MYE MWCS-AT9-LFA User manual

MWCS-AT9-LFA
MYE 900MHz (Wireless) CableSAT
for Life Fitness
MYE Entertainment
1-661-964-0217
www.myeclubtv.com
All Rights Reserved 2016

TO T
POWER
“IN”
T
POWER
CABLE
MLF-CSPWR Power Splitter Cable
1
23
4
5
7
8
9
MYE CableSAT Transmitter Connections for Life Fitness.
MWCS Model Description Cable 1 Cable 2 Cable 3
MWCS-AT9-LFA Life Fitness MWC-LF-IFC1 MWC-LF-IFC2 MLF-CSPWR
CableSAT Transmitter MWCS-T
Transmitter Installation
1) Disconnect the T controller cable from the back of the Life Fitness T .
2) Plug the T ’s controller cable into the Molex end of the MYE cable MWC-LF-IFC1.
3) Plug the RJ45 end of the MYE cable MWC-LF-IFC1 into the CableSAT transmitter “Control In.”
4) Plug the MYE cable MWC-LF-IFC2 into the Life Fitness T controller jack.
5) Plug the MYE cable MWC-LF-IFC2 into the CableSAT transmitter “Out.”
6) Disconnect the DC power plug from the Life Fitness T .
7) Plug the DC power plug into the bottom connector of the MLF-CSPWR Power Slitter Cable.
8) Connect the 2.5mm plug of the power-splitter cable to the T
9) Connect the 1.3mm plug of the power-splitter cable to the transmitter.
10) Remove the elcro backing and install CableSAT transmitter to rear of T enclosure.
**Before using CableSAT, the T tuner needs to be scanned to register the set top box on channel 3
MWC-LF-IFC2
MWC-LF-IFC1

Receiver Installation
OPTION 2: ALIGN THE
RECEI ER’S IR WINDOW
WITH THE SET TOP BOX IR
WINDOW
EXAMPLE OF IR EMITTER
INSTALLED
TO FRONT OF SET TOP BOX
OPTION 1:
IR EMITTER CABLE
TO SET TOP BOX IR
RECEI ER
OPTION 1:
IR EMITTER CABLE
RUN TO SET TOP BOX
MACA-9 power
supply for power
Use MWCS-C -S straight cable to run power from the MACA-9V power supply to the
CableSAT receiver’s power IN.
Connecting the receiver to the SET TOP BOX can be achieved by ONE of the two options.
OPTION 1: Plug the MWCS-IR emitter cable into the receiver an attach the IR
!!!!!.emitter to the Set Top Box IR win ow.
OPTION 2: Align the CableSAT receiver’s IR win ow with the IR win ow of the Set Top Box.

***Once the receiver is installed you can select your Set Top Box (below).
Unit is shippe in AT&T mo e. Match the lit LEDS to your Set Top Box type.
1) Start with the CableSAT Receiver power isconnecte .
2) Using a pen or paperclip, press an hol the “PGM” switch.
3) Connect power to CableSAT Comman Receiver.
4) Hol in the “PGM” switch until the “power” an “learn” LEDs are soli .
5) Release the “PGM” switch. Transmitter is now in AUTO LEARN mo e.
6) Point the TV’s IR remote control at the IR win ow on the si e panel of the CableSAT Receiver.
7) Press the Channel Up key on the remote control.
8) The learn LED will flicker an the Programme LED will light soli once the comman has been
!!..learne . The learn LED will then light soli again.
9) Press the Channel Down key on the remote control.
10) Again the Learn LED will flicker an the Programme LED will light soli once the comman
!!has been learne . Learn LED will light soli again.
11) Press the following keys in succession. Be sure to wait for the Learn an Program LED to light
!!up as each key is learne .
12) Press: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, an “Enter” on the remote.
13) All LEDS will flash briefly to in icate that the CableSAT receiver is programme an rea y.
****If you get a re ERROR light, remove power from the receiver an start again.
1) Start with the CableSAT Receiver power isconnecte .
2) Using a pen or paperclip, press an hol the “PGM” switch.
3) Connect power to CableSAT Comman Receiver.
4) Hol in the “PGM” switch until the “power” an “learn” LEDs are soli .
4) Release the “PGM” switch. Transmitter is now in AUTO LEARN mo e.
5) Press an release the switch a 2n time.
6) All LEDS will light briefly, followe by the Power LED. This in icates you are now in the
!..set top box series of Presets.
7) To select one of the set top boxes liste press the “PGM” switch to cycle through the
!..Presets. Set Top Boxes are represente in the chart below.
8) Once the esire set top box is isplaye , press an hol the “PGM” switch until the re
!!“error” LED turns soli .
9) Release the “PGM” key. All LEDS will flash briefly to in icate the CableSat Receiver is
!...programme an rea y for use.
LED
LEARN MODE
LEARNED COMMANDS
AT&T
COMCAST
DIRECTV
VERIZON, RCN , GRANDE
MEDIACOM, ROGERS,
SUDDENLINK, BEND,
WAVE, CHARTER (ARRIS)
TIME WARNER, COX,
WOW, BRIGHT HOUSE,
CABLEVISION, OPTIMUM
CHARTER (CISCO)
DISH, BELL CANADA
COX MINI BOX
1POWER
2LEARN
PROGRAMMED
4ERROR
***IR remote Auto Learn Mode.
For use when your Set Top Box is not listed in PRESETS.

11/9/16
man_mwcs_at_lfa_V1_F
