Muskoka Muskoka MM289CW User manual

Assembly Instructions
Instructions d'assemblage
Instrucciones de ensamblado
Model / Modèle / Modelo: MM289CW
ELECTRIC FIREPLACE
MANTEL
with convertible back
for corner option
MANTEAU DU FOYER
ÉLECTRIQUE
avec dos convertible pour
option de coin
REPISA DEL HOGAR
ELÉCTRICO
con parte posterior
convertible para la
opción de esquina

TIPS FOR ASSEMBLY OF YOUR
NEW MANTEL
• Before you begin assembly, locate the instructions and hardware. Take out all the parts and
compare them to the diagrams below. Be sure you have all the parts and can identify them.
• A helping hand is always good: assemble your mantel with an adult assistant if possible. Some
pieces are heavy and will need to be held by a helper. Assembly time will be approximately
30-60 minutes.
• Locate a good Phillips-head screwdriver. You may also use an electric screwdriver but be careful not
to strip the head of the screw by over tightening them.
TOP 1PC
289CW.10
BASE 1PC
289CW.01
CENTRAL PANEL 1PC
289CW.06
ANTI-TIP DEVICE 2 SETS
CORNER ATTACHMENT 1PC
289CW.11
LEFT FRONT
PANEL 1PC
289CW.04
RIGHT SIDE
PANEL 1PC
289CW.03
LOWER
CENTRAL PANEL 1PC
289CW.07
FIREBOX SUPPORT 1PC
289CW.08
FIREBOX SHELF 1PC
289CW.09
LEFT SIDE
PANEL 1PC
289CW.02
RIGHT FRONT
PANEL 1PC
289CW.05

GET READY TO START
Before assembly, use scissors to unwrap the parts from the packaging. DO NOT use a box cutter or
exacto-knife as you may cut into the mantel pieces inside the box and damage the finish. Check for the
hardware bag which is red and located inside the packaging taped to the top box. Be sure you DO
NOT discard any pieces.
For the easiest assembly, use a power Phillips-head screwdriver. DO NOT over tighten the screws.
Step 1
Locate the hearth and place it on the floor. Do not put it up against
the wall at this point in the assembly as you need to get in behind
the mantel to insert several screws.
Step 2
Locate the left side panel and the left front panel. Facing the
front of the hearth, take the left side panel, positioning it so the
holes in the blocks on the bottom line up with the screw holes
in the hearth. Locate the left front panel and position it next to
the left side panel, lining up the holes in the blocks with the
screw holes in the hearth.
Step 3
Repeat Step 2, but with the right side panel and the right
front panel.
Step 4
Locate the lower central panel and the firebox support.
Attach the lower panel by placing the wide white side to the front
and inserting the 4 screws. Be careful as you tighten the screws to
ensure that you DO NOT come through the front of the panel. Attach
the firebox support behind the first panel in the same manner, lining
up the 2 holes (one on each side) with the holes in the legs. Insert
and tighten the 2 screws. Be careful as you tighten the screws to
ensure that you DO NOT come through the side of the mantel.
Place the firebox shelf onto the firebox supports. Attach the shelf to
the supports by inserting and tightening the 4 screws.

Step 5
Locate the header piece that will be attached to the left and
right legs and will sit above the firebox. Position the header
with the finished side facing the front of the mantel. Insert
and tighten the 4 screws which will hold the header in place.
Step 6
Get your helper and locate the top of your mantel. This top
is very heavy. It will take 2 people to lift and position it in
place. Ensure the top goes over the positioning guide
located on the header. The top must go over this guide to
be positioned correctly. Once the top is in place insert and
tighten the 4 screws which hold the top in place.
Step 7
If you are using this mantel in a corner application, locate the triangular piece of wood which attaches
to the mantel to create the corner unit. You must attach this piece for all corner applications. Simply take
the triangle and slide the brackets with the holes onto the pins which are already attached to the
mantel. Once the triangle is attached push it up so it is level with the mantel and lock it into place. To
lock it into place simply turn the horizontal wooden blocks attached to the underside of the mantel into
a vertical position to support the weight of the triangle.

Step 8
Take your electric firebox out of its packaging and position it
between the 2 legs of the mantel. Once you are close to the wall,
plug the firebox into the nearest outlet.
The firebox comes with 3 metal brackets and 20 black screws. These
metal brackets must be attached to both the sides of the firebox and
the mantel to ensure that your firebox does not move around as you
use it. Two of the brackets have 2 large holes on one side. These
large holes line up with 2 screws on the side of the firebox. The other
screws provided must be inserted into the holes at the other end of
the bracket and into the firebox. The other side of each bracket
attaches to the mantel.
The third bracket has no holes on one side. That side should go up
against the firebox but should not be attached as the heater sits right
underneath the bracket. Only the mantel side should be attached.
If you have any questions about the firebox please reference the
installation instructions that come with the unit. Please
reference the Quick Tips section of that instruction manual.
Step 9
You are now ready to position your mantel against the wall.
This step requires 2 people to move the unit.
Anti-tipping device
At this point you must attach the anti-tipping device to your mantel
and your wall. This device is a safety feature that will prevent your
mantel from tipping over if a weight is applied which can unbalance
the unit (like a child climbing onto it).

WARRANTY
Greenway Home Products is pleased to offer in home warranty repairs.
DO NOT RETURN THIS PRODUCT TO THE STORE:
Please contact Customer Service at: 1-866-253-0447
web: www.greenwayhp.com
email: suppor[email protected]
Canada: 400 Southgate Dr., Guelph, Ontario, Canada, N1G 4P5
USA: 6507 Fairfield Dr., Northwood,Ohio, USA, 43619
Limited Warranty Definitions:
Greenway Home Products:
(Greenway) Manufacturer.
Mantel: Mantel manufactured by Greenway Home Products.
Purchaser: Purchaser of the Mantel
Distributor: Facility authorized to sell Greenway Home Products.
Warranty Card Greenway Home Products Limited Warranty Registration
Card identifying the Purchaser and product model.
Greenway Limited Warranty:
Greenway warrants to the Purchaser that the Mantel is free from defects in material and
workmanship, under normal use and service, for 1 year (1 year limited parts) from the date
of purchase.
All warranty repairs must be preauthorized by Greenway Home Products. Greenway will,
at its option, replace or repair free of charge any defective part, which the Purchaser shall
notify their Distributor or Greenway Home Products within the warranty period. The
obligation of Greenway Home Products under this warranty, is expressly limited to such
replacement or repairs.
The provisions of this limited warranty shall not apply to the following:
1. Accidents.
2. Unauthorized repairs or alterations.
3. Normal maintenance.
4. Changes made to other units manufactured after this mantel was manufactured.
5. Incidental damages caused by failure of the mantel such as inconvenience or loss of use.
6. Improper installation.
The provisions of this limited warranty shall not apply to deterioration due to wear and
exposure beyond the following limitations:
1. For 180 days from the date of purchase for exterior finished surfaces.

Due to the properties of natural wood, Greenway Home Products makes no warranty against
mineraling of wood components.
Greenway Limited Warranty is void unless the following conditions are adhered to:
1. Warranty registration must be completed and returned to Greenway Home Products.
2. All warranty repairs must be preauthorized by Greenway repair facility.
3. Greenway reserves the right to inspect defective parts that have been replaced under
warranty. Dealer is expected to hold defective parts for 60 days.
4. Only parts and accessories and other material, available through Greenway Home
Products are to be used in the performance of warranty service.
5. Purchasers are responsible for presenting/notifying their Distributor as soon a problem
exists. The warranty repairs should be completed in a reasonable amount of time from
the date of authorization. Not to exceed 30 days past notification.
This limited warranty is expressly in lieu of any other expressed or implied warranty,
including any implied warranty or merchantability or fitness for a particular purpose and of
any obligations or liabilities on Greenway Home Products which neither assumes nor
authorizes any other person to assume for it any other liability in connection with the Mantel
manufactured by it.
The warranty is null and void if used in commercial or industrial applications.
