Nanoptix ULTRA SYSTEM User manual

Owner’s Manual
First Edition – April 18, 2017
Last Revised – April 23, 2020
Document # 700075-0000R

Document # 700075-0000R
April 23, 2020
ii
WIRELESS ULTRA SYSTEM
OWNER’s Manual
Legal Notices
Disclaimer
Information in this document is subject to change without notice. Consult your Nanoptix Inc. sales
representative for information that is applicable and current. Nanoptix Inc. reserves the right to
improve products as new technology, components, software, and firmware become available.
No part of this document may be reproduced or transmitted in any form or by any means,
electronic or mechanical, for any purpose without the express written permission of Nanoptix Inc.
Copyright
Copyright 2020 by Nanoptix Inc.
Dieppe, New Brunswick Canada
All rights reserved
Printed in Canada
Confidential, Unpublished
Property of Nanoptix Inc.
Trademarks
Nanoptix is a trademark.
Other trademarks and registered trademarks are the property of their respective holders.
Federal Communications Commission (FCC)
Radio Frequency Interference Statement
Warning
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own
expense.

Document # 700075-0000R
April 23, 2020
iii
WIRELESS ULTRA SYSTEM
OWNER’s Manual
Information to the User
This equipment must be installed and used in strict accordance with the manufacturer's
instructions. However, there is no guarantee that interference to radio communications will not
occur in a particular commercial installation. If this equipment does cause interference, which can
be determined by turning the equipment off and on, the user is encouraged to contact Nanoptix
Inc. immediately.
Nanoptix Inc. is not responsible for any radio or television interference caused by unauthorized
modification of this equipment or the substitution or attachment of connecting cables and
equipment other than those specified by Nanoptix Inc. The correction of interferences caused by
such unauthorized modification, substitution or attachment will be the responsibility of the user.
In order to ensure compliance with the Product Safety, FCC and CE marking requirements, you
must use the power supply, power cord, and interface cables, which were shipped with this
product or which meet the following parameters:
Power Supply
UL Listed power supply with standard 60Hz-50Hz, 100-240VAC input and 12VDC isolated output
for the Game Interfaces, 24VDC output for the Spill Proof printer. Power supplies used must be
equipped with AC line filtering, over-current and short-circuit protection. The use of these
products with a power supply other than a Nanoptix Inc. approved one will require you to test the
power supply with the Nanoptix Inc. product for FCC and CE mark certification.
Communication Interface Cable
An approved Nanoptix interface cable must be used with this product. Use of a cable other than
Nanoptix approved product will require that you test the cable with the Nanoptix Inc. printer and
your system for FCC and CE mark certification.
Power Cord
A UL listed, detachable power cord must be used. A power cord with Type SVT marking must be
used. For applications outside North America, power cords that meet the particular country’s
certification and application requirements should be used.
The use of a power cord other than described here may result in a violation of safety certifications
that is in force in the country of use.
Industry Canada (IC)
Radio Frequency Interference Statement
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada.
NOTE: Information contained in this manual applies to the following
firmware versions:
Controller Box - Host: 1.0O
Controller Box - Game: 1.0K
Spill Proof Printer: 5.64A
Zigbee Module: 4060

Document # 700075-0000R
April 23, 2020
iv
WIRELESS ULTRA SYSTEM
OWNER’s Manual
Table of Contents
Table of Contents.......................................................................................................... iv
About the Wireless Ultra System................................................................................... 1
Game Interface General specifications ................................................................................... 1
Spill Proof Printer General Specifications .............................................................................. 2
1Description of the Wireless Ultra System.................................................................. 3
1.1Game Interface configured as “HOST” ..................................................................... 4
1.2Game Interface configured as “GAME” .................................................................... 4
1.3Digi Xbee Wireless Module ......................................................................................... 5
1.4Spill Proof Printer ........................................................................................................ 5
1.5Control Box ................................................................................................................... 6
1.5.1Control Box Operation ........................................................................................................... 6
2Meters......................................................................................................................... 7
3Configuration and Setup ........................................................................................... 8
4DIP Switch Settings ................................................................................................. 10
5Communication Ports.............................................................................................. 11
5.1Spill Proof Serial RS-232 Port - 9 pin DB9 .............................................................. 11
5.2Game Interface (HOST) – Molex 10 pin Receptacle ............................................... 11
5.3Game Interface (GAME) – Molex 4 pin Receptacle ............................................... 11
5.4Game Interface (GAME) – Molex 6 pin Receptacle ............................................... 11
6Ordering Miscellaneous Supplies............................................................................ 12
7Troubleshooting....................................................................................................... 13
7.1Factory reset ............................................................................................................... 13
7.2Testing the Ultra Wireless System ............................................................................ 13
7.2.1LED Status ............................................................................................................................ 13
7.2.2Power on information ticket ................................................................................................. 13
7.3Testing the Spill Proof Printer .................................................................................. 14
7.3.1LED Status ............................................................................................................................ 14
7.3.2Power on information ticket ................................................................................................. 14
8Maintenance & Cleaning Instructions.................................................................... 15
9Access Accounting Information Remotely.............................................................. 15
10Service & Support................................................................................................ 15

Document # 700075-0000R
April 23, 2020
v
WIRELESS ULTRA SYSTEM
OWNER’s Manual
Figures
FIGURE 1: WIRELESS ULTRA SYSTEM ......................................................... 3
FIGURE 2: GAME INTERFACE – “HOST” ..................................................... 4
FIGURE 3: GAME INTERFACE – “GAME” ..................................................... 4
FIGURE 4: SPILL PROOF PRINTER ............................................................... 5
FIGURE 5: CONTROL BOX ........................................................................... 6
FIGURE 6: WIRELESS ULTRA SYSTEM ......................................................... 8
FIGURE 7: DIP SWITCHES ......................................................................... 10
FIGURE 8: GAME INTERFACE LEDS ........................................................... 13
FIGURE 9: POWER ON TICKET .................................................................. 13
FIGURE 10: POWER ON TICKET ................................................................ 14
Tables
TABLE 1: GAME INTERFACE SPECIFICATIONS .............................................. 1
TABLE 2: SPILL PROOF PRINTER SPECIFICATION ......................................... 2
TABLE 3: 9 PIN RS232 SERIAL INTERFACE ............................................... 11
TABLE 4: 10 PIN GAME TERMINAL INTERFACE(S) ....................................... 11
TABLE 5: 4 PIN GAME TERMINAL INTERFACE(S) ......................................... 11
TABLE 6: 6 PIN GAME TERMINAL INTERFACE(S) ......................................... 11
TABLE 7: POWER SUPPLY PART NUMBERS ................................................ 12
TABLE 8: CABLES AND CONSUMABLES ..................................................... 12
TABLE 9: MISCELLANEOUS PARTS ............................................................ 12
TABLE 10: GAME INTERFACE LED STATUS................................................ 13
TABLE 11: SPILL PROOF PRINTER LED STATUS ......................................... 14

Document # 700005-0000R
April 3, 2019
1
WIRELESS ULTRA SYSTEM
OWNER’s Manual
About the Wireless Ultra System
Game Interface General specifications
Operating Temperature -40°C to +85°C
Operating Relative Humidity 5% to 90% RH at 50C (non-condensing)
Communication 2.4GHz OQPSK with DSSS
Range 200 ft (60m), PRO 300 ft (90m)
Communication Interface RS-232C
Transmit Power 3.1mW (+5dBm), PRO 63mW (+18dBm)
Frequency Band ISM 2.4 GHz
Channels 16 Channels
Security 128-bit AES
Emission Standards United States - FCC Part 15 Subpart B
Canada - Industry Canada ICES-003
Europe – EN 55022
Class A emissions
Immunity Standards EN55024
Table 1: Game Interface Specifications

Document # 700005-0000R
April 3, 2019
2
WIRELESS ULTRA SYSTEM
OWNER’s Manual
Spill Proof Printer General Specifications
Print Method Direct Thermal
Resolution 8 dot/mm (203 dpi)
Print Width 80mm
Paper Width 80mm or 82.5 mm
Max Roll Diameter 82.5mm
Operating Temperature 0 to 50 C
Storage Temperature -40 C to +65 C
Operating Relative Humidity 5% to 90% RH at 50C (non-condensing)
Communication Interface Options USB and RS-232C, optional RS-485
Optional Interface Cash Drawer Kick Out
Memory/Firmware 64 Mbit of RAM, 16 Mbit of flash
Resident Character Sets Arial Bold (6 sizes)
Note: Other Character sets can be
pro
g
rammed quickl
y
Integrated Bar Codes UPC-A, UPC-E, interleaved 2 of 5, Code 39,
Code 128, EAN 8, EAN 13.
Speed Up to 125 mm/second
Sensors  Paper out
 Door open

Top of form
(
optional
)
Human Interface Drop-in paper loading, status LED, paper feed
button
Dimensions 130mm width x 110mm height x 180mm depth
Weight 0.55 Kg
Agency Compliance Underwriters Laboratory - UL 60950
Safety of Information Technology Equipment,
includin
g
Electrical Business Equipment
Canadian Standards Association - CSA 22.2
No. 60950
Safety of Information Technology Equipment,
includin
g
Electrical Business Equipment
TUV / VDE / GS Mark
Safety of Information Technology Equipment,
includin
g
Electrical Business Equipment
Underwriters Laboratories - IEC 60950 / EN
60950 CB Test Report and Certificate
Emission Standards United States - FCC Part 15 Subpart B
Canada - Industry Canada ICES-003
Europe – EN 55022
Class A emissions (Completer System)
Class B emissions
(
Spill Proof printer onl
y)
Table 2: Spill Proof Printer Specification

Document # 700005-0000R
April 3, 2019
3
WIRELESS ULTRA SYSTEM
OWNER’s Manual
1 Description of the Wireless Ultra System
The Wireless Ultra System has been designed to manage small game rooms. With simple non-
intrusive connections, the system can be scaled up or down to adapted to different needs.
From remotely clearing credits and printing behind the counter, to acting as a complete
bookkeeping center.
Figure 1: Wireless Ultra System
A – Pulse Wires
B – Force Cashout
Wires
C – GAME - Game
Interface
D – Printer Cable
E – Spill Proof
Printer
F – HOST - Game
Interface
G – Control Box

Document # 700005-0000R
April 3, 2019
4
WIRELESS ULTRA SYSTEM
OWNER’s Manual
1.1 Game Interface configured as “HOST”
The HOST is the central controller of the system and functions as a hub between all
components. The HOST is connected to the control box via an RJ-12 connector. The printer
communicates with and provides power to the HOST via a 10 pin Molex connector. The
individual GAMES interfaces communicate with the HOST with a Digi International Xbee module
using Zigbee wireless communication (IEEE’s 802.15.4)
Figure 2: Game Interface – “HOST”
1.2 Game Interface configured as “GAME”
The GAMES are installed in each cabinet and communicate with the game board via 2 wire
harnesses. Once paired, the GAMES relay information to and from the HOST.
Figure 3: Game Interface – “GAME”

Document # 700005-0000R
April 3, 2019
5
WIRELESS ULTRA SYSTEM
OWNER’s Manual
1.3 Digi Xbee Wireless Module
The wireless capabilities of the system are provided by the Xbee transceiver utilizing the Zigbee
suite of short-range communication protocols. Each HOST and GAME box contain one and are
linked to each other automatically in a mesh network shortly after power-up. In a typical
installation, each box should be able to communicate up to 100 feet apart. If additional distance
is required, repeaters can be used to extend the range.
1.4 Spill Proof Printer
The Nanoptix Spill-Proof thermal printer is extremely fast, quiet, and very reliable. With thermal
printing technology, there is no ribbon cassette to change, and paper loading is extremely
simple. It is powered by a 24VDC power supply. It’s used for printing reports. It communicates
and provide power to the HOST game interface through the DB9 connector.
For more information on the Spill Proof printer, please refer to the Spill Proof printer manual
Figure 4: Spill Proof Printer

Document # 700005-0000R
April 3, 2019
6
WIRELESS ULTRA SYSTEM
OWNER’s Manual
1.5 Control Box
The Control Box is the user interface of the Wireless Ultra System. It is used to remotely clear
credits and print bookkeeping information.
Figure 5: Control Box
1.5.1 Control Box Operation
 LEDs 1 to 6
o ON solid: Indicates that the corresponding game terminal is connected and
turned ON.
o Blinking: Indicates that the corresponding game terminal is being played ???
o All 6 LEDs blinking: Printer is in error
 Force Cashout Remotely:
o The numbered buttons <1> through <6> are primarily used to remotely force a
cashout of the corresponding game terminal. Pressing a numbered button
simulates the action of pressing the “knock-off” button. The game board will
send pulses to its credits out hard meter, which the game interface will detect
and count. Once the pulses stop for more than 3 seconds, the Spill Proof printer
will print a cashout ticket for the amount corresponding to the pulses received.
 Reprint Last Cashout:
o Pressing and holding the <Soft Meters> button while at the same time pressing
the number <1> button will print the “LAST CASHOUT” ticket
 Print Soft Meters “Dailies”
o Pressing the <Soft Meters> button will print the “DAILIES” and the “GAME
REPORT”
Note: You will be prompted for a password if one has been set.

Document # 700005-0000R
April 3, 2019
7
WIRELESS ULTRA SYSTEM
OWNER’s Manual
 Clear Soft Meters “Dailies” numbers
o Pressing and holding the <Soft Meters> button then pressing the number <6>
button will clear the “DAILIES” but not the “GAME REPORT”.
 Set Password on Soft Meters “Dailies”
o Pressing and holding the <Soft Meters> button then turning the <key> ON then
OFF, and finally releasing the <Soft Meters> button. All the LEDs will turn off
and you will be prompted for a 4 digit password. choose your password by
pressing the buttons <1> through <6> in the order desired, the LED of each key
pressed will turn on once it has registered. The maximum password length is 8
digits. Once the desired password has been entered, press the <Soft Meters>
again to save the value.
Note: All instructions including the password itself will be printed. Also If no keys
are pressed within 15 seconds while entering the password, the operation will
timeout.
 Clear Soft Meters “Dailies” Password
o Pressing and holding the <Soft Meters> button then turning the <key> ON then
OFF, and then release the <Soft Meters> finally turning <key> ON then OFF a
second time, will clear and remove the password
 Print Bookkeeping
o Turning the <key> will print the “GAME REPORT” and “BOOKKEEPING”
information and then automatically clear both
2 Meters
The HOST Game Interface maintains 3 full sets of (non-volatile) electronic meters: Soft Meter,
Key Meter, and Central Meter. Each set is completely independent from each other. The Soft
meter and hard meter can be individually cleared at any time.
 The Soft Meter “Dailies”
This meter is typically used by the “location operator”. To print this set of meters, press
the “Soft Meter” button. To clear the values back to zero, press the “Soft Meter” button
and button “6” simultaneously.
 The Key Meter “Bookkeeping”
This meter is typically used by the “route operator”. To print the key meters, turn the key.
The key meter report will be printed immediately and will ALWAYS be cleared following
the report.
 The Central Meter “Remote Access”
This meter can be accessed remotely. The accumulated data is accessed by a
customized application such as Nanoptix WINDSHIELD software.

Document # 700005-0000R
April 3, 2019
8
WIRELESS ULTRA SYSTEM
OWNER’s Manual
3 Configuration and Setup
Figure 6: Wireless Ultra System
1. Power off all gaming terminals
2. Remove Game Interface black boxes (C) from packaging and place inside each gaming
terminal that you wish to monitor with the system.
3. Connect each Game Interface black boxes (C) to the game terminal using cables (A) &
(B) along with the red wiretaps (included).
4. Cable (A) part # 210029-0302R “WHITE-GREEN-BLACK”
 Attach the white wire (PULSE IN) to the gaming terminal’s “credits in” hard
meter or directly to the coin mech, bill acceptor, etc. using the enclosed red
wiretaps
 Attach the green wire (PULSE OUT) to the gaming terminal’s “credits out”
hard meter using the enclosed red wiretaps
 Attach the black wire (GND) to the ground connection of the gaming
terminal’s power supply using the enclosed red wiretaps

Document # 700005-0000R
April 3, 2019
9
WIRELESS ULTRA SYSTEM
OWNER’s Manual
5. Cable (B) part # 210029-0121R “BLUE-RED-BLACK”
 Attach the blue wire (FORCE CASHOUT) to the gaming terminal’s “knock-off”
button using the enclosed red wiretaps
 Attach the red wire (+12Vdc - SUPPLY VOLTAGE) to the +12 VDC of the
gaming terminal’s power supply using the enclosed red wiretaps.
 Attach the black wire (GND) to the ground connection of the gaming terminal’s
power supply using the enclosed red wiretaps.
6. Install Spill Proof printer (E) at the bar or counter (for further info consult Spill Proof
Printer Owner’s Manual)
7. Connect the Host Game Interface (F) to the Spill proof printer (E) using cable (D)
8. Connect the Control box (G) to the Host Game Interface’s (F) left RJ12 receptacle
9. Power ON the Spill Proof printer (C) with paper loaded
10. Turn ON all gaming terminals, if the installation was completed correctly, within 60
seconds the control box (G) lights corresponding to the connected games will be
illuminated.
Note: Additional cables (not shown) are used for advanced programming and firmware
updates

Document # 700005-0000R
April 3, 2019
10
WIRELESS ULTRA SYSTEM
OWNER’s Manual
4 DIP Switch Settings
Figure 7: DIP Switches
GAMES BOXES (1 to 5)
Switches # 1, 2, 3 & 4 - Game number
DIP Switch #
(
1 - 2 - 3 - 4
)
Game
number
1 - 0 - 0 - 0 01
0 - 1 - 0 - 0 02
1 - 1 - 0 - 0 03
0 - 0 - 1 - 0 04
1 - 0 - 1 - 0 05
0 - 1 - 1 - 0 06
1 - 1 - 1 - 0 07
0 - 0 - 0 - 1 08
1 - 0 - 0 - 1 09
0 - 1 - 0 - 1 10
1 - 1 - 0 - 1 11
0 - 0 - 1 - 1 12
1 - 0 - 1 - 1 13
0 - 1 - 1 - 1 14
1 - 1 -1 - 1 S/W Controlled
Switches # 5 & 6 - Credit Size – IN
DIP Switch #
(
5 - 6
)
Credit Size IN
Pulse per credit
0 - 0 1
1 - 0 5
0 - 1 25
1 - 1 100
Switches # 7 & 8 - Credit Size – OUT
DIP Switch #
(
7 - 8
)
Credit Size OUT
Pulse per credit
0 - 0 1
1 - 0 5
0 - 1 25
1 - 1 100
HOST BOX
DIP Switch # 1 Function
0 Cashless S
y
stem
1
(
default
)
A
ccountin
g
Onl
y
S
y
stem
DIP Switch # 2 Function
0
(
default
)
Nanoptix Scanner/LCD
1 Handheld Scanner/Pole
Displa
y
DIP Switch # 3 Function
0 Cash out ticket is not printed
1
(
default
)
Cash out ticket is printed
DIP Switch # 4 Function
0 No Controller Box Included
(
with Spill proof
)
1 (default) Controller Box Included (with
Spill proof
)
DIP Switch # 5 Function
0
(
default
)
Print 1 cashout receipt
1 Print a cashout receipt & a
duplicate cashout receip
t
DIP Switch # 6 Function
0
(
default
)
Verifies printer status
1I
g
nores printer status
DIP Switch # 7 Function
0 Multi-To-One OFF (Less than
15
g
ames
)
1 (default) Multi-To-One ON (More than
15
g
ames
)
DIP Switch # 8 Function
0
(
default
)
Future
1

Document # 700005-0000R
April 3, 2019
11
WIRELESS ULTRA SYSTEM
OWNER’s Manual
5 Communication Ports
5.1 Spill Proof Serial RS-232 Port - 9 pin DB9
Pin Si
g
nal Name Spill Proof I/O Game Interface I/O Function
1 Aux power
(
5VDC
)
Output Input Power HOST
2 PRT
_
TXD Outpu
t
Input Transmi
t
3 PRT_RXD Input Outpu
t
Receive
5 Di
g
ital Ground Di
g
ital Ground Di
g
ital Ground Di
g
ital Ground
4, 6, 7, 8 ,9 N/
A
N/
A
N/
A
N/
A
Table 3: 9 Pin RS232 Serial Interface
5.2 Game Interface (HOST) – Molex 10 pin Receptacle
Pin Si
g
nal Name Game Interface I
/
OSpill Proof I/O Function
2 Di
g
ital Ground Di
g
ital Ground Di
g
ital Ground Di
g
ital Ground
6 Aux power
(
5VDC
)
Input Output Power HOST
7 Game I/F
_
TXD Outpu
t
Input Transmi
t
8 Game I/F
_
R
X
D Input Outpu
t
Receive
1,3,4,5,7,9,10 N/
A
N/
A
N/
A
N/
A
Table 4: 10 Pin Game terminal interface(s)
5.3 Game Interface (GAME) – Molex 4 pin Receptacle
Pin Si
g
nal Name Game Interface I
/
OEGM I/O Function
1 Pulse IN Input Outpu
t
Coin IN meter
2 Di
g
ital Ground Di
g
ital Ground Di
g
ital Ground Di
g
ital Ground
3 Pulse OUT Outpu
t
Input Coin OUT meter
4 N/
A
N/
A
N/
A
N/
A
Table 5: 4 Pin Game terminal interface(s)
5.4 Game Interface (GAME) – Molex 6 pin Receptacle
Pin Si
g
nal Name Game Interface I
/
OEGM I/O Function
1 12 VDC Input Outpu
t
12 VDC power
4 Knock off Input Outpu
t
Knock off switch
6 Di
g
ital Ground Di
g
ital Ground Di
g
ital Ground Di
g
ital Ground
2, 3, 5 N/
A
N/
A
N/
A
N/
A
Table 6: 6 Pin Game terminal interface(s)

Document # 700005-0000R
April 3, 2019
12
WIRELESS ULTRA SYSTEM
OWNER’s Manual
6 Ordering Miscellaneous Supplies
Power Supply and Power Cord
Part Part Numbe
r
Power Suppl
y
(
24VDC, 2.5A max, 60W
)
270034-0002R
Power cord
(
North America
)
102080-0000R
Power Cord
(
Continental Europe
)
102080-0001R
Table 7: Power Supply part numbers
Cables and Consumables
Part Part Numbe
r
USB Cable 2M
(
A
to mini B
)
102085-0002R
Serial
(
DB9 to DB9
)
null modem 102812-0000R
Thermal paper roll 100505-2060R
Table 8: Cables and Consumables
Miscellaneous Parts
Part Part Numbe
r
Standard Xbee Zi
g
bee module 270016-0011R
PO Xbee Zi
g
bee module 270016-0012R
Ran
g
e Extender 270031-0001R
Table 9: Miscellaneous parts

Document # 700005-0000R
April 3, 2019
13
WIRELESS ULTRA SYSTEM
OWNER’s Manual
7 Troubleshooting
7.1 Factory reset
In the event the system has developed any kind of issue in its operation, the memory can be
fully restored back to factory settings. To do so, turn and hold the control box key while
powering on. In the event this does not correct the issue, please contact Nanoptix support.
7.2 Testing the Ultra Wireless System
7.2.1 LED Status
Figure 8: Game Interface LEDs
LED numbe
r
Game interface as HOST Game Inte
r
face as GAME
1
(
D907
)
5.0 VDC 5.0 VDC
2
(
D904
)
HOST POWER HOST POWER
3
(
D305
)
, 4
(
D304
)
N/
A
N/
A
5
(
D303
)
8 pin Molex Power 8 pin Molex Power
6
(
D403
)
6 pin Molex Power 6 pin Molex Power
7
(
D602
)
10 pin Molex Power 10 pin Molex Power
8
(
D100
)
Sendin
g
Zi
g
bee poll to all GAMES Respondin
g
to Zi
g
bee poll from HOST
Table 10: Game Interface LED status
7.2.2 Power on information ticket
Every time the Wireless Ultra System is turned on, a power-on ticket will be printed by the Spill
Proof printer. The resident status ticket lists the firmware version current settings. This ticket
can also be used as confirmation that the HOST game interface is communicating with the Spill
Proof printer.
Figure 9: Power ON Ticket
NANOPTIX ULTRA
ACCOUNTING SYSTEM
HOST V1.0H WITH BOX RTC
24 GAMES MAX
2020/01/01 00:01:00

Document # 700005-0000R
April 3, 2019
14
WIRELESS ULTRA SYSTEM
OWNER’s Manual
7.3 Testing the Spill Proof Printer
7.3.1 LED Status
Condition LED Status
Unit read
y
ON
Unit is in Reset or Bootin
g
OFF
Paper Out Slow Blink
Temperature, Volta
g
e, Print head error Med Blink
Cover open, Paper
j
am Fast Blink
Table 11: Spill Proof printer LED status
7.3.2 Power on information ticket
The Spill Proof printer’s proper operation can be verified by printing a resident status ticket.
During power-up, hold the form feed button activated for a minimum of 10 seconds, then
release. The resident status ticket displays the firmware version, communication settings,
sensor readings as well as other important information.
Figure 10: Power ON Ticket
Model: CALLISTO-FX
Firmware: CAL-3.10M-61AUZtHX
COMMUNICATION
Interface: Serial
Baud: 9600
Data Bits: 8
Parity: NONE
Handshaking: PRT STATUS
Print Mode: Page
Aux Port: Site Controller 1
PRINT CONTROL
Darkness Control: -1%
Voltage: 24.3 Volts
Temperature: 26 Celsius
Speed: 3.8 IPS – 96mm/sec
Black Bar Index: Disabled
SYSTEM RESOURCES
FLASH -Used: 0
-Free: 24576
LIBRARY INVENTORY
Templates:
Print Regions:
Graphics: None
Fonts: 0,1,2,3,4,5,6,7,8,13,14,15
MANUFACTURING INFORMATION
Printer ID: 5465789
Date Code: 20080717
PWM Setting: 7F7F7F7FFFFFFF
A to D: DE7AA400FD000000
Current Configuration:
B00DFFFFFFFFFFFFFFFFFFFFFFF
Status: C21-2.41G-40-40-40-40-40-P

Document # 700005-0000R
April 3, 2019
15
WIRELESS ULTRA SYSTEM
OWNER’s Manual
8 Maintenance & Cleaning Instructions
The Game Interfaces and Control Box do not require any maintenance or cleaning. Refer to the
Spill Proof manual for printer maintenance.
9 Access Accounting Information Remotely
In addition to the HARD meter and SOFT meter, a third electronic meter is available, and this
one can be accessed remotely. The CENTRAL meters information can be retrieved by
connecting the HOST game interface to the internet. This information can be customized and
displayed by website or software program such as Nanoptix WINDSHIELD For additional
information, contact Nanoptix Support.
10 Service & Support
Service Dept.
Nanoptix Inc.
699 Champlain Street
Dieppe, New Brunswick
E1A 1P6 CANADA
Toll-free North America: [phone]
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Web site: www.nanoptix.com
