Nakayama PB6210 User manual

WWW.NIKOLAOUTOOLS.GR
ART NO:
FR
RO
el
SL
EN
IT
BG
PB6210 PB6310
024255 - 024248 2.2

WWW.NIKOLAOUTOOLS.GR
2
1
3 4
5 6
2
27 8

WWW.NIKOLAOUTOOLS.GR
3
9 10
11
12
13 14
16
17 18 19
15

EN
WWW.NIKOLAOUTOOLS.GR
4
Descripon of symbols
Safety instrucons
Symbols are used in this manual to aract your aenon to possible risks. The safety symbols and the explicaons which accompany them must be perfectly
understood. The warning themselves do not prevent the risks and can not be a substute for proper methods of avoiding accidents.
This symbol, before a safety comment, indicates a precauon, a warning or a danger. Ignoring this warning can lead to an accident for yourself or for
others. To limit the risk of injury, re or electrocuon always apply the recommendaons indicated.
Before any use, refer to the corresponding paragraph in the present manual. Read the
instrucon handbook and follow all warnings and safety instrucons.
Conforms to relevant safety standards.
Keep all children, bystanders and helpers 15
meters away from the brush cuer.
The exhaust and other parts of the engine will get very hot
during use, do not touch.
Gasoline is very ammable. Avoid smoking or bringing any
ame or sparks near fuel.
Beware of thrown objects hit by cung aachments.
Never use without properly mounted blade guard. The max speed marking.
Beware of foot injury by cung aachment Wear head protecon, hearing protecon and eye
protecon when using the device.
Wear robust footwear when using the device. Wear protecve gloves when using the device.
The part to refuel the “MIX GASOLINE” on fuel tank cap.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilies, or lack of experience and knowledge,
unless they have been given supervision or instrucon concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
1) Training
- Read the instrucons carefully. Be familiar with the controls and the proper use of the appliance.
- This product has been designed for use in cung grass, and it should never be used for any other purpose.
- Never allow children or people unfamiliar with these instrucons to use the appliance. Local regulaons may restrict the age of the operator.
- Never mow while people, especially children, or pets are nearby.
- The operator or user is responsible for accidents of hazards occurring to other people or their property.
- Avoid running the engine indoors. The exhaust gases contain harmful carbon monoxide.
2) Preparaon
- While cung, always wear substanal footwear and long trousers.
- Do not operate the appliance when barefoot or wearing open sandals.
- Thoroughly inspect the area where the appliance is to be used and remove all stones, scks, wires, bones, and other foreign objects.
- Before using, always visually inspect to see that the blades, blade bolts and cuer assembly are not worn or damaged. Replace worn or damaged blades and
bolts in sets to preserve balance.
- On mul-bladed appliances, take care as rotang one blade can cause other blades to rotate.
3) Operaon
- Operate only in daylight or in good arcial light.
- Avoid operang the appliance in wet grass, where feasible.
- Always be sure of your foong on slopes.
- Walk, never run.
- Exercise extreme cauon when changing direcon on slopes.
- Do not cung excessively steep slopes.
- Use extreme cauon when reversing or pulling the appliance towards you.
- Never operate the appliance with defecve guards or shields, or without safety devices.
- Switch on the motor according to instrucons and with feet well away from the blade(s).

EN
WWW.NIKOLAOUTOOLS.GR
5
Descripon of main parts
Addional safety warnings
- In this case, do not lt it more than absolutely necessary and li only the part which is away from the operator. Always ensure that both hands are in the
operang posion before returning the appliance to the ground.
- Do not put hands or feet near or under rotang parts.
- Never pick up or carry an appliance while the motor is running.
4) Maintenance and storage
- Keep all nuts, bolts, and screws ght to be sure the appliance is in safe working condion.
- Check the grass catcher frequently for wear or deterioraon.
- Replace worn or damaged parts for safety.
For rotary mowers, ensure that only replacement cung means of the right type are used.
- Never store the equipment with petrol in the tank inside a building where fumes can reach an open ame or spark;
- Allow the engine to cool before storing in any enclosure;
- To reduce the re hazard, keep the engine, silencer and petrol storage area free of grass, leaves, or excessive grease;
- If the fuel tank has to be drained, this should be done outdoors.
1. Grip the handles of the brush cuer rmly with both hands. If you suspend the work, Place the throle into the idling posion.
2. Always be sure to maintain a steady, even posture while working.
3. Maintain the speed of the engine at the level required to perform cung work and never raise the speed of the engine above the level necessary.
4. If grass gets caught in the blade during operaon , or if you need to check the unit of refuel the tank always be sure to turn o the engine.
5. If the blade touches a hard object like a stone immediately stop the engine and check it something is wrong with the blade. If so,replace the blade by new
one.
6. If someone calls out while working , always be sure to turn o the engine before turning around.
7. Never touch the spark plug or plug cord while the engine is in operaon .Doing so may result in being subjected to an electrical shock .
8. Never touch the muer ,spark plug or other metallic parts of the engine while the engine is in operaon or immediately aer shung down the engine.
Doing so may result in serious burns .
9. When you nish cung in one locaon and wish to connue work in another spot, turn o the engine and turn the unl as the blade faces away from your
body.
10. Check the cung aachment stop turning under the engine idle before start to use the machine.
A
1
2
3
4
5
6 7
8
910
20
19
18
17 15 16
23 22 21
13
11
12
14

EN
WWW.NIKOLAOUTOOLS.GR
6
Component list (picture A)
Intended use
Assembly
Technical data
Displacement: 62cc
Power: 3hp
Sha diameter: 28mm
Handle type: Bicycle handle
Belt type: Double
Cutting diameter: 255mm (brush cutter) 440mm (grass
trimmer)
* The manufacturer reserves the right to make minor changes
to product design and technical specicaons without prior no-
ce unless these changes signicantly aect the performance
and safety of the products. The parts described / illustrated in
the pages of the manual that you hold in your hands may also
concern other models of the manufacturer’s product line with
similar features and may not be included in the product you just
acquired.
* To ensure the safety and reliability of the product and the war-
ranty validity, all repairs, inspecon, repair or replacement work,
including maintenance and special adjustments, must only be
carried out by technicians of the authorized service department
of the manufacturer.
* Always use the product with the supplied equipment. Oper-
aon of the product with non-provided equipment may cause
malfuncons or even serious injury or death. The manufacturer
and the importer shall not be liable for injuries and damages re-
sulng from the use of non-conforming equipment.
This brush cuer has been designed for cung grass. Any other use is not permied.
The brush cuer is suitable for private use in the garden only, brush cuer for private use are those which are used for cung grass in the garden, however not
for cung grass in public parks, playing elds or on farms or in forest.
Non-permied users:
Persons who are not familiar with the operang manual, children, young people under the age of 16 as well as persons under the inuence of alcohol, drugs
or medicaon must not operate the unit.
Working hours for gasoline brush cuers.
While it is permied to use a brush cuer at any me, operators should always show due consideraon to others living nearby.
1. Connecng the aluminum sha to the motor (pictures 1 and 2).
1.1 Align the four screw holes on the sha reducer and on the side of the four brush cuer motor housing screw hole and insert the screws into the hex
wrench holes (as shown in pictures 1 and 2).
2. Installing the handle (pictures 3 - 6).
2.1 Remove the staple handle and staple plate.
2.2 Place the handle sha on the bracket handle, then clamp plate and staple handle back on the handle sha and ghten the staple handle so that rmly
secure the handle.
3. Installing the plasc cover (pictures 7 and 8).
3.1 Align the two screw holes on the board with the screw holes on the plasc board.
3.2 Insert the two combinaon screws into the screw holes and ghten them securely with the Allen key shut, then nish the installaon.
4. Assembling the cung head.
4.1 Release the nut (pictures 9 and 10). Line up the two holes of ange and shield, use one screw driver to hold the ange as below and turn the socket
wrench clockwise, the nut will be released.
1 Le handle
2 Right handle
3 Throle lever
4 Lock OFF lever
5 Engine switch
6 Safe guard
7 Blade
8 Nylon cuer
9 Fuel bole
10 Screw driver
11 Inner ange
12 Outer ange
13 Shield
14 Nut
15 Spark plug cover
16 Engine
17 Air lter
18 Recoil starter handle
19 Belt
20 Handle bracket
21 Wrench
22 Hex
23 Hex wench
PB6210 & PB6310*
* PB6310 = equipped with antivibration

EN
WWW.NIKOLAOUTOOLS.GR
7
4.2 Fit the Nylon cung head (pictures 11 and 12). Remove another shield aer release the nut. Sll hold the ange, take the Nylon cung head on the sha
and rotate counter-clockwise, the Nylon cung head is ed.
4.3 Release the Nylon cung head (pictures 11 and 12). Use screw driver to hold ange and then rotate the Nylon cung head clockwise, it will be replaced.
4.5 Release blade (pictures 13 - 19). Use screw driver to hold ange and release nut, the blade can be took o.
Warning!
Please make sure the cung head has been assembled correctly before
use!
Note: The packaging material is made of recycle materials. Dispose of
packaging materials in accordance with regulaons.
Danger of injury! Fuel is explosive!
DANGER! - Turn o and cool the motor down before lling
the tank with fuel.
- You must observe all safety instrucons relang to handing
fuel.
Warning! Take care of the emission of exhaust gases.
Always shut o engine before fueling. Never add fuel to a
machine with a running or hot engine. Take care of re!
Risk of device damage!
The device is supplied without motor or gearbox oil.
ATTENTION! Before operang, you must ll it with fuel.
Filling up with fuel | Draining fuel
Never use oil for 4-cycle engine use or water cooled 2-cycle engine. It can cause spark plug fouling exhaust port blocking or piston ring scking.
Mixed fuels, which have been le unused for a period of one month or more may clog the carburetor or result in the engine failing to operate properly.
Put remained fuel into an airght container and keep it in the dark and cool room.
Recommended mixing rao:
Use a special type 2-cycle engine oil (30ml of oil for each 1 litre of unleaded gasoline 94 octanes or higher).
– Unscrew the tank cap and remove it.
– Pour in the fuel carefully. Avoid spilling!
– Screw the tank cap on rmly by hand.
Draining fuel
– Hold a collecon container beneath the fuel
drain bolt (not included on all models).
– Unscrew the tank cap and remove it.

EN
WWW.NIKOLAOUTOOLS.GR
8
Danger of injury!
Do not operate the device unless you did not nd any faults.
If a part has became defecve, make sure to replace it before
you use the device again.
Danger of injury!
Before starng work, always check the ground and remove all
objects which could be thrown by the device.
Operaon
Starng and stopping the engine.
Do not start the unit unl it has been completely assembled. Before switching on the unit, always checking the oil.
Check before use!
– Check the device for leaks.
– Check the device for visual defects.
– Check that all parts of the device have been securely ed.
– Check that all safety devices are in proper condion.
Once the machine has been set up properly, start the engine as follow:
1. Press the fuel pump more than 5 mes. 2. Turn the engine switch to the ON posion.
3. Put the choke lever on the OFF posion 4. Pull the recoil starter handle to start the engine,
as following picture.
5. Wait a while adjust the choke lever to ON posion.

EN
WWW.NIKOLAOUTOOLS.GR
9
When the engine has been switched o, the cuer connues
running for several seconds therefore do not stand close to
cung head of brush cuer unl the cuer has come to a
standsll!
Maintenance
6. When the engine is running and idling. The throle lever on handle is as above picture. First press the lock o lever and then switch the
throle lever on, the machine will be working.
7. If use Nylon cuer, before cung, need
bump to feed line on hardness area
8. If meet any problems, press the engine
switch, the machine will stop running. If need
stop cung head working, release the throle
lever.
9. If the machine is hot, the choke lever can be
adjusted to ON posion directly when re start
the machine.
Before performing any maintenance or cleaning work, Always turn o the engine.
1. Do not spray the unit with water. Ingress of water may damage the engine and electrical connecon.
2. Clean the unit with a cloth, hand brush, etc.
Maintenance schedule
12 hours of use 24hours of use 36hours of use
Air lter Clean Clean Replace
Spark plug Check Clean Replace
Expert inspecon is required:
a) If the brush cuer strikes an object.
b) If the motor stops suddenly
c) If the blade is bent (do not align!)
d) If the gears are damaged.
Replacing and resharpening the cung blade at the end of the mowing season always resharpen the cung blade or, if required, replace the cung blade
with a new one. Always have the cung blade resharpened or replaced by a Service center (measurement of imbalance).

EN
WWW.NIKOLAOUTOOLS.GR
10
Unbalanced blades will cause the lawn mower to vibrate violently-risk of accident !
Change and clean the spark plug
1) Once the engine has cooled, remove the spark plug using the socket spanner supplied.
2) Clean the plug with a wire brush.
3) Using a feeler gauge; set the gap to 0.6-0.7 mm.
4) Install the spark plug carefully by hand, to avoid cross-threading.
5) Aer the spark plug is seated, ghten with spanner to compress the washer.
Clean the air lter
Unclip the air lter cover and remove the sponge lter element. To avoid objects falling into the air tank, replace the air lter cover. Wash the lter element
in warm soap water, rinse and allow drying naturally.
Warning! Never run the engine without the air lter element installed.
Storing the unit
Aer cung, clean the unit thoroughly. Store the unit in a dry room allow the motor to cool down beforehand.
Troubleshoong
Before performing any maintenance or cleaning work, always turn o the engine and wait unl the cuer has come to a standsll
1) Engine does not run:
- Check if there is fuel in the fuel tank.
- Make sure the ON/OFF switch is in the ON posion.
- Make sure the spark plug cable is in posion.
2) Engine power drops:
- Have cung blade resharpened /replaced (customer service center)
3) if the temperature of machines is too high :
- Insure the machines have rest at regular me.
Faults that cannot be repaired with the help of the above instrucons can only be repaired by an authorised service department.
