Murphy TAH-97026B User manual

■
3000 and 4000 RPM –0 to 100,000 hours
■
Sensing from Magnetic Sensor, Battery
Charging Alternator or Ignition Signal
■
High Visibility Analog Readout
■
Air Core Movement
■
Easy Calibration
■
Through Dial Lighting
■
Powered by 12 VDC Battery
Available Converter for 24 to 12 VDC
Description
The AT Series tachometers are rugged, transis-
torized instruments with solid-state circuitry for
indication of engine RPM. They are equipped
with a bracket for mounting into a standard 3-
3/8 in. (86 mm) dash mounting hole. A full 270°
sweep of the pointer gives an accurate indication
on a large easy–to–read scale and the dial can be
illuminated for night reading. The ATH Series
models are also equipped with hourmeter to
record the elapsed running time of an engine.
Models available for Alternator, Magnetic
Sensor or Ignition signal
These instruments are designed to function from
pulses generated by an alternator with 4, 8, 12,
14, or 16 poles on the rotor. The pulses can also
be obtained from the ring gear of an engine by
means of an electromagnetic sensor (magnetic
pickup). Murphy’s magnetic sensor driven mod-
els are designed to function with flywheels hav-
ing anywhere from 70 to 225 teeth.
Ignition signal model available for 4, 6 or 8
cylinder, spark-ignated engines.
All models are for negative ground, positive
ground or isolated electrical systems and are
protected against reverse polarity hookup.
All models are powered by 12 VDC and are
reverse polarity protected.
Series Models
ATS Series Magnetic Sensor Signal Tach
70 - 225 pulses
*
12 VDC, 2733 Hz to 13.62 kHz
@ 3000 RPM
ATHS Series Magnetic Sensor Signal
Tachometer/Hourmeter
70-225 pulses
*
12 VDC, 2733 Hz to 13.62 kHz @
3000 RPM
ATA Series Alternator Signal Tachometer
3-27 pulses
*
12 VDC, 137 to 1330 Hz @ 3000 RPM
ATHA Series Alternator Signal
Tachometer/Hourmeter
3-27 pulses
*
12 VDC, 137 to 1330 Hz @ 3000 RPM
or 193 to 1815 Hz @ 4000 RPM
ATHI Series Ignition Signal
Tachometer/Hourmeter
4, 6 or 8 cylinder engines @ 4000 RPM
Applications
These tachometers are specially designed for use
on truck, marine, industrial, or stationary engines.
Specifications
Power Input: 12 VDC (11.5 to 16 V)
[0.84 to 1.44W].
Back Light: 3 to 4.7 W.
RPM Input Signal Voltage: 1.5 Vrms min. from a
magnetic pickup or alternator (minimum 3-pole).
Accuracy: Tachometer: ± 2% full scale.
Hourmeter: ± 0.01% hours, ± 1 count.
Temperature Range: -5 to 185°F (-20 to +85°C).
Dial: 270° sweep (white numerals over black)
Bezel: 304 Stainless Steel.
Scales: 0 - 3000 RPM or 0 - 4000 RPM†.
Case Material: Plastic.
Hourmeter Range: Measures elapsed time:
100,000 hours in 0.1 increments (tenths).
Shipping Weight: 0.89 lb. (403 g).
Shipping Dimensions: 5-1/2 x 5-1/2 x 5-1/2 in.
(140 x 140 x 140 mm).
AT and ATH Series
Bezel Styles
bright stainless black stainless
bright SAE black SAE
**
TAH-97026B
Revised 05-05
Catalog Section 20
(00-02-0260)
Tachometers and Tach/Hourmeters
TAH-97026B page 1 of 2
* To determine pulses per engine revolution, work the
formulas on the back page and use the pulses per revolu-
tion number to determine if the tachometer can be used
for your application.
** Products covered by this bulletin comply with EMC
Council directive 89/336/EEC regarding electromagnetic
compatibility except as noted.
† Range available only for ATHA-40-12-A; ATHI-40-12-A

How to Determine if the Tachometer or Tach/
Hourmeter is Suitable for Your Equipment
A. Ignition sensing Tach/hourmeters can be used on 4, 6 or 8 cylinder, spark
ignited engines.
B. Magnetic pick up sensing Tachometer or Tach/hourmeters will operate from
70 to 225 tooth flywheels.
C. Alternator sensing Tachometer or Tach/hourmeters will operate from 3 to 27
pulses per engine revolution. To obtain the number of pulses per engine revo-
lution, work the following formulas:
1. Determine the number of poles on your alternator. Look for the
designation/type in the manufacturer's manual or remove the
pulley and fan to count the number of poles on the rotor.
2. The ALTERNATOR TACHOMETER CHART lists common
alternators and their minimum and maximum pulley ratios.
Determine pulley ratio with the following formula:
PULLEY RATIO= CRANK SHAFT PULLEY DIAMETER
ALTERNATOR PULLEY DIAMETER
3. Check that Pulley Ratio falls within the range shown on the
PULLEY RATIOS CHART for a particular alternator. If ratio falls
in the shaded area, the tachometer can be calibrated for the application.
4. To determine the pulses per engine revolution:
NUMBER OF POLES X PULLEY RATIO = PULSES PER ENGINE REVOLUTION
2
ALTERNATOR TACHOMETER CHART
Manufacturer Designation/Type Poles Minimum Maximum
*
pulley-ratio pulley-ratio
*Although the tach may be calibrated for higher input frequencies in some cases, as shown on the
Pulley Ratio chart, pulley ratios in excess of 5.0 are NOT recommended nor are they normally used.
Prestolite
Load Handler
Load Handler
Leece Neville
Bosch
C.E. Neihoff
Delco Remy
Delco Remy
Delco Remy
Delco Remy
Delco Remy
Hitachi
Hitachi
Lucas
Mando
Motorcraft
Nippondenso
Powerline
Powerline
Valeo
All
88A, 8LHA, 89C, 8LHC
All 5 inch models
All
G and K Series
All
30DN
15SI, 21SI, 40DN, 40SI
10DN, 10SI, 12SI
20DN, 25SI, 27SI
29SI, 30SI
LT125, LT130, LT133
LT150
All
All
All
All
Series 23
Series 24, 25, 26
All
8
16
12
12
12
12
4
12
14
16
16
8
12
12
12
12
12
14
12
12
0.75
0.375
0.5
0.5
0.5
0.5
1.5
0.5
0.42
0.375
0.375
0.75
0.5
0.5
0.5
0.5
0.5
0.42
0.5
0.5
6.5
3.25
4.3
4.3
4.3
4.3
13
4.3
3.7
3.25
3.25
6.5
4.3
4.3
4.3
4.3
4.3
3.7
4.3
4.3
How to Order
Order the Tachometer or Tachometer/Hourmeter by model number.
Magnetic Sensor Tachometer 3000 RPM; 70 - 225 pulses 12 VDC
Model # Designation
ATS-30-12 Bright Stainless Steel Bezel
ATS-30-12-A Black Stainless Steel Bezel
ATS-30-12-B SAE Bright Stainless Steel Bezel
ATS-30-12-C SAE Black Stainless Steel Bezel
Magnetic Sensor Tach/Hourmeter 3000 RPM; 70 - 225 pulses 12 VDC
ATHS-30-12 Bright Stainless Steel Bezel
ATHS-30-12-A Black Stainless Steel Bezel
ATHS-30-12-B SAE Bright Stainless Steel Bezel
ATHS-30-12-C SAE Black Stainless Steel Bezel
Alternator Signal Tachometer 3000 RPM; 3 - 27 pulses 12 VDC
ATA-30-12 Bright Stainless Steel Bezel
ATA-30-12-A Black Stainless Steel Bezel
ATA-30-12-B SAE Bright Stainless Steel Bezel
ATA-30-12-C SAE Black Stainless Steel Bezel
Alternator Signal Tach/Hourmeter 4000 RPM; 3 - 27 pulses 12 VDC
ATHA-40-12 Bright Stainless Steel Bezel
ATHA-40-12-A Black Stainless Steel Bezel
ATHA-40-12-B SAE Bright Stainless Steel Bezel
ATHA-40-12-C SAE Black Stainless Steel Bezel
ATHA-40-12-A Black Stainless Steel Bezel
Ignition Signal Tach/Hourmeter 4000 RPM; 4, 6 or 8 cylinder 12 VDC
ATHI-40-12-A Black Stainless Steel Bezel
Optional Power Input Convertor
ATVC12/24 24 VDC to 12 VDC Converter
3-53/64 in.
(97 mm)
3-5/8 in.
(92 mm)
21/32 in.
(17 mm)
3-3/8 in. min.
(86 mm)
Mounting Hole
RPM
x 100
HOURS 1
10
Dimensions
0.5 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
4
8
12
14
16
PULLEY RATIOS CHART
NO. OF POLES
1.5 —– 13
0.75 —– 6.5
0.5 —– 4.3
0.42 —– 3.7
0.375 —– 3.25
RATIO Minimum Maximum
TAH-97026B page 2 of 2
