Mutable Instruments Ears User manual

Ears requires a -12V / +12V power supply (2x5 pin connector). The ribbon cable connector must be
aligned so that the red stripe of the ribbon cable (-12V) is on the same side of the module’s power header
as the “Red stripe” marking on the board. The module draws 5mA from both the +12V and the -12V supply
rails.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
This device meets the requirements of the following standards: EN55032, EN55103-2,
EN61000-3-2, EN61000-3-3, EN62311.
A. Gain control, 0 to +40dB. This large gain ranges covers everything - from the amplification of line-level
instruments, to the magnification of tiny sonic details captured by external contact microphones.
B. Contact microphone. Scratch, tap, rub, brush… to your heart’s delight.
Mutable Instruments | Ears
1 of 3

1. Hi-Z Audio input. Amplifies an external source. Patching a cable here disconnects the contact
microphone.
2. Audio output. The red LED indicates clipping.
3. Envelope CV output. The white LED indicates the envelope CV level.
4. Gate output. Emits +8V when the envelope exceeds a threshold. The activity of this output is indicated
by the orange LED.
The jumpers at the back of the module adjust the response of the envelope follower and gate detector.
The last setting, corresponding to the longest time or higher voltge, is obtained by removing the jumper.
This product is covered by Mutable Instruments’ warranty, for one year following the date of manufacture.
This warranty covers any defect in the manufacturing of this product. This warranty does not cover any
damage or malfunction caused by incorrect use - such as, but not limited to, power cables connected
backwards, excessive voltage levels, or exposure to extreme temperature or moisture levels.
The warranty covers replacement or repair, as decided by Mutable Instruments. Please contact our
customer service ([e-mail]) for a return authorization before sending the
module. The cost of sending a module back for servicing is paid for by the customer.
Mutable Instruments encourages modding and hacking, but we will not service modified units or provide
any assistance in the realization of mods.
