MyKronoz ZeTime User manual

USER GUIDE
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per MyKronoz ZeTime o cerca il tuo prodotto tra le
migliori offerte di Smartwatch

THE FIRST SMARTWATCH
WITH NO COMPROMISES
Thanks for choosing MyKronoz ZeTime, you’re now part of the global
family of ZeTime owners who have decided together with us to
break the rules of traditional smartwatches to deliver a companion
device with no compromises. ZeTime was born in Switzerland,
home country of the traditional watch industry and this is why it has
been thought and developed with a lot of care and passion with
only the final owner in mind. ZeTime is assembled with some high
quality materials and technologies to make it not only an amazing
smartwatch but certainly a beautiful piece of jewelry you’ll be proud
of wearing every day.
Stainless Steel Watch Case: ZeTime comes in 6 dierent colors of
high grade stainless steel to suit your style and your tastes but more
importantly guarantee you the best durability over time.
Natural Sapphire Glass: In order to provide the best watch
possible, it was mandatory for us not to make any sacrifices on the
type of glass we were using on ZeTime. That’s why we selected
a special sapphire glass that works perfectly with our customized
touch panel.
Customized TFT Screen & Smart Movement: To be a revolutionary
smartwatch we had to achieve something that nobody did before!
Delivering a watch with a full round TFT display combined
together with a smart mechanical movement controlled by the
watch CPU. The result is mind-blowing and oers an absolutely
unique user experience.
5 ATM Certification: Because our watches accompany us pretty
much everywhere we go, we have built ZeTime to oer the best
performance in all kinds of environments and especially when in
contact with water.
Up to 30 days battery life: Thanks to our proprietary operating
system we’re not only able to oer perfect compatibility with both
Android and iOS devices but also to deliver unprecedented battery
life for a smartwatch. 3 days in fully operational smart mode and an
additional 30 days once the screen is o, guaranteeing that you’ll
never be out of juice for keeping track of time.

- 3 -
- 39 -
1. Charging
2. Battery life
3. Set up
4. Calibration
5. System requirements
6. Incoming calls
7. Missed calls
8. SMS
9. Notifications
10. Reminders
11. Activity
12. Inactivity alerts
13. Heart rate
14. Sleep
15. Alarm
16. Camera remote
17. Music control
18. Anti-lost function
19. Weather forecast
20. Stopwatch
21. Timer
22. Find my phone
23. Customize your watch
24. Home time zone
25. Wrist flick
26. Left hand mode
27. Night mode
28. Settings
29. Firmware update
30. Watch band
31. Accessories
32. Tech. specs
- 08 -
- 09 -
- 10 -
- 11 -
- 12 -
- 13 -
- 14 -
- 15 -
- 16 -
- 17 -
- 18 -
- 22 -
- 23 -
- 24 -
- 25 -
- 26 -
- 27 -
- 28 -
- 28 -
- 29 -
- 31 -
- 31 -
- 32 -
- 32 -
- 33 -
- 33 -
- 34 -
- 35 -
- 36 -
- 37 -
- 38 -
- 39 -
TABLE OF CONTENTS

- 4 -
Color
touchscreen
Upper
button
Smart
crown
Lower
button
OVERVIEW
I UPPER BUTTON
Press to light up the screen, return to home page from any menu
or put the device in standby mode.
I LOWER BUTTON
• Press to light up the screen, go one step back in the menu
structure, exit a menu or have access to your calendar events from
your home page.
• Press & Hold to Power ON/OFF.
I UPPER + LOWER BUTTON
Press & Hold the upper button and the lower button for 10 seconds
to reset the device.
Warning: all data stored into the device will be lost.
I SMART CROWN
• Turn the crown to navigate through the main menu.
• Press the crown to select an app.
• Double press to manually move the hands to 9:15
• Single press to enable night mode (from standby screen).

- 5 -
Marketing weekly
meeting with Fred...
NO! Thi...
Hi , Jack ! H...
Yes , I’m ve...
Long press
to change your
watch face.
Swipe right
to access
activity
menu.
Swipe down
to display
shortcuts
menu.
Tap once
To select an item
or open
a menu.
Tap twice
To return to
previous
page.
BASIC TOUCHSCREEN OPERATIONS
I FROM THE WATCH FACE
I FROM ANY SCREEN
Swipe left
to access
main
menu.
Swipe up
to display
notification
center.
X2

- 6 -
SMART CROWN OPERATIONS
Turn the crown
to navigate through the main menus.
-
Press the crown
to select an app.
-
Press twice
manually move the hands to 9:15 from any screen.
-
Press once
to enable night mode
from standby screen.
ZeTime is equipped with a smart crown to enhance the navigation
experience in the watch menus. It can be used from many
dierent screens to select, navigate or adjust some
settings. Pressing the crown will validate your selection.

- 7 -
SHORTCUTS
Swipe down from the main watch face
to access ZeTime shortcuts.
Weather
Instantly access the local
weather conditions and
next 3 days forecast.
Flight mode and
Bluetooth status
Brightness
Set screen brightness
for better visibility.
Vibration
Buzzer
Mute all notifications.
Turn on vibration (default).
Turn on vibration & buzzer.
(Also enable customized setting
from the mobile app).
Turn on buzzer.
Flight mode is disabled.
Bluetooth is not connected.
Flight mode is enabled.
Flight mode is disabled.
Bluetooth is connected.
Helps you find your phone
as long it is in range
with your ZeTime.
Shows the remaining battery
level of your watch.
Heart rate
Keep track of your heart rate.
Monitor it.
Battery level
Find my phone

- 8 -
1.CHARGING YOUR ZETIME
We recommend you to initially charge your ZeTime for about
90 minutes before using it for the first time.
ZeTime will operate for up to 3 days in smartwatch mode and an additional
30 days in traditional mode.
ZETIME CHARGER CABLE
1. Position the back of your ZeTime on the charging dock.
2. Plug the USB cable into the charger.
3. Plug the large end of the USB cable into a USB power source.
4. A battery indicator will fill in to indicate charging is in progress and turn to
solid green when it’s fully charged.
5. Unplug the cable after ZeTime is charged.
When the battery level gets low, a low battery indicator will
appear on the watch screen.
i

- 9 -
2.BATTERY LIFE
Your ZeTime operates with a single battery, which powers
both the digital screen and analog movement in the most
energy ecient manner in order to oer up to 30 days battery
life on a single charge.
When fully charged, ZeTime will deliver about 3 days battery life in its fully
operational smartwatch mode, tracking your activity and alerting you of
incoming notifications or calls.
Once a certain minimum battery level will be reached, ZeTime will
automatically turn off the smartwatch functions to continue providing
an additional 30 days battery life to power the smart movement.
During this 30 days period, hands will only indicate the local time, no
additonal functions will be available.
You have the freedom to enable activity tracking together with analog
mode but this will aect the overall battery life. This operation can be
performed in the mobile app advanced settings (power o mode > Hands
running + Activity tracking).
CHARGE
The 3 days smartwatch function is an estimate based on the
anticipated average use of the device. Many features and functions
- such as the HR tracker and the touchscreen - consume more
energy, so your actual battery life may vary.
i

- 10 -
3.SET UP
When turning ON your ZeTime for the first time, you’ll be
prompted to download the ZeTime mobile app on your
smartphone in order to proceed to its initial set up.
I TO SET UP YOUR ZETIME
1. Ensure the Bluetooth is enabled on your mobile smartphone.
2. Download the ZeTime mobile app from the app store or the Google Play
Store.
3. Open ZeTime mobile App on your smartphone. Sign up if you are a new
member or Log in with your existing account. After entering your personal
information, follow the on-screen instructions.
4. Make sure ZeTime is nearby and select it in the list of devices.
5. A pairing request will appear on your smartphone. Press pair to accept it.
6. Then, you will receive a pairing request on your ZeTime display. Tap on the
screen to accept the pairing.
7. When ZeTime is successfully paired, you will be notified on both devices.
At the end of the setup process, you might be prompted to install a new
version of the watch firmware. We strongly advise you to do it before you start
using ZeTime. This will ensure that you have the most up to date software on
your device and benefit from all the latest features. Before the update make
sure to have more than 30% battery on your smartphone.
After the initial pairing, ZeTime will automatically connect to your
phone as long as it is turned on and within range. If you want to
pair your ZeTime with another account or smartphone, you first
need to unpair from the current one. On the mobile app, go to
Settings > click on Unpair ZeTime. Then, repeat the pairing procedure
described above.
i

- 11 -
4.CALIBRATION
During the set up process, you’ll be prompted to proceed to
hands calibration. This is a mandatory step to ensure your watch
is perfectly time-synched with your smartphone.
Calibration can be done after the set up process directly on the watch in the
settings or from the mobile app by following the steps below:
• Open your app.
• Click on Settings and then on Advanced Settings.
• Then, click on Calibration and follow the on-screen instructions.
Align the hour hand with the red
dot at the top of the screen, and
align the minute hand with the
hour hand, then press NEXT to
synch your ZeTime with your
smartphone.
To calibrate your watch, move
hands by slowly swiping your
finger around the virtual dial on
the smartphone screen. You
can fine-tune the position of the
hands by using the « + / - » on the
phone screen.
When travelling in another time zone, do not forget to synchronize your
watch with the mobile app in order to make it automatically adjust
to local time.
i

- 12 -
5.SYSTEM REQUIREMENTS
Visit www.mykronoz.com to get the latest compatibility list.
- iOS -
iOS 8+ devices with Bluetooth 4.0 BLE
iPhone 4s, 5, 5c, 5s, 6, 6s, 6s plus, 7, 7 plus, 8, 8 plus & X
iPad (3
rd,
4
th
and 5
th
generation), iPad Mini,
iPod touch (5
th
generation)
- ANDROID -
Selected Android 5.0+ devices that support
Bluetooth 4.0 BLE
ZeTime will sync the notifications of SMS, emails, social media,
calendar events, and personal life reminders once the ZeTime app
has been successfully installed on your smartphone .
i
It is required to install ZeTime mobile app on your smartphone to
properly set up and use your watch.

- 13 -
6.INCOMING CALLS
7.MISSED CALLS
When receiving a call, a notification will appear on your ZeTime.
You can accept or reject it straight from your wrist. The phone call
will occur on your smartphone, not on your watch.
Missed calls are visible in the notification center as well as in
the dedicated missed call app in the watch.
ANGELINA
INCOMING CALL
Android users can also reply to an incoming call by sending a
short preset text message or an emoji directly from their watch
(not available for iOS users).
To delete all your missed calls, long press the screen.
i
i
JENNIFER
STEPHANE
CINDY
MAXIM

- 14 -
8.SMS
With ZeTime you can receive and read your SMS straight from
your wrist. Thanks to its proprietary smart movement, ZeTime
detects the information that is displayed on the screen and
moves the hands horizontally to maximize visibility, allowing the
text to be seen clearly.
Quick reply (Android only): ZeTime allows you to reply using
emojis or preset short answers directly from your watch. You
can also create your own preset answers using the mobile app.
To delete all your SMS notifications, go on the SMS list and long
press the screen. To erase a specific SMS, select the message and
slide it to the left with your finger.
i

- 15 -
9.NOTIFICATIONS
ZeTime is able to receive virtually all notifications received by
your phone.
Calendar events: ZeTime synchronizes your events from your
calendar. You can see your next upcoming 16 events in your
ZeTime. Your smartwatch will notify you of upcoming events. You
can slide to discard this event.
i
Each notification will appear over your selected watch face with its dedicated
icon to identify the service. Some notifications may be identified with a blue
generic icon.
To read your notication, simply
touch the screen on the notification
area and it will open instantly.
Swipe left to delete
the notification.
Hands will automatically move
away from the text to facilitate
your reading.
Long press on your
notifications list to delete
them all.

- 16 -
NOTIFICATIONS SETTINGS:
When you open your ZeTime mobile app and select
Notifications in the settings menu, the following screen
will appear:
For each type of
notification you can select
the type of alert you want:
ring, vibrate or silent.
To set it up, simply
expand the option menu
by tapping on the
notification type.
Press on the slider buttons
to activate or disable
the notifications.

- 17 -
10.REMINDERS
You can set and manage reminders directly with ZeTime mobile
app. You can create up to 10 reminders and select the type,
time and schedule for them. For each reminder you can decide
the type of alert you want to receive (ringtone, vibration or both).
A single tap on your ZeTime helps dismisses the reminder. If not
dismissed, the same alert will repeat after two minutes.
I TO SET UP A REMINDER
•Open the ZeTime mobile app.
•Click on the reminder tab.
•Set up your preferred reminder type.
•Choose the date and time of the reminder.
I REMINDER ICON
After setting your reminders, you can find them in the corresponding
menu on your ZeTime.
i
Sport

- 18 -
11.ACTIVITY
ZeTime automatically tracks your activity throughout the day.
On the main application screen, you can view your daily activity
in real-time over your set goals and get a detailed report in
the mobile app.
Your watch has a built-in 3-axis accelerometer that allows you
to track your daily activity based on your movements. This,
together with your profile information, allows your watch to
calculate your steps, walking distance, minutes of activity and
calories burned. In order to get the most accurate results we
recommend you to wear your watch on your left wrist if you’re
a right handed and to your right one if you are a left handed.
I FROM YOUR ZETIME
FOLLOW YOUR ACTIVITY:
• You can access the activity home screen simply by swiping to the right
from the watch face or selecting the corresponding menu from the first page
of the applications menu.
• Swipe down to see your number of steps, distance, calories and active
minutes. You can also use the smart crown to navigate inside this menu.
The activity tracker resets at midnight and ZeTime has the ability
to store up to 10 days of your activity data. Then, you will have
to synchronize your ZeTime with your mobile app in order to avoid
loss of data.
i
Overall activity Steps
Calories burned
Distance
Minutes of activity

- 19 -
I FROM ZETIME MOBILE APP
CUSTOMIZE YOUR ACTIVITY DASHBOARD:
When you have set up your watch with your mobile app, you will be able
to customize your Activity page at your convenience.
In order to do so, you just have to long press on one of your activity bars
for 3 seconds. Then you must hold this icon and make the entire
section slide down or up.
Long press on any of your activity bars for 3 seconds to save your modi-
fication.

- 20 -
SET UP ACTIVITY GOALS:
You can set your daily goals from the mobile app or in the activity
section of the watch settings.
We recommend you to set ambitious but realistic goals in order to
keep a healthy daily activity. You can obviously raise your goals over
time to increase your performance. On average it is recommended to have
at least 30 minutes of physical activity per day.
Your ZeTime tracks your progress towards a daily goal of your
choice. Some of the watch show a goal progress ring or bar to
keep you motivated. When you reach your goal, ZeTime vibrates
and displays a Goal achieved notification.
i
OK
