My Weigh iBALANCE iM01 User manual

Thank you for purchasing the My Weigh® iBalance® iM01™ digital scale. Please read all operating instructions
carefully before use. This electronic scale is a precision instrument. With normal care and proper treatment, it will
provide years of reliable service. For more information please visit www.myweigh.com
Never load the scale with more than the maximal capacity. Although the iBalance® iM01™ is designed to be
extremely durable with extra overload protection built into the case, overloading will permanently damage it! Avoid
any exposure to extreme heat or cold, your scale works better when operated at normal room temperature. Keep
your scale in a clean environment. Dust, dirt, moisture, vibration, air currents and/or a close proximity to other
Gently apply all items to be weighed onto tray top. Avoid shaking, dropping or otherwise shocking the scale. Scales
are delicate instruments and unlike cellular phones, scales have delicate sensors that determine how much an item
weighs. If you drop or shock your scale, these sensors “feel” the shock and are sometimes destroyed. This happens
with all digital scales. We design our scales to be as resistant to shock or drops as possible, however there is no way
for us to protect 100% against load cell or sensor damage.
Failure to follow these instructions will void your warranty.
Always allow the scale to acclimate to normal room temperature for at least one hour before use. Give your scale
stabilize.
PRECAUTIONS BEFORE USING THE BALANCE
is to use Static-Guard spray, and spray it on both sides of the weighing platform.
2. Before the initial use, please remove the protection screw. Re-install this screw before transport to help avoid
possible damage.
3. The balance must be in an exactly horizontal position in order to achieve accurate measurement results. In order
to bring the balance into a horizontal position, the adjustable feet are turned either clockwise or counter-clockwise
until the air bubble on the front panel is in the center of the marked circle.
4. Please use an independent power outlet to avoid interference from other electrical appliances.
5. Don’t put any object on the platform before powering on.
6. When possible please allow the scale to warm up for several minutes before operation.
7. Items should always be placed on the center of the platform when being weighed.
8. For optimum accuracy, recalibrate before each use.
USER MANUAL


1.
KEYPAD FUNCTIONS
ON/OFF power switch.
SAMPLING & COUNTING.
UNIT(g, ozt or ct ) selection.
TARE is used to deduct the weight of an
item or container. The symbol will
appear and reading will go to zero. Press it
again to exit the tare mode (when empty),
the tare indication will disappear.
ZERO is used to return the display to zero if
a small weight reading is left while
unloaded/empty.
DISPLAY SYMBOLS
•
Scale is in ZERO mode.
•
Scale is in TARE mode.
•
BATTERY needs recharging.
•
The display reading is STABLE.
•
pcs Scale is in COUNT mode.
•
ct Unit is CARAT.
•
ozt Unit is TROY OUNCE.
•
g Unit is GRAM.
•
In charge Scale is in the process of RECHARGE.
SCALE FEATURES
DATA TRANSMISSION PORT
on right side of the scale
PROTECTION SCREW
on the left side of the scale
ADJUSTABLE FEET
on bottom of each corner of the scale
OPTIONAL CLEAR WIND SCREEN
AIR BUBBLE LEVEL

COUNTING FUNCTION
1. Press , the display will show“ 10Cnr”(means sample size is 10 pcs)
2. Press again and again,“10、”“20、”“50、”“100”pcs will appear in succession.
Stop at the one you want to use.
3. Put the exact quantity of samples desired on the platform and press , the set sample size will appear.
4. Keep adding objects to be counted on the pan, the total number of the objects will be displayed.
If the unit weight is too small for the counting resolution, the display will show“ErrPcS”
ERROR MESSAGES
When an applied load exceeds the capacity,“-----9”will appear on the display. Remove excessive load immediately.
The unit may return to normal operation. Remember:You can permanently damage the scale and void your warranty
by overloading it!
The LCD will display“ERR 1”if the weight placed on the platform is incorrect during calibration.
POWER SUPPLY
The iMO1™ is powered by the DC 6V/1.3Ah rechargeable sealed lead-acid battery
or directly by the 8.5V / 0.2A AC power adaptor.
When the symbol appears, it indicates that the battery needs to be recharged. The balance will automatically
CALIBRATION
Press and hold (do not release) and power the scale on with , release when the LCD shows“CAL”.
2. Press again, it shows“000000”. This is where you would input the calibration weight you are going to use to
calibrate (500 grams is recommended). Use to cycle through the 6 zeros shown on the screen and use on
the selected digit to adjust selected digit. To calibrate a the recommended 500 grams, the screen must read
“000500”. Once this is set, place the 500 gram calibration weight on the tray.
WEIGHT RESPONSE SPEED
Press and hold (do not release) and power the scale on with .Wait until the display shows“nb0”,“nb1”,
“nb2”, or“nb3”. You can now release . Press again to select your response speed. (nb0: slowest, nb3 fastest)
RANGE OF ZERO TRACK AND ZERO DISPLAY SELECTION
1. Press and hold (do not release) and power the scale on with . Wait until the display shows“0.5d. 1.0d.

2. The display will then show“ZEr-S”or“ZEr-L”press to select the zero display range. (ZEr-S means 0d and ZEr-L
means ± 3.0d) Press
5. You can choose the communication method by pressing to rotate/revolve (Co: send in succession, st: send
After that the scale will return to normal weighing mode.
DATA TRANSMISSION – SERIES RS-232 INTERFACE (only for communication)
g, ozt, ct
UnitsCapacity
SPECIFICATIONS
2 min.
200mm x 240mm x 80mm
1200g
116mm diameter
DC 6V/1.3Ah rechargeable sealed lead-acid battery
or 8.5V / 0.2A AC/DC power adaptor
Optimum 10-40°C (50-104°f)
1000g x 0.01g
Auto-OFF
Scale dimension
Net/gross weight
Tray dimension
Up to scale’s maximum capacity
± 5% of max. capacity
Tare range
Zero range
Operating temperature
Power Source
1. iBalanceEIA-RS232 C’sUART signal
2. Format
(1) Baud rate: 1200 bps 2400 bps 4800bps 9600 bps
(2) Data bits: 8bits
(3) Paritybit: none
(4) Stopbit: 1 bit
(5) Code ASCII
DATA FORMAT：
HEAD1HEAD2DATA UNIT CR
1 234 5 67 8 910 11 12 13 1415 16 1718 19 20
HEAD1 (2BYTES) HEAD2 (2BYTES)
OL- overload NT - net weight mode
ST - stable US - unstable
DATA(8BYTE)
2D (HEX) =“- ”(negative sign) 20 (HEX) =“ ”(blank)
2E (HEX) =“. ”(decimal point)
UNIT (4 byte)
g =20(HEX); 20 (HEX); 20 (HEX); 67(HEX)
kg = 20 (HEX); 20(HEX); 6B (HEX); 67(HEX)
ct =20 (HEX); 20 (HEX); 63 (HEX); 74 (HEX)
ozt = 20 (HEX); 6F (HEX); 7A(HEX); 74 (HEX)
CR= OA (HEX); OD (HEX)
TRANSMISSION EXAMPLE
stable net +0.168 g
HEAD, HEAD, DATA UNIT CR
ST, NT +0.168 g OA, OD
