GBC 1130s
Paper Shredder
Instruction Manual

1.0 1130S Introduction
This service manual covers adjustment, disassembly, operation, preventative maintenance, trou-
bleshooting procedures and contains an illustrated parts list for the GBC Shredmaster 1130S shred-
der. The GBC Shredmaster 1130S straight cut shredder is designed for small offices and low vol-
ume requirements.
Innovative engineering has provided this shredder with the following operating and safety features:
1. Automatic Operation- The unit begins to operate when paper actuates the trigger in the shred-
der throat area. The motor stops running when the paper has cleared the cutting head and after the
shredder has timed out.
2. Overload Warning- Whenever the capacity of the shredder is exceeded the unit will stop shred-
ding and the "Reverse" icon will illuminate.
3. Bin Full- When the shred bag becomes full, the motor automatically turns off and the "Bin full"
icon will illuminate. The shredder will not operate until the shredded material is either compacted or
emptied.
4. Door Ajar- When the door of the shredder is not fully closed, the "Door Ajar" icon will illumi-
nate. This is a safety feature that will only allow the shredder to operate when the cabinet door is in
the closed position.
Before attempting any repairs on the 1130S shredder, review the operating instructions first to gain
experience and familiarity with its operation. You will then be better prepared to use the remaining
sections of this manual to troubleshoot and repair the shredder.
4

5
Required
Electrical
Service:
115V AC +/ -
10%, 60 Hz, 15 Amp
Electrical
Rating: 115V AC
3A, @ 60Hz
Motor:
1/8 Hp
Thermally Protected
Duty Cycle: 10 Min. On/30 Min. Off
Dimensions:
HxWxD 26.75’’ x 16.75’’x 15’’
(67.9 x 42.5 x 38.1 cm)
Weight W/
Cabinet: 38.71 lbs.
Shredding
Speed: 25 FPM @ 1 sheet
Shred Size: 5/32’’ (4mm)
Throat
Width: 9 1/4’’ (23.5cm)
Capacity: 11-
12 sheets of 20# Bond
Paper
Noise Level: 68 dB No Load
Shipping
Carton
Dimensions:
HxWxD
32.06’’ x 22.5’’ x 20’’
(81.4 x 57.15 x 50.8 cm)
2.0 1130S Specifications

3.0 1130S Safety Instructions6

7
3.0/4.0 1130S Installation/Operation
