MuxLab 500733 User manual

P/N: 94-000835-A SE-000835-A
6G-SDI Extender Over UTP with Ethernet
500733
Installation & Operation Manual

Page 2
6G-SDI Extender Over UTP with Ethernet

Page 3
Copyright Notice:
Copyright © 2016 MuxLab Inc. All rights reserved.
Printed in Canada. No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or
otherwise without prior written permission of the author.
Trademarks:
MuxLab Broadcast is a registered trademark of MuxLab Inc.
6G-SDI Extender Over UTP with Ethernet

Page 4
Table of Contents
1. Overview.........................................................................5
1.1. Description..............................................................5
1.2. Features...................................................................8
2. Technical Specifications ..............................................10
3. Installation Procedure.................................................12
3.1. Parts List ...............................................................12
3.2. Product Overview .................................................13
3.3. Physical Installation..............................................15
3.4. Installation & Power-up Procedure.......................16
3.5. Supported SDI Modes...........................................17
3.6. Supported Video Modes........................................18
3.7. SDI Input Connection ...........................................19
3.8. SDI Output Connection.........................................19
3.9. Ethernet Connection..............................................20
4. Firmware Upgrade Procedure....................................21
4.1. Firmware Upgrade Procedure ...............................21
4.2. USB Driver Setup .................................................24
5. Unit Control and Status...............................................27
6. Troubleshooting ...........................................................28
7. Appendix.......................................................................30
A. ASCII Command Set.............................................30
8. Product Warranty Policy............................................33
6G-SDI Extender Over UTP with Ethernet

Page 5
1.
Overview
1.1.
Description
The 6G-SDI Extender over UTP with Ethernet is a unique new
solution from MuxLab for extending SDI cameras or other SDI
sources up to 4K resolution with the added benefit of extending the
signal up to 330ft (100m) using Cat5e/6 cable. This multichannel
extender supports up to 6Gbps of data transfer over the UTP link,
and allows for versatile combinations of sources, including one
6G-SDI source, two 3G-SDI sources or four HD-SDI sources.
In addition Ethernet may be transmitted over the same UTP data
link between Transmitter and Receiver. This Ethernet path may be
used as a video Return Channel for AV monitoring and talk-back
with the use of devices such as the MuxLab 3G-SDI / RS232 over
IP Extender (model 500756) to transmit a 3G-SDI video return
signal (typically a resulting edited video) from the sink back
toward the source. Two Ethernet ports are available on both the
Transmitter and Receiver. The devices also support bi-directional
RS232 pass-through between Transmitter and Receiver for control
of end devices, and can also be used to return tally light and
camera control unit (CCU) signals.
Standard Cat5e/6 UTP cable is used for the extension. The 6G-SDI
Extender with Ethernet supports PoE, whereby the Transmitter
may be powered by the Receiver via the UTP link. The Ethernet
Port A provides PoE (PSE) to a connected device supporting PoE
(PD), such as the above mentioned 3G-SDI / RS232 over IP
Extender (model 500756). See an example of this on the following
diagram.
6G-SDI Extender Over UTP with Ethernet

Page 6
Figure 1: System Overview
6G-SDI Extender Over UTP with Ethernet

Page 7
Applications:
• Cinema recording
• Movie making
• Studio video production
• News media coverage / live reporting
6G-SDI Extender Over UTP with Ethernet

Page 8
1.2.
Features
Extend up to 4K @ 30Hz resolution to 330ft
(100m) over Cat5e/6.
Supports multichannel transmission of one 6G-SDI
source, two 3G-SDI sources, or four HD-SDI
sources.
Supports the transmission of two Ethernet ports.
Port A supports 100Mbps and Port B 10Mbps.
Supports bi-directional RS232 pass-through for
remote control of end devices, and as a return for
tally light and camera control unit (CCU) signals.
Maximum resolution supported: 4096x2160 @
24/25Hz, 3840x2160 @ 30Hz.
Supported SMPTE Standards:
SMPTE-292M, SMPTE-296M, SMPTE-372M,
SMPTE-424M, SMPTE-425M
Supports all 6G channel configurations (1, 2, or 4
BNC).
Automatic SDI Link recognition and configuration.
Automatic activation of long reach mode 500ft
(150m) when a 3G signal is detected.
USB interface for field upgradable firmware and
diagnostics.
The Receiver supplies PoE (PSE) to power the
Transmitter.
6G-SDI Extender Over UTP with Ethernet

Page 9
Ethernet Port A of both the Transmitter and
Receiver is capable of supplying PoE (PSE) power
to a connected MuxLab Over IP PoE (PD) device.
Ethercon connectivity and solid Aluminum
enclosure for ruggedized use.
Multiple ¼”-20 threads for Camera mounting or
equipment attachment.
6G-SDI Extender Over UTP with Ethernet

Page 10
2.
Technical Specifications
Specifications
Environment
6G-SDI Digital Signal Transmission
Enclosure
Aluminum casing :
Tx & RX: 110mm (4.3”) x 110mm (4.3”) x 32mm (1.250”)
Color
Tx & RX: Black
Control
Serial Console Emulation with USB Interface
Compliance
FCC, CE, RoHS
Power
48VDC, 0.7Amp
External Power Supply with US, UK and Euro blades
Table 1 - Specifications
