HL80 Series LED High Mast Light
Products description and application
HL80 series modular LED high mast lights, combined with a variety of optical
lenses, provide lighting solutions with high efficiency, energy saving and low
maintenance rate, and provide stable and comfortable lighting effects for the
lighting area, so that staff can focus more on work safety and improve work
efficiency. It is mainly used for industrial lighting in ports, large-scale
operation mines, airports, stadiums and other places.
Features
⚫High thermal conductivity aluminum extrusion molding heat sink,
improve LED service life.
⚫Well-designed heat flow channels keep the luminaire excellent heat
dissipation performance.
⚫Equipped with waterproof and breathable valve to balance the
temperature and pressure inside and outside the lamp to protect the
LED light source device.
⚫A variety of optical light distribution options are available for more
lighting scenarios.
⚫Clear and visible illumination angle adjustment, suitable for lighting in a
variety of different positions.
⚫Optional light shield can be used to make the light interception effect of
lamps better and effectively reduce glare.
General Specifications
Standard
CE：
EN60598-1、EN60598-2-5、EN62493、EN62471、EN55015、EN61547、EN61000-3-2、EN61000-3-3
UL：
UL1598、UL8750/CSA C22.2 NO250.0-08、CSA C22.2 No250.13
Electrical
Mechanical
Rated voltage
100-240VAC
Color
Silvery white
Frequency
50/60Hz
Housing
Aluminum alloy
Rated power
400W 600W 800W 1000W
Cover
PC
PF
PF＞0.9
Finish
Anodized
EMC
IEC61000-4-2 Contact discharge:8KV
Weight
12Kg 17Kg 22Kg 28Kg
Air discharge:15KV
Mounting
Bracket
IEC61000-4-3 800~1000MHz 10V/m
Ta
-40˚C ~ +50˚C
IEC61000-4-4 ±2KV
Vibration level
ANSI C136.31 1.5g
IEC61000-4-5 DM:±6KV CM:±10KV[1]
IP Rate
IEC60529 IP67
IEC61000-4-6 0.15~80MHz 10V/m
Anti-corrosion
ISO12944 C5 M
EN55015 CLASS C
Wiring method
Lead wire
Photometric
Light source
LED
Source life
≥50000h
Color temp
Cold white:5700K Warm white:2700K
Beam angle
30°/60°/Asymmetric20°×100°
CRI
Cold white:Ra≥70 Warm white:Ra≥80
Luminous
efficacy
（30°/60°）Cold white:150lm/W Warm white:125lm/W
Asymmetric（20°×100°）Cold white:140lm/W Warm white:120lm/W
[1] This standard test meets the functional state B. It is normal for the lamp to flash at the moment of surge, and it can be
automatically recovered.

2|5 datasheet-HL80-2209-en.1.1
HL80 Series LED High Mast Light
Mounting dimensions
Unit:mm
Installation and use method:
1. Drill holes on the intended installation surface.
The lamp should be fixed to the installation
surface with M12 bolts and anti-separation nuts.
The installation surface should be flat and have
sufficient mechanical strength.
2. The installation height is greater than 3 m, two
or more screws are required.
3. Adjust the fixture to the angle and direction
that needs to be illuminated and fix it firmly.
3.1
3.2
3.3
4. Fix the safety chain in a suitable place, and
the fixing surface should have sufficient
mechanical strength.
930
430
374 171
316
HL80-400W
HL80-600W
HL80-800W
HL80-1000W
90
150
240
14
14
80
180
14
14
300
80
180
14
14
80
180
14
14
171
283
430
374
550
740
430
374 171
316
360
430
374 171
262
√
×
17
≤4mm
!
90°
3°
3°
0
15
30
45
60
75
90
15
30
45
60
75
90
17
12N.m
!

3|5 datasheet-HL80-2209-en.1.1
HL80 Series LED High Mast Light
Wiring diagram
Wiring usage:
1. Non-professional electricians do not operate.
2. Make sure the circuit power switch is turned off before
wiring.
3. The external power cord of the lamp must meet the
three-core sheathed wire of at least 16AWG (1.3mm²).
4. Connect the power supply wire directly to the L, N, PE
terminal or the external power cord of the lamp (need to
pay attention to the corresponding polarity, and handle the
waterproof and anti-electric shock at the connection).
5. For your safety, please make sure the light fixture is well
grounded in the circuit.
6. The power cord can only be turned on after checking
that the connection is correct.
Lighting distribution curve
Precautions
1.PC material parts of the product should not be in direct or indirect contact with industrial alcohol, banana
water, isopropanol, carbon tetrachloride, cyclohexanone and other organic solvents, otherwise there will be
the risk of corrosion and cracking.
2.Ensure that the circuit power switch is off before wiring, please connect to rated working voltage when
using.
3.Lamps are not suitable to be covered by thermal insulation materials, maintain good ventilation.
4. Lamps are not suitable for direct installation on the surface of common combustible materials.
5. The shortest distance between the lamp and the object to be illuminated is 3 meters to avoid fire.
6. When using the lamp, do not look directly at the bright light source.
7. When the lamp is in use, the surface of the shell and lampshade has a certain temperature rise, which is
a normal phenomenon.
8. Replacement and maintenance of lamps should first cut off the power supply, and should be carried out
by professionals after the lamps are cooled.
9. "Do not stare at the operating light source" "The luminaire should be positioned so that prolonged
staring into the luminaire at a distance closer than 10,976 m is not expected".
10. To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be effectively fixed
to the wall if the wiring is within arm's reach.
11. For non-user replaceable light sources (for plastic lamp cover models):"The light source contained in
this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person".
12. For type Y attachments:if the external flexible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar qualified person in order to avoid
a hazard.
13. Please read the manual carefully before use, if you have any questions, please contact our company.
Brown-L
Blue-N
Yellow/Green-PE
30°
60°
20°×100°

4|5 datasheet-HL80-2209-en.1.1
HL80 Series LED High Mast Light
Selection table
HL80-①②③④⑤⑥
①Voltage
②Power
③Color temp
④Beam angle
⑤Wire method
⑥Mounting
A 100-240VAC
400 400W
C 5700K
M 30°
1 Lead wire 2m
A Bracket(U type/6mm/hole spacing
90~150mm&240~300mm/high 240mm)
600 600W
N 4000K
W 60°
B Bracket(stretch out/6mm/hole spacing
80~180mm/high257mm)
800 800W
W 2700K
R 20°×100°
C Bracket(stretch out/6mm/hole spacing
80~180mm/ width80mm)
1000 1000W
How to Order
Code
Model
Voltage
Power
Color
temp
Beam
angle
Wire method
Mounting
1000521_003
HL80-A400WM1A
100-240VAC
400W
2700K
30°
Lead wire 2m
Bracket (U type /6mm/hole spacing
90~150mm&240~300mm/high 240mm)
1000521_004
HL80-A400WW1A
100-240VAC
400W
2700K
60°
Lead wire 2m
Bracket (U type /6mm/hole spacing
90~150mm&240~300mm/high 240mm)
1000521_005
HL80-A400WR1A
100-240VAC
400W
2700K
20°×100°
Lead wire 2m
Bracket (U type /6mm/hole spacing
90~150mm&240~300mm/high 240mm)
1000521_007
HL80-A400CM1A
100-240VAC
400W
5700K
30°
Lead wire 2m
Bracket (U type /6mm/hole spacing
90~150mm&240~300mm/high 240mm)
1000521_008
HL80-A400CW1A
100-240VAC
400W
5700K
60°
Lead wire 2m
Bracket (U type /6mm/hole spacing
90~150mm&240~300mm/high 240mm)
1000521_009
HL80-A400CR1A
100-240VAC
400W
5700K
20°×100°
Lead wire 2m
Bracket (U type /6mm/hole spacing
90~150mm&240~300mm/high 240mm)
1000521_011
HL80-A600WM1B
100-240VAC
600W
2700K
30°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/high257mm)
1000521_012
HL80-A600WW1B
100-240VAC
600W
2700K
60°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/high257mm)
1000521_013
HL80-A600WR1B
100-240VAC
600W
2700K
20°×100°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/high257mm)
1000521_015
HL80-A600CM1B
100-240VAC
600W
5700K
30°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/high257mm)
1000521_016
HL80-A600CW1B
100-240VAC
600W
5700K
60°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/high257mm)
1000521_017
HL80-A600CR1B
100-240VAC
600W
5700K
20°×100°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/high257mm)
1000521_019
HL80-A800WM1C
100-240VAC
800W
2700K
30°
Lead wire 2m
Bracket(stretch out /6mm/hole spacing
80~180mm/ width80mm）
1000521_020
HL80-A800WW1C
100-240VAC
800W
2700K
60°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_021
HL80-A800WR1C
100-240VAC
800W
2700K
20°×100°
Lead wire 2m
Bracket(stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_023
HL80-A800CM1C
100-240VAC
800W
5700K
30°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_024
HL80-A800CW1C
100-240VAC
800W
5700K
60°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_025
HL80-A800CR1C
100-240VAC
800W
5700K
20°×100°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_027
HL80-A1000WM1C
100-240VAC
1000W
2700K
30°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_028
HL80-A1000WW1C
100-240VAC
1000W
2700K
60°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_029
HL80-A1000WR1C
100-240VAC
1000W
2700K
20°×100°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_031
HL80-A1000CM1C
100-240VAC
1000W
5700K
30°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_032
HL80-A1000CW1C
100-240VAC
1000W
5700K
60°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)
1000521_033
HL80-A1000CR1C
100-240VAC
1000W
5700K
20°×100°
Lead wire 2m
Bracket (stretch out /6mm/hole spacing
80~180mm/ width80mm)

5|5 datasheet-HL80-2209-en.1.1
HL80 Series LED High Mast Light
Manufactory
Shanghai Nanhua Electronics Co., Ltd
Address
Building 9, No.1755 Wenbei Road, Jiading District, Shanghai
Correct Disposal of this product
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To
return your used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
