MYTORQ MYBT-ASP0520 User manual

Automatic Industrial Cordless Brushless
Power Torque Screwdrivers Series
OPERATION AND MAINTENANCE MANUAL
Rechargeable -TYPE Automatic Brushless Series
SAING EI CORP.
https://www.mytorqtools.com
Y2F151A-15E-002
MYBT-ASP0520
MYBT-ASP1030
MYBT-ASP2045

1
Before you use the Cordless Screwdriver for the first time, it is
essential to read and understand the manual completely (including
the spare parts view). The term “Cordless Screwdriver” in all of the
warning listed below refers to your main operated appliance.
Icon Instructions
1. 2. 3. 4.
5. 6. 7. 8. 9.
1. Read instruction manual.
6. Do not operate in an explosive atmosphere.
2. Observe caution and safety notes.
7. Do not disassemble.
3. Recyclable.
8. Forbid to throw away.
4. For indoor use only.
9. CE certification.
5. Do not expose to wet or rain conditions.
Accessories
Item
Quantity
Unit
Manual
1
PCS
Waist hook
1
PCS
Driver hook
1
PCS
Screw M3*0.5P*8L
1
PCS
Bit
2
PCS
Guarantee Card
1
PCS

2
Warning
Read all instructions and make sure the appearance of the device has no damage before you use it.
Failure to follow all instructions listed below may result in electric shock fire and/or serious injury.
1. Keep the working area nice and clean.
1.1 Mess and dark areas may cause of accidents.
1.1 Keep the device away from rain or moisture to decrease the risk of electric shock or short-
circuiting occurred.
2. Be alert to workplace safety
2.1 Use the device under a well lit and clean environment.
2.2 Keep children and other people away unless the person has been assigned for the task to avoid the
danger of injury.
2.3 Do not play around while the tool is being used to avoid the danger of distractions.
2.4 Do not work with the device in potentially explosive environments in which there are
inflammable liquids, gases or dusts. Electrical power tools create sparks, which can ignite dusts or
fumes.
2.5 Do not use the device if you are tired or under the influence of drugs, alcohol or medication.
3. When the devices are not being used, store them in a safe place.
4. Use a suitable device for the job will be safer at work and have a better result.
5. Always use a screwdriver that is intended for the task you are undertaking. Do not overload or use
it improperly such as drilling or tapping.
6. Dress properly. Do not wear loose clothing or jewels while operating the tool to avoid the danger
of trapping.
7. By using the device correctly, make sure to hold it firmly with two hands in place before starting
the trigger.
8. When using the electrical power tool, take into account the auxiliary handle or waist hook is
advantage of working conditions. On the contrary, the purposes of the waist hook or driver hook is
convenient to put the device away and easier to keep it out of reach of children.
9. Look after either the device or the battery carefully and have any damaged parts repaired by an
authorized or qualified shop. Always keep the tool nice and clean; pay attention on the machine
grease which might ruin the tool.
10. Disconnect the plug from the power source after the charger has been used.
11. Take apart the battery from the device when it is not being used.
12. Use only the accessories that are detailed in the operating instructions. The use of others which are
not recommended in the operating instructions may affect the functioning of the device. It could
lead to an increased risk of personal injury as well.
13. Remain alert at all times and watch what you are doing during proceeding. Before operation,
always check every part is in good condition and move freely in order to function properly.
14. This device only applies for metal screw bits designated with their dimensions and their shape. Do
not recommend to countersink or force of loading on any material such as plastic and wooden.
15. The device does not apply for elastic or tensile load with washer on.
16. To prevent parts in gearbox from damage, replace the grease at least once for every year.
17. It is necessary for the operators to read and follow up all the operating instructions in this manual.
SAING EI is not responsible for any personal injury that might cause of disobeying the safety
advice.
18. Use a safety device. Wear protective earmuffs to reduce personal injury.

3
19. Noise:
The typical A-weighted noise level acc. To EN62841-2-2
.Sound pressure level(LpA): 53.6 dB(A)
.Sound power level(LwA): 64.6 dB(A)
Vibration:
The vibration total value acc. EN62841-2-2
.Vibration emission value ah (m/s²): 0.17 m/s²
.Uncertainty K (m/s²): 0.02 m/s²
Cordless Tool Protections
▉Over electric current protection ▉Prevent from low power
▉Thermal Protector ▉Stall protection
▉Slow rotation protection ▉Sleep & power saving mode
▉Battery Identification ▉
Start operation protection: The screwdriver cannot
switch the opposite direction during operation
Warning
Do not attempt to repair or disassemble this cordless screwdriver, the warranty
will be considered void.
1. To maintain the tool, make sure to remove the battery pack before maintaining or repairing the
device by a qualified technician.
2. Do not attempt to disassemble or reassemble the device it may result in poor performance or
danger of injury; the warranty applies only to initial package.
3. Do not repair the device with other than genuine SAING EI replacement parts may result in
poor performance or danger of injury, the warranty will be considered void.
4. temperature between 0∘C ~ 35∘C would be an ideal condition of carrying out the tasks on the
device.

4
Operating Instructions
1. Charge the battery in the charging station before first use to make sure operates at its highest
capacity. To ensure operators against injuries, Don't Press Pressure plate trigger before start or
disassemble the device and push down screwdriver.
2. Follow below steps to correctly install & remove battery.
Insert Battery Steps
Remove Battery Steps
(1) Take screwdriver and battery.
(1) Press the release button and take it out of the
Device.
(2) Insert the rechargeable battery into the device
follow by the arrow as showing.
(2) Follow the arrow direction.
(2) Follow the arrow direction. (3) Removed completely.
Battery
Release Button

5
Function / Operating Introduction
Function Name Figure
No. Description
(1) push down the screwdriver to start
(2) Trigger Switch
(3) Bit Sleeve
(4) Torque Fixing Ring
(5) Torque Fixing Ring/Coupler
(6) Driver Hook
(7) S waist Screw Hole
(8) S Waist Hook
(9) OK/NG/Power/Hi &Lo Indicating Light
Manual / Function
1. Full Auto Shut-Off Screwdriver
It stops automatically when the screw has been tightened up and reached the set-up torque level.
The device will not cause damage of task since no continue running after screws are tightened.
(1) MYBT-ASP0520 series are push start type cordless screwdriver. Holding screwdriver (without
press lever) push it all the way down to your object and at this moment screwdriver's bit is
making clockwise turn. The screwdriver can be shut off by either stop pushing or when screw
has been tightened up.
(2) Lever: It will enable reverse mode by press lever on MYBT-ASP0520 series. To do so:
(a.) Press lever from your screwdriver.
(b.) Push screwdriver against to your object and at this moment screwdriver’s bit is turning
counterclockwise. To stop spinning by stop pushing screwdriver.
(c.) It will not change bit’s spinning direction if leave or press lever during pushing screwdriver.
(9)
(8)
(7)
(6)
(2)
(5)
(4)
(3)
(1)
push down
screwdriver
Forward (screw) Reverse (unscrew)
(1). Press lever from
your screwdriver
(2). push down
Screwdriver

6
(3) Bit Sleeve
To Switch the bit and compatibility, pull the head of the type B screwdriver, and install the bit
according to the diagram below, and push it in following the arrow indicated on the diagram.
(4) Torque Adjustment Ring:
Turn torque adjust ring counter clock wise to increase torque output, on the other hand decrease
torque output by turning torque adjust ring clock wise. 0 printed on the torque adjust ring
indicates the minimum torque for setting and 8 for the maximum torque setting. Do not turn
torque adjust ring lower than 0 or higher than 8 to avoid torque adjust ring getting stuck with
clutch.
(5) Torque Fixing Ring/Coupler
5-1 Torque Fixing Ring: To prevent torque to be adjusted, fixed upside-underside housing and
clutch.
5-2 Coupler: Fixed upside-underside housing and clutch.
(6) Driver Hook
It is convenient for the production lines efficiently to have spring balancers to work together
with the tools to be more.
(7) S Waist Screw Hole
(8) Waist Hook
The waist hook allows users to carry the device easily by attaching it to their work belt.
Coupler
Torque Fixing Ring
Pull the bit holder
Insert the bit into

7
(9) OK/NG/Beep Sound Indicating Light Explanation
Protection:
1. Protection at low voltage: short beeps come with red-light flashing when enable screwdriver,
and then disable screwdriver that both beeps and red-light flashing keep going for 5 seconds which
means the battery’s voltage now is low. If screwdriver could not be started by pushing it and come
with 2 short/ 1 long beeps plus red-light flashing the battery is now out of power; moreover,
followed by the above situation then release screwdriver from pushing, both beeps and red-light
flashing signs will remain the same. (The screwdriver will not detect battery power when enable
motor and PCBs’ temperature protection.)
CAUTION!!
Low battery indicator on: When low battery protected indicator on, screwdriver can not reach to its
maximum torque setting. Please change battery pack or charge it.
2. Temperature Protection: When red-light begins flashing along with beeps for 9 times the
screwdriver will be locked.
3. Sleep & Power Saving Mode: It will enter sleep mode when the screwdriver stopped for about 5
seconds, press the lever can wake up sleep. The power will be cut off when sleep more than 24
seconds, press the switch can restore power.
Signal Indicator
Sound Judgment
Start
Release switch
to stop running
Screw reaches
set torque
Screw NG
Current
Protection
Signal
Indicato
r
Running No lights 1
red
1
green
3
red
6
red
Stop No lights No lights No lights No lights No lights
Beep Sound No 1 short NO 3 shorts 6 shorts

8
Other Cautions
1. The best condition of using the tool is under 8 hours a day, do not over loaded.
cording to operating frequency and torque loaded, we suggest adding lubricating oils in clutch
per 3-6 months, and kindly contact with distributor when product's maintenance.
2. Do not attempt to repair or disassemble this cordless screwdriver without authorization. Always
have the device serviced by assigned factory or qualified person in order to have the warranty
effective continually.
3. SAING EI is not responsible for any poor performance or damage caused by customers own
modification of the tool.
4. It is necessary for the management to have every operator to read and follow all instructions in
this manual. Do not attempt to repair or disassemble this cordless screwdriver themselves.
5. Chemicals, Acetone, Benzene, Alcohol, Thinner, Ketone, trichloroethylene, etc. shall not be in
contact with the surface of the screwdriver in order to prevent chemical damage.
6. Please follow instruction carefully and do not drop or shock the screwdriver.
7. This is an external torque adjustment screwdriver, 0 on the torque adjust ring stands for
minimum torque and 8 for maximum torque. The rated operation time is 1 second / 3seconds
(ON / OFF). Appropriate fastening frequency is 15 fasteners in each minute. Overrunning may
damage motor due to overheat. Proper amount of screwdriver resting is recommended to prevent
motor overheating.
8. The screwdriver could not be used before end of OK/ NG beeps and light signal.
9. For your safety stop operating your screwdriver in any time during torque adjustment and be
aware of mistouch any trigger from your screwdriver.
10. Each operational torque setting, using time and frequency may result in different level of wear
and tear, at higher torque setting and use extensively could accelerate the wearing down of tool.
After one month, the torque is getting reduce gradually at the rate of 2~3% or 3~5 %( max
torque). The longer use of the device, torque reduction will become stable and the users could
measure the torque by a tester on a regular time schedule to check if the torque power still meets
the criteria.
11. The torque range of MYBT-ASP0520 series must be measured by the SAING EI torque meter
KTM-150.
12. SAING EI cordless screwdriver torque output is generated by clutch mechanism, and it is
applicable to ISO 6789.
Slow speed
(rpm)
operation
frequency
Slow speed
(rpm)
operation
frequency
Slow speed
(rpm)
operation
frequency
Slow speed
(rpm)
operation
frequency
900
1.0 ON 3.0 OFF
650
1.0 ON 3.0 OFF
450
2.0 ON 5.0 OFF
250
2.0 ON 5.0 OFF
850
1.0 ON 3.0 OFF
600
1.0 ON 3.0 OFF
400
2.0 ON 5.0 OFF
200
2.0 ON 5.0 OFF
800
1.0 ON 3.0 OFF
550
2.0 ON 5.0 OFF
350
2.0 ON 5.0 OFF
150
2.0 ON 5.0 OFF
750
1.0 ON 3.0 OFF
500
2.0 ON 5.0 OFF
300
2.0 ON 5.0 OFF
100
2.0 ON 5.0 OFF
700
1.0 ON 3.0 OFF

9
Specifications
* 1N.m=10.2Kgf.cm 1N.m=8.85Lbf.in
Bits Code ~ B: Hex 6.35mm
Accessory ~Ｂit no.：No.2．．．．Bit use in dia 3.0~4.0mm screw
MYBT-ASP0520 with BIT 1# & 2# 1 Pcs. Each.
MYBT-ASP1030/ MYBT-ASP2045 with BIT 2# 2 Pcs.
CAUTION
SAVE THE INSTRUCTIONS
DO NOT DESTROY
MODEL MYBT-ASP0520 MYBT-ASP1030 MYBT-ASP2045
INPUT VOLTAGE(DC)
DC 10.8V
TORQUE
(N.m)
hard joints
0.5-2
1-3
2-4.5
soft joints
80%↓
0.5-1.6 1-2.4 2-3.6
Torque accuracy (%)
±3%
Torque adjustment
Stepless
Duty cycle
1.0s ON 3.0s OFF
Unloaded Speed
(min-1 )±10%
HI
1200
1200
700
LO
850
850
500
Screw size (mm)
Machine
screw
2.3~3.5 2.6~4.0 4.0~5.0
Weight (g)
720g (contain battery)
Length (mm)
300mm (contain battery)
Model of Torque Fixing Ring
KC-28A
Model of Suspension Rack
KH-1
Applicable battery
SKC-LB1030S
Applicable charger station
MYCS-ID50
Applicable Bit type
HEX 5mm, HEX 6.35mm

10
To adjust the torque on these screwdrivers. Proceed as follows :
1. Determine the torque output of the tool by checking a tightened fastener with a torque wrench.
2. Increase or decrease the torque by rotating torque Adjusting Ring. Rotating the Ring clockwise
to a higher number on the torque Scale increase torque output while rotating the Ring
counterclockwise to a lower number decreases the torque output.
3. Check the adjustment with a torque wrench. A number of factors will affect torque output from
one job to another. Final torque adjustment should be made at the job through a of series of
gradual increase. Always start below the desired torque and work upward.
4. Adjust the bit torque by changing the driving in length of the adjust ring at the end.
5. The relationship between torque scale and bit torque is as shown Ring, in the torque diagram.
The figures of torque scale do not indicate bit torque values. However, the clamping torque of
screw itself is different form type, size, material of the screw and the material of its mating part.
Use it as standard to obtain an appropriate clamping torque.
6. The (Return torque method) in which once-clamped screw is returned with torque wrench or the
like is available as one of torque control methods, however, note that the measured values by the
return torque method generally appear in 10%~30% lower than the actually clamping torque.
7. The torque checker measures the torque of screwdriver. The clamping torque of screw itself is
different from the clamped conditions. Understand the correlation between clamping torque
values and the torque checker values perform the torque control properly.
1. In reverse rotation, the clutch is turned off when a screw is tightened at large torque, set same
or higher torque to unscrew.
2. The number from zero to eight on the Torque Scale are reference number only and not an
indication of actual torque output.
3. Please refer to SAING EI websitehttps://www.mytorqtools.com for the detail component list.
Torque Adjustment Operation
CAUTION
Our company reserves the right to modify the product without prior notice.
