1
4.2 Document Feeder Jam.........................................................................................................................4-2
4.3 Document Feeder Multi-feeding or Skew .............................................................................................4-2
4.4 Mirror Carriage Error.............................................................................................................................4-2
4.5 Transmit Error.......................................................................................................................................4-3
4.6 Transmit Black Lines ............................................................................................................................4-3

ii
4.7 Cannot transmit ....................................................................................................................................4-3
4.8 Receive Errors......................................................................................................................................4-3
4.9 Will not Auto-Answer ............................................................................................................................4-4
4.10 Recording paper misfeed....................................................................................................................4-5
4.11 Error Codes ......................................................................................................................................4-19
4.12 Service Call Error..............................................................................................................................4-22
4.13 Image Failure....................................................................................................................................4-35
Section5 Maintenance & Adjustment......................................5-1
5.1 Maintenance schedule..........................................................................................................................5-2
5.2 Re/Disassemble..................................................................................................................................5-18
5.3 Adjustment..........................................................................................................................................5-81
5.3.1 Printer registration (top)...............................................................................................................5-81
5.3.2 Printer registration (side).............................................................................................................5-82
5.3.3 FBS registration (top) ..................................................................................................................5-83
5.3.4 FBS registration (side).................................................................................................................5-84
5.3.5 ADF registration (top)..................................................................................................................5-85
5.3.6 ADF registration (side) ................................................................................................................5-86
5.3.7 FBS zoom adjustment (Vertical)..................................................................................................5-87
5.3.8 FBS zoom adjustment (Horizontal) .............................................................................................5-88
5.3.9 ADF zoom adjustment (Vertical) .................................................................................................5-89
5.3.10 ADF zoom adjustment (Horizontal) ...........................................................................................5-90
5.3.11 Adjust the image deformation caused by Mirror carriage A and B at the incorrect position......5-91
5.3.12 Adjustment of the position of Mirror carriage A and B...............................................................5-93
5.3.13 Adjustment of height of ADF......................................................................................................5-94
5.3.14 Adjustment of the skew on the ADF..........................................................................................5-95
5.3.15 Adjustment of the platen cover position.....................................................................................5-96
5.3.17 Adjustment of Retard roller pressure.........................................................................................5-97
Section6 Options......................................................................6-1
6.1 Memory Upgrade..................................................................................................................................6-2
6.2 Telephone Handset ..............................................................................................................................6-4
6.2.1 Attaching the optional handset ..........................................................................................................6-5
6.2.2 Adjusting handset ..............................................................................................................................6-5
6.3 Mechanical Page Counter ....................................................................................................................6-7
6.3 Attaching the optional page counter .....................................................................................................6-8
6.4 PAPER FEED UNIT..............................................................................................................................6-9
6.5 Large Capacity Cassette ....................................................................................................................6-25
6.6 2-Bin/Shift Tray Unit............................................................................................................................6-54
6.7 Duplex Unit .........................................................................................................................................6-74
6.8 Second phone line..............................................................................................................................6-88
6.9 RS-232C Interface..............................................................................................................................6-96

1-1
Section 1
General Description
1.1 Product Description
The MFX-2500 is Multi-function product with flat bed scanner and Group 3 and V.34 HDX modem facsimile
machine. Documents are printed on plain paper using dry electrophotographic printing.
3d right1

General Description Muratec MFX-2500
1-2
1.2 General specifications
Item Specifications / Comments
Type Multi-function product with flatbed scanner.
Group 3 and V.34 HDX console type facsimile with high-speed facsimile
transmitter and receiver.
Telephone network PSTN (Public Switched Telephone Network) or equivalent.
Compatibility ITU-T T.4 and T.30
Coding method ITU-T-standard JBIG, MH, MR and MMR, Murata-proprietary MSE.
Communication method •Full-duplex per ITU-T V.34 (only for control channel)
•Half-duplex per ITU-T V.34, V.17, V.29, V.27ter and V.21
Modem •33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800, 14400,
12000, 9600, 7200, 4800 and 2400 bps per ITU-T V.34.
Control signal speed is 1200 or 2400 bps.
•14400, 12000, 9600, 7200, 4800 and 2400 bps with automatic fallback
per ITU-T, V.17, V.29, V.27ter and V21.
Control signal speed is 300 bps.
Dual Access Allows up to four simultaneous operations
Display LCD: 9 lines, 26 characters per line.
Language: English/French/Spanish
Scanning method CCD
Printing method Dry electrophotographic printer
Effective scanning width 214 mm (8.4
″
), 277 mm (10.9
″
) (User selectable)
Printing margin Upper: 4 mm, Lower: 4 mm, Right: 4 mm, Left: 4 mm
ADF (Auto Document Feeder) section
Document size (Width ×Length)
Single sheet
Max: 300 mm(11.8
″
) ×900 mm(35.4
″
) (Tx)
300 mm(11.8
″
) ×450 mm(17.7
″
) (Copy)
Min: 120 mm(4.7
″
) ×100 mm(3.9
″
)
Two or more sheets
Max: 279 mm(11.0
″
) ×432 mm(17.0
″
)
Min: 216 mm(5.8
″
) ×139 mm(4.1
″
)
Document thickness
Single sheet: 30.2g-104.7g/m2
Two or more sheets: 52.3g-104.7g/ m2
Acceptable document size
FBS (Flatbed scanner) section (Width ×Length)
Max: 279 mm(11.0
″
) ×432 mm(17.0
″
) Min: No limit

Muratec MFX-2500 General Description
1-3
Item Specifications / Comments
Acceptable recording paper
size 1st cassette (Multi purpose cassette):
For fax reception: Letter(SEF/LEF), Legal(SEF), Ledger(SEF),
Half-letter(SEF/LEF)
For copying: Letter(SEF/LEF), Legal(SEF), Ledger(SEF),
Half-letter(SEF/LEF), A3(SEF), B4(SEF),
A4(SEF/LEF), B5(SEF/LEF), A5(SEF/LEF),
A6(SEF), F4(SEF), Postcard(SEF), Custom-
sized**, DL(SEF), COM10(SEF),
Monarch(SEF), Executive(SEF/LEF)
2nd/3rd*/4th*/5th* cassette:
For fax transmission: Letter(SEF/LEF), Legal(SEF), Ledger(SEF)
For copying: Letter(SEF/LEF), Legal(SEF), Ledger(SEF),
A3(SEF), B4(SEF), A4(SEF/LEF), F4(SEF)
Large Capacity Cassette*: Letter(LEF)
Bypass tray*: Same paper sizes are available as 1st cassette for
copying.
Acceptable recording paper
type 1st cassette: Plain paper, PasteBoard/Labels, Transparency, Envelope/Postcard
2nd/3rd*/4th*/5th* cassette: Plain paper
Large Capacity Cassette*: Plain paper
Bypass tray*: Same paper types are available as 1st cassette for
copying.
Paper weight: 60-90g/m2
Document Memory 16MB (1,330 pages)
Error Correction Mode
(ECM) Transmit and receive
Operating environment Ambient temperature: 10
°
Cto 35
°
C(50
°
Fto 95
°
F)
Relative humidity: 15 % to 85 % with no condensation
Power requirements 120 VAC ±10 %; 50-60 Hz
Power consumption Standby: TBD W
Memory Transmit:TBD W
Receive: TBD W
Copy: TBD W
Maximum: TBD W
(Simultaneous copying, communicating and scanning)
*: Option
**: Width: 140 mm(5.5
″
) to 432 mm(17.0
″
), Length: 90 mm(3.6
″
) to 297 mm(11.7
″
)

General Description Muratec MFX-2500
1-4
Item Specifications / Comments
Dimensions: 603 (W) ×671 (D) ×751 (H) mm
Weight 67.7 Kg (148.9 lb)
Weight includes: a toner bottle, a drum cartridge, Multi purpose cassette,
2nd cassette
Keypad layout
TBD
Body Color Muratec light gray (91-242)

Muratec MFX-2500 General Description
1-5
1.3 Scanning specifications
Item Specifications / Comments
Scanning method CCD
ADF (Auto Document Feeder) section
Document size (Width ×Length)
Single sheet
Max: 300 mm(11.8
″
) ×900 mm(35.4
″
) (Tx)
300 mm(11.8
″
) ×450 mm(17.7
″
) (Copy)
Min: 120 mm(4.7
″
) ×100 mm(3.9
″
)
Two or more sheets
Max: 279 mm(11.0
″
) ×432 mm(17.0
″
)
Min: 216 mm(5.8
″
) ×139 mm(4.1
″
)
Document thickness
Single sheet: 30.2g-104.7g/m2
Two or more sheets: 52.3g-104.7g/ m2
Acceptable document size
FBS (Flatbed scanner) section (Width ×Length)
Max: 279 mm(11.0
″
) ×432 mm(17.0
″
) Min: No limit
Document feeding direction
(ADF) Face up
ADF section: Yes (Letter(SEF/LEF), Legal(SEF), Ledger(SEF),
Half-letter(SEF/LEF))
Document size auto-
detection FBS section: Yes (Letter(SEF/LEF), Legal(SEF), Ledger(SEF),
Half-letter(SEF/LEF))
Scanning width 214 mm (8.4
″
), 277 mm (10.9
″
) (User selectable)
Scanning resolution Transmission:
Normal: 8 dots/mm ×3.85 lines/mm (203 dpi ×98 lpi)
Fine: 8 dots/mm ×7.7 lines/mm (203 dpi ×196 lpi)
SuperFine: *16 dots/mm ×15.4 lines/mm (406 dpi ×392 lpi)
Grayscale (Memory Tx): 8 dots/mm ×7.7 lines/mm (203 dpi ×196 lpi)
Grayscale (Feeder Tx): *16 dots/mm ×15.4 lines/mm (406 dpi ×392 lpi)
*: In the case that the remote fax has the ability of “16 dots/mm ×15.4 lines/mm”.
If not, the super fine resolution is 8 dots/mm ×15.4 lines/mm, and the
grayscale resolution in feeder transmission is 8 dots/mm ×7.7 lines/mm.
Copy:
Normal: N/A
Fine: N/A
SuperFine: 600 dpi ×600 lpi
Grayscale: 600 dpi ×600 lpi
Other: 400 dpi ×400 lpi (Selectable by user setting.)
Scanning contrast 5 levels (Auto/Manual adjustment)
Grayscale 256 levels
Automatic document feeder
(ADF) capacity Letter: 50 sheets / Legal: 50 sheets
Ledger (11
″
×17
″
): 30 sheets
Document scanning time Transmission:
Normal: 0.8 sec/page
Fine: 0.8 sec/page
Super fine: 1.7 sec/page
Grayscale(Memory Tx): 0.8 sec/page
Grayscale(Feeder Tx): 1.7 sec/page
Copy:
Super fine: 2.6 sec/page
Grayscale: 2.6 sec/page
Other (400 dpi): 1.7 sec/page
(Based on Letter(LEF) blank page)

General Description Muratec MFX-2500
1-6
1.4 Printer specifications
Item Specifications / Comments
Printing resolution Laser diode beam scanning
600 dpi ×600 lpi
Printing method Dry electrophotographic printer
Fusing method Heat roller
Printing margin Upper: 4 mm, Lower: 4 mm, Right: 4 mm, Left: 4 mm
Printing speed 25 ppm (Based on Letter(LEF) paper)
Acceptable recording paper
size 1st cassette (Multi purpose cassette):
For fax reception: Letter(SEF/LEF), Legal(SEF), Ledger(SEF),
Half-letter(SEF/LEF)
For copying: Letter(SEF/LEF), Legal(SEF), Ledger(SEF),
Half-letter(SEF/LEF), A3(SEF), B4(SEF),
A4(SEF/LEF), B5(SEF/LEF), A5(SEF/LEF),
A6(SEF), F4(SEF), Postcard(SEF), Custom-
sized**, DL(SEF), COM10(SEF),
Monarch(SEF), Executive(SEF/LEF)
2nd/3rd*/4th*/5th* cassette:
For fax transmission: Letter(SEF/LEF), Legal(SEF), Ledger(SEF)
For copying: Letter(SEF/LEF), Legal(SEF), Ledger(SEF),
A3(SEF), B4(SEF), A4(SEF/LEF), F4(SEF)
Large Capacity Cassette*: Letter(LEF)
Bypass tray*: Same paper sizes are available as 1st cassette for
copying.
Acceptable recording paper
type 1st cassette: Plain paper, PasteBoard/Labels, Transparency, Envelope/Postcard
2nd/3rd*/4th*/5th* cassette: Plain paper
Large Capacity Cassette*: Plain paper
Bypass tray*: Same paper types are available as 1st cassette for
copying.
Paper weight: 60-90g/m2
Recording paper capacity 1st cassette: 250 sheets
2nd/3rd*/4th*/5th* cassette: 500 sheets
Large Capacity Cassette*: 2,500 sheets
Bypass tray*: 1 sheet
Output paper tray capacity 250 sheets
Optional 2-Bin tray:
Upper: 100 sheets, Lower: 250 sheets
Receive paper feeding
direction Face down
Warm up time Under 60 seconds
*: Option
**: Width: 140 mm(5.5
″
) to 432 mm(17.0
″
), Length: 90 mm(3.6
″
) to 297 mm(11.7
″
)

Muratec MFX-2500 General Description
1-7
1.5 Memory specifications
Item Specifications / Comments
Document memory 16 MB (Standard)
Optional memory upgrade: See the table below.
Document stored capacity 1,330 pages
Document memory backup (Total memory capacity : Backup time)
16 MB: 60 hours 24 MB: 36 hours
40 MB: 12 hours 56 MB: 5 hours
The backup battery requires about 48 hours to reach full charge after
power to the fax unit is restored.
Memory usage indication Shows on the LCD
Option memory upgrade
Built-in Connector
P5A Connector P5B Total memory
8 MB — — 8 MB (8192 KB)
8 MB + 8 MB — 16 MB (16384 KB) ←Standard
8 MB + 8 MB + 8 MB 24 MB (24576 KB)
8 MB + 8 MB + 24 MB 40 MB (40960 KB)
8 MB + 24 MB + 24 MB 56 MB (57644 KB)

General Description Muratec MFX-2500
1-8
1.6 G3 modem section
Transmission mode V.17
Modulation method 128 Pt. TCM 64 Pt. TCM 32 Pt. TCM 16 Pt. TCM
Transmission speed
(bit/s) 14400 12000 9600 7200
Modulation speed
(baud) 2400 2400 2400 2400
Carrier frequency (Hz) 1800
Detection method Synchronism
Automatic equalizer Automatic adaptive equalizer
Transmission mode V.29 V.27ter V.21
Modulation method 16 Pt. QAM 8 Pt. QAM 8 Pt. PhM 4 Pt. PhM FSK
Transmission speed
(bit/s) 9600 7200 4800 2400 300
Modulation speed
(baud) 2400 2400 1600 1200 300
Carrier frequency (Hz) 1700 1800 f (0) = 1850
f (1) = 1650
Detection method Synchronism FS
Automatic equalizer Automatic adaptive equalizer None
1.7 V.34 HDX modem section
Transmission mode V.34
Modulation method TCM
Transmission speed
(bit/s) 33600 31200 28800 26400 24000 21600 19200 16800
Symbol rate (baud) 3429
None 3200
None 3000
None 2800
None 2400
Carrier frequency (Hz) 3429 baud: 1959 high, 1959 low
3200 baud: 1920 high, 1829 low
3000 baud: 2000 high, 1800 low
2800 baud: 1867 high, 1680 low
2400 baud: 1800 high, 1600 low
Detection method Synchronism
Automatic equalizer Automatic adaptive equalizer
Transmission mode V.34
Modulation method TCM
Transmission speed
(bit/s) 14400 12000 9600 7200 4800 2400
Symbol rate (baud) 3429 None
3200 None
3000 None
2800 None
2400
Carrier frequency (Hz) 3429 baud: 1959 high, 1959 low
3200 baud: 1920 high, 1829 low
3000 baud: 2000 high, 1800 low
2800 baud: 1867 high, 1680 low
2400 baud: 1800 high, 1600 low
Detection method Synchronism
Automatic equalizer Automatic adaptive equalizer

Muratec MFX-2500 General Description
1-9
1.8 Features and Functions
1.8.1 Dialer
Item Specifications / Comments
Autodialer 300 total; 78 one-touch, 222 speed dial.
(Up to 40 digits per location; 24 characters per location ID)
Programmable one-touch. 6 total
The programmable one-touch keys simplify complex fax operation.
The following multi-step operations can be programmed.
Fax communication
•Delayed transmission
•Broadcasting
•Regular polling
•Batch transmission
•F-code transmission
•F-code polling
Soft key 4 total
Fax communication
Set the following On/Off operation into the Soft keys.
•Memory transmission on/off (Default setting)
•Transmission confirmation stamp on/off (Default setting)
•Confirmation report on/off (Default setting)
•Hook/Call request (Default setting)
•Cover page on/off
•TTI on/off
Copy
Pressing the soft key, the following copy setting display will appear.
•Combine
•Repeat
•Series copy
•Erasing boarder
•Erasing center
•Binding margin
•Directional magnification
•Positive/negative copy
•Duplex (with optional Duplex unit)
•Booklet (with optional Duplex unit)
Macro key 6 total
The macro keys simplify multiple fax or copy operations.
Up to 60 steps can be programmed in one macro key.
Up to 130 characters can be entered in the title of the macro key.
Telephone index Select autodialer entries in LCD by Location ID name.
Type of dialing Tone or pulse (10 pps)
Dialing pause time 2-10 seconds. (Initial setting: 2 seconds)
Redial Auto redial in fax mode, programmable for 2 to 15 attempts (default: 2) at
1 to 5 minutes intervals (default: 1); manual last-number redial.
PIN access Available
On-hook dialing Available
Dialing in the event of a
power failure
Works only if the handset is attached.
The fax can receive a telephone call, but it cannot send or receive a fax
message.

General Description Muratec MFX-2500
1-10
1.8.2 Fax Transmitting
Item Specifications / Comments
Transmit Terminal Identifier
(TTI)
Alphanumeric or symbol, up to 22 characters.
Subscriber ID: Numeric, up to 20 characters
3 patterns of TTI can be registered.
Memory transmission Available.
Feeder transmission Available.
Quick memory transmission Available.
Rotate transmission Available. (Letter only)
Delayed transmission Programmable up to 31 days in advance.
Broadcasting Up to 330 locations.(78 one-touch, 222 speed dial and 30 normally dial).
Relay broadcast / Relay
broadcast initiation
(ITU-T sub-address
compatible)
Specify up to 300 numbers for remote “hub” unit using a one-touch key, a
speed-dial number or a call group number.
When receiving a document via ITU-T sub-addressing from another
machine to F-Code relay box, your fax machine will relay it to other
machine you set up on your relay box.
Also, you can send (relay broadcast initiation) the document to hub
machine’s F-Code box with ITU-T sub-address and you get the hub
machine relayed it to other machine.
Group communication Allows multiple broadcasting or polling locations to be placed in up to 32
call groups. Up to 300 locations can be placed in a group.
SecureMail transmission
(ITU-T sub-address
compatible))
ITU-T sub-address: Up to 20 characters.
ITU-T password: Up to 20 characters.
Delayed commands Store up to 100 delayed commands.
Security transmission Compares the last 4 numbers of the dialed fax number to the last 4 digits
of the subscriber ID.
Batch transmission 5 boxes with a location ID of 24 characters. 40 files per box.
Programmable up to 24 hours per box.
Numbering pages Just before sending a fax, you can set your fax machine to number each
page in order. This will help the recipient keep track of all the pages.
Cover page Cover page shows date and time, sender’s name and fax number, and a
40-character user-programmable message.
Department code For tracking transmissions by department.
Hold up to 100 department codes.
Call request During sending or receiving, a voice conversation can be initiated on the
same call after each page is printed.
(Works only if the optional handset is attached.)
Note: Not available at V.34 communication.

Muratec MFX-2500 General Description
1-11
1.8.3 Fax Receiving
Item Specifications / Comments
Receive mode Tel ready, Fax ready, Fax/Tel ready, Tel/Fax ready and Ans/Fax ready
mode; user selectable.
Receive reduction rate
Auto: Automatically reduces printouts from 100 % to 25 %.
Reduction margin: 0-85 mm (Initial setting: 40 mm)
Fixed reduction rate: Select the fixed reduction rates from 100%, 97%,
91%, 81% or 75%.
Rotate reception Available.
Half-page reception Available.
(This feature tells the machine to combine two of half-page receptions onto
a single sheet.)
SecureMail reception
(ITU-T sub-address
compatible)
Up to 50 mailboxes for receiving, 4 digits passcode.
Holds a document up to 31 days (or no limit).
ITU-T sub-address: Up to 20 characters.
ITU-T password: Up to 20 characters.
Block junk fax Ability to reject “junk fax” receptions: user selectable three options.
Specify up to 50 numbers in the blocked numbers list.
Closed network Proprietary network option.
Out of paper reception Receives up to 250 communications to memory if recording paper or toner
is empty.
Security reception You can tell the machine to keep all received faxes in memory (but not
print them) after a certain time; then, later, you instruct it to go ahead and
print out the saved faxes.
Distinctive Ring Detection Ability to answer on specific ring patterns. User selectable
Number of rings Select 1 to 10 rings. (Initial setting: 2 rings.)
Remote reception upon
second phone connection
Fax is activated upon termination of a call that is answered by a telephone
connected to second phone jack.
1.8.4 Polling
Item Specifications / Comments
Regular polling Retrieves a document from the remote fax machine.
Delayed polling Programmable up to 31 days in advance.
Continuous polling Retrieves continuously a document from any remote fax machine for the
designed time.
Database polling
(ITU-T sub-address
compatible)
Retrieves a document stored in a memory box in the remote fax machine.
You must enter a ITU-T sub-address and password to retrieve a document
from any remote fax’s memory box.
Polled transmission A remote fax machine retrieves a document stored in your fax machine.

General Description Muratec MFX-2500
1-12
1.8.5 Copy
Item Specifications / Comments
FCOT (First Copy Out Time) TBD
Multiple copies Up to 99
Copy reduction and
enlargement rate
Manual: Reduces/enlarges copies by the 1 % ratio from 400 % to 25 %.
Fixed: Select the fixed rates from 154, 129, 121, 77, 64, 50 %
Directional magnification Reduces/enlarges copies at different ratios horizontally and vertically.
From 25% to 400%
From 0.1
″
to 50.0
″
Copy protect Available.
Copy reservation Available, up to 10 jobs.
Interrupt copy Available.
Rotate copy Available.
Shift sorting Available (with optional shift tray)
Editing the copy image Available the following copy image editing.
•Binding margin: 0 mm to 30 mm (0
″
to 1.0
″
) Default: 0 mm (0
″
)
•Erasing center: 1 mm to 50 mm (0.1
″
to 2.0
″
) Default: 1 mm (0.1
″
)
•Erasing boarder: 4 mm to 50 mm (0.2
″
to 2.0
″
) Default: 4 mm (0.2
″
)
•Series copy
•Combine: 2 in 1, 4 in 1, 8 in 1
•Repeat: 2, 4, 8 repeats
•Separate line (for Combine and Repeat): 0.1 mm to 0.9 mm
(0.01
″
to 0.05
″
)
Default: 0.3 mm (0.01
″
)
•Booklet copy
•Positive/negative copy
•Duplex copy: Available with optional duplex unit.
Single-sided Æ two-sided,
Bound documents(Book) Æ two-sided
1.8.6 Other features
Item Specifications / Comments
Silent operation Available
Operation protect Not Available
Second telephone jack Available
Daylight saving Available
Distinctive Ring Detection Available
Transmission confirmation
stamp
If you set, it will automatically place a small stamp mark on the front of
each original document that it successfully scans.

Muratec MFX-2500 General Description
1-13
1.8.7 Reports
Report Description
One-touch dial list Prints numbers stored in the one-touch keys.
Speed dial list Prints phone numbers stored in speed dial locations.
Programmable one-touch
list
Prints numbers stored in programmable one-touch keys.
Group number list Prints groups stored in the autodialer.
User settings list Prints current machine settings as programmed by the user.
Command list Prints the delayed commands.
Confirmation report Transmit Confirmation Report (TCR) or Receive Confirmation Report
(RCR); User selectable on/off.
Activity journal Prints a cumulative total of the last about 100 transmissions and/or
receptions; user selectable as manual or automatic.
Cover page Transmit cover page showing date, receiver’s and sender’s names, and a
40-character user-programmable message.
Batch transmission box list Batch transmission boxes stored remote fax number and transmit starting
time.
Batch transmission file list Print the files number list of documents stored in the batch transmission
box.
Department time list Print the total communication time and quantity of pages printed for each
department code.
F-code box list List of F-code boxes stored in fax machine.
F-code box file list Print the box and files number list of documents stored in the F-code box.
F-code reception message Notifies of F-code box receptions.
Blocked numbers list List of the blocked number.
Function list Prints a program mode list showing user programming tree.
Power failure report Prints if any documents in memory were erased due to power failure.
Check message Prints if communication error occurs; accompanied by audible alarm.
Machine setting list Prints current machine settings as programmed by user.
Fax setting list Prints current fax settings as programmed by user.
Copy setting list Prints current copy settings as programmed by user.
Macros list Prints a list of Macro titles.
Fax Forward list Print the Fax Forward patterns.
1.9 Supply Yields
Item Specifications / Comments
Toner bottle 11,000 pages (All yields based on letter-sized sheets, 6 % document
coverage and three-page interval printing.)
Drum cartridge 67,000 pages
Image transfer roller 150,000 pages
Document separator roller 100,000 pages
Retard roller 100,000 pages
Paper pick up roller 120,000 pages
Paper dust remover 120,000 pages
Fuser unit 300,000 pages
Ozone filter 100,000 pages
Exposure lamp 1,000 hours (continuous lighting)
Stamp 3,000 times
