INSTALLATION AND OPERATION INSTRUCTIONS FOR:
VENTED GAS FIREPLACE HEATER
NATURAL GAS MODELS GDS 28-N and GS 28-N
PROPANE GAS MODELS GDS 28-P and GS 28-P
Model GS28 is made up of Model GDS28 and B-Vent Adapter Kit GS-150KT
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33, ANSI Z21.88
Fax:[phone] Email:[email protected]
Web:www.napoleonfireplaces.com
Wolf Steel Ltd., 24 Napoleon Rd.,
Barrie, ON., Canada L4M 4Y8 [phone]
R-2000
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
WARNING: If the information in these instructions is not followed exactly, a fire or
explosionmayresultcausingpropertydamage,personalinjuryordeath.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Donottrytolightanyappliance.
• Donottouchanyelectricalswitch.
• Donotuseanyphone in your building.
• Immediatelycallyourgassupplierfrom
aneighbour'sphone.Followthe gas sup-
plier's instructions.
• If you cannot reach your gas supplier,
callthefiredepartment.

2
W415-0153/A/10.29.01
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
Pg 13 GAS INSTALLATION
Remote Wall Switch / Thermostat
14 FINISHING
Door Closing & Opening
Log Placement
15-16 OPERATION / MAINTENANCE
Spill Switch
Venting Action Check
Operating Instructions
Maintenance
17 REPLACEMENT BLOWER
18 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustments
19-20 REPLACEMENTS
Ordering Replacement Parts
Termination Kits
Burner Kit
Replacement Parts
Accessories
21-22 TROUBLE SHOOTING GUIDE
Pg 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5 LOCATION & CLEARANCES
5-10 DIRECT VENT SPECIFICS
MODEL GDS28
Vent Lengths
Special Installation Example
Offset Installation Example
Air Terminal Locations
Wall & Ceiling Protection
Horizontal Venting Installation
Vertical Venting Installation
Stove Vent Connection
Mobile Home Installation
11-12 B-VENT SPECIFICS
MODEL GS28 Chimney Installation
'B' Vent Adaptations
'B' Vent Installation
Combustion Air
Adding Vent Sections
Flashing and Storm Collar Installation
TABLE OF CONTENTS
WARNING
• The stove is a vented gas-fired heater. Do not burn wood or other materials in this stove.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should
stayawayto avoid burns or clothing ignition. Supervise young childrenwhentheyareinthe same room as
the stove.
• Due to high temperatures, the stove should be located out of traffic and away from furniture and draperies.
• Clothing or other flammable material should not be placed on or near the stove.
• Any safety screen or guard removed for servicing must be replaced prior to operating the stove.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the
stoveand venting system are kept clean. The stoveanditsventing system should be inspected before use
and at least annually by a qualified service person. More frequent cleaning may be required due to exces-
sive lint from carpeting, bedding material, etc. The stove area must be kept clear and free from combusti-
ble materials, gasoline and other flammable vapours and liquids.
• Under no circumstances should this stove be modified.
• This stove must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this stove if any part has been under water. Immediately call a qualified service technician to
inspect the stove and to replace any part of the control system and any gas control which has been under
water.
• Do not operate the stove with the glass door opened, cracked or broken. Replacement of the glass should
be done by a licensed or qualified service person.
• Do not strike or slam shut the stove glass door.

3
W415-0153/A/10.29.01
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO9002 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen who
take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test station. The
complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that you, the
customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace are war-gas fireplace are war-
gas fireplace are war-gas fireplace are war-
gas fireplace are war-
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-
age only), gold plated parts against tarnishing, porcelainized enamelled components and aluminumage only), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
age only), gold plated parts against tarnishing, porcelainized enamelled components and aluminumage only), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
age only), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
extrusion trims.extrusion trims.
extrusion trims.extrusion trims.
extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
covered andcovered and
covered andcovered and
covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will provide replacement parts free of charge during the first year ofwill provide replacement parts free of charge during the first year of
will provide replacement parts free of charge during the first year ofwill provide replacement parts free of charge during the first year of
will provide replacement parts free of charge during the first year of
the limited warranty.the limited warranty.
the limited warranty.the limited warranty.
the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. Repair work,Labour related to warranty repair is covered free of charge during the first year. Repair work,
Labour related to warranty repair is covered free of charge during the first year. Repair work,Labour related to warranty repair is covered free of charge during the first year. Repair work,
Labour related to warranty repair is covered free of charge during the first year. Repair work,
however, requires the prior approval of an authorized company official. Labour costs to thehowever, requires the prior approval of an authorized company official. Labour costs to the
however, requires the prior approval of an authorized company official. Labour costs to thehowever, requires the prior approval of an authorized company official. Labour costs to the
however, requires the prior approval of an authorized company official. Labour costs to the
account ofaccount of
account ofaccount of
account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on a predetermined rate schedule and any repair work mustare based on a predetermined rate schedule and any repair work must
are based on a predetermined rate schedule and any repair work mustare based on a predetermined rate schedule and any repair work must
are based on a predetermined rate schedule and any repair work must
be done through an authorizedbe done through an authorized
be done through an authorizedbe done through an authorized
be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEON warrants its products against manufacturing defects to the original purchaser only -- i.e., the individual or legal entity (registered customer) whose name appears on the
warrantyregistration card filedwith NAPOLEON-- provided thatthe purchase wasmade through anauthorized NAPOLEONdealerand issubjectto thefollowingconditions andlimitations:
Thisfactory warrantyis nontransferableand may not be extendedwhatsoever byany ofour representatives.
Thegas fireplacemust beinstalled by a licenced, authorizedservice technicianor contractor.Installation mustbe done in accordance with the installationinstructions includedwith the
productand alllocal and national building andfire codes.
Thislimited warrantydoesnot coverdamages caused bymisuse, lack ofmaintenance, accident,alterations,abuse orneglect and partsinstalled fromother manufacturers willnullify this
warranty.
Thislimited warrantyfurther does notcover anyscratches, dents, corrosionor discolouring causedby excessiveheat, abrasive andchemical cleanersnor chipping onporcelain enamel
parts,mechanical breakageof PHAZER™logs and embers, nor any venting componentsused inthe installationof the fireplace.
NAPOLEONwarrants itsstainless steel burnersagainst defects inworkmanship and materialfor life,subjectto thefollowing conditions: Duringthe first 10years NAPOLEONwillreplace
or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthe firstyear only,thiswarrantyextends tothe repair orreplacement ofwarranted parts whichare defectivein material or workmanship providedthat theproduct has beenoperated in
accordancewith theoperation instructions andunder normalconditions.
After the first year, with respect to this President's Limited Lifetime Warranty, NAPOLEON may, at its discretion, fully discharge allobligations withrespect to this warranty by refunding
tothe originalwarranted purchaserthe wholesaleprice ofany warranted but defective part(s).
After thefirst year, NAPOLEON willnot beresponsible forinstallation, labouror any othercosts orexpenses relatedto thereinstallationof awarranted part,and such expenses are not
coveredby thiswarranty.
Notwithstandingany provisionscontained inthis President's LimitedLifetime Warranty, NAPOLEON’Sresponsibilityunder thiswarranty isdefined as aboveand itshall not inany event
extendto any incidental,consequential orindirect damages.
This warrantydefines theobligations andliabilityof NAPOLEON withrespectto theNAPOLEON gasfireplace andany otherwarrantiesexpressedor impliedwith respect tothis product,
itscomponents oraccessories areexcluded.
NAPOLEONneither assumes,nor authorizes any third partyto assume,on its behalf, any otherliabilities withrespect tothe saleof this product.NAPOLEON will notbe responsiblefor:
over-firing,downdrafts, spillagecaused by environmentalconditions suchas rooftops, buildings,nearby trees,hills, mountains, inadequatevents orventilation, excessive ventingconfigu-
rations, insufficient makeup air, or negative air pressures which may or may not be caused by mechanical systems such as exhaust fans, furnaces, clothes dryers, etc.
Any damages to fireplace, combustion chamber, heat exchanger, brass trim or other component due to water, weather damage, long periods of dampness, condensation, damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
Thebill ofsale orcopy will berequired togetherwith aserial number and a modelnumber whenmaking anywarranty claims from your authorizeddealer. Thewarranty registrationcard
mustbe returnedwithin fourteendays to register the warranty.
NAPOLEONreserves theright tohave itsrepresentative inspectany productor partthereof priorto honouringany warrantyclaim.
ALLSPECIFICATIONS ANDDESIGNS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICEDUE TOON-GOINGPRODUCT IMPROVEMENTS.NAPOLEON® ISA REGISTERED
TRADEMARKOFWOLFSTEEL LTD. PATENTSU.S.5.303.693.801, DES. 417,497-CAN.2.073.411,2.082.915. © WOLFSTEELLTD.

4
W415-0153/A/10.29.01
GENERAL INFORMATION
Foryoursatisfaction,thisstovehasbeentest-fired
to assure its operation and quality!
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. When the valve is set to "HI", the manifold pres-
sure under flow conditions is 3.5 inches water column for
natural gas and 10 inches water column for propane. When
the fireplace is installed at elevations above 4,500 ft., and
in the absence of specific recommendations from the lo-
cal authority having jurisdiction, the certified high altitude
input rating shall be reduced at the rate of 4% for each
additional 1,000 ft.
Change in flame appearance from "HI" to "LO" is more
evident in natural gas than in propane. Expansion / con-
traction noises during heating up and cooling down cycles
are normal and to be expected.
GDS28: Maximum input is 30,000 BTU/hr for natural
gas and 26,000 BTU/hr for propane. Maximum output for
natural gas is 25,500 BTU/hr at an efficiency of 85% with
the fan on and 75% with the fan off. Maximum output for
propane is 22,360 BTU/hr at an efficiency of 86% with the
fan on and 76% with the fan off. Maximum A.F.U.E. (annual
fuel utilization efficiency) rating is 76% for natural gas and
77% for propane. This stove is not approved for closet or
recessed installations. It is approved for bathroom, bed-
room and bed-sitting room installations.
This stove may be installed in an aftermarket permanently
located, manufactured mobile home, where not prohibited
by local codes.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for
use with other gases, unless a certified kit is used.
GS28: Maximum input is 30,000 BTU/hr for natural
gas and 26,000 BTU/hr for propane. Maximum
output for natural gas is 24,600 BTU/hr at an
efficiency of 82% with the fan on and 80% with
the fan off; and 21,600 BTU/hr for propane at an
efficiency of 83% with the fan on and 80% with
the fan off. This stove is approved for bedroom
and bed-sitting room installations.
CARE OF GLASS, AND PLATED PARTS
Do not use abrasive cleaners to clean these parts. Buff
lightly with a clean dry cloth.
The glass is 3/16" ceramic glass available from your Na-
poleon / Wolf Steel Ltd. dealer.
Do not substitute materials.
Clean the glass after the first 10 hours of operation with a
recommended gas fireplace glass cleaner. Thereafter
clean as required.
Do not clean glass when hot!
If the glass is not kept clean permanent discolouration
and / or blemishes may result.
GENERAL INSTRUCTIONS
THIS GAS STOVE SHOULD BE INSTALLED AND SERV-
ICED BY A QUALIFIED INSTALLER to conform with local
codes. Installation practices vary from region to region and
it is important to know the specifics that apply to your
area, ie: in Massachusetts State:
• The fireplace damper must be removed or welded in
the open position prior to installation of a fireplace
insert.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36
inches.
• The appliance is not approved for installation in a
bedroom or bathroom unless the unit is a direct-vent.
In absence of local codes, install to the current CAN1-
B149 Installation Code in Canada or to the National Fuel
Gas Code, ANSI Z223.1-1988, and NFPA 54-1988 in the
United States. Mobile home installation must conform
with local codes or in the absence of local codes, install
to the current standard for gas equipped mobile housing
CAN/CSA Z240 MH Series in Canada or ANSI Z223.1-
1988 and NFPA 54-1988 in the United States.
Purge all gas lines with the glass door of the stove
opened. Assure that a continuous gas flow is at the
burner before closing the door.
Under extreme vent configurations, allow several min-
utes(5-15)fortheflametostabilizeafterignition.
For optimum performance, it is recommended that all
horizontalrunshave a ¼ inch riseperfoot.
Objects placed in front of the fireplace must be kept a
minimum of 48" away from the front face of the unit.
The stove and its individual shutoff valve must be discon-
nected from the gas supply piping system during any pres-
sure testing of that system at test pressures in excess of
½ psig (3.5 kPa). The stove must be isolated from the gas
supply piping system by closing its individual manual shut-
off valve during any pressure testing of the gas supply pip-
ing system at test pressures equal to or less than ½ psig
(3.5 kPa)
The stove, when installed with a blower, must be electri-
cally connected and grounded in accordance with local
codes. In the absence of local codes, use the current CSA
C22.1 CANADIAN ELECTRICAL CODE in Canada or the
ANSI/NFPA 70-1996 NATIONAL ELECTRICALCODE inthe
United States. The blower power cord must be connected
into a properly grounded receptacle. The grounding prong
must not be removed from the cord plug.

5
W415-0153/A/10.29.01
MAINTAIN THESE MINIMUM CLEARANCES TO
COMBUSTIBLES:
A. 7" D. 143/4"
B. 2" E. 4"
C. 1"*F. 9½"
NOADDITIONAL FLOOR PROTECTION IS REQUIRED
MINIMUM 20" FROM STOVE TOP TO CEILING
*AT ADISTANCE OF 1" FROM THE WALL, ACCESS TO THE BLOWER
SWITCH, ON-OFF SWITCH OR THE BLOWER POWER CORD MAY
NOT BE PRACTICAL.
Aterminalshallnotterminatedirectlyaboveasidewalk
or paved driveway which is located between two sin-
gle family dwellings and serves both dwellings. Local
codesorregulationsmayrequire differentclearances.
Do not allow the inside liner to bunch up on horizontal or
vertical runs and elbows. Keep it pulled tight. A 1-1/4" air
gapallaroundbetweentheinnerlinerandouterstovepipe
isrequiredforsafe operation.
Useafirestopwhenpenetratinginteriorwalls,floororceil-
ing.
LOCATION AND CLEARANCES
Provide adequate ventilation and combustion air.
Provideadequateaccessibilityclearance forservicing
and operating the stove.
Never obstruct the front opening of the stove.
GDS28 AND GS28:
As long as clearance to combustibles is kept within the
required distances, the most desirable and beneficial lo-
cation for a Napoleon stove is in the centre of a building,
thereby allowing the most efficient use of the heat created.
The location of windows, doors and the traffic flow in the
room where the stove is to be located should be consid-
ered. If possible, you should choose a location where the
vent will pass through the house without cutting a floor or
roof joist.
FIGURE2
VENTING LENGTHS AND AIR TERMI-
NAL LOCATIONS
Use only Wolf Steel or Simpson Dura-Vent Model DV-GS
venting components. Minimum and maximum vent lengths,
for both horizontal and vertical installations, and air termi-
nal locations for either system are set out in this manual
and must be adhered to. For Simpson Dura-Vent, follow
the installation procedure provided with the venting com-
ponents. Both Wolf Steel and Simpson Dura-Vent venting
components may have a 0" rise per foot on horizontal runs.
When using Wolf Steel venting components, use only the
following vent kits: WALL TERMINAL KIT GD175 (7-1/2' of
ventingincluded),or1/12 TO 7/12 PITCH ROOF TERMINAL
KIT GD110, 8/12 TO 12/12 ROOF TERMINAL KIT GD111,
FLAT ROOF TERMINAL KIT GD112 orSTOVEPERISCOPE
KIT GD180 (for wall penetration below grade) in conjunc-
tion with the appropriate venting components.
For optimum performance, it is recommended that all
horizontal runs have a minimum ¼ inch rise per foot.
DIRECT VENT SPECIFICS - GDS28
These vent kits allow for either
horizontal or vertical venting of
the stove. FIGURES 3, 4, & 5.
The maximum number of 4"
flexible connections is two hori-
zontally or three vertically (ex-
cluding the stove and the air
terminal connections).
When terminating vertically, the
minimum vertical rise is
34 inches above the stove and
the maximum vertical rise is
40 feet.
Deviation from the minimum vertical vent length can
createdifficultyinburnerstart-upand/or carboning.
Use an adjustable pipe as the final length of rigid pip-
ing to the stove for ease of installation.
FIGURE1
15"
WINDOW OPENING
11¼"
22½"
26
3
/
4
"
7"ø AIR
INTAKE
FIGURE3
17
3
/
4
"
12"
10"
4"ø
FLUE
18½" 5½"
GAS LINE ACCESS HOLE
LOCATED IN PEDESTAL
BASE

6
W415-0153/A/10.29.01
HORIZONTAL RUN NOT TO EXCEED VERTICAL RISE
SPECIAL INSTALLATION EXAMPLE
When a horizontal offset is required in a through-the-roof
installation, the following procedure for vent length calcula-
tions must be followed:
Inaninstallation as shown in FIGURE 7,
lengths A and C are known based on
room height and roof requirements.
Length C must never be less than 29
inches. Any 90° and 45° elbows must
be calculated as 5 feet of venting
each.
The allowable horizontal run can be cal-
culated using these parameters. In this
example, the total vertical height is 20
feet (length "A" is required to be 11 feet
while length "C" needs to be 9 feet). The
maximum vertical length is 40 feet and
all runs and elbows must be subtracted
from this maximum vertical length.
The maximum allowable horizontal run that "B" can be is:
40 ft. (maximum vertical run length)
-11 ft. (through the roof vertical rise "A")
-10 ft. (2 - 90° elbow)
- 9 ft. (vertical run "C")
10 ft. (maximum allowable horizontal length for "B")
The length of "B" must never be greater than the length
of "A" and "C" combined.
OFFSET INSTALLATION EXAMPLE
FIGS 5
FIGURE4
If a first run of 72 inches is re-
quired,using the "First Vent Run"
on the chart shows that a maxi-
mum second run of 48 inches
is allowable.
IF NECESSARY, THE FIRST
RUN AND THE SECOND
RUN MAY BE REVERSED.
REQUIRED
VERTICAL
RISE FROM
FIREPLACE
TO FIRST EL-
BOW IN
INCHES
FIGURE6 CALCULATED HORIZONTAL VENT RUN IN FEET
For optimum flame appearance and stove performance,
keep the vent length and number of elbows to a minimum.
The air terminal must remain unobstructed at all times.
Examine the air terminal at least once a year to verify that it
is unobstructed and undamaged.
The maximum horizontal run is 34 inches with a 90° elbow
located 29" above the stove. FIGURE 4.
The maximum horizontal run with a 57 inch vertical rise
immediately above the stove is 20 feet . Figures 5.
If vertical rises greater than 57 inches are necessary,
the increased rise must be deducted from the maxi-
mumhorizontalrun.
Use chart, Figure 6, to calculate horizontal runs for vertical
rises between 29 and 57 inches.
When calculating maximum run lengths, include 10 feet
for each 90° elbow or 5 feet for each 45° elbow.
Do not include the first elbow directly off the unit.
FIGURE8
57"
first run
72"
second run
48"
FIGURE9
C
B
A
FIGURE7

7
W415-0153/A/10.29.01
FIGURE10
AIRAIR
AIRAIR
AIR TERMINTERMIN
TERMINTERMIN
TERMINAL INSTAL INST
AL INSTAL INST
AL INSTALLAALLA
ALLAALLA
ALLATIONS:TIONS:
TIONS:TIONS:
TIONS:
**
**
* Recommended to prevent condensation on windows and thermal breakage
****
****
** It is recommended to use a heat shield and to maximize the distance to vinyl clad soffits.
******
******
*** The periscope GD-201 requires a minimum 18 inches clearance from an inside corner.
********
********
**** This is a recommended distance. For additional requirements check local codes.
††
††
† Three feet above if within 10 feet horizontally.
‡‡
‡‡
‡ A vent shall not terminate directly above a sidewalk or paved driveway that is located between two single family
dwellings and serves both dwellings.
††††
††††
†† Permitted only if the veranda, porch, deck or balcony is fully open on a minimum of two sides beneath the floor.
†*†*
†*†*
†* Recommenced to prevent recirculation of exhaust products. For additional requirements check local codes.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
12INCHES
9INCHES
12INCHES*
18INCHES**
12INCHES**
0INCHES
0 INCHES***
2 INCHES***
3FEET****
3FEET****
9INCHES
3FEET†
7FEET****
12INCHES****
16INCHES
2FEET†*
Clearanceabove grade,veranda porch,deck or balcony.
Clearancetowindows or doors thatopen.
Clearanceto permanently closedwindows.
Verticalclearancetoventilatedsoffitlocated abovetheterminalwithin
a horizontal distance of 2 feet from the centerline of the terminal.
Clearanceto unventilatedsoffit.
Clearanceto an outside cornerwall.
Clearance to an inside non-combustible corner wall or protruding
non-combustible obstructions (chimney, etc.).
Clearance to an inside combustible corner wall or protruding com-
bustible obstructions ( vent chase, etc.).
Clearanceto each sideof the centerlineextended above themeter
/ regulator assembly.
Clearanceto a serviceregulator vent outlet.
Clearance to a non-mechanical air supply inlet to the building or a
combustion air inlet to any other appliance.
Clearance to a mechanical air supply inlet.
Clearance above a paved sidewalk or paved driveway located on
public property unless fitted with a heat shield kit GD-301.
Clearanceunder a veranda,porch, deck orbalcony.
Clearanceabove theroof.
Clearancefrom an adjacentwall includingneighbouring buildings.
CANADIAN U.S.A.
12INCHES
12INCHES
12INCHES*
18INCHES**
12INCHES**
0INCHES
0 INCHES***
2 INCHES***
3FEET
6FEET
12INCHES
6FEET
7FEET‡
12INCHES††
16INCHES
2FEET†*
INSTALLATIONS

8
W415-0153/A/10.29.01
VERTICAL INSTALLATION: This application occurs when
venting through a roof. FIGURE 3.
Installation kits for vari-
ous roof pitches are
available from your Na-
poleon dealer. See Ac-
cessories to order the
specific kit required.
1. Determine the air terminal location and move the stove
into position. Cut and frame 9 inch openings in the ceiling
and the roof to provide the minimum 1 inch clearance be-
tween the stove pipe and any combustible material. Try to
center the exhaust
pipe location midway
between two joist to
prevent having to cut
them. Use a plumb
bob to line up the
center of the open-
ings.
DONOTFILLTHIS SPACE WITHANYTYPEOFMATERIAL.
A vent pipe shield will prevent any materials such as insu-
lation, from filling up the 1" air space around the pipe.
FIGURE 15. Nail headers between the joist for extra sup-
port.
2. Apply a bead of caulking (not supplied) to the frame-
work or to the Wolf Steel vent pipe shield plate or equiva-
lent (in the case of a finished ceiling), and secure over the
openinginthe ceiling. FIGURE 14. Afirestop must be placed
on the bottom of each framed opening in a roof or ceiling
that the venting system passes through. FIGURE 13. Apply
a bead of caulking all around and place a firestop spacer
over the vent shield to restrict cold air from being drawn
into the room or around the stove. Ensure that both spacer
and shield maintain the required clearance to
combustibles. Once the vent pipe is installed in its final
position, apply sealant between the pipe and the firestop
spacer.
3. In the attic, after the pipe
has been installed, slide the
vent pipe collar down to cover
up the open end of the shield
andtighten.Thiswillpreventany
materials, such as insulation,
from filling up the 1" air space
around the pipe. FIGURE15
VENT PIPE
SHIELD
VENT
PIPE
COLLAR
FIGURE14
FIGURE13
For safe and proper operation of the stove, follow
the venting instructions exactly.
HORIZONTAL INSTALLATION: This application occurs
when venting through an
exterior wall. FIGURES
4, 5, & 11. Having deter-
mined the air terminal lo-
cation, cut and frame a hole
in an exterior wall with a
minimum square or round
opening of 9". (As an alter-
native to framing, a vent
pipe shield may be in-
stalled, ensuring a 1" clear-
ance to combustibles.
See Figure 12.)
For optimum performance, the stove pipe should rise
¼" per foot of run.
1. Mark and cut the vent pipe shield to the determined
depth of the combustible wall. Apply a bead of caulking (not
supplied) to the framework or to the shield plate (in the
case of a finished wall) and secure the shield through the
opening to the interior wall. The final location of the vent
pipe shield should maintain the required clearance to
the 7" vent pipe. Do not fill this cavity with any type of
material. Apply a bead of caulking all around and place a
firestop spacer over the vent shield to restrict cold air from
being drawn into the room or around the stove. Ensure that
both spacer and shield maintain the required clearance to
combustibles. Once the vent pipe is installed in its final
position, apply sealant between the pipe and the firestop
spacer.
FIGURE12
OR
WALL AND CEILING PROTECTION
FIGURE11

9
W415-0153/A/10.29.01
VERTICAL VENTING INSTALLATION
1. Fasten the roof
support to the roof us-
ing the screws pro-
vided. The roof support
is optional. In this case
the venting is to be ad-
equately supported
using either an alter-
nate method suitable
to the authority having
jurisdiction or the op-
tional roof support.
2. Slip a 4" diameter length of aluminium flexible liner a
minimum of 2" over the inner sleeve of the air terminal.
Secure to the sleeve using 3 screws
and flat washers. Seal the joint and
screw heads using high temperature
sealant. Repeat using a 7" diameter
length of rigid piping.
If the attic space is tight, we rec-
ommend adding sufficient lengths
of 7" rigid piping, secured and
sealed as necessary.
3. Thread the air terminal pipe assembly down through
the roof support and attach, ensuring that a minimum 16"
of air terminal will penetrate the roof when fastened. The
air terminal must be located vertically and plumb.
4. Remove nails from the shingles, above and to the
sides of the chimney. Place the flashing over the air termi-
nal and slide it underneath the sides and upper edge of
the shingles. Ensure that the air terminal is properly
centered
within the
flashing, giv-
ing a 3/4"
margin all
around. Fas-
ten to the roof.
Do NOT nail
through the
lower portion
of the flash-
ing. Make weather-tight by sealing with caulking. Where
possible, cover the sides and top edges of the flashing
with roofing material.
5. Apply a heavy bead of waterproof caulking 2 inches
above the flashing. Slide the storm collar around the air
terminal and down to the caulking. Tighten to ensure that a
weather-tight seal between the air terminal and the collar
is achieved. Attach the other storm collar centered between
the air intake and air exhaust slots onto the air terminal.
Tighten securely.
6. Attach the vertical rain cap.
7. In the attic, slide the vent pipe collar down to cover up
the open end of the shield and tighten. This will prevent any
materials, such as insulation, from filling up the 1" air space
around the pipe. Figure 15.
HORIZONTAL VENTING INSTALLATION
For safe and proper operation of the stove, follow the
ventinginstructionsexactly.
Forhorizontalruns,both WolfSteelandSimpsonDura-
vent venting components may have a 0" rise per foot.
For optimum performance it is recommended that all
horizontal runs have a minimum ¼ inch rise per foot.
1. Stretch the 4" diameter aluminium flexible liner to the
required length taking into account the additional length
needed for the finished wall surface.
Spacers are attached to the 4" inner flex liner at predeter-
mined intervals to maintain a 1-1/4" air gap to the 7" outer
stove pipe. These spacers must not be removed.
Slip a 4" diameter length of aluminium flexible liner a mini-
mum of 2" over the inner sleeve of the air terminal. Secure
to the sleeve using 3 screws. Seal the joint and screw
heads using the high temperature sealant provided.
2. Slip the first section of 7" diameter stove pipe a mini-
mum of 2" over the outer sleeve of the air terminal.Secure
to the sleeve using 3 screws. Seal the joint and screw
heads using high temperature sealant.
3. Insert the liners through the firestop / vent pipe shield.
Holding the air terminal (lettering in an upright, readable
position), secure to the exterior wall. Make weather tight by
sealing with caulking (not supplied). The air terminal mount-
ing plate may be recessed (up to 3/4" maximum) into the
exterior wall or siding.
4. If more than one length of liner needs to be used to
reach the stove, couple them together as illustrated in
FIGURE 17. Seal the joints using the same procedure as
described above.
The vent system must be supported approximately every
10 feet along a horizontal run. Use supports or equivalent
non-combustible strapping to maintain the 1" clearance
from combustibles.
FIGURE16
FIGURE17
FIGURE18
FIGURE19
FIGURE20

10
W415-0153/A/10.29.01
Ensure that the sealant is not visible on the exte-
rior pipes once installation is completed. An op-
tional decorative brass band is available for this
use. (Standard with a GD175 kit). In the event that
the venting must be disassembled, care must be
taken to reseal the venting.
MOBILE HOME INSTALLATION
In Canada, mobile home installation may be vented hori-
zontally or vertically. In the United States, it may only be
installed vertically. See "Vertical Venting" or "Horizontal Air
Terminal Installation" for installation.
The fireplace is equipped with two 5/16" diameter holes
located near each corner of the base. For mobile home
installations, the fireplace must be fastened in place. Use
#10 screws, inserted through the holes in the base to se-
cure. It is recommended that the fireplace be secured in all
installations.
STOVE VENT CONNECTION
1. Attach the adjustable pipe to the last section of rigid
piping. Secure with screws and seal.
2. Install the 4" aluminium flexible liner to the stove. Se-
cure with 3 screws and flat washers. Seal the joint and
screw holes using the high temperature sealant provided.
3. Run a bead of high temperature sealant around the
inside of the air intake collar. Pull the adjustable pipe a
minimum 2" into the air intake collar.
Continue with "Gas Installation" Page 13
SEALANT
SPEED SWITCH
COMBUSTION AIR
COVER PLATES
& GASKETS
8"
SWITCH
ON/OFF
2" OVERLAP
11½"
VARIABLE
SELF DRILLING
SCREWS
#8x1/2"
HI-TEMP
FIGURE21

11
W415-0153/A/10.29.01
COMBUSTIONAIRCOVER
PLATES & GASKETS
INSTINST
INSTINST
INSTALLING 'B'ALLING 'B'
ALLING 'B'ALLING 'B'
ALLING 'B' VENTVENT
VENTVENT
VENT::
::
:
Follow the instructions for "Wall and Ceiling Protection".
ADAPTERINSTALLATION FIGURE 24
1. Remove the spill switch bracket from the rear of the
adapter.
2. Gently pull the two wire terminals (located inside the 7"
flue collar at the top of the stove) out approximately 8 inches.
3. Bring the wires through the lower hole in the adapter and
out the spill switch opening.
To pass the wires through
theholemoreeasily,temporarilytapethetwoterminals
together.
4. With the spill switch opening aligned to the back of the
stove, push the crimped edge of the adapter into the stove
flue collar.
5. Connect the wire terminals to the spill switch and re-
secure the bracket.
6. Secure the terminal block into place as shown with the
screw supplied.
7. Unscrew the wire access cover plate from the rear right
hand side of the firebox. Remove and discard the gasket.
SEE FIGURE 25. Remove the knockout from the cover plate
and insert the protective bushing. Pull both spill switch wires
through the bushing taking up any slack. Replace the cover
plate. Connect one wire end to the terminal block and the
other end to terminal 1 of the gas valve. FIGURE 31. Con-
nect the two wires running down the left side of the unit
from the on-off switch to the remaining tab on the terminal
block and to terminal 3 on the gas valve.
CHIMNEY INSTALLATION
THREE TYPES OF
CHIMNEY SYSTEMS
MAY BE USED WITH
THIS STOVE:
B-VENT SPECIFICS - MODEL GS28
FIGURES22
SWITCH
SPILL
ADAPTER
FIGURE24
'B' VENT ADAPTATIONS
1. Remove and discard the two combustion air cover plates
and gaskets located on the rear panel of the unit. SEE FIG-
URE 23.
2. Replace the four screws per side to secure the rear
panel to the unit.
FIG.23
FIGURE25
TERMINALBLOCK
TERMINAL BLOCK
WIRE ACCESSWIRE ACCESS
WIRE ACCESSWIRE ACCESS
WIRE ACCESS
COCO
COCO
COVER PLAVER PLA
VER PLAVER PLA
VER PLATETE
TETE
TE

12
W415-0153/A/10.29.01
For aesthetics, the adapter has been designed to accept
a standard matte black 7" stove pipe and the Napoleon
decorative brass band (standard with the GS-150KT). Both
are available from your Napoleon dealer.
B-VENT MODEL GS28 ONLY:
Attach the B-Vent label, shown below, in the control
area of the appliance.
COMBUSTION AIR
A chimney venting this stove shall not vent any solid
fuelburningappliance.
For optimum performance it is recommended that all
horizontal runs have a minimum ¼ inch rise per foot.
Any stove needs air for safe operation and must be
installedinsucha waythatadequatecombustionairis
available.
ADDING VENT SEC-
TIONS: For ease of assem-
bly, a 7" telescoping stove
pipe may be installed over the
4" vent connection of the
adapter. Add vent sections,
twist locking (clockwise) se-
curely, to the required height.
The vent should extend, at
least, 3 feet above its point of
contact with the roof and, at
least, 2 feet higher than any
wall, roof or building within 10
feet. FIGURE 26. (This is a
guideline only; local venting
codes should be followed
which may differ in height and
clearance requirements.)
Continue with "Gas Installation" Page 13
INSTALLING FLASHING AND STORM
COLLAR
Remove nails
from the shingles
above and to the
sides of the chim-
ney. Place the
flashing over the
vent pipe and
slide it under-
neath the sides
and upper edge
of the shingles.
Ensure that the
vent pipe is properly centered within the flashing, giving a
3/4" margin all around. Fasten to the roof on the top and
sides. DO NOT NAIL through the lower portion of the flash-
ing. Make weather-tight by sealing with caulking. Where
possible, cover the sides and top edges of the flashing
with roofing material.
Apply waterproof caulking around the vent, 1" above the
top of the flashing and push the storm collar down into the
caulking. FIGURE 27. Attach a rain cap to the top of the last
vent section.
FIGURE26
FIGURE27
ATTACHTHISLABELIN THE CONTROLAREAOFTHEFIREPLACE.
THIS FIREPLACE HAS BEEN CONVERTED TO A ‘B’VENT MODEL.
ATTACHEZCETETIQUETTEDANSLA REGION DE CONTROLEDUFOYER.
CEFOYER A ETECONVERTI A UN MODELEA SYSTEME D’EVACUATION ‘B’.

13
W415-0153/A/10.29.01
Mark the appropriate boxes on the rating plate label to indi-
cate the model type depending on the installation (direct
ventor B-vent).
Read the section on opening the door in "Finishing" prior
to proceeding to prevent damaging the unit.
Bring the gas line to the stove through either the opening
in the pedestal back or through the floor directly beneath
the pedestal base.
Install rigid black pipe, or 1/2" type L copper tubing with a
shutoff valve to the stove.
Seal and tighten the gas line securely to the flex connector
supplied.DONOTKINKFLEXIBLECONNECTOR.
MODEL GDS28 ONLY: Attach the two leads from the on/
off switch to terminals 1 and 3 located on the gas valve.
Do not connect either the wall switch, thermostat or
gas valve to electricity (110 volts).
FIGURE28
O
L
O
T
P
I
L
L
O
T
I
H
N
O
P
O
I
F
F
FIGURE29
GAS INSTALLATION
Check for gas leaks by brushing on a soap and water solu-
tion. DO NOT USE OPEN FLAME.
Forease of accessibility,an optional remotewallswitch
or millivolt thermostat may be installed in a convenient
location. Route a double strand of solid core millivolt
wirefrom the gas stoveto the wall switch/ millivolt ther-
mostat. The recommended maximum lead length de-
pends on the wire size: WIRESIZE
MAX.LENGTH
14 gauge 100 feet
16 gauge 60 feet
18 gauge 40 feet
DIRECT VENT MODEL GDS28: Disconnect the exist-
ing wires from terminals 1 and 3 (from the on/off switch)
and replace with the leads from the wall switch/millivolt
thermostat.
B-VENT MODEL GS28: Disconnect the on/off switch wire
from terminal 3 on the valve and the second switch wire
from the terminal block. Replace each connection using
the wires from the wall switch/millivolt thermostat.
SERIALNUMBER
NO.DESERIE
MODELCDVS280/GDS28APPROVEDFOR BEDROOM,BATH-
ROOM&BEDSITTINGROOMINSTALLATION. SUITABLE FOR
MOBILEHOMEINSTALLATION IFINSTALLEDIN ACCORDANCE
WITHTHECURRENTSTANDARDCAN/CSAZ240MHSERIES
GAS EQUIPPED MOBILE HOMES, IN CANADA OR IN THE
UNITED STATES THE MANUFACTURED HOME
CONTRUCTION AND SAFETY STANDARD, TITLE 24 CFR,
PART3280.WHENTHISUSSTANDARDISNOT APPLICABLE
USETHESTANDARD FORFIRESAFETY CRITERIAFORMANU-
FACTUREDHOMEINSTALLATIONS,SITESAND COMMUNI-
TIES,ANSI/NFPA501A.
HOMOLOGUEPOURINSTALLATIONDANSUNE CHAMBRE A
COUCHER,UNESALLEDEBAIN ET UN STUDIO.APPROPRIE
POURINSTALLATIONDANSUNE MAISON MOBILESISONIN-
STALLATION CONFORME AUX EXIGENCES DE LA NORME
CAN/CSAZ240MHSERIE DEMAISONSMOBILES EQUIPEESAU
GAZ,ENVIGUEURAUCANADAOUAUXETATS-UNISDELA
NORMEDESECURITEETDECONSTRUCTION DE MAISONS
MANUFACTUREES,TITRE24CFR,SECTION3280.DANSLE
CAS OU CETTE NORME D'ETATS-UNIS NE PEUT ETRE
APPLIQUEE,SEREFERERALANORMERELATIVEAU CRITERE
DEMESURESDESECURITE CONTRE L'INCENDIEPOURLES
INSTALLATIONSDANSLESMAISONSMANUFACTURES, LES
SITESETLESCOMMUNAUTES,ANSI/NFPA501A .
STEADYSTATEEFFICIENCY(NG):75%FANOFF/78%FANON
STEADYSTATEEFFICIENCY(LP):75%FANOFF/79%FANON
EFFICACITE CONSTANTE (GN): 75%VENT.ARRETE
78%VENT.FONCTIONNE
EFFICACITECONSTANTE(GP):75% VENTILATEURARRETE
79%VENTILATEURFONCTIONNE
STEADY STATE EFFICIENCY APPLIES TO CANADA ONLY /
L'EFFICACITECONSTANTES'APPLIQUENTSEULEMENTAU
CANADA.
AFUE (NG/LP) (GN/GP): 64%/ 65%
MINIMUMANDMAXIMUMHORIZONTALVENT LENGTHS ARE
25INCHESAND20FEETRESPECTIVELY.LESLONGUEURS
HORIZONTALESMINIMALEETMAXIMALESONT25 POUCES
ET20PIEDS RESPECTIVEMENT.
THEAPPLIANCEMUSTBEVENTEDUSINGTHEAPPROPRI-
ATENAPOLEON VENT KITS. SEE OWNERS INSTALLATION
MANUALFORVENTINGSPECIFICS.PROPERREINSTALLA-
TIONANDRESEALING ISNECESSARYAFTER SERVICINGTHE
VENT-AIRINTAKESYSTEM.
L'APPAREIL DOIT EVACUER SES GAZ EN UTILISANT
L'ENSEMBLE D'EVACUATION PROPRE A NAPOLEON.
REFERERAUMANUELD'INSTALLATIONDEPROPRIETAIRE
POURL'EVACUATIONPRECISE.ILEST IMPORTANT DEBIEN
REINSTALLERET RESCELLER L'EVENT APRES AVOIR AS-
SURELEMAINTIEN DUSYSTEMEDEPRISE D'AIR.
MANIFOLD PRESSURE: 3.5 INCHES W.C. (NG) / 10 INCHES
W.C.(LP)
PRESSION AU COLLECTEUR: 3.5" D'UNE COLONNE
D'EAU(GN) 10" D'UNE COLONNE D'EAU (PG)
MINSUPPLYPRESSURE: 4.5"W.C.(NG)/11"W.C.(LP)
PRESSIOND'ALIMENTATIONMIN:4.5"D'UNECOLONNED'EAU
(GN) 11" D'UNE COLONNE D'EAU (PG)
MAX.SUPPLYPRESSURE:7"W.C.(NG) / 13" W.C. (LP)
PRESSIOND'ALIMENTATIONMAX:7"D'UNECOLONNED'EAU
(GN) 13" D'UNE COLONNE D'EAU (PG)
FOR USE WITH GLASS DOORS CERTIFIED WITH THIS UNIT
ONLY.
UTILISER AVEC LES PORTES VITREES HOMOLOGUEES
SEULEMENTAVECCETTEUNITE.
WARNING:DONOTADDANYMATERIALTOTHEAPPLIANCE,
WHICHWILLCOMEINCONTACTWITHTHEFLAMES,OTHER
THANTHATSUPPLIEDBYTHEMANUFACTURERWITHTHEAP-
PLIANCE.
AVERTISSEMENT: N'AJOUTEZ PAS A CET APPAREIL
AUCUN MATERIAU DEVANT ENTRER EN CONTACT
AVECLESFLAMMESAUTRE QUECELUIQUIEST FOURNI
AVECCETAPPAREIL PARLEFABRICANT.
MINIMUMCLEARANCETOCOMBUSTIBLEMATERIAL/
DEGAGEMENTSMINIMAUXDESMATERIAUXCOMBUSTIBLES:
A7" D17½"
B2" E6¼"
C1" F9½"
20"TOCEILINGFROMSTOVETOP
20"ENTRE LEDESSUSDUFOYERETLEPLAFOND
ELECTRICAL RATING / CLASS.: 115V1.5AMP60HZ
MODEL CS280/GS28 APPROVED FOR BEDROOM, &
BEDSITTINGROOMINSTALLATION.HOMOLOGUEPOURIN-
STALLATION DANS UNE CHAMBRE A COUCHER, & UN
STUDIO.
STEADY STATE EFFICIENCY (NG): 80%FAN OFF / 82%
FAN ON
STEADY STATE EFFICIENCY (LP): 80% FAN OFF / 83%
FAN ON
EFFICACITE CONSTANTE (GN): 80%VENT.ARRETE
82%VENT. FONCTIONNE
EFFICACITECONSTANTE (GP):80%VENTILATEURARRETE
83%VENTILATEURFONCTIONNE
STEADYSTATEEFFICIENCY APPLIESTOCANADAONLY /
L'EFFICACITECONSTANTES'APPLIQUENTSEULEMENTAU
CANADA.
AFUE (NG/LP) (GN/GP): 66%/68%
THISAPPLIANCEMUSTBEINSTALLEDUSINGANADAPTER
KITGS-150KT.CETAPPAREILDOITETREINSTALLEENUTILI-
SANTUNENSEMBLEADAPTATEURGS-150KT.
NOTFORUSEWITHSOLIDFUEL
UNCOMBUSTIBLESOLIDENEDOIT PAS ETRE UTILISE
AVECCETAPPAREIL
WOLF STEEL LTD
BARRIE, ONTARIO CANADA
MADEINCANADA/ FABRIQUEAUCANADA
WS-385-165
GDS28
CERTIFIED UNDER: CSA 2.33A-M98, ANSI Z21.88A-1998 VENTED GAS FIREPLACE HEATER. APPLIANCE MUST BE INSTALLED USING
BURNER KIT: GDS28BN-KT, OR GDS28BP-KT.
HOMOLOGUE SELON LES NORMES: CSA 2.33A-M98, ANSI Z21.88A-1998 FOYER DE CHAUFFAGE AU GAZ AVEC EVACUA-
TION. CET APPAREIL DOIT ETRE INSTALLE EN UTILISANT UN ENSEMBLE DU BRULEUR: GDS28BN-KT, OU GDS28BP-KT.
ALTITUDE/ELEVATION
INPUT/ALIMENTATION
REDUCEDINPUT/ALIMENTATIONREDUITE
OUTPUT(CDVS280/GDS28)RENDEMENT
OUTPUT(CS280/GS28)RENDEMENT
ORIFICE/INJECTEUR
DIRECTVENTMODEL
‘B’VENTMODEL
0-4500ft (0-1370m)
30,000BTU/h
18,000BTU/h
22,500BTU/h
24,000BTU/h
#37
0-4500ft (0-1370m)
26,000BTU/h
15,000BTU/h
19,500BTU/h
20,800BTU/h
#53
GDS28-P
GS28-P
CDVS280-P
CS28-P
CDVS280-N
CS280-N
GDS28-N
GS28-N

14
W415-0153/A/10.29.01
DOOR CLOSING AND OPENING
When installing the fire viewing door, a simple procedure
must be followed in order to not damage the door. First
open both side doors fully. Insert the pins on the door left
side into the hinge bushings. Swing the door closed and
engage the latches into the catch slots. Push the latch han-
dles backwards to secure the closed door. It may be nec-
essary to lift the door when securing it to ensure that it is in
a horizontal position.
To open the door, repeat in reverse order.
FINISHING
LOG PLACEMENT INSTRUCTIONS
PHAZERTM logs, glowing embers and charcoal embers ex-
clusive to Napoleon Fireplaces, glow when exposed to di-
rect flame and provide a unique and realistic glowing effect
that is different in every installation. Use only certified
PHAZERTM logs, glowing embers and charcoal embers
available from your Napoleon / Wolf Steel Ltd. dealer.
Positioning the logs improperly will cause flame
impingement and carboning.
Place the back log into the firebox pushing it as close to the
firebox wall as possible and centered onto the log support
pan. FIGURES31
FIGURES 30
Place the front log on the ember screen lining up the studs
with the holes on the bottom of the log.
CATCH
SLOT
DOOR
LATCH
HINGE
PIN
BUSHING
Set the two crossover logs into the pockets provided on
both the front and rear logs., as shown.
Tear the glowing embers into pieces and place onto the
screen beneath the front log. Care should be taken to shred
the embers into thin, small irregular pieces as only the
exposed edges of the fibre hairs will glow when exposed
to direct flame; however care should be taken to not block
the burner ports. Blocked ports can cause an incorrect flame
pattern, carbon deposits and delayed ignition.
FRONT LOG
3
RIGHT LOG
4
6CHARCOAL EMBERS
LEFT LOG
Randomly place the charcoal embers along the front of the
support pan and some onto the screen in a realistic man-
ner. Fine dust found in the bottom of the bag should not
be used. Do not place any embers on the burner.
Log colours may vary. During the initial use of the fireplace,
the colours will become more uniform as colour pigments
burn in during the heat activated curing process.
5
GLOWING
EMBERS
REAR LOG
2
SCREEN
1
FRONT LOG
STUDS

15
W415-0153/A/10.29.01
OPERATING INSTRUCTIONS
The on-off switch is located on the back of the unit at the top left corner on models GDS28 and GS28.
Whenlitforthefirsttime,thefireplacewillemit aslightodourforafewhours.Thisisanormaltemporarycondition
caused by the curing of the logs and the "burn-in" of internal paints and lubricants used in the manufacturing
processandwillnot occuragain.Simplyopena windowtosufficientlyventilatetheroom. Afterextendedperiods
ofnon-operationsuch asfollowingavacationor awarmweatherseason,the fireplacemayemitaslightodourfor
a few hours. This is caused by dust particles in the heat exchanger burning off. Open a window to sufficiently
ventilatetheroom.
MODEL GS28 ONLY: VENTING ACTION
CHECK
A check for correct venting action must be made
before theinstalledstoveisleft withthecustomer.
Test in the following manner:
1. Close all doors and windows in the room / start
exhaust fans in the home / turn fire-
place blower off (if equipped).
2. Set controls to "high" and light
the unit.
3. Wait 5 minutes. Light a match
and extend it 1" into the hole located
above the spill switch bracket on the
adapter.
4. Venting action is satisfactory if
the flame stays lit. Venting action is
unsatisfactory if the flame extin-
guishes.
5. If venting action is unsatisfactory, turn the unit off,
wait 10 minutes and try again. If the match does not stay
lit, turn the unit off and check for vent blockage or restric-
tion. If necessary, consult with a qualified inspector.
Purge all gas lines with the glass door open. As-
sure that a continuous gas flow is at the burner
before closing the door. Allow several minutes
(5-15) for the flame to stabilize after ignition.
MODEL GS28 ONLY: SPILL SWITCH
This is a thermally activated switch, attached to the back
of the chimney adapter, which senses the change in
temperature and shuts down the gas valve in the event
of a severe downdraft of air or a blocked or disconnected
vent. It acts as a safety shutoff to prevent a build up of
carbon monoxide or an explosion of unburnt gases dur-
ing start up. If the flue is blocked or has no "draw", the spill
switch will automatically shut off the supply of gas within
about 5-10 minutes.
TAMPERING WITH THE SWITCH CAN RESULT IN CAR-
BON MONOXIDE (CO) POISONING AND POSSIBLE
DEATH.
OPERATION / MAINTENANCE
FIGURE32
OPERATING INSTRUCTIONS
FOR YOUR SAFETY READ BEFORE OPERATING
D. Do not use this fireplace if any part has been under
water. Immediately call a qualified service technician to
inspect the fireplace and replace any part of the control
system and any gas control which has been under water.
WHAT TODO IFYOUSMELL GAS:
• Turn off all gas to the fireplace.
• Open windows.
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone
in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire de-
partment.
WARNING: Ifyoudonotfollow theseinstructionsex-
actly, a fire or explosion may result causing property
damage, personal injury or loss of life.
A. This fireplace is equipped with a pilot which must be
lit by hand while following these instructions exactly.
B. Before operating smell all around the fireplace area
for gas and next to the floor because some gas is
heavier than air and will settle on the floor.
C. Useonlyyourhand to turn the gas control knob / manual
shutoff knob. Never use tools. If the knob will not turn by
hand, do not try to repair it. Call a qualified service tech-
nician. Force or attempted repair may result in a fire or
explosion.

16
W415-0153/A/10.29.01
LIGHTING INSTRUCTIONS
WARNING:WARNING:
WARNING:WARNING:
WARNING: The gas valve has an interlock device which will not allow the pilot burner to be lit until the thermo-
couple has cooled. Allow approximately 60 seconds for the thermocouple to cool.
When lighting and relighting, the gas knob cannot be turner from PILOT to OFF unless the knob is depressed.
1. STOP! Read the safety information on the operating
label.
2. Turn off all electric power to the fireplace.
3. Turn the gas knob clockwise
to off.
4. Wait five (5) minutes to clear out any gas. If you smell
gas including near the floor, STOP! Follow "B" on the op-
erating label. If you don't smell gas go to the next step.
5. Find pilot located in front of the back log.
6. Turn gas knob counter-clockwise to pilot.
7. Depress and hold the gas knob while lighting the pilot
with the push button igniter. Keep knob fully depressed
for one minute, then release. If the pilot does not con-
tinue to burn, repeat steps 3 through 6.
8. With the pilot lit, turn the gas knob counter-clockwise
to on.
9. If equipped with a remote ON-OFF switch, main burner
may not come on when you turn the valve to ON. The
remote switch must be in the ON position to ignite the
burner.
10. Turn on all electric power to the fireplace.
PILOT
THERMOPILE
THERMO-
COUPLE
BURNER
1. Turn off all electric power to the fireplace if service is to
be performed. 2. Push in gas control knob slightly and turn clock-
wise to off. Do not force.
MAINTENANCE INSTRUCTIONS
Turn off the gas and unplug electrical
power before servicing the stove!
CAUTION: Label all wires prior to disconnection when serv-
icing controls. Wiring errors can cause improper and dan-
gerous operation. Verify proper operation after servicing.
This stove and its venting system should be inspected
before use and at least annually by a qualified service per-
son. The fireplace area must be kept clear and free of com-
bustible materials, gasoline or other flammable vapours
and liquids. The flow of combustion and ventilation air must
not be obstructed.
1. In order to properly clean the burner and pilot assem-
bly, remove the logs exposing both assemblies.
2. Keep the control compartment, logs, burner, air shut-
ter opening and the area surrounding the logs clean by
vacuuming or brushing, at least once a year.
3. Check to see that all burner ports are burning. Clean
out any of the ports which may not be burning or are not
burning properly.
4. Check to see that the pilot flames are large enough to
engulf the thermocouple and the thermopile on one leg
and reaches toward the burner on the other leg.
5. Replace the cleaned logs.
6. Check to see that the main burner ignites completely
on all openings when the gas knob for the burner is turned
on. A 5-10 second total light-up period is satisfactory. If
ignition takes longer, consult your Napoleon dealer/dis-
tributor.
7. Check that the door gasketing is not broken or miss-
ing. Replace if necessary.
8. Lift the door from its hinges to clean hinge pins and
lubricate using high-temp dry graphite if necessary. Re-
place.
NOTE: Duetothehigh temperaturesthatthehingesex-
perience,wetlubricantssuchasoilandWD40willcause
the hinge to seize and are therefore not suitable.
TO TURN OFF GAS
P
I
P
I
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
GAS KNOB AT OFF

17
W415-0153/A/10.29.01
REPLACEMENT BLOWER
Blower replacement may be done through either the
firebox or from the rear of the unit. Using the rear panel
is recommended.
1. Turn off the electrical power and the gas supply to the
stove.
INSTALLATION THROUGH THE REAR
PANEL:
FOR MODEL GDS28
2. Remove the two combustion air covers and gaskets
held on with 4 screws each. Remove the rear panel held
in place with 6 screws.
3. Remove the 2 screws holding the blower to its mount-
ing plate. Disconnect the two blower wires.
4. Replace the blower and reconnect the two wires. When
replacing the rear panel, ensure that the wires are neither
pinched nor interfere with the blower operation. Ensure
that the combustion air cover plates and gaskets are prop-
erly installed and sealed.
FOR MODEL GS28
2. Remove the 8 screws securing the air intake manifolds
to the rear panel. Remove the rear panel held in place with
6 screws.
3. Remove the 2 screws holding the blower to its mount-
ing plate. Disconnect the two blower wires.
4. Replace the blower and reconnect the two wires. When
replacing the rear panel, ensure that the wires are neither
pinched nor interfere with the blower operation. Re-se-
cure the air intake manifolds.
INSTALLATION THROUGH THE FIRE-
BOX:
Replacement blower access gasket is required.
2. Open the lower control door, the two side doors, and the
fire viewing door. Remove the logs.
3. Remove the blower access plate held on with 6 screws.
4. Disconnect the two blower wires. Remove the blower
bracket held on with 2 screws.
5. Replace the blower using the existing bracket. Replace
the bracket/blower assembly on the unit.
6. Reconnect the two wires. Hold the replacement gasket
in place and reattach the blower access plate. Replace the
logs. Close all doors.
Turn the gas supply and electricity back on.
Becausethe bloweris thermallyactivated, whenturned
on, it will automatically start approximately 15-30 min-
utesafterlightingthe stoveandwillrunforapproximately
30-45minutesafter the stove hasbeen turned off. Use
of the fan increases the output of heat.
Drywalldustwillpenetrateinto theblowerbearingscaus-
ing irreparable damage and must be prevented from
cominginto contact withthe bloweror its compartment.
Any damage resulting from this condition is not cov-
eredby the warrantypolicy.
FIGURE33
FIGURE35 -INSTALLATIONFROM THEFRONT
FIGURE34- INSTALLATIONFROMTHEREAR
BLOWER
SCREWS
AIR INTAKE MANIFOLDS

18
W415-0153/A/10.29.01
PILOT BURNER ADJUSTMENT
Adjust the pilot screw to provide properly sized flame. Turn
in a clockwise direction to reduce the gas flow.
FIGURE36
FLAME MUST ENVELOP
UPPER 3/8" TO 1/2" OF
THERMOCOUPLE &
THERMOPILE
THERMOPILE
THERMO-
COUPLE
FIGURE37
P
I
INLET PRESSURE
TAP
P
I
PILOT SCREW
MANIFOLD TAP
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
ADJUSTMENTS
VENTURI ADJUSTMENT
Remove the 2 screws securing the control panel plate. To
access the venturi, remove the air housing cover plate, held
on with 2 screws. Take care not to damage the gasket.
Natural gas and propane models have air shutters set fully
open. Closing the air shutter will cause a more yellow flame,
but can lead to carboning. The flame may not appear yel-
low immediately; allow 15 to 30 minutes for the final flame
colour to be established. After making adjustments re-
place the gasket and cover plate. Re-secure the control
panel plate.
FIGURE38b
Air shutter adjustment must only be
done by a qualified gas installer!
FIGURE39
FIGURE38a
CONTROL PANEL PLATE
AIR HOUSING
COVER PLATE

19
W415-0153/A/10.29.01
included with GD175
included
with
GD180
REPLACEMENTS
ORDERING REPLACEMENT PARTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally all parts
can be ordered through your Napoleon dealer or distributor. When ordering replacement parts always give the following
information: 1. MODEL &SERIAL NUMBER OF FIREPLACE 3. PART NUMBER 5. FINISH
2. INSTALLATION DATE OF FIREPLACE 4. DESCRIPTION OF PART
REPLACEMENT PARTS
For warranty replacement parts, a photocopy of the original invoice
will be required to honour the claim.
GDS28 / GS28 TERMINATION KITS ALL KIT
ITEMS MAY BE PURCHASED SEPARATELY
PART # DESCRIPTION
GD175 - WALL TERMINAL KIT
BM6790 90° ELBOW - 7" DIAMETER
GD222 TERMINALASSEMBLY
BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7" DIA
W500-0077 FIRESTOP / WALL PLATE
W020-0032 HARDWARE
BRTC7 BRASS TRIM COLLAR
BM6724 24" STOVE PIPE - 7" DIAMETER
W010-0300 10' ALUMINIUM FLEX LINER C/WSPACERS - 4" DIA
W025-0001 DECORATIVE BRASS BAND
GD180 - PERISCOPE TERMINAL KIT
BM6790 90° ELBOW - 7" DIAMETER
GD201 PERISCOPE
BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7" DIA
W500-0077 FIRESTOP / WALL PLATE
W020-0032 HARDWARE
BRTC7 BRASS TRIM COLLAR
BM6724 24" STOVE PIPE - 7" DIAMETER
W010-0300 10' ALUMINIUM FLEX LINER C/WSPACERS - 4" DIA
W025-0001 DECORATIVE BRASS BAND
GD110 - ROOF TERMINAL KIT - 1/12 TO 7/12 PITCH
W010-0569 AIR TERMINAL
W120-0036 VERTICAL CAP
W010-0567 ROOF SUPPORT
W170-0063 STORMCOLLAR
W263-0054 ROOF FLASHING
GD111 - ROOF TERMINAL KIT - 8/12 TO 12/12 PITCH
W010-0569 AIR TERMINAL
W120-0036 VERTICAL CAP
W010-0567 ROOF SUPPORT
W170-0063 STORMCOLLAR
W263-0055 ROOF FLASHING
GD112 - ROOF TERMINAL KIT - FLAT ROOF
W010-0569 AIR TERMINAL
W010-0567 ROOF SUPPORT
W120-0036 VERTICAL CAP
W263-0056 ROOF FLASHING
W170-0063 STORMCOLLAR

20
W415-0153/A/10.29.01
PART # DESCRIPTION
REPLACEMENT PARTS:
GDS28/GS28
W725-0035 SIT VALVE - NG
W725-0034 SIT VALVE - LP
W100-0056 BURNER
W455-0026 #38 BURNER ORIFICE - NG
W455-0003 #54 BURNER ORIFICE - LP
W010-0575 PILOT ASSEMBLY - LP
W010-0636 PILOT ASSEMBLY - NG
W455-0052 PILOT ORIFICE - LP
W455-0053 PILOT ORIFICE - NG
W680-0008 THERMOCOUPLE
W680-0004 THERMOPILE
W290-0029 PILOTGASKET
W010-0865 EMBER SCREEN ASSEMBLY
W357-0001 PIEZO IGNITER
W425-0235 CONTROL PANEL
GL-620 4pc LOG ASSEMBLY C/WEMBERS
W135-0058 FRONT LOG
W135-0059 BACK LOG
W135-0060 LEFT LOG
W135-0061 RIGHT LOG
W361-0016 GLOWING EMBERS
W550-0001 CHARCOAL EMBERS
W573-0008 HIGH TEMPERATURE SEALANT
W715-0195 PEDESTAL TRIM
W290-0043 BURNER GASKET
W385-0045 NAPOLEONLOGO
W290-0045 BLOWER ACCESS GASKET
W430-0002 MAGNETIC CLOSURE
W390-0002 LATCH
W660-0009 ON/OFF SWITCH
W690-0002 THERMODISC
W380-0002 VARIABLE SPEED SWITCH KNOB
WKB-13 VARIABLE SPEED SWITCH
GZ-552 REPLACEMENTBLOWER
W030-0022 ACCENT BAR
W200-0077 BLACKTRIVET
GS28
W010-0459 ADAPTOR C/WSPILL SWITCH
W660-0006 SPILL SWITCH
ACCESSORIES / OPTIONS
GDS28 / GS28:
W690-0001 MILLIVOLTTHERMOSTAT
W690-0002 HAND-HELD REMOTE
W690-0010 REMOTE CONTROL - ADVANTAGE
W690-0011 REMOTE CONTROL - ADVANTAGE PLUS
GS328-K BLACK DOOR KIT
GS328-G GOLD DOOR KIT
W300-0038 FRONT WINDOW GLASS
W300-0037 SIDE WINDOW GLASS
W562-0022 GLASSGASKET
GS200-G GOLDTRIVET
GS14R-KT RED ENAMELLED EURO KIT
GS14F-KT GREEN ENAMELLED EURO KIT
GS14S-KT ALMOND ENAMELLED EURO KIT
GS14K-KT BLACK ENAMELLED EURO KIT
GS14-KT METALLIC BLACK EURO KIT
GS14SS-KT STAINLESS STEEL EURO KIT
W175-0124 CONVERSION KIT - NG TO LP
GDS28:
BM6745 45° ELBOW
GD-301 HEAT GUARD
W175-0001 4" COUPLER
GD-303 VINYL SIDING SHIELD
GD-201 PERISCOPE
GS28:
GS-150KT ADAPTORKIT
W025-0001 DECORATIVE BRASS BAND
O
L
O
T
P
I
L
L
O
T
I
H
N
O
P
O
I
F
F
W725-0035
W725-0034
W455-0026
W455-0003
GZ-552
W135-0058 W135-0060
W135-0061
W361-0016
W550-0001
GS328-K
GS328-G
W135-0059
W430-0002
W200-0077
GS200-G
W390-0002
W100-056
W425-0235
W010-0865
