Mutable Instruments Blinds User manual

Blinds requires a -12V / +12V power supply (2x5 pin connector). The red stripe of the ribbon cable (-12V
side) must be oriented on the same side as the “Red stripe” marking on the board. The module draws
70mA from the -12V rail and 70mA from the +12V rail.
Current consumption can reach 90mA on either rail depending on the color and brightness of the LEDs.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
This device meets the requirements of the following standards: EN55032, EN55103-2,
EN61000-3-2, EN61000-3-3, EN62311.
Blinds is a 4-channel voltage-controlled signal polarizer. Each channel consists of a polarizer circuit, also
known as a four-quadrant multiplier. This circuit acts like a VCA, except that a negative control voltage will
cause the output signal to be inverted, instead of being silenced. Blinds’ outputs are daisy-chained,
allowing adjacent groups of 2, 3, or all 4 channels, to be mixed together.
Mutable Instruments | Blinds
1 of 4

A. Channel polarity and gain. At 12 o’clock, the channel is muted. Turn clockwise to amplify, turn
counter-clock- wise to amplify and invert.
B. Modulation attenuverter. Adjusts the amount and polarity of modulation from the modulation input (2),
i.e. how much, and in which direction, the channel polarity and gain will wiggle around the central value
set by A.
1. Signal input. Blinds’ inputs are DC-coupled and accept both audio and CV signals. This input receives
+5V when no patch cable is inserted.
2. Modulation input. This input is also DC-coupled. When audio-rate signals are present on both the
signal and modulation input, Blinds works as a pure ring-modulator.
3. Signal output. When no patch cable is plugged into an output, the signal from this channel is routed to
the next channel. For example, when no patch cable is patched into output 1, output 2 will contain the sum
of channel 2 and channel 1. If nothing is patched into outputs 1, 2 and 3, then output 4 will contain the
sum of all four channels.
4. Gain and polarity indicator. The color corresponds to the polarity (green = positive, red = negative),
the bright- ness to the gain.
5. Output level and polarity indicator.
The following equation describes the operation performed by each channel:
Where Vout is the output voltage, Vin the input voltage, Vmod the control voltage, BigKnob and
SmallKnob the position of the big and small knobs, represented as a number between -1 and 1 (0 being
the 12 o’clock position).
Because Vin is normalized to +5V, when nothing is patched into Vin, this equation becomes:
Mutable Instruments | Blinds
2 of 4

In this case, the big knob controls an offset between -5V and +5V, and the small knob a gain between -1
and +1. In other word, each channel of Blinds can be used as an attenuverter with offset control circuit.
A ring modulator is an imperfect four-quadrant multiplier realized with a diode ring circuit. Because it is
based on a bipolar VCA circuit, Blinds realizes a purer sounding version of ring-modulation, very close to
the mathematical ideal of signal multiplication. Don’t worry though, the familiar sounds of bells, american
metaphysical circuses and Daleks are still there!
When Blinds is used as a ring modulator, with audio rate signals going in both inputs, the big knob controls
a very interesting parameter: carrier rejection (how much of the unmodulated signal will “bleed” on top of
the ring-modulated signal).
Because of mechanical backlash in the construction of the potentiometer, the vertical mark on the panel
might not be perfectly aligned with the white pointer of the knob when a channel has zero offset. In
addition, some envelope generators or LFO might have a residual “bleed” voltage - they sometimes sit a
few mV below 0 after their release. Trust your ears and the LEDs when zeroing a channel!
This product is covered by Mutable Instruments’ warranty, for one year following the date of manufacture.
This warranty covers any defect in the manufacturing of this product. This warranty does not cover any
damage or malfunction caused by incorrect use - such as, but not limited to, power cables connected
backwards, excessive voltage levels, or exposure to extreme temperature or moisture levels.
The warranty covers replacement or repair, as decided by Mutable Instruments. Please contact our
customer service ([e-mail]) for a return authorization before sending the
module. The cost of sending a module back for servicing is paid for by the customer.
Mutable Instruments encourages modding and hacking, but we will not service modified units or provide
any assistance in the realization of mods.
