Mylek MYBWF05ET User manual

PROGRAMMABLE ELECTRIC TOWEL RAIL
MYBWF05ET &MYBWF08ET
BEFORE USE:
Please read the instructions carefully. You must inspect the appliance including its
cable and plug for any signs of damage. If the product is damaged, DO NOT USE
and contact your supplier immediately for refund, replacement or advice.
This product is only suitable for well insulated spaces or occasional use

BEFORE USING THIS HEATER:
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electric shock, and
injury to persons. This includes but is not limited to the
following:
CAUTION:
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge of the product. The
appliance is to be operated by responsible adults only after
reading and understanding these instructions. Children should be
supervised at all times to ensure that they do not play with the
appliance. Children under 16 years should not operate the unit or
carry out maintenance and/or clean the unit. Any infirmed
persons in the vicinity of the unit should be accompanied by a
responsible and competent able bodied adult. Remove the
packing and make sure that the appliance is intact. If there is any
doubt concerning the integrity of the unit do not use the
appliance and contact our recommended after-sales service. Do
not leave any packaging materials within easy reach of children.
Before switching on appliance check if the electrical voltage and
frequency of the circuit correspond to those indicated on the
appliance. Use the appliance only for the stated purpose, namely
as a heater for domestic use. Do not use it for any other
application as it could be dangerous.
SAFETY INSTRUCTIONS:
• The product is for indoor use only.
• The item should be used only as intended.

• Check item carefully before use. Do not switch on heater with
defects or damaged power cable.
• The appliance should be connected to the same voltage as
shown on the rating label and printed in the manual.
• The heater should only be plugged into grounded sockets.
• Before plugging in the heater, make sure it is switched off.
• Do not use the appliance near flammable liquids or any
flammable materials.
• The appliance must not be located immediately below a
socket outlet.
• If the power cable is damaged in any way, send it to the
nearest after sales service recommended by the manufacturer
for replacement.
• Do not connect the appliance to extension cables or multiple
outlets.
• Do not damage or knot the power cable.
• Before cleaning the appliance or carrying out any
maintenance switch off the heater, unplug from its power
source and leave to cool for 1 hour.
• Never expose the appliance to external weather conditions
(rain, sun, etc.)
• If the appliance is not being used or becomes faulty, switch it
off contact your supplier for refund, replacement or advice.
• Do not touch heater with wet hands.
• Always unplug the item, before cleaning or if the item
becomes faulty.
• Never carry the heater by the power cable.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.

• CAUTION: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not be
supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on
and off by the utility.
• Do not wrap the cable around the appliance after use.
• Children of less than 3 years should be kept away unless
continuously supervised.
• Children aged from 3 years and less than 8 years shall not
plug in, regulate and clean the appliance or perform user
maintenance.
• CAUTION — Some parts of this product can become very
hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• The appliance should only be connected to the same voltage
as printed on the rating label and manual.
• WARNING: In order to avoid overheat i n g , d o n o t c o v e r t h e
heater. Hang towels on the front rail provided.
• Never place foreign objects into the air vents.
• CAUTION: In order to avoid a hazard due to inadvertent
resetting of the thermal cutout, this appliance must not be
supplied through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on and off
by the utility.

• Do not use this heater in the immediate zones surroundings of
a bath, a shower or a swimming pool. Please use a qualified
electrician to make sure the unit is installed in the correct
zone in a bathroom.
WARNING:
• In order to avoid a hazard for young children, this appliance
should be installed so that the lowest part of the heater rail is
at least 600 mm above the floor.
• The heater is to be installed so that switches and other
controls cannot be touched by a person in the bath or shower.
Please make sure this unit is fitted by a quaified electrician.
BATHROOM ZONES GUIDANCE:
Zone 0: Inside the bath or shower itself. Appliance used in this
zone must be low voltage and totally immersion proof,
IPX7 minimum.

Zone 1: All circuits in this zone must be protected with a 30mA
residual current device (RCD). It is good practice to use
IPX5 in this zone.
Zone 2: Appliance in this area must have a minimum IPX4
rating.
Zone 3: This area must be outside of the water spray zones 0, I
and 2. No special requirements are needed in this area.
Our product attains IPX4, so it can be installed in Zone 2 or
Zone 3.
Make sure that the distance from walls and objects is respected
INSTALLATION OF TOWEL RAIL
：
Turn the product around and install the towel rail from top as below figure 1
and fix it with 4 screws on the rear cover as below figure 2.
figure 1 figure 2
BEFORE INSTALLATION ON THE WALL:
M6*15mm
ø 10mm
x4
M6 x 50mm
B
A
x4C
0 1 2 3 4 5 cm6 7
Tools needed (not provided)

INSTALLATION:
B
C
x2
M4 x 6mm
D
> 800mm
SOL
≥600mm
≥150mm
≥150mm
≥150mm
D
ø 10mm

Warning! Please choose correct installation area, always check to ensure there is
no wiring, pipe work, etc. in the area to be drilled.
A． Place the hanging rack on the wall as a guide ruler (please make sure the holes
are at parallel level), use a pen to mark the hole positions
B． Drill holes in the wall with ɸ10mm drill bit and insert the plastic wall plugs
C． Fasten the hanging rack on the wall with the screws, making sure the hanging
rack is in correct direction
D． Gently insert the bottom of the heater first to the bottom of the hanging rack
and then gently push the top heater body onto the top hanging rack
E． Secure the heater into place with the screws provided.
Warning: Before plugging in the unit make sure the radiator is properly
secured to the wall. This will avoid future problems.
Unit Description:
1. Front cover
2. Towel bracket
3. Control panel
4. On/off switch
1
2
3
1
2
3
4
4

Control Panel:
1. Standby indicator
2.Heating indicator
3. Comfort mode indicator
4. ECO mode indicator
5. LED display
6. Standby button
7. Mode button
8. Increase button
9. Decrease button
10. Timer button
Operation
The unit must be installed by a qualified electrician.
1. Plug or Spur the appliance to AC 230V 50-60Hz socket. Verify the rated
current of the power socket whether it fits the requirements and equipped with a
safety grounding device.
2. Press the on/off switch at the right bottom corner, you will hear a sound which
indicates the unit is in standby, the standby indicator is illuminated.
3. Press standby button to start the heater. For the first use the heater is in
default settings as shown below: (If default settings are different, it will simply
because the unit has been quality tested after production).
Comfort mode
Target temperature setting: 22 °C
Day: 1(Monday), Time: 00:00 (Off)
Window open function: Off
Timer: Off
Note: Please note: If the unit is in standby mode the unit will keep the clock and day
settings. Depending how long the unit is switched off at the mains or unplugged, the
clock and day may need to be reset when powered back up.
3
4
5
6
7
8
9
10
1
2

4. Clock and day of week setting:
- Press 3 seconds to enter clock and day of week setting
- The screen display “d”, press and to select the day from 1-7.
1
Monday
2
Tuesday
3
Wednesday
4
Thursday
5
Friday
6
Saturday
7
Sunday
- Press to confirm day setting and the clock will show hour setting, the
screen will display: h.
- Press and to set the current hour
- Press to confirm hour setting and enter the minute setting, the screen
displays: .
- Press and to set the current minute
- Press to confirm all settings
Note: The clock and calendar will reset to factory default settings if unit is
completely powered down or without power supply.
Standard Heating Mode:
This mode can be used without the use of the weekly timer by choosing
Comfort mode or ECO mode. Press to select mode selection Comfort or
ECO. By pressing , heating mode runs in a continuous cycle as below:
• Comfort mode: Press and to set the temperature from 5-35℃.
• ECO mode: Press and to set the temperature from 1-31℃.
Note: ECO mode=Comfort mode - 4℃.

Use of countdown timer: In standard heating ECO or Comfort mode you can leave
the model on permanent or program the countdown timer so the unit turns off after
your set hours have elapsed, press the button once and the “0h” will flash,
using the or key choose your set hour from 0-9 hours. When the timer-off
function is enabled, the display shows the remaining time. Adjust the timer to 0h to
close this function.
Timer quick setting: Press one time, the screen display “0 h”, press one
time again to select the timer from 2h,4h,8h in a continuous cycle
• Anti-frost mode: Press the button until the screen displays . In this
mode you cannot set the countdown timer or adjust the temperature or set the
window open function. The target temperature is 7℃, if the room falls to 7℃or
below, the unit will operate. This is a preferred mode for garages, caravans etc.
Using the Preset programs 1 and 2:
Note: Clock and day setting must be set for correct usage of P1/P2 programs. It is
advised to set day and clock in advance for the program to work correctly.
Programs P1 and P2 are not adjustable and are pre-set.
To choose program P1 or P2 below press the button until P1 or P2 is chosen.
Set your preferred room temperature by pressing the or button. Once
temperature is chosen, the display will revert back to the chosen program P1 or P2.
The unit will now operate in P1 or P2 program.
See below for pre-set settings over a 7 day period for programs P1 and P2:
Program P1
• P1 (Figure 1) is a preset program Monday-Sunday. See image below for P1
preset program which shows the unit settings in a 24hr period which will repeat
over a 7 day period. (The image below (Figure 1) is just for illustration purposes
only and not shown on the LED display.)
P1: (Monday-Sunday) preset program.
00:00am – 01:00am comfort mode, 01:00am – 07:00am ECO mode
and 07:00am – 00:00am comfort mode.

Figure 1
Program P2
• P2 (Figure 2) is a preset program Monday-Friday and Saturday -Sunday. See
image below for P2 preset program which shows the unit settings in a 24hr
period which will repeat over a 7 day period. (The images (Figure 2 and 3)
below are just for illustration purposes only and not shown on the LED display.)
P2:(Monday-Friday) preset program
00:00am – 01:00am comfort mode, 01:00am – 05:00am ECO mode,
05:00am – 09:00am comfort mode, 09:00am – 19:00pm ECO mode,
19:00pm – 00:00am .
Figure 2
P2:(Saturday-Sunday) preset program
00:00am – 01:00am comfort mode, 01:00am – 08:00am ECO mode,
08:00am – 11:00am comfort mode, 11:00am – 13:00pm ECO mode,
13:00pm – 16:00pm comfort mode, 16:00pm – 20:00pm ECO mode and
20:00pm – 00:00am comfort mode.
Figure 3
Using the adjustable program 3:
P3: Can be adjusted to meet your requirements.
P3 is the only program that can be set to your requirements, each day and hour can
be set individually by following the instructions below.

•Below are examples of what you can adjust P3 program to, although you can
adjust this program to meet your own requirements. (Images (Figure 4 and 5)
below are just for illustration purposes only and not shown on the LED display.)
P3:(Monday-Friday) Adjustable program.
00:00am – 01:00am comfort mode, 01:00am – 05:00am ECO mode,
05:00am –09:00am comfort mode, 09:00am – 12:00pm ECO mode,
12:00pm – 16:00PM comfort mode, 16:00pm – 18:00pm ECO mode and
18:00pm – 00:00am comfort mode.
Figure 4
P3:(Saturday-Sunday) Adjustable program
01:00am – 05:00am ECO mode,05:00am – 01:00am Comfort mode
Figure 5
How to adjust P3 program setting:
It is good practice to spend time carefully studying and practicing the programming
of program 3 to fully understand the benefits which include time saving and cost
savings. If at any time you require assistance on how to program the product please
call out dedicated customer service help line on Customer Services on 0800 091
3171.
1. Press until P3 mode is chosen and displayed; press for 4 seconds until
is displayed and flashing.
2. Press and to choose the day you want to set from
(Monday-Sunday). Press to confirm the Day.

3. The screen displays for hour setting, press to choose either Comfort
mode or ECO mode or press so neither the Comfort or ECO lights show
so the heater will be in anti-frost mode. Press to move to the next hour to set or
to the previous hour to set, choosing Comfort mode , ECO mode or
show no lights for the unit to operate in anti-frost mode in this hour, repeat this
process up to hour 23, after setting hour 23, press to revert back to the current
day and press again to move to the next day to be set.
4. Repeat the operation until you have completed the schedule of every hour and
every day.
5. When the last day is programmed , press again to revert to .
6. Your settings are then saved and can be adjusted at any time to suit your needs by
simply following these instructions again.
7. The temperature can be set to your needs by simply pressing the or
button at any time whilst the unit is in operation.
Open window function:
Press and button together, the screen displays , then it comes back to
display target temp after 3 seconds (if there is timer, display remaining time), which
means that the open windows function is ready. When the item is heating, the
detected room temp drops rapidly over 2 degrees in 2 minutes, open window
function would be activated, while the screen would display and flash. The
item stops heating.
To exit open windows function, press to return the working mode when open
windows function was activated then screen stop flashing ,or wait 20 minutes to
automatically come back to previous working mode, or press to enter the
standby condition, the open window function would be reset when the item is turned
on again
To turn off open windows function completely: Press and button together,
the screen displays , then it comes back to display target temp after 3 seconds

PAT TESTING:
When used in a workplace, this product must be safety-tested yearly by a qualified
electrician (PAT Tested) in order to comply with the Electricity at Work Regulations.
We recommend that it is PAT tested regularly when used in a domestic environment.
OVERHEAT SAFETY DEVICE:
Your heater is fitted with a safety device to switch off the heater in the event of
overheating. If the safety device is operated, please turn the heater off, unplug the
heater and let it completely cool down, inspect for any blockages of the air inlet or
outlet, plug the heater back in and try again. Plug in the appliance and switch it on.
If the appliance can’t operate normally, remove the plug immediately from the
socket and contact your supplier for refund or replacement or advice.
MAINTENANCE:
1. The appliance needs regular external cleaning only.
2. After use and before cleaning always unplug or switch the unit off at the power
socket and wait until the item is cool.
3. When switched off and cool any dust can be lightly brushed off the grilles.
4. Using a soft, moist cloth, with or without a mild soap solution, carefully clean
the exterior surface of the product.
5. Do not clean the unit with abrasive materials or solvents.
6. Do not allow water or other liquids to run into the interior of the product, as this
could create a fire and/or electrical hazard.
The importer retains his right to make changes in appearance and completeness of
the item without preliminary notification to the customer.
The item is for indoor use only.
The manufacturer does not assume any liability for any damage caused directly or
indirectly by not following this instruction manual, general safety rules, or
interference in the construction of the product.

Information requirement for the electric local space heaters
Model identifier(s): MYBWF05ET
Item
Symbol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local space
heaters only (select one)
Nominal heat output
Pnom
0.5
kW
manual heat charge control, with integrated
thermostat
No
Minimum heat output
(indicative)
Pmin
0.5
kW
Manual heat charge control with room and/or
outdoor temperature feedback
No
Maximum continuous
heat output
Pmax,c
0.5
kW
electronic heat charge control with room and/or
outdoor temperature feedback
No
Auxiliary electricity consumption
fan assisted heat output
No
At nominal heat
output
elmax
NA
kW
Type of heat output/room temperature control (select
one)
At minimum heat
output
elmin
NA
kW
single stage heat output and no room
temperature control
No
In standby mode
elSB
0.00025
kW
Two or more manual stages, no room
temperature control
No
with mechanic thermostat room temperature
control
No
Model identifier(s): MYBWF08ET
with electronic room temperature control
No
Item
Symbol
Value
Unit
electronic room temperature control plus day
timer
No
Heat output
electronic room temperature control plus week
timer
Yes
Nominal heat output
Pnom
0.8
kW
Other control options (multiple selections possible)
Minimum heat output
(indicative)
Pmin
0.8
kW
room temperature control, with presence
detection
No
Maximum continuous
heat output
Pmax,c
0.8
kW
room temperature control, with open window
detection
Yes
Auxiliary electricity consumption
with distance control option
No
At nominal heat
output
elmax
NA
kW
with adaptive start control
No
At minimum heat
output
elmin
NA
kW
with working time limitation
Yes
In standby mode
elSB
0.00025
kW
with black bulb sensor
No
Contact details
Hygiene Supplies Direct Limited, Ground floor, Tayson House,
Methley Road, Castleford WF10 1PA

SERVICE WARRANTY
Hygiene Supplies Direct guarantees the product free from defects in materials and
workmanship for a period of 1 year from date of purchase. Should this unit be
operated under conditions other than those recommended, at voltages other than the
voltage indicated on the unit, or any attempts made to service or modify the unit,
then the warranty will be rendered void. The product you buy may sometimes differ
slightly from illustrations. This warranty is in addition to, and does not affect, your
statutory rights. If you have any problems with this product, please call our Help
Desk on 0800 091 3171 or email: [email protected]
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
The importer retains his right to make changes in appearance and completeness of
the item without preliminary notification to the customer.
The item is for indoor use only.
The manufacturer does not assume any liability for any damage caused directly or
indirectly by not following this instruction manual, general safety rules, or
interference in the construction of the product.
YESSS Electrical, YESSS House, Normanton, WF6 1TN declares that the Mylek Heaters are exclusively
manufactured and imported for Hygiene Supplies Direct Ltd
Made In China
