Murphy Diagnostic Display PV10 User manual

0810305
10-21-08
Section 78
PowerView™- Model PV10 – Diagnostic Display
Features
•Display supports electronically controlled engines and
equipment applications that use SAE J1939 Controller Area
Networks.
•Displays Active and Stored diagnostic trouble codes for
diagnosing equipment malfunctions.
•Displays Engine Hours, SPN, FMI, and OC information on a
graphic display.
•Provides enhanced visual alarm indication using Ultra-bright
ALARM or SHUTDOWN LEDs (amber and red).
•Simple installation and connections to the system bus.
•Rugged design for demanding applications includes backlit
display and is sunlight viewable.
Product Description
The PV10 Diagnostic display is a CAN device that receives data from a
controller or ECU and then displays Active and Stored Fault messages and
Engine Hours.
The default mode provides hourmeter data from the ECU for cumulative
engine hours.
The PV10 is equipped with two buttons to quickly select between Active or
Stored Faults, a graphic display, two LED to indicate the Active fault's Alarm
or Shutdown status in a sealed enclosure that matches the PowerView line
of gages.
Fault Messages
Fault messages are formatted to display SPN (Suspect Parameter Number), FMI (Failure Mode Indicator) and OC
(Occurrence Count) codes that conform to the SAEJ1939 protocol.
Bezel Styles
AB
A-20 Style A A-20 Style BB Low Profile SAE Style DB Low Curved Style

Warranty - A limited warranty on materials and workmanship is given with this FW Murphy product. A copy of the warranty
may be viewed or printed by going to www.fwmurphy.com/support/warranty.htm
In order to consistently bring you the highest quality, full featured products, we reserve the right to change our specifications and designs at any time.
MURPHY, the Murphy logo, MurphyLink
™ and PowerView ™ are registered and/or common law trademarks of Murphy Industries, Inc. This document,
including textual matter and illustrations, is copyright protected by Murphy Industries, Inc., with all rights reserved. (c) 2008 Murphy Industries, Inc.
Product Dimensions
Specifications
Operating Voltage
6.0 VDC minimum to 36 VDC maximum
Power Supply Operating Current
460mA max @ 12VDC
810mA max @ 24VDC
Reversed Polarity: Withstands reversed battery
terminal polarity.
Environmental
Operating Temperature: -40°C to 70°C
(-40°F to 158°F)
Storage Temperature: -55°C to 85°C
(-67°F to 185°F)
Sealing:IP68
CAN Bus: SAE J1939 compliant
Connectors
4-pin AMP ”Mini-universal Mate-N-Lok connector”
AMP Plug: P/N 172338-1
AMP Socket: P/N 171639-1 (4 each, assumes 18
gauge wire. See AMP Plug specification to match
socket and wire size.)
Maximum Panel Thickness: 3/8 inch (9.6 mm)
Shipping Weights (all models): 0.2 lb. (0.1 kg.)
Shipping Dimensions (all models): 3-7/8 x 2-3/4 x 2-3/4
in. (98.4 x 69.85 x 69.85 mm)
How to Order
Accessories
Wiring Harness, PVW-PDA-12 PowerView 10 CAN and Power (P/N 78-00-0613)
Wiring Harness, PA-30 PowerView 10 Loose Wiring (P/N 78-00-0614)
Terminating Resistor, PVMJR (PN 78-00-0480)
