MYTORQ MYCS-ID50 User manual

OPERATION MANUAL FOR CHARGE STATION
ANLIDAR INDUSTRIAL CO., LTD.
http://www.anlidar.com
Y2F154-8E-001
MYCS-ID50-E
MYCS-ID50

1
Icon Explanation
Read manual Caution Double insulation Indoor use only No humidity
No fire No disassemble No disposal CE Certification ETL Certification
Caution
Please read all instructions carefully before operate the rechargeable battery and charger. Also please
follow all the instructions and pay attention to all the warring.
Important Notification
1. Please operate under the correct voltage to the charger in according with the operation manual.
2. When charging the battery, please make sure the grounding and safety components are properly attached
before operate.
3. The charger should store in clean and dry area. Do not place heave stuff on the charger. Please do not
charge the battery when the temperature is above 33℃.
4. Please do not place the charger in the poorly ventilated place, nor expose the charger in the dust or metal
crumb.
5. Do not expose the charger directly under sun, high temperature, high humidity , and highly explosive
gas.
6. Do not place charger on high shelf. The charger should be placed on the leveled, firmed spot that prevent
children from reaching.
7. Do not abuse the cord. Never use the cord to carry, pull or unplug the charger. Keep cord away from heat,
oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
8. Please read all instructions carefully before operate the charger. Failure to follow all instructions listed
below may result in electric shock fire and/or serious injure.
9. It is forbidden to use different brand of battery other then Kilews on the charger. To disassemble and
modify the charge are also not allowed.
Grounding Instruction
The charger needs to be grounded all the time in case of electrical shock. The grounding wire must be
connected firmly with power supply equipment for effective grounding result. The leading wire with
yellow-green color is a grounding wire. Never attempt to connect this yellow-green color wire on electrified
connector.

2
Caution
1. Please match the correct Lithium-ion rechargeable battery for this charger, which is only manufacture by
Kilews. Do not apply different type or brand of battery on this charger, otherwise may cause error or
danger.
2. Please match the charger with the battery models MYCS-ID50/MYCS-ID50-E.
3. The use of other than genuine Anlidar replacement parts or battery may result in decreased tool performance
and increased maintenance, and may invalidate all warranties.
4. Keep children, and bystanders away while charging the battery, in case of danger.
5. Please do not plug in the charger when the plug or users’ hand is wet.
6. To disassemble or modify the charger’s plug may cause danger or malfunction.
7. This charger only applies to the rechargeable battery of Kilews. Please do not apply the charger to other
different brand of battery or for other propose.
8. Please do not attempt to disassemble or modify the charger and the rechargeable battery.
9. USB jack: To update the firmware and maintenance only, users can not use this function.
Operation Instruction
1. Please check the cord to see if there any damage before plug in the charger. Hold the plug of power cord
while plugging in or unplugging charger.
2. Do not place chargers near oil, chemical materials or heated objects, also please be alert not to scratch the
power cord by sharp object.
3. When the charger is not in use, please unplug the power and store in dry safe place where it is not reachable
by children.
4. Charger and battery assemble
Assemble
MYCS-ID50
MYCS-ID50-E
Decomposition
MYCS-ID50
MYCS-ID50-E
(1).The direction of
battery when removing.
(2).Decomposition steps finished.
(2).Assemble steps finished.
(1).The direction of the battery
when inserting, push all the
way.
(1).The direction of
battery when removing.
(2).Decomposition steps finished.
(2).Assemble steps finished.
(1).The direction of the battery
when inserting, push all the
way.

3
Caution: Protection Functions
1. Over charged protection
2. Current protection
3. Shortage protection (fuse implement)
4. Battery reverse current protection
5. MYCS-ID50/MYCS-ID50-E Built-in ID recognition feature protection
6. Temperature protection
Temperature protection detail explanation
(1) When the battery temperature is between 0-10℃, the charger will use low current to pre-charge the
battery until the battery temperature higher than 10℃ , then the charger switch back to normal charging
mode. When the battery temperature is below 0℃, the charger will stop charging the battery.
(2) When the battery temperature is above 45℃, the charger will automatically change to low current to charge
the battery. When the battery temperature is exceed 50℃, the charger will stop charging the battery and
make warring beep sound.
(3) When the charger detects the battery temperature is lower 0℃ or above 50℃, then the charging process will
be stopped.
Display Description
Contents
Charger stand
1 pcs
Power cord
1 pcs
Operation manual
1 pcs
Warranty certification
1 pcs
Light Display and
Warning Beep
Description
Beeps
Red
light
Yellow
light
Green
light
Cell balance
N/A
OFF
Flash
OFF
Charging under 80%
N/A
Flash
OFF
OFF
Charging over 80%~99%
N/A
Flash
ON
OFF
Charging Complete100%
Three long beeps
ON
OFF
ON
Charging Error
Continuous short beeps
Flash
OFF
Flash
ID matched OK
One second short B sound
----
----
----
ID matched NG
N/A
Flash
OFF
Flash
Idle mode
N/A
ON
OFF
OFF
Light Display

4
Specification
Caution
SAVE THE INSTRUCTIONS
DO NOT DESTROY
Model
Charger Station
MYCS-ID50
MYCS-ID50-E
Battery Identification
Yes
Yes
Input Voltage
100V –240V
Output Voltage
12.6VDC
Output Current
3A
Dimension W ＊L ＊H
145mm＊115mm＊93mm
145mm＊115mm＊80mm
Weight
0.5(Kg)
Battery Type
Li-ion
Applicable Battery Models
Charging Time
Battery Capacity
SKC-LB1025S
Prox. 40min
2500 mAh
SKC-LB1025E
Prox. 40min
2500 mAh

KILEWSINDUSTRIALCO..LTD.
CUSTOMER
ITEM NO:
TITLE:
DWG NAME
DWG NO:
MATERIAL
DES. BY
CHKD.BY
APPD.BY
SHRINK
DATE
DATE
DATE
PRODUCTION NO.
THIRD ANGLE PROJECTION.
UNITSCALESHT NO.
OF SHTS.
MODELNO:
MYCS-ID50
接點
位置
接點
位置
編
號排插圖示

KILEWSINDUSTRIALCO..LTD.
CUSTOMER
ITEM NO:
TITLE:
DWG NAME
DWG NO:
MATERIAL
DES. BY
CHKD.BY
APPD.BY
SHRINK
DATE
DATE
DATE
PRODUCTION NO.
THIRD ANGLE PROJECTION.
UNITSCALESHT NO.
OF SHTS.
MODELNO:
MYCS-ID50-E
接點
位置
接點
位置
編
號排插圖示
