Napoleon BGNV40-N User manual

1
W415-0813 / A / 04.19.10$10.00
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
1.2A
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 4Y8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.napoleonfireplaces.com • [email protected]
SAFETY INFORMATION
!WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by a
qualified installer, service agency or the supplier.
CERTIFIED FOR CANADAAND UNITED STATES USING ANSI/CSAMETHODS.
BGNV40-N
NATURAL GAS
BGNV40-P
PROPANE
CERTIFIED UNDER CANADIANAND AMERICAN NATIONAL STANDARDS: CSA 2.22,ANSI Z21.50 FOR VENTED GAS FIREPLACES.

2
W415-0813 / A / 04.19.10
NOTE: changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.1.1 ISLAND 5
2.1.2 OPEN-END 5
2.1.3 PENINSULA 5
2.1.4 SEE-THRU 5
2.2 GENERAL INSTRUCTIONS 6
2.3 GENERAL INFORMATION 7
2.4 RATING PLATE INFORMATION 7
3.0 VENTING 8
3.1 VENTING SAFETY SWITCH 8
3.2 HIGH LIMIT SWITCH 9
3.3 VENTACTION CHECK 9
4.0 INSTALLATION 9
4.1 GAS INSTALLATION 10
5.0 FRAMING 11
5.1 MINIMUM CLEARANCE TO COMBUSTIBLES 11
5.2 PENINSULA 11
5.2.1 INSTALLATION 11
5.2.2 COUNTER TOP / BAR INSTALLATION 12
5.2.3 BRICK PANEL INSTALLATION 12
5.2.4 FACING 13
5.2.5 FINISHING 13
5.3 OPEN-END 13
5.3.1 INSTALLATION 13
5.3.2 BRICK PANEL INSTALLATION 14
5.3.3 FACING 14
5.3.4 FINISHING 14
5.4 SEE-THRU 15
5.4.1 INSTALLATION 15
5.4.2 BRICK PANEL INSTALLATION 15
5.4.3 FACING 15
5.4.4 FINISHING 16
5.5 ISLAND 16
5.5.1 INSTALLATION 16
5.5.2 BRICK PANEL INSTALLATION 16
5.5.3 FACING 17
5.5.4 FINISHING 17
5.6 MINIMUM MANTEL CLEARANCES 18
6.0 FINISHING 19
6.1 HEAT SHIELD STAND-OFF REMOVAL (SEE-THRU INSTALLATION ONLY) 19
6.2 DOOR INSTALLATION 19
6.3 END DOOR INSTALLATION 19
6.4 LOG PLACEMENT 20
6.5 CHARCOAL EMBERS 21
6.6 LOGO PLACEMENT 21
6.7 LOUVRE INSTALLATION 22
7.0 OPTIONAL BLOWER INSTALLATION 23
8.0 OPERATION 25
9.0 ADJUSTMENTS 26
9.1 PILOT BURNER ADJUSTMENT 26
9.2 VENTURI ADJUSTMENT 26
9.3 FLAME ADJUSTMENT 26
9.4 FLAME CHARACTERISTICS 27
10.0 MAINTENANCE 27
10.1 CARE OF GLASS 28
10.2 CARE OF PLATED PARTS 28
11.0 REPLACEMENTS 29
12.0 TROUBLE SHOOTING 33
13.0 SERVICE HISTORY 35
14.0 WARRANTY 36

3
W415-0813 / A / 04.19.10
1.0 INSTALLATION OVERVIEW
Door, see “DOOR
INSTALLATION” section.
Bricks, see “BRICK PANEL
INSTALLATION” section.
Louvres, see “LOUVRE
INSTALLATION” section.
End door, see “END
DOOR INSTALLA-
TION” section.
Vent, see “VENTING”
section.
Rating plate, see “RATING
PLATE INFORMATION”
section.

4
W415-0813 / A / 04.19.10
2.0 INTRODUCTION
3.16
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate
appliance according to operating instructions could cause fire or injury.
• Risk of fire or asphyxiation do not operate appliance with fixed glass removed.
• Do not connect 110 volts to the control valve.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal
edges may be sharp.
• Do not burn wood or other materials in this appliance.
• Young children should be carefully supervised when they are in the same room as the appliance. Tod-
dlers, young children and others may be susceptible to accidental contact burns. Aphysical barrier is
recommended if there are at risk individuals in the house. To restrict access to an appliance or stove,
install an adjustable safety gate to keep toddlers, young children and other at risk individuals out of the
room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and
draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot
surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children
from hot surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the
appliance and venting system are kept clean. The appliance and its venting system should be inspected
before use and at least annually by a qualified service person. More frequent cleaning may be required
due to excessive lint from carpeting, bedding material, etc. The appliance area must be kept clear and
free from combustible materials, gasoline and other flammable vapors and liquids.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe serving a separate solid fuel burning appli-
ance.
• Do not use this appliance if any part has been under water. Immediately call a qualified service techni-
cian to inspect the appliance and to replace any part of the control system and any gas control which
has been under water.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass
should be done by a licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As
with all plastic bags, these are not toys and should be kept away from children and infants.
• As with any combustion appliance, we recommend having your appliance regularly inspected and ser-
viced as well as having a Carbon Monoxide Detector installed in the same area to defend you and your
family against Carbon Monoxide.

5
W415-0813 / A / 04.19.10
2.1 DIMENSIONS
2.1.2 OPEN-END
2.1.3 PENINSULA
2.1.1 ISLAND
2.1.4 SEE-THRU
38"
32 1/2"
36" 22 1/8"
22 1/8"
21/2"
41/4"
ELECTRICAL
INLET
GAS
INLET
61/2"
38"
32 1/2"
36"
38" 22 1/8"
22 1/8"
25 1/8"
21/2"
41/4"
ELECTRICAL
INLET
GAS
INLET
61/2"
38"
32 1/2"
36"
38"
22 1/8"
22 1/8"
2
1
/
2
"
4
1
/
4
"
ELE
C
TRI
C
A
L
INLET
G
A
S
INLET
6
1
/
2
"
22
1
/
8
"
38
"
3
2
1
/
2
"
36
"
4
0"
22 1/8"

6
W415-0813 / A / 04.19.10
2.2 GENERAL INSTRUCTIONS
THIS GAS APPLIANCE SHOULD BE INSTALLED AND SERVICED BY A QUALIFIED INSTALLER to
conform with local codes. Installation practices vary from region to region and it is important to know the
specifics that apply to your area, for example in Massachusetts State:
• This product must be installed by a licensed plumber or gas fitter when installed within the commonwealth
of Massachusetts.
• The appliance damper must be removed or welded in the open position prior to installation of a appliance
insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches.
• A Carbon Monoxide detector is required in all rooms containing gas fired appliances.
• The appliance is not approved for installation in a bedroom or bathroom unless the unit is a direct vent
sealed combustion product.
The installation must conform with local codes or, in
absence of local codes, the National Gas and Propane
Installation Code CSA B149.1 in Canada, or the National
Fuel Gas Code, ANSI Z223.1 / NFPA54 in the United
States. Suitable for mobile home installation if installed in
accordance with the current standard CAN/CSA Z240MH
Series, for gas equipped mobile homes, in Canada or
A
NSI Z223.1 and NFPA 54 in the United States.
A
s long as the required clearance to combustibles is
maintained, the most desirable and beneficial location for an appliance is in the center of a building, thereby
allowing the most efficient use of the heat created. The location of windows, doors and the traffic flow in the
room where the appliance is to be located should be considered. If possible, you should choose a location
where the vent will pass through the house without cutting a floor or roof joist.
We suggest that our gas
hearth products be installed
and serviced by professionals
who are certied in the U.S.
by the National Fireplace
Institute
® (NFI) as NFI Gas
Specialists
www.ncertied.org
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT,
WITH THE GLASS DOOR OPENED OR REMOVED.
PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE.
PROVIDE ADEQUATE VENTILATION.
NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.
OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48” FROM THE
FRONT FACE OF THE UNIT.
SURFACES AROUND AND ESPECIALLY ABOVE THE APPLIANCE CAN BECOME HOT. AVOID CONTACT
WHEN THE APPLIANCE IS OPERATING.
FIRE RISK. EXPLOSION HAZARD.
HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE PRESSURE TESTING
GAS LINE AT TEST PRESSURES ABOVE 1/2 PSIG. CLOSE THE MANUAL SHUT-OFF VALVE BEFORE
PRESSURE TESTING GAS LINE AT TEST PRESSURES EQUAL TO OR LESS THAN 1/2 PSIG.
USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE.
USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENTING
COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION.
!
WARNING

7
W415-0813 / A / 04.19.10
2.3 GENERAL INFORMATION
2.4 RATING PLATE INFORMATION
BGNV40
NG LP
Altitude (FT) 0-4,500 0-4500
Max. Input (BTU/HR) 30,000 30,000
Max. Output (BTU/HR) 20,400
Efficiency (w/the fan on) 68%
Min. Inlet Gas Supply
Pressure 4.5" Water Column 11" Water Column
Max. Inlet Gas Supply
Pressure 7" Water Column 13" Water Column
Manifold Pressure (Under
Flow Conditions) 3.5" Water Column 10" Water Column
When the appliance is installed at eleva-
tions above 4,500ft, and in the absence of
specific recommendations from the local
authority having jurisdiction, the certified
high altitude input rating shall be reduced
at the rate of 4% for each additional
1,000ft. Expansion / contraction noises
during heating up and cooling down cycles
are normal and to be expected.
This appliance is approved for bedroom
and bed-sitting room installations and is
suitable for mobile home installation.
NO EXTERNAL ELECTRICITY (110 VOLTS OR 24 VOLTS) IS REQUIRED FOR THE GAS SYSTEM OPERA-
TION.
FOR YOUR SATISFACTION, ALL BURNER ASSEMBLIES HAVE BEEN TEST-FIRED TO ASSURE THEIR
OPERATIONS AND QUALITY!
Expansion / contraction noises during heating up and cooling down cycles are normal and are to be expected.
If utilizing one of Wolf Steel's trim or surround kits, see "FRAMING" section for removal of the top extension.
NOTE: The protective wrap on plated parts is best removed when the assembly is at room temperature
but this can be improved if the assembly is warmed, using a hair dryer or similar heat source.
CERTIFIEDUNDER/HOMOLOGUESELON LES NORMES:CSA 2.22b-2009 &ANSI Z21.50b-2009, VENTEDGAS FIREPLACE/FOYER AGAZ VENTILE.
MADE IN CANADA / FABRIQUE AU CANADA
SERIALNUMBER/NO.DE SERIE: BGNV40/BCNV400
WOLF STEEL LTD, BARRIE, ON, CANADA
MANIFOLD PRESSURE: 3.5" WATER COLUMN
PRESSION AU COLLECTEUR: 3.5" D'UNE COLONNE D'EAU
MINIMUM SUPPLY PRESSURE: 4.5" WATER COLUMN
PRESSION D'ALIMENTATION MINIMALE: 4.5" D'UNE COLONNE D'EAU
MAXIMUM SUPPLY PRESSURE: 7.0" WATER COLUMN
PRESSION D'ALIMENTATION MAXIMALE: 7.0" D'UNE COLONNE D'EAU
NOTFOR USEWITHSOLIDFUEL.FOR USEWITHGLASS
DOORSANDCOVERSCERTIFIEDWITHTHISUNITONLY.
MANIFOLD PRESSURE: 10" WATER COLUMN
PRESSION AU COLLECTEUR: 10" D'UNE COLONNE D'EAU
MINIMUM SUPPLY PRESSURE: 11" WATER COLUMN
PRESSION D'ALIMENTATION MINIMALE: 11" D'UNE COLONNE D'EAU
MAXIMUM SUPPLY PRESSURE: 13" WATER COLUMN
PRESSION D'ALIMENTATION MAXIMALE: 13" D'UNE COLONNE D'EAU
UNCOMBUSTIBLESOLIDENEDOITPASETREUTILISEAVECCET
APPAREIL.UTILISERAVECLESPORTESVITREESHOMOLOGUEES
ET COUVERTURES SEULEMENTAVECCETTEUNITE.
AVERTISSEMENT:N'AJOUTEZPASACETAPPAREILAUCUNMATERIAU DEVANTENTRER
ENCONTACTAVECLES FLAMMESAUTRE QUE CELUI QUIEST FOURNIAVECCETAPPAREILPAR
LEFABRICANT.
THEAPPLIANCE MUST BEVENTED USING "B" VENT. SEE OWNERSINSTALLATIONMANUALFOR
VENTINGSPECIFICS.
L'APPAREIL DOIT EVACUER SES GAZ EN UTILISANT L'EVENT "B". REFERER AU MANUEL
D'INSTALLATION DE PROPRIETAIRE POUR L'EVACUATION PRECISE.
ELECTRICALRATING/ CLASSIFICATION:115V0.82AMP, 60HZ
OPTIONALFANKIT/ ENSEMBLEDEVENTILATEURFACULTATIF:GZ550-KT
W385-0250_C
VENTED GAS FIREPLACE. APPROVED FOR BEDROOM, AND
BED-SITTINGROOM INSTALLATION. FOYERAGAZ VENTILE.HOMOLOGUEPOUR INSTALLATION DANSUNE CHAMBRE A COUCHER, ET UN STUDIO.
MODELBGNV40N
MODELBCNV400N ALTITUDE/ELEVATION
INPUT/ALIMENTATION
REDUCED INPUT / ALIMENTATION REDUITE
ORIFICE / INJECTEUR
0-4500FT(0-1370m)
30,000BTU/h
20,000BTU/h
#52
MODELBGNV40P
MODELBCNV400P
0-4500FT(0-1370m)
30,000BTU/h
20,000BTU/h
#39
WARNING:DO NOT ADDANY MATERIALTO THEAPPLIANCE, WHICH WILL COME IN
CONTACT WITH THE FLAMES, OTHER THAN THAT SUPPLIED BY THE MANUFACTURER
WITHTHEAPPLIANCE.
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALS /
DEGAGEMENTSMINIMAUXDESMATERIAUX COMBUSTIBLES:
TOP/DESSUS 0 RECESSED DEPTH / PROFONDEUR D'ENCASTRE 25 ¼"
"1TNEVE/TNEV0REHCNALP/ROOLF
SIDES/ COTES 0 "5UAETNAM/ELTNAM *
BACK/ ARRIERE 0
*MAXIMUMHORIZONTALEXTENSION / L'EXTENSION HORIZONTALE MAXIMALE: 3".
SEE INSTRUCTION MANUAL FOR GREATER EXTENSIONS. REFERER AU MANUEL
D'INSTRUCTIONPOURDES EXTENSIONS PLUS GRANDES.
REFERENCE # W/N 15511
INSTALLER: It is
your responsibil-
ity to check off the
appropriate box
on the rating plate
according to the
model, venting and
gas type of the ap-
pliance.
For rating plate loca-
tion, see “INSTALLA-
TION OVERVIEW”
section.
4.1
If the appliance is installed directly on carpeting, vinyl tile or other combustible material other than wood
flooring, the appliance shall be installed on a metal or wood panel extending the full width and depth.
If the optional fan or blower is installed, the junction box must be electrically connected and grounded in
accordance with local codes, use the current CSA C22.1 Canadian Electrical Code in Canada or theANSI/
NFPA 70 National Electrical code in the United States.

8
W415-0813 / A / 04.19.10
3.0 VENTING
!
WARNING
RISK OF FIRE, MAINTAIN SPECIFIED AIR SPACE CLEARANCES TO VENT PIPE AND APPLIANCE.
3.1 VENTING SAFETY SWITCH
This thermally activated switch, located in front of
the draft hood, senses an increase in temperature
and acts as a safety shut-off, see "A". It shuts down
the gas to the main burner in the event of a severe
downdraft of air or a blocked or disconnected chimney
flue. If the flue is blocked or has no "draw", the safety
switch will automatically shut off the supply of gas to
the main burner within 10 minutes.
This switch must be manually reset by depressing the
plunger.
The one wire running from the vent safety switch is
attached to terminal 1 of the valve, see "B". The other
wire (laying loose in the valve control area) may be
attached to a wall switch or thermostat.
TAMPERING WITH THE SAFETY SWITCH CAN RESULT IN CARBON MONOXIDE POISONING AND
POSSIBLE DEATH.
!
WARNING
PLUNGER A
HI LIMIT
SWITCH
B
This is a vented appliance and must be connected to a chimney in accordance with the current installation
codes. In absence of local codes, install to the current CAN/CGA B149 in Canada or to the current National
Fuel Gas Code ANSI Z223.1 in the United States. This model can be common-vented.
A minimum five inch diameter (5" Ø) B-vent or class A vent is required. Aminimum 5' vent height is required.
Secure the B-vent to the exhaust collar on the appliance top with 3 screws. In cold climates, the use of a B-
vent and an insulated chase is recommended.
Under extreme vent configurations, allow several minutes (5-15) for the flame to stabilize after ignition. Provide
a means for visually checking the vent connection to the appliance after the appliance is installed.

9
W415-0813 / A / 04.19.10
3.2 HIGH LIMIT SWITCH
VALVE
THERMOSTAT OR
WALL SWITCH
VENT SAFETY
SWITCH HIGH LIMIT
SWITCH
This thermally activated switch, located in front of
the draft hood, senses an increase in temperature
and acts as a safety shut-off (See 'A' below). It shuts
down the gas to the main burner in the unlikely event
of the appliance overheating. The HI Limit switch will
automatically reset after the appliance has cooled
down, resuming gas flow to the main burner.
A test for correct venting action must be made before the installed appliance can be left with the cus-
tomer.
Follow the procedure below:
2.3.1 Close all doors and windows in the room / start exhaust fans in the home /
turn the appliance blower off (if so equipped).
2.3.2 Set controls to "high" and light the appliance.
2.3.3 Wait 5 minutes. Light a match and hold to the front of the draft hood.
Venting action is satisfactory, if smoke and flames are drawn into the draft hood.
Venting action is unsatisfactory, if the smoke spills back, and the flame splays out-
ward. If venting action is unsatisfactory, turn off the appliance, wait 10 minutes and
try again. If the smoke is still not drawn into the draft hood, turn the appliance off and
check for vent blockage or restriction. If necessary, consult with a qualified inspector.
The Vent Safety or Hi Limit switches must not be adjusted or disabled.
In the event that either switch or any associated parts are exchanged, only
original manufacturer's parts may be used.
3.3 VENT ACTION CHECK
4.0 INSTALLATION
!
WARNING
FOR SAFE AND PROPER OPERATION OF THE APPLIANCE, FOLLOW THE VENTING INSTRUCTIONS
EXACTLY.
ALL INNER EXHAUST AND OUTER INTAKE VENT PIPE JOINTS MAY BE SEALED USING EITHER RED
RTV HIGH TEMP SILICONE SEALANT W573-0002 (NOT SUPPLIED) OR BLACK HIGH TEMP MILL PAC
W573-0007 (NOT SUPPLIED) WITH THE EXCEPTION OF THE APPLIANCE EXHAUST FLUE COLLAR
WHICH MUST BE SEALED USING MILL PAC.
IF USING PIPE CLAMPS TO CONNECT VENT COMPONENTS, 3 SCREWS MUST ALSO BE USED TO
ENSURE THE CONNECTION CANNOT SLIP OFF.
DO NOT CLAMP THE FLEXIBLE VENT PIPE.
RISK OF FIRE, EXPLOSION OR ASPHYXIATION. IMPROPER SUPPORT OF THE ENTIRE VENTING
SYSTEM MAY ALLOW VENT TO SAG AND SEPARATE. USE VENT RUN SUPPORTS AND CONNECT
VENT SECTIONS PER INSTALLATION INSTRUCTIONS.
RISK OF FIRE, DO NOT ALLOW LOOSE MATERIALS OR INSULATION TO TOUCH THE VENT PIPE.
REMOVE INSULATION TO ALLOW FOR THE INSTALLATION OF THE ATTIC SHIELD AND TO
MAINTAIN CLEARANCES TO COMBUSTIBLES.
68.2A

10
W415-0813 / A / 04.19.10
4.1 GAS INSTALLATION
30.1A
Installation and servicing to be done by a qualified installer. Do not use open flame.
• Move the appliance into position and secure.
• If equipped with a flex connector the appliance is designed to accept a 1/2” gas supply. Without the
connector it is designed to accept a 3/8” gas supply. The appliance is equipped with a manual shut off
valve to turn off the gas supply to the appliance.
• Connect the gas supply in accordance to local codes. In the absence of local codes, install to the
current CAN/CSA-B149.1 Installation Code in Canada or to the current National Fuel Gas Code, ANSI
Z223.1 / NFPA 54 in the United States.
• When flexing any gas line, support the gas valve so that the lines are not bent or kinked.
• The gas line flex-connector should provide sufficient movement to permit shifting the burner assembly
on it’s side.
• Check for gas leaks by brushing on a soap and water solution.
!
WARNING
RISK OF FIRE, EXPLOSION OR ASPHYXIATION. ENSURE THERE ARE NO IGNITION SOURCES SUCH
AS SPARKS OR OPEN FLAMES.
SUPPORT GAS CONTROL WHEN ATTACHING GAS SUPPLY PIPE TO PREVENT DAMAGING GAS LINE.
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT
WITH THE GLASS DOOR OPENED OR REMOVED. PURGING OF THE GAS SUPPLY LINE SHOULD BE
PERFORMED BY A QUALIFIED SERVICE TECHNICIAN. ASSURE THAT A CONTINUOUS GAS FLOW IS AT
THE BURNER BEFORE CLOSING THE DOOR. ENSURE ADEQUATE VENTILATION. FOR GAS AND
ELECTRICAL LOCATIONS, SEE “DIMENSION” SECTION.
ALL GAS CONNECTIONS MUST BE CONTAINED WITHIN THE APPLIANCE WHEN COMPLETE.
HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE TESTING GAS
LINE AT TEST PRESSURES ABOVE 1/2 PSIG.
VALVE SETTINGS HAVE BEEN FACTORY SET, DO NOT CHANGE.
4.1.1
4.1.2
4.1.3
4.1.4
4.1.5
4.1.6

11
W415-0813 / A / 04.19.10
5.0 FRAMING
!
WARNING
RISK OF FIRE!
IN ORDER TO AVOID THE POSSIBILITY OF EXPOSED INSULATION OR VAPOUR BARRIER COMING
IN CONTACT WITH THE APPLIANCE BODY, IT IS RECOMMENDED THAT THE WALLS OF THE APPLI-
ANCE ENCLOSURE BE “FINISHED” (IE: DRYWALL / SHEETROCK), AS YOU WOULD FINISH ANY
OTHER OUTSIDE WALL OF A HOME. THIS WILL ENSURE THAT CLEARANCE TO COMBUSTIBLES IS
MAINTAINED WITHIN THE CAVITY.
DO NOT NOTCH THE FRAMING AROUND THE APPLIANCE STAND-OFFS. FAILURE TO MAINTAIN AIR
SPACE CLEARANCE MAY CAUSE OVER HEATING AND FIRE. PREVENT CONTACT WITH SAGGING
OR LOOSE INSULATION OR FRAMING AND OTHER COMBUSTIBLE MATERIALS. BLOCK OPENING
INTO THE CHASE TO PREVENT ENTRY OF BLOWN-IN INSULATION. MAKE SURE INSULATION AND
OTHER MATERIALS ARE SECURED.
WHEN CONSTRUCTING THE ENCLOSURE ALLOW FOR FINISHING MATERIAL THICKNESS TO MAIN-
TAIN CLEARANCES. FRAMING OR FINISHING MATERIAL CLOSER THAN THE MINIMUMS LISTED
MUST BE CONSTRUCTED ENTIRELY OF NON-COMBUSTIBLE MATERIALS. MATERIALS CONSISTING
ENTIRELY OF STEEL, IRON, BRICK, TILE, CONCRETE, SLATE, GLASS OR PLASTERS, OR ANY COM-
BINATION THEREOF ARE SUITABLE. MATERIALS THAT ARE REPORTED AS PASSING ASTM E 136,
STANDARD TEST METHOD FOR BEHAVIOUR OF MATERIALS IN A VERTICAL TUBE FURNACE AT
750°C AND UL763 SHALL BE CONSIDERED NON-COMBUSTIBLE MATERIALS.
MINIMUM CLEARANCE TO COMBUSTIBLES MUST BE MAINTAINED OR A SERIOUS FIRE HAZARD
COULD RESULT.
THE APPLIANCE REQUIRES A MINIMUM ENCLOSURE HEIGHT. MEASURE FROM THE APPLIANCE
BASE.
IF STEEL STUD FRAMING KITS WITH CEMENT BOARD ARE PROVIDED, THEY MUST BE INSTALLED.
71.1
5.2.1 INSTALLATION
It is best to frame your appliance after it is posi-
tioned and the vent system is installed. Use 2x4's
and frame to local building codes.
A = 22 1/8" minus finishing material thickness each
side.
To install the appliance face flush with the finished
wall, position the framework to accommodate the
thickness of the finished wall.
THE UNIT IS NOT LOAD BEARING
38 1/4”
22 1/8”
38”
6 1/8”
2 1/2”
5.2 PENINSULA
5.1 MINIMUM CLEARANCE TO COMBUSTIBLES
Minimum clearance to combustible construction from appliance:
Sides, back, bottom, and top 0"
Recessed depth (corner installation) 25¼"

12
W415-0813 / A / 04.19.10
5.2.2 COUNTER TOP / BAR INSTALLATION
When finishing the appliance, combustible material
may rest directly on the top extension.
NOTE: Maximum weight tolerance is 400 lbs,
provided that it is evenly distributed across the
top extensions of the appliance.
In order to achieve a counter top or bar type ap-
pearance with the minimum height allowed, fram-
ing must be non-combustible and may be done
with metal studding attached to the top extension
sides or the upper frame of the appliance.
* The top extension may be removed if non-com-
bustible framing is faced with a non-combustible
material placed flush with the front face of the
appliance and extending from the top of the ap-
pliance. (Example: cement board) (not supplied).
Combustible counter / bar tops must maintain a
minimum of 38" from the base of the appliance to the
underside of the top.
NOTE: Wolf Steel trim and/or surround kits will
not totally cover the top extension of the ap-
pliance. In order to obtain a smooth transition
from the trim / surround to the wall, it is recom-
mended that the top extension be removed and
the appliance be installed following the above
procedure.
STUD
3"
NON-COMBUSTIBLE
MATERIAL *METAL
3" *COMBUSTIBLE
MATERIAL
EXTENSION
TOP
5½"
SEE FIGURE
BELOW
NON-COMBUSTIBLE
MATERIAL
COMBUSTIBLE
MATERIAL
TOP EXTENSION
TOP OF THE UNIT
5.2.3 BRICK PANEL INSTALLATION
RETAINER
DETAIL 5
STEP 3STEP 2STEP 1
STEP 4
STEP 5
Install the base panels as illustrated. The side panel sits under the bracket tab. Holding the side panel in posi-
tion, bend down the tab to secure.

13
W415-0813 / A / 04.19.10
5.2.4 FACING
5.2.5 FINISHING
Combustible materials may be installed flush with the
front of the appliance but must not cover any of the black
face-areas of the appliance. Non-combustible material
(brick, stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
appliance.
When roughing in the appliance, raise the appliance
to accommodate for the thickness of the finished floor
materials, (tile, carpeting, hard wood) which if not planned
for will interfere with the opening of the lower access door
and the installation of many decorative flashing acces-
sories.
Objects placed in front of the appliance should be kept a
minimum of 48" away from the glass front face.
DRYWALL DRYWALL
5" MIN
Refer to "FINISHING" section for complete instructions regarding log placement, glass door and upper and
lower louvre attachments.
5.3.1 INSTALLATION
5.3 OPEN-END
It is best to frame your appliance after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes.
NOTE: The one side stud must be steel.
LEFT CORNER Appliance ILLUSTRATED
To install the appliance face flush with the finished
wall, position the framework to accommodate the
thickness of the finished wall.
A= 25 1/8" minus finishing material thickness each side.
A
38 1/4"
THE UNIT IS
NOT LOAD
BEARING
38 1/4"
6 1/2"
2 1/2"

14
W415-0813 / A / 04.19.10
5.3.3 FACING
Combustible materials may be installed flush with the front of the appliance but must not cover any of the black
face-areas of the appliance. Non-combustible material (brick, stone or ceramic tile) may protrude in these
areas.
It is not necessary to install a hearth extension with this appliance system.
When roughing in the appliance, raise the appliance to accommodate for the thickness of the finished floor ma-
terials, i.e. tile, carpeting, hard wood, which if not planned for will interfere with the opening of the lower access
door and the installation of many decorative flashing accessories.
Objects placed in front of the appliance should be kept a minimum of 48" away from the glass front faces.
5.3.2 BRICK PANEL INSTALLATION
Install the base panels as illustrated in steps 1-4, see "PENINSULA
INSTALLATION PROCEDURE" section. The side panel sits under the
bracket tab. Holding the side panel in position, bend down the tab to
secure. DETAIL 6.
STEP 5
STEP 6
RETAINER
DETAIL 6
5.3.4 FINISHING
Refer to "FINISHING" section for complete instructions regarding
log placement, glass door and upper and lower louvre attach-
ments.
DRYWALL
4" MIN
DRYWALL

15
W415-0813 / A / 04.19.10
5.4.1 INSTALLATION
5.4 SEE-THRU
It is best to frame your appliance after it is positioned and the
vent system is installed. Use 2x4's and frame to local building
codes.
See "BAR TYPE / COUNTER TOP INSTALLATION" section.
A= 22 1/8" minus finishing material thickness, each side.
A
38 1/4"
40 1/2"
6 1/2"
2 1/2"
5.4.2 BRICK PANEL INSTALLATION
Install the base panels as illustrated in steps 1-4, see "PEN-
INSULA INSTALLATION PROCEDURE" section. Both side
panels sit under the bracket tab. Holding the side panel in
position, bend down the tab to secure. DETAIL 6.
RETAINER
RETAINER
STEP 5
STEP 6
DETAIL 5 & 6
5.4.3 FACING
Combustible materials may be installed flush with the front of the appliance but must not cover any of the
black face-areas of the appliance. Non-combustible material (brick, stone or ceramic tile) may protrude in
these areas.
It is not necessary to install a hearth extension with this appliance system.
When roughing in the appliance, raise the appliance to accommodate for the thickness of the finished floor
materials, i.e. tile, carpeting, hard wood, which if not planned for will interfere with the opening of the lower ac-
cess door and the installation of many decorative flashing accessories.
Objects placed in front of the appliance should be kept a minimum of 48" away from the glass front faces.

16
W415-0813 / A / 04.19.10
5.4.4 FINISHING
Refer to "FINISHING" section for complete instructions
regarding log placement, glass door and upper and
lower louvre attachments. DRYWALL DRYWALL
4"
MIN
5.5.1 INSTALLATION
5.5 ISLAND
It is best to frame your appliance after it is positioned.
Use 2x4's and frame to local building codes.
A= 221/8 " minus finishing material thickness each
side.
B= 36 " minus finishing material thickness each end.
To install the appliance face flush with the finished wall,
position the framework to accommodate the thickness
of the finished wall.
A
B
38 1/4"
THE UNIT IS NOT LOAD BEARING
6 1/2"
22 1/8”
36”
2 1/2"
5.5.2 BRICK PANEL INSTALLATION
Install the base panels as illustrated in steps 1-4, see "BRICK PANEL INSTALLATION" section.

17
W415-0813 / A / 04.19.10
DRYWALL DRYWALL
5.5.3 FACING
Combustible materials may be installed flush with
the front of the appliance but must not cover any
of the black face-areas of the appliance. Non-com-
bustible material (brick, stone or ceramic tile) may
protrude in these areas.
It is not necessary to install a hearth extension with
this appliance system.
When roughing in the appliance, raise the appliance
to accommodate for the thickness of the finished
floor materials, i.e. tile, carpeting, hard wood, which
if not planned for will interfere with the opening of
the lower access door and the installation of many
decorative flashing accessories.
Objects placed in front of the appliance should be
kept a minimum of 48" away from the glass front
faces.
5.5.4 FINISHING
Refer to "FINISHING" section for complete instructions regarding mantel requirements and installations, log
placement, glass door and upper and lower louvre attachments.

18
W415-0813 / A / 04.19.10
5.6 MINIMUM MANTEL CLEARANCES
Combustible mantel clear-
ance can vary according to
the mantel depth. Use the
graph to help evaluate the
clearance needed. The three-
sided top extension piece
may be removed if non-com-
bustible framing is faced with
a non-combustible material.
Dashed lines are suitable mantel sizes and clearances
when a non-combustible facing is used.
MANTEL WIDTH
H
E
I
*
H
T
M
A
N
T
E
L
COMBUSTIBLE MATERIALS
7
"
MANTLE
T
O
P
O
F
U
NI
T
3
" MANTL
E
T
O
P
O
F THE
U
NI
T
TOP EXTENTIO
N
7
"
3"
!
WARNING
RISK OF FIRE, MAINTAIN ALL SPECIFIED AIR SPACE CLEARANCES TO COMBUSTIBLES. FAILURE
TO COMPLY WITH THESE INSTRUCTIONS MAY CAUSE A FIRE OR CAUSE THE APPLIANCE TO
OVERHEAT. ENSURE ALL CLEARANCES (I.E. BACK, SIDE, TOP, VENT, MANTEL, FRONT, ETC.) ARE
CLEARLY MAINTAINED.
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE
HEAT RESISTANT TO PREVENT DISCOLOURATION.
73.1

19
W415-0813 / A / 04.19.10
6.0 FINISHING
6.1 HEAT SHIELD STAND-OFF REMOVAL (SEE-THRU INSTALLATION ONLY)
HEAT SHIELD
STAND-OFFS
END HEAT
SHIELD SHOWN
When using a non-combustible finishing material, the stand-offs may be removed, by
removing the set screw in the centre and sliding the stand-offs out of the mounting
clips.
6.2 DOOR INSTALLATION
DOOR OPENING AND CLOSING: The upper louvres must be removed to allow the door to be opened or
closed. To access the lower door latch, open the valve control door. Release the top and bottom door latches,
located at the right side of the door.
!
WARNING
GLASS MAY BE HOT, DO NOT TOUCH GLASS UNTIL COOLED.
THE DOOR LATCHES ARE PART OF A SAFETY SYSTEM AND MUST BE PROPERLY ENGAGED. DO
NOT OPERATE THE APPLIANCE WITH LATCHES DISENGAGED.
FACING AND/OR FINISHING MATERIALS MUST NOT INTERFERE WITH AIR FLOW THROUGH AIR
OPENINGS, LOUVRES OPENINGS, OPERATION OF LOUVRES OR DOORS OR ACCESS FOR
SERVICE. OBSERVE ALL CLEARANCES WHEN APPLYING COMBUSTIBLE MATERIALS.
BEFORE DOOR IS REMOVED TURN THE APPLIANCE OFF AND WAIT UNTIL APPLIANCE IS COOL TO
THE TOUCH. DOORS ARE HEAVY AND FRAGILE SO HANDLE WITH CARE.
75.1
6.3 END DOOR INSTALLATION
Ensure that the door is properly clipped onto the steel lip to prevent overheating, glass breakage and / or dis-
coloration of the upper trim.
To install the door(s), hook it over the steel lip located above the door opening.
Secure with screws along the bottom of the door. Tighten screws snugly. Do not over-tighten.
DOOR
STEEL LIP

20
W415-0813 / A / 04.19.10
6.4 LOG PLACEMENT
PhazerTM logs, glowing and charcoal embers, exclusive to Wolf Steel Ltd. appliances, provide a unique and
realistic glowing effect that is different in every installation. Take the time to carefully position the embers for a
maximum glowing effect.
6.4.2 Place log #1 diagonally across the textured
burner cover onto the studs. The texture is
designed to cradle the underside of the log.
LOCATING
STUDS
LOCATING SCREWS
6.4.3 Depending on the type of installation, the
view of the log positioning will reverse. Here
the lower end of log #2 rests near the back
left corner of the firebox on the locating stud.
The upper end sits on top of log #1, inside
the groove on log #2.
6.4.4 Log # 3 is made up of two pieces, a and b.
Piece #3a is the base of log #3. The base
sits diagonally in the designated area located
between logs #1 and fits tight up against #2.
6.4.1 Looking at the appliance from the valve side,
place the fibre burner onto the locating screws
on the pan burner as illustrated above. It is
important not to cover any burner ports with
the fibre burner.
!
WARNING
FAILURE TO POSITION THE LOGS IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE
ONLY LOGS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY
DAMAGE OR PERSONAL INJURY.
LOGS MUST BE PLACED IN THEIR EXACT LOCATION IN THE APPLIANCE. DO NOT MODIFY THE
PROPER LOG POSITIONS, SINCE APPLIANCE MAY NOT FUNCTION PROPERLY AND DELAYED
IGNITION MAY OCCUR.
THE LOGS ARE FRAGILE AND SHOULD BE HANDLED WITH CARE.
76.1A
