MuxLab 500114 User manual

Specifications
Environment
PoE CCTV IP
Devices
PoE CCTV IP cameras with a 10/100Mb/s Ethernet port, using up to
15.4 Watts.
Transmission
Transparent to the user
Standard supported
Ethernet side:
IEEE 802.3 10BaseT,
IEEE 802.3U 100Base-TX
IEEE 802.3af compatible PoE (on camera side only)
PoE Power
Class 3
Connectors
One (1) BNC 75 Ohms.
One (1) RJ45S for Cat 5e/6 unshielded or shielded twisted pair.
LED Indicators
Power, IP Traffic, 100MBps
Throughput
Unidirectional Mode: 100 Mbps downstream and 1 Mbps upstream
Bidirectional Mode: 60 Mbps downstream and upstream
Maximum Distance
RG59/RG6: Up to 3281 ft (1000m) @ 100Mbps
UTP Cat 5e/6: Up to 330 ft (100 m)
Note: When installed in an electrically noisy environment, an STP
cable must be used. Also, cross-connection reduces the effective
distance depending on the grade of twisted cable used.
RJ45 Pin
Configuration
Reverse Polarity
Sensitive. Use EIA/TIA
568A or 586B straight-
through wiring.
RJ45 Link
Pin 1 (R) Pin 2 (T)
Pin 3 (R) Pin 6 (T)
Pin 4 (R) Pin 5 (T)
Pin 7 (R) Pin 8 (T)
Cable
UTP/STP: One (1) Cat 5e/6 or better twisted pair cables required
RG59/RG6: 75 Ohms (avoid CCS cable)
Power Supply
One (1) 110-240V/24VDC 2.7A.
Power Consumption
Network Side: 1.82 Watt Camera Side: 1.73 Watt
Temperature
Operating: 0° to 40°C Storage: -20° to 85°C
Humidity: Up to 95% non-condensing
Enclosure
Metal
Accessories
Wall-mount brackets included
Dimensions
4.37” x 2.95” x 0.99” (110 x 75 x 25 mm)
Weight
2 lb (0.91 kg)
Compliance
Regulatory: FCC, CE, RoHS Flammability: 94V0
Warranty
2 years
Order Information
500114-US CCTV IP PoE Extender Kit, 1Km, US
500114-UK CCTV IP PoE Extender Kit, 1Km, UK
500114-EU CCTV IP PoE Extender Kit, 1Km, EURO
LongReach CCTV IP PoE
Extender Kit, 1Km
500114
Quick Installation Guide
Overview
The LongReach CCTV IP PoE Extender Kit, 1Km (500114) allows one IP camera (15.4
Watts) to be connected up to 3281 ft (1000m) via a single 75-ohm coax cable in a point-
to-point configuration. The maximum distance depends on the grade and quality of
coaxial cable.
Applications
CCTV IP surveillance
Installation
1. Identify the connectors on the Extenders as indicated on the product labels.
© MuxLab Inc. 94-000762-A SE-000762-A © MuxLab Inc. 2014
8495 Dalton Road, Mount Royal, Quebec, Canada. H4T 1V5
Tel: [phone] Fax: [phone]
Toll Free (North America): [phone]
E-mail: [email protected]m URL: www.muxlab.com

2. Attach the surface-mount brackets if required as shown below.
3. Verify that the distance between the CCTV IP PoE extenders is within MuxLab
specifications (see Specifications table).
4. To install the Network Side Device:
4a. Connect the extender to the PoE Ethernet Switch with a UTP Cable.
4b. Connect one (1) length of RG59 or RG6 coaxial cable to the COAX
LINK connector on the Extender.
5. To install the Camera Side Device:
5a. Connect the extender to the camera with a Cat5e/6 cable.
5b. Connect one (1) length of RG59 or RG6 coaxial cable to the COAX
LINK connector on the Extender.
6. Connect the 24VDC Power supply to the network side device first, and then plug
the power supply into an AC power outlet. If power is present, the green power
LED of the Network and Camera side device will be ON.
7. Power on the equipment and verify the image quality. The following is a diagram
of a typical configuration.
Tables
Troubleshooting
The following table describes some of the symptoms, probable causes and possible solutions
in respect to the installation of the LongReach CCTV IP PoE Extender Kit, 1Km:
Symptom
Network Side
LEDs
Camera Side
LEDs
Probable Cause
Possible
Solutions
Power
IP Traffic
Power
IP Traffic
No Image
OFF
OFF
OFF
OFF
No power
• Check the power
connection.
No Image
ON
OFF
OFF
OFF
Coaxial Cable
• Check the coaxial
cables.
No Image
ON
OFF
OFF
OFF
Distance
• Check the coaxial
cables length and
quality.
No Image
ON
OFF
ON
OFF
UTP Cable
• Check the UTP Cable
pin out.
No Image
ON
ON
ON
ON
No Traffic
• Check network
configuration.
Choppy Image
ON
BLINK
ON
BLINK
Distance
• Check cable length
• Check the coaxial
cable quality.
If you still cannot diagnose the problem, please call MuxLab Customer Technical Support at
877-689-5228 (toll-free in North America) or ([phone] (International).
