Napoleon NZ-26 User manual

W415-0585 / B / 11.28.06
1
INSTALLATION AND
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 4Y8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030
[phone] •fax[phone] •www.napoleonfireplaces.com •[email protected]
R-2000
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
If the information in these instructions is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or death.
SOLID FUEL BURNING - ZERO CLEARANCE
Installation and operation instructions for Hi-Tech
listed fireplace
THIS FIREPLACE HAS BEEN TESTED AND LISTED BY INTERTEK TESTING SERVICES TO STANDARDS: CAN/ULC S610, UL 127, FOR ZERO CLEARANCE FIREPLACES, AND TO ULC
S639 FOR STEEL LINER ASSEMBLIES FOR SOLID FUEL BURNING MASONRY FIREPLACES. CERTIFIED UNDER USA ENVIRONMENTAL PROTECTION AGENCY (E.P.A.) JULY 1990 AND
THE OREGON DEPARTMENT OF ENVIRONMENTAL QUALITY (D.E.Q.) PARTICULATE EMISSION STANDARDS
NZ-26
NZ-26WI

W415-0585 / B / 11.28.06
2
WARNINGS & SAFETY PRECAUTIONS

W415-0585 / B / 11.28.06
3

.
PG 2-5 INTRODUCTION
Warnings & Safety
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
6 hI-EFFICIENCY hEATING
Five Options
7-9 INSTALLATION / FRAMING
NZ-26WI Location & Clearance
NZ-26WI Framing
NZ-26 Location & Clearance
NZ-26 Framing
Outside Combustion Air
Mantle Clearance
Hearth Extension
9-11 ChIMNEY INSTALLATION
Adding Chimney Sections
Offset Chimney Installation
Installing Flashing And Storm Collar
Connection to a Masonry Chimney
12-13 FINIShING
NZ-26 Attaching the Handle
NZ-26WI Attaching the Handle
  TopFirebrickandBafeInstallation
Firebrick Removal
14 OPTIONAL BLOWER
15 FEATURES
Controlling Combustion Air
Achieving Proper Draft
16-17 OPERATING INSTRUCTIONS
Fuel Loading and Burn Cycle
Ash Removal Procedures
17 MAINTENANCE
  Gasket/BafeReplacement
NZ-26 Door Glass Replacement
NZ-26WI Door Glass Replacement
Creosote Formation And Removal
Run-Away or Chimney Fire
Fire Extinguishers and Smoke Detectors
Woodpile Maintenance
18-19 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Accessories
20 TROUBLE ShOOTING
21 SERVICE hISTORY
TABLE of CONTENTS
PLEASE RETAIN ThIS MANUAL FOR FUTURE REFERENCE
NZ-26
NZ-26WI
FIGURE 1
FIGURE 2
44
1
/ 2 "
39
1
/ 2 "
24
3
/ 4 "
25
1
/ 2 "
38
1
/ 4 "
12" 17
1
/ 2 "
19
1
/ 2 "
2
1
/ 2 "
10"
29
1
/ 2 "
32
1
/ 2 "
ELECTRICAL INLET
LEFT SIDE
14"
43
1
/ 2 "
39
1
/ 2 "
38
1
/ 4 "
25
1
/ 2 "
12"
24
3
/ 4 "
4" ELECTRICAL INLET
LEFT SIDE
6
1
/ 4 "
30
3
/ 4 "
32
1
/ 2 "
14"
45" MIN
74"
52"
3
1
/
2
"
MIN.
2" MIN
TO CHIMNEY
WARNING ATTENTION
NON-COMBUSTIBLEFINISHING
AND/ORFRAMING MATERIALS
REQUIRED.
SEEINSTALLATIONMANUAL
FORDETAILS.
DESMATÉRIAUX DE FINITION
OUDES PIÈCES DE CHARPENTE
INCOMBUSTIBLESSONT REQUIS.
VOIRLE MANUEL D'INSTRUCTIONS
POURLES DÉTAILS. W385-0329/B
MAINTAINCLEARANCE
TOCOMBUSTIBLES.
MAINTENEZLES D É GAGEMENTS
AUXMAT É RIAUXCOMBUSTIBLES.
WARNING ATTENTION
NON-COMBUSTIBLEFINISHING
AND/ORFRAMING MATERIALS
REQUIRED.
SEEINSTALLATIONMANUAL
FORDETAILS.
DESMATÉRIAUX DE FINITION
OUDES PIÈCES DE CHARPENTE
INCOMBUSTIBLESSONT REQUIS.
VOIRLE MANUEL D'INSTRUCTIONS
POURLES DÉTAILS. W385-0329/B
MAINTAINCLEARANCE
TOCOMBUSTIBLES.
MAINTENEZLES D
É
GAGEMENTS
AUXMAT
É
RIAUXCOMBUSTIBLES.
Warning: The NZ-26WI requires 6"clearance to combustibles on the sides. Cement board or
other non-combustible facing required.

W415-0585 / B / 11.28.06
4
NAPOLEON products are manufactured under the strict Standard of the World Recognized ISO 9001 : 2000 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen who take great pride in their work.
The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that you, the customer, receives the quality
product that you expect from NAPOLEON.
NAPOLEON WOOD FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your new NAPOLEON wood fireplace are warranted against defects for as long as you
own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel baffle retainer, ceramic glass (thermal breakage only),
gold plated parts against tarnishing, porcelainized enamelled components, aluminum extrusion trims ashdrawer, and cast iron castings.
Electrical (110V) components and wearable parts such as blowers, thermal switch, switches, wiring, firebrick, gasketing, and high temperature
paint are covered and NAPOLEON will provide replacement parts free of charge during the first year of the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. Repair work, however, requires the prior approval of
an authorized company official. Labour costs to the account of NAPOLEON are based on a predetermined rate schedule and any repair
work must be done through an authorized NAPOLEON dealer.
CONDITIONS AND LIMITATIONS
NAPOLEON warrants its products against manufacturing defects to the original purchaser only -- i.e., the individual or legal entity (registered customer) whose name appears on
thewarrantyregistrationcardledwithNAPOLEON -- provided that the purchase was made through an authorized NAPOLEON dealer and is subject to the following conditions
and limitations:
This factory warranty is non-transferable and may not be extended whatsoever by any of our representatives.
Thewoodreplacemustbeinstalledbyanauthorizedservicetechnicianorcontractor.Installationmustbedoneinaccordancewiththeinstallationinstructionsincludedwiththe
productandalllocalandnationalbuildingandrecodes.
This limited warranty does not cover damages caused by misuse, lack of maintenance, accident, alterations, abuse or neglect and parts installed from other manufacturers will
nullify this warranty.
This limited warranty further does not cover any scratches, dents, corrosion or discolouring caused by excessive heat, abrasive and chemical cleaners nor chipping on porcelain
enamelparts,noranyventingcomponentsusedintheinstallationofthereplace.
Intherstyearonly,thiswarrantyextendstotherepairorreplacementofwarrantedpartswhicharedefectiveinmaterialorworkmanshipprovidedthattheproducthasbeen
operated in accordance with the operation instructions and under normal conditions.
Aftertherstyear,withrespecttothePresident'sLimitedLifetimeWarranty, NAPOLEON may, at its discretion, fully discharge all obligations with respect to this warranty by
refunding to the original warranted purchaser the wholesale price of any warranted but defective part(s).
Aftertherstyear,NAPOLEON will not be responsible for installation, labour or any other costs or expenses related to the reinstallation of a warranted part, and such expenses
are not covered by this warranty.
NotwithstandinganyprovisionscontainedinthePresident'sLimitedLifetimeWarranty,NAPOLEON’Sresponsibilityunderthiswarrantyisdenedasaboveanditshallnotin
any event extend to any incidental, consequential or indirect damages.
ThiswarrantydenestheobligationsandliabilityofNAPOLEON with respect to the NAPOLEONwoodreplaceandanyotherwarrantiesexpressedorimpliedwithrespectto
this product, its components or accessories are excluded.
NAPOLEON neither assumes, nor authorizes any third party to assume, on its behalf, any other liabilities with respect to the sale of this product. NAPOLEON will not be responsible
for:over-ring,downdrafts,spillagecausedbyenvironmentalconditionssuchasrooftops,buildings,nearbytrees,hills,mountains,inadequateventsorventilation,excessiveventing
congurations,insufcientmakeupair,ornegativeairpressureswhichmayormaynotbecausedbymechanicalsystemssuchasexhaustfans,furnaces,clothesdryers,etc.
Anydamagestoreplace,combustionchamber,heat exchanger,brasstrimorothercomponent due to water,weatherdamage,longperiods of dampness, condensation,
damaging chemicals or cleaners will not be the responsibility of NAPOLEON.
The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from your authorized dealer. The warranty registra-
tion card must be returned within fourteen days to register the warranty.
NAPOLEON reserves the right to have its representative inspect any product or part thereof prior to honouring any warranty claim.
ALL SPECIFICATIONS AND DESIGNS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE DUE TO ON-GOING PRODUCT IMPROVEMENTS. NAPOLEON® IS A
REGISTERED TRADEMARK OF WOLF STEEL LTD. PATENTS U.S. 5.303.693.801 - CAN. 2.073.411, 2.082.915. © WOLF STEEL LTD.
WARNING: 


FOR YOUR SAFETY











W415-0585 / B / 11.28.06
5
This is the most ef-
ficient, simple and
trouble free wood-
burning system we
know of and works
as follows:
Primary combustion air enters through the air control inlet box
regulated by a draft control, travels up the side through a duct
and enters the top centre of the combustion chamber into a
preheating airwash located across the top and then down
thewindowtofeedthereandalsotoensurethattheglass
remains clean.
Secondary air feeds directly into the combustion chamber at
hearth level through the log retainer and also through inlets lo-
cated at the bottom back corners of the combustion chamber.
This air travels up the riser to the four secondary air tubes
located at the top and shoots out laterally to oxidize the gases
rising to the smoke exit.
Thecombustionchamberislinedwithhigh-temperaturerebrick
on all sides, and across the bottom to maintain a high tempera-
ture in the combustion chamber so that gases mixing with the
preheated air from the secondary air tubes are easily ignited
andburned.Thereplacesidesandbackpermitazeroclear-
ance installation and direct the heat upwards and forwards
intotheroom.Besuretoprovidesufcientcombustionair.
There are many other appliances in your home competing for
air such as a kitchen range hood, forced air heating devices
or a bathroom exhaust fan.
If the outside air feature is utilized, you will never experience a
shortage of combustion air. If you choose not to utilize outside
air and experience draft or smoking problems, you may need
to open a door or window.
After extended periods of non-operation such as following a
vacation or a warmweatherseason,thereplacemayemit
a slight odour for a few hours. This is caused by dust parti-
clesonthereboxburningoff.Openawindowtosufciently
ventilate the room.
CALIFORNIA PROP 65 WARNING:
Use of this product may produce smoke which contains
chemicals known to the State of California to cause can-
cer, birth defects, or other reproductive harm.
Do not use makeshift compromises during
installation.Do not block or restrict air, grille or
louvre openings! Do not add a hood.
Burning your unit with the ash dump door open or
ajar creates a re hazard that may result in discol-
oration to the gold plated door, internal damage to
the replace or a house and/or chimney re.
All venting connections must be in compliance with the chimney
manufacturers installation instructions.
Clearances referred to throughout this manual are the minimum
requirements.
YourNapoleonreplacemustbeinstalledinaccordancewith
all national and local building code standards and the standard
of Chimney and Fireplaces, Vents and Solid Fuel Burning Appli-
ances NFPA #211. Consult the authority having jurisdiction (such
asmunicipalbuildingdepartment,redepartment,reprevention
bureau, etc.) to determine the need to obtain a permit. If you are
in doubt about the proper installation for your situation, contact
yourdealerorlocalbuildingorreofcial.Themanufacturerdoes
notguaranteethatthisreplaceanditsoptionswillcompletely
heat your entire home.
Expansion / contraction noises during heating up and cooling
down cycles are normal and to be expected.
Mobile home installation (NZ-26 ONLY) requires that
thereplacebesecuredtotheoor.Itisrecommendedthat
inallcases,thereplace be secured totheoor. Usethe
pallet packing brackets to accomplish this.
If the glass is not kept clean permanent discolouration and
/ or blemishes may result. Normallyahotrewillcleanthe
glass. The most common reasons for dirty glass include:
notusingsufcientfueltogetthestovethoroughlyhot,us-
ing green or wet wood, closing the draft so far that there is
insufcientairforcompletecombustion.Ifitisnecessaryto
clean the glass, use a soft cloth with a non-abrasive cleaner.
Do not clean the glass when hot!
The glass is very strong but do not let burning fuel rest or fall
against it and always close the door gently. Never force it
shut!
Iftheglassshouldevercrackwhilethereisburning,donot
openthedooruntilthereisoutanddonotoperatethestove
again until the glass has been replaced with a new 5mm thick
piece of ceramic glass, available from your Napoleon / Wolf Steel
Ltd. dealer. Do not substitute materials.
For information on glass removal and replacement, see
Maintenance.
Do not use abrasive cleaners to clean plated parts. Buff lightly
with a clean dry cloth.
Prolonged high temperature burning with the door ajar may
cause a permanent rainbowing effect on the lower edge of a
gold plated door.
INTRODUCTION
GENERAL INSTRUCTIONS GENERAL INFORMATION
CARE OF GLASS & PLATED PARTS
FIGURE 3

W415-0585 / B / 11.28.06
6
Tooperatethishi-efciencyreplaceasabasicsystem,the
blowerisnotrequired,however,toenhanceitsefciencya
blower is recommended.
A blower kit (NZ62) may be purchased with the op-
tion of adding up to one additional blower. These blowers
are installed in the bottom of the unit and are used to direct
theheatintotheroomwherethereplaceislocated.The
blowers are controlled, by a variable speed switch, located
insidethereplace.
A thermostAtic Air coNtrol (NZ690kt) may be
used for constant heat, complete with automatic damper and
thermostat,wallmountedintheroomcontainingthereplace,
and at least 10 feet (minimum) from the replace.
A hot Air grAvity veNt system (NZ220) may be
used to distribute heat to an adjoining room (located either
above,orbesidetheroomcontainingthereplace)byway
of vents, eliminating the need of an additional blower. While
this system may be used in conjunction with the optional
blowers,itcouldreducetheowofhotairbeingdistributed
to additional rooms. It must be experimented with and the
dampers adjusted manually to suit your requirements. This
may take a few attempts; thereafter adjustments should no
longer be required as is normally experienced with your
central heating system registers.
The heat shield cover plate must be removed before
installing the gravity vent. The hot air vent must be in-
stalled in an upward direction! NEVER install in a down-
ward direction. Figure 6. The hot air gravity vent system
is not to be connected to a central heating system (for
this application use the NZ62CH). This option may not
be used in mobile homes.
No more than two hot air gravity vents can be installed to
replace.Individualventrunsarenottoexceed10feet.
All hot air gravity vents must be insulated.
A ceNtrAl heAtiNg system (NZ62ch) may be
used to heat rooms up to 50 feet from the unit.A wall mounted
thermostat located in the room to be heated controls the
blowersupplyingwarmairfromtheroomcontainingthere-
place. If a hot air duct system exists, the central heat blower
may safely be tied into this system to reduce the amount of
new ducting required. Consult with a heating specialist to
ensure a proper duct layout for your home. If the NZ62CH
is installed at the bottom of the unit, it could introduce a cool
draftintotheroomthatthereplaceisinstalledin.
Ahot Air distributioN kit (gA-566) may be used
todistributewarmairfromthereplacebase(only)intoa
separate location in the home.
These options may be incorporated with one another. If the
optional blowers are to be installed, make provision during
framingtoroutea110voltpowerlinetothereplace.Detailed
installation instructions are included with each venting kit.
FIGURE 6
hI-EFFICIENCY hEATING
FIVE OPTIONS
STOVE TOP
FIGURE 4
HEAT SHIELD COVER PLATE
FIGURE 5b
FIGURE 5
When attached to the top or sides of the unit, it provides a
higher heat output. This option may not be used in
mobile homes.
REMOTE VIEWING OPTIONS
NOTE: MASONRY REMOTE VENTING OPTIONS COME OFF THE
SIDE INSTEAD OF THE TOP.
NO
DUCTING CENTRAL HEATING
OPTION
GRAVITY VENT
OPTION (1 DUCT)
CENTRAL HEATING &
GRAVITY VENT OPTION
GRAVITY VENT
OPTION (2 DUCT)
*RIGHT SIDE
ONLY
NO
DUCTING
CENTRAL HEATING &
GRAVITY VENT OPTION
NZ-26:
NZ-26WI:

W415-0585 / B / 11.28.06
7
Do not build shelves or cupboards into the area
above the replace.
Whilethereplacecanbe installed directly ontheoor, a
non-combustible hearth extension is required in front of the
replace,thatmustnotbebuilthigherthanthebottomofthe
replacetoavoidairowblockage.Itmaythereforebeadvis-
abletobuildthereplaceonaraisedplatform.Theminimum
distancebetweentheedgeofthereplaceandanyadjacent
wall, at right angles to it, is 21 inches. A wall projecting at 45°
fromtheouteredgeofthereplaceisallowed;projectionsinto
this area are permitted. Do not install into any area having a
heightlessthan7feet(ceilingtoreplacebottom,excluding
hearth height). See Section on Framing.The location of
windows,doorsandthetrafc ow in theroomwherethe
stove is to be located should be considered. If possible, you
should choose a location where the chimney will pass through
thehousewithoutcuttingaoororroofjoist.
MAINTAIN ThESE MINIMUM CLEARANCES TO
COMBUSTIBLES:
Fireplace framing:
Top: 44 1/2"
Rear Stand-Off: 0"
Side: 6"
Fireplace nishing:
Sides: 6"
Top: (to ceiling from base) 84"
Factory Built Chimney: 2"
Hot Air Gravity Ductwork Insulation: 1"
BASE OF UNIT TO CEILING:
Enclosure must have ventilation 84"

-

FIGURE 8a
FIGURE 8b: Framing Requirements
FIGURE 8c: Finishing Requirements
Note: In order to avoid
the possibility of exposed
insulation or vapour bar-
rier coming in contact
withthereplace body,
it is recommended that
thewallsofthereplace
enclosure be “nished”
(ie: drywall/sheetrock),
asyouwouldnishany
other outside wall of a
home. This will ensure
that clearance to com-
bustibles is maintained
within the cavity.
Nz-26WI LOCATION & CLEARANCES
Nz-26WI FRAMING
WALL
WALL
WALL
WALL
2” MIN. TO
CHIMNEY
45°
21”
21” 50 1/2”
26”
60 1/8”
42 1/2”
2” MIN. TO
CHIMNEY
86”
50 1/2” MIN. 6” MIN.
6”
Clearances to nishing materials for framing: From top
of unit to ceiling non-combustible material must be used
and a minimum of 6" to either side.
Objects placed in front of the replace must be kept a
minimum of 48" away from the front face of the unit.
Non-combustible material (brick, stone, cement board or
ceramic tile) may protrude over the black painted surface of
thereplacefront.
The replace front should be framed using metal studs.
We recommend that the replace be secured to the oor
in all cases. Use the pallet packing brackets to accomplish
this.Areplaceenclosurewithaheightof7feetfromthe
baseoftheunitmustbeprovidedwithsufcientaircircula-
tiontoavoidarehazard.Installventilationgrilles(minimum
openingsof40sq.inches)atbothoorandceilinglevelsof
theenclosure.Thesegrillesmustnotrestricttheowofheat
by more than 25%.
Do not place insulation into the enclosure around the
replace or the chimney. Combustible framing materials
may not be closer than 6" from the side of the unit and
44 1/2" from the top of the unit.
A steel header must be used and installed not less than
12" above the unit. Thereafter wood studs may be used.
It is strongly recommended to use metal studs entirely to
frame & support the non-combustible facing.

W415-0585 / B / 11.28.06
8
INSTALLATION / FRAMING
Do not build shelves or cupboards into the area
above the replace.
Whilethereplacecanbe installed directly ontheoor, a
non-combustible hearth extension is required in front of the
replace,thatmustnotbebuilthigherthanthebottomofthe
replacetoavoidairowblockage.Itmaythereforebeadvis-
abletobuildthereplaceonaraisedplatform.Theminimum
distancebetweentheedgeofthereplaceandanyadjacent
wall, at right angles to it, is 21 inches. A wall projecting at 45°
fromtheouteredgeofthereplaceisallowed;projectionsinto
this area are permitted. Do not install into any area having
aheightlessthan6feet(ceilingtoreplacebottom,exclud-
ing hearth height). See Section on Framing. The location
ofwindows,doorsandthetrafcowintheroomwherethe
stove is to be located should be considered. If possible, you
should choose a location where the chimney will pass through
thehousewithoutcuttingaoororroofjoist.
MAINTAIN ThESE MINIMUM CLEARANCES TO
COMBUSTIBLES:
Fireplace framing:
Top Stand-Off: 0"
Rear Stand-Off: 0"
Side Stand-Off: 0"
Fireplace nishing:
Sides: 3½"
Top: 63/4"
Recommended: 6 3/4
Factory Built Chimney: 2"
Hot Air Gravity Ductwork Insulation: 1"
TOP OF UNIT TO CEILING:
Enclosure must have ventilation 32½"
(Ceiling height between 6 and 7 feet)
Enclosure does not require ventilation 44½"
(Ceiling height 7 feet or more)

-

FIGURE 7b: Framing Requirements
FIGURE 7c: Finishing Requirements
Note: In order to avoid
the possibility of exposed
insulation or vapour bar-
rier coming in contact
withthereplace body,
it is recommended that
thewallsofthereplace
enclosure be “nished”
(ie: drywall/sheetrock),
asyouwouldnishany
other outside wall of a
home. This will ensure
that clearance to com-
bustibles is maintained
within the cavity.
Nz-26 LOCATION & CLEARANCES
Nz-26 FRAMING
FIGURE 7a
Clearances to nishing materials for framing: 6
3/4
" mini-
mum of non-combustible material to the top of the unit
and a minimum 3½" to either side. However we recom-
mend that 6
3/4
" of non-combustible material be used all
around.
Objects placed in front of the replace must be kept a
minimum of 48" away from the front face of the unit.
Non-combustible material (brick, stone, cement board or
ceramic tile) may protrude over the black painted surface of
thereplacefront.
The replace should be framed using 2x4 lumber. Mobile
home installation requires the replace to be secured to
the oor. We recommend that the replace be secured
to the oor in all cases. Use the pallet packing brackets
to accomplish this. If ducting is to be installed, the minimum
enclosure ceiling height is 7 feet. Without ducting, the ceiling
height may be brought down to a minimum of 6 feet. However
areplaceenclosurewithaheightlessthan7feetmustbe
providedwithsufcientaircirculationtoavoidarehazard.
Install ventilation grilles (minimum openings of 40 sq. inches)
atbothoorandceilinglevelsoftheenclosure.Thesegrilles
mustnotrestricttheowofheatbymorethan25%.
Do not place insulation into the enclosure around the
replace or the chimney. Combustible framing materials
may not be closer than 2 inch from the side of the unit
and 5 inches from the top of the unit.

W415-0585 / B / 11.28.06
9
Napoleon models NZ-26 & NZ-26WI have the option of taking
outsideairdirectlyintothereplacethroughtheopeningon
the left hand side or taking inside air through the lower front
louvres or a combination of both.
If the optional fresh air kit (available through your Napoleon
/ Wolf Steel Ltd. dealer) is installed, it must not draw air from
the attic or garage. It may only come from outside the house.
The maximum length of the 4 inch air duct is 20 feet; thereafter
enlarge the duct to a 6 inch diameter.
Decide on the most convenient location for the fresh air inlet
ductandhoodwhichmaybeinstalledaboveorbelowoor
level.
Make a 5 inch hole in an outside wall of the house. From
outside, place the fresh air hood into the hole, open side
down.
At each end, carefully pull back the insulation sleeve expos-
ingtheexibleduct.Placetheinsulatedexibleductoverthe
freshairhoodandoverthereplaceoutsideairconnector.
Carefully push the insulation sleeve back over the duct. Us-
ing the clamps, fasten the insulated duct into place on both
sides.Figure 9.
For outside air only, re-install the inside air cover plate, shown
in Figure 37, to cover the control box inside air opening. See
Section on Combustion Air Control.
FIGURE 9
OUTSIDE COMBUSTION AIR
MANTLE CLEARANCES
hEARTh EXTENSION
A chimney venting the replace shall not vent any
other appliance.
The minimum overall chimney height from the top of
thereplaceis11feet.
The maximum overall chimney height from the top of
thereplaceis34feet.
Factory-built chimney systems for use in dwellings
constructed for three or more families must be enclosed
abovetheroominwhichthereplaceislocated.This
enclosuremusthaveareresistanceratingequaltoor
greaterthanthatoftheoororroofassemblythrough
which they pass.
If the chimney system is enclosed within the attic area,
a rafter radiation shield is required.
The chimney should not be built with an offset angle in
excess of 45° in Canada and 30° in USA.
ChIMNEY INSTALLATION
The chimney must extend at least 3 feet above its point
of contact with the roof and at least 2 feet higher than
any wall, roof or building within 10 feet.
If the chimney extends more than 5 feet above the roof,
it must be secured using a roof brace or guide wires.
Ensure that minimum clearances are maintained
Portions of the chimney that extend through accessible
spaces must always be encased to avoid personal
contact with the chimney and thereby avoid damage
to the chimney.
A raincap must be installed to avoid internal damage
and corrosion.
The chimney must be supported at a maximum of 20
foot intervals (approx. 200 lbs/20 ft).
The NZ-26 & NZ-26WI were tested to CAN/ULC S610 and UL 127 Factory Built Fireplace Standards. These Fireplaces have
metthetestcriteriaforZeroClearanceInstallationtoCombustibleSurfacesandCertiedtoburnFirewoodonly.
Any 6" diameter chimney listed to these standards may be installed. In accordance with these standards, the unit may also
be connected to any chimney listed to ULC-S629 for Canada or UL-103HT for the United States.
Installation of all types of factory-built chimney systems is to be in accordance with the chimney manufacturers installation
instructions. An appropriate chimney manufacturers anchor base plate and anchor base plate gasket is required in order
to initiate the twist lock mechanism. Use the high temperature gasket, supplied, to seal between the anchor plate and the
replacetop.
FIGURE 10
An acceptable 16" x 50" non-combustible (ie: brick, stone
or ceramic tile) hearth extension must be installed. Ensure
thatthegapbetweenthereplaceandafactory-builthearth
extension is sealed with sand/cement grout or covered with a
metal strip (or both) to prevent sparks and embers from fall-
ingintothisarea.Araisedhearthtogetherwiththereplace
built on a raised platform is recommended for easier wood
loadingandreviewing.
Mantle clearance
can vary accord-
ing to the mantle
depth.

W415-0585 / B / 11.28.06
10
1.Movethereplaceintoposition.Trytocentretheexhaust
ueofthereplace,midpointbetweentwojoiststoprevent
having to cut them. Use a plumb bob to line up the centre.
2. Cut and frame an opening in the ceiling to provide a
minimum clearance of 2" between the outside of the chimney
and any combustible material. DO NOT FILL THIS SPACE
WITH ANY TYPE OF MATERIAL! Nail headers between
the joists for extra support. Firestop spacers must be placed
onthebottomofeachframedopeninginanyoororceiling
that the chimney passes through.
3. Hold a plumb bob from the underside of the roof to deter-
mine where the opening in the roof should be. Cut and frame
the roof opening maintaining proper 2" clearances.
FIGURE 14
OFFSET ChIMNEY INSTALLATION
ADDING ChIMNEY SECTIONS
FIGURE 13 - 4 ELBOWS
FIGURE 12 - 2 ELBOWSFIGURE 11 - STRAIGHT UP
No Off-Set. Minimum overall chimney
height is 11 feet.
Single off-set with two 15°, 30° or 45°
elbows. Minimum overall chimney
height is 11 feet.
Double off-set with four 15°, 30° or
45° elbows. Minimum overall chimney
height is 11 feet.
* The rst ue offset closest to the top of the unit must
be a minimum distance of 12 inches from the top of the
replace.
NOTE: 30° or 45° offsets may be installed back to back.
FIGURE 15
Add chimney sections, twist locking (clockwise) securely, to
the required height. Use a rafter radiation shield whenever
the chimney system is enclosed within an attic area.
The rst ue offset closest to the top of the unit
must be a minimum distance of 12" from the top
of the replace.
An insulated elbow must be used when it becomes neces-
sary to offset the chimney in order to clear a joist or to pass
through an upstairs closet.
Attach an elbow to the chimney section, angled toward the
offset. Secure with 3 - #8X1/2" sheet metal screws. To achieve
the minimum offset, attach and secure a return elbow to the
rst.Toachievelongeroffsets,youmayinstallanyavailable
length of chimney pipe between the elbows.
Supportsmustbeusedontherstverticalchimnneysection
after a return elbow.
FIGURE 16

W415-0585 / B / 11.28.06
11
IF THE
CHIMNEY IS
UNLINED:
A stainless steel
liner listed to either
Standard ULC-
S640M, ULC-
S639 in Canada
or UL-1777 in
the USA: Liners
for New Masonry
Chimneys, may be
used to connect
thereplacetothe
chimney. The liner
must be continuous
from the replace
to the chimney
cap and be installed only per manufacturers instructions.
Figure 19. In both cases, the chimney structure must be
supported by angle iron anchored into the masonry walls.
Figures 19 & 20. The allowable masonry used in chimney
construction is 3-1/2" brick, solidly mortared and fully
encasingtheue.Ensuretherearenoleaks.
In no case is the masonry enclosure to be supported by the
NZ-26replace.Allowa1"(oneinch)aircavityforexpan-
sion.
Remove the nails from the shingles above and to the sides
ofthechimney.Placetheashingoverthechimneypipeand
slide underneath the sides and upper edge of the shingles.
Ensure that the chimney pipe is properly centered within the
ashing,givinga3/4"marginallaround.Fastentotheroofon
the top and sides. DO NOT NAIL through the lower portion
oftheashing.Makeweather-tightbysealingwithcaulking.
Wherepossible,coverthesidesandtopedgesoftheashing
withroongmaterial.Applywaterproofcaulking,providedwith
theashing,aroundthechimney,1"abovethetopoftheash-
ing and push the storm collar down into the caulking. Insert
a rain cap onto the top of the last chimney section.
FIGURE 18
INSTALLING FLAShING AND STORM
COLLAR
FIGURE 17
FLUE TILE SUPPORT FOR A MASONRY FIREPLACE
HI-TEMP GASKET
FIREPLACE TOP
Foramasonryreplaceuseauetilesupport.Forapre-
fabricated chimney use an anchor plate.
Napoleon Models NZ-26 &
NZ-26WI may be connected
to either a lined or unlined
masonry chimney.
IF THE CHIMNEY IS
LINED, theuesmustbe
madeofvitriedclayandbe
in sizes of 8" square, 8" x 12",
or 8" round with a minimum
height of 11 feet above the
replace. Eight inch round
flues are recommended.
Installation must conform to
both national and local code
requirements.
FIGURE 19
FIGURE 20
CONNECTION TO A MASONRY
ChIMNEY
FIGURE 22
FIGURE 21
FIREPLACE TOP
ANCHOR PLATE
HI-TEMP GASKET

W415-0585 / B / 11.28.06
12
Right Door Handle (operating)
1. Insert the door rod through the round hole of the latch
ensuringtheatedgeofthe“D”shapedholepointstowards
the hinges.
2. Slide the end of the door rod through the bushing at the
top of the door as shown.
3. Insert the handle shaft
through the door and the
latch.
4. Securewith3atwash-
ers and a nut.
5. Feed the handle through
the handle spacer and into
the handle shaft.
Attach the handle as shown so that
when the door is closed, the handle
will be centred in the slot located
onthe replace front.Toachieve
this you may have to experiment
(on the upper and lower screws)
with one of the variations shown.
Tighten securely.
FIGURE 23
FINIShING
Nz-26 ATTAChING ThE hANDLE
Place gasket rope along the upper ledge of the air
chamber and on the top of the rear bricks. The top and
bottomamespreaderscometapedtogether.Thistape
willburnawayintheinitialringoftheunit.Onsubsequent
brickremovals,thebottomamespreadermustbetapedto
thetopspreadertoeasetopbrickandbaferemovalandto
avoiddamagingthebrebafes.
1
1
2
gAsket rope locAtioN
reAr
bricks
Unscrew and remove the front tube retainer. Note that the
rsttuberetaineralsoholdsthesidebrickinplace.Slide
the tube either to the left or right and remove. Remove
the two middle tubes in the same fashion.
Thereplaceisshippedwiththerebricksinplace.Topre-
bricks,brebafesandgasketropearenotinstalled.
TOP FIREBRICk AND BAFFLE
INSTALLATION:
fibre bAffle
tube
top firebrick
tube
retAiNer
FIGURE 24
FIGURES 25
FIGURE 27
FIGURE 28
Nz-26WI INSTALLING DOOR
hARDWARE
1
2
FIGURE 26
Left Door Handle (xed)
1. Insert the handle shaft
through the door.
2. Secure with a lock
washer,3atwashersand
a nut.
3. Feed the handle
through the handle spacer
and
into the handle shaft.
Note #1: You
may need to
move washers
ro the oterh side
of the latch to
obtainsufcient
door seal.
Note #2: The
nalangleofthe
left door handle should mirror the right door handle in the
closed position. Tighten the nut to secure the left handle at
the desired angle.
FIGURE 26b

W415-0585 / B / 11.28.06
13
TOP FLAME SPREADER
BOTTOM FLAME SPREADER
FIBRE BAFFLES
TOP FIBREBRICKS
TUBE BURNERS
GASKET
LEFT SIDE FIBREBRICK RIGHT SIDE FIBREBRICK REAR FIBREBRICKS
GASKET
RIGHT FRONT FIBREBRICK
LEFT FRONT FIBREBRICK
BOTTOM RIGHT FIBREBRICKBOTTOM LEFT FIBREBRICK
BAFFLE SUPPORT
Inserttheleftbafe,thenthelefttoprebrick.Repeat
usingtherightbafeandbrick.
The bafes are made of a brittle material. Care must be
taken not to bend or force them.
Replace the three front tubes. Position the center edges
of both bafes and bricks until they lie snugly together.
Slidethebafesupportbracketintoplacealongthefrontof
theunitbetweenthefronttubeandthetwotoprebricks.
3
WARNING: Operation of the replace without the top
rebricks and the bafes can result in excessive tem-
peratures that could damage the replace, chimney and
the surrounding enclosure.
top flAme spreAder
bottom flAme spreAder
fibre bAffle (1 of 2 showN)
top firebrick (1 of 2 showN)
3a
3b
bAffle support brAcket
FIGURES 29
FIGURES 30
FIGURES 32
If you need to remove the bricks (to lighten the replace
for ease of installation, replacement, etc), follow this se-
quence:
For Firebrick Removal: Remove the ashwell grate. This
allowsthefourbottombrickstoberemovedrst.
Slide out the bafe support bracket from above the front
tube.
Reachingabovethetoprebricksandbafes,liftandtapethe
bottomamespreadertothetopspreadertoeasetopbrick
andbaferemovalandtoavoiddamagingthebrebafe.
Remove the three front tubes.
Removethetoprebrickontheright,.
Removethebafes,startingwiththerightside.
Remove the gasket rope. Check the rope for deterioration
and replace if necessary. Remove the rear bricks (pull the two
bricks forward at the centre, and lift the bottom of the bricks
out). Remove the side bricks (tilt the tops inward).
4
FIGURES 31
4

W415-0585 / B / 11.28.06
14
3. Slidetherstblowertothebackofthereplacetak-
ing care not to damage the terminals. Position the blower
onto the studs and secure using the lock washers and wing
nuts provided. Pull the leads to the front and right side of the
ashpan housing.
4. Slide the second blower into place, position onto the
studs and secure as before.
5. Remove the junction box cover located on the lower
right outside of the unit. Use a nut connector to attach the
black wire of the variable speed switch to the black power
wire.
6. Pass the four blower leads and both thermodisc leads
through the junction box bushing. Connect one blower lead
from each blower and one of the thermodisc leads using a
nut connector and connect the other two blower leads to the
white power supply wire using a nut connector.
7. Connect the other thermodisc lead to the black wire
of the variable speed switch using a nut connector. Secure
ground wire (green) to the threaded weld stud located on the
junction box wall. Re-install the junction box. Ensure that the
wires will not interfere with the blower.
Because the blower is thermally activated, when turned
on, it will automatically start approximately 15-45 minutes
after lighting the replace. Use of the blower increases
the output of heat.
Drywall dust will penetrate into the blower bearings
causing irreparable damage and must be prevented from
coming into contact with the blower or its compartment.
Any damage resulting from this condition is not covered
by the warranty policy.
FIGURE 36
THERMODISC LOCATION
JUNCTION
BOX c/w
VARIABLE
SPEED SWITCH
SECOND BLOWER
SINGLE BLOWER
 
and must be electrically connected and grounded in accordance
with local codes. In the absence of local codes, use the current
CSA C22.1 CANADIAN ELECTRICAL CODE in Canada or the
ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in the United
States.
1. Turn off any elec-
trical power to the fire-
place (if applicable). Open
the lower louvred control
door.
2. Locate the vibration reducing pad (one per blower)
over the two threaded studs, piercing 2 holes into the pad.
The blower must be able to be positioned entirely onto the
pad. If only one blower is used, install on the left hand side
ofthereplace.
SINGLE BLOWER INSTALLATION:
3. Slide the
blower to the back
ofthereplacetak-
ing care not to dam-
age the terminals.
Position the blower
onto the studs and
secure using the
lock washers and
wing nuts provided. Pull the leads to the front and right side
of the ashpan housing.
4. Remove the junction box. Use a nut connector to at-
tach one of the black wires of the variable speed switch to
the black power supply wire.
5. Pass the two blower leads and one thermodisc lead
through the junction box bushing. The thermodisc is located
inside the outer shell, just above the louvre door. Figure 36.
Connect one blower lead to the thermodisc lead using a nut
connector and the other blower lead to the white power supply
wire using a nut connector.
6. Thread the other thermodisc lead through the junc-
tion box bushing and connect to the other black wire of the
variable speed switch using a nut connector. Secure ground
wire (green) to the threaded weld stud located on the junction
box wall. Re-install the junction box. Ensure that the wires
will not interfere with the blower.
DUAL BLOWER INSTALLATION:
FIGURE 34
FIGURE 33
OPTIONAL BLOWER INSTALLATION
FIGURE 35

W415-0585 / B / 11.28.06
15
If the outside combustion air kit is not used, air may still be
drawndirectlyintothereplace throughthelowerlouvres.
Outside and inside air may be combined by pulling the outside
air lever out as far as possible, and turning the lever 90° to
its locking position.
Shouldyoundafrostbuildupontheaircontrolboxora
draftfromthereplace,closetheoutsideairleverwhenthe
replaceisnotinuse.
Air control box is shipped with inside air cover plate in
open position.
FIGURE 38
FEATURES
Draftistheforcewhichmovesairfromthereplaceupthrough
the chimney. The amount of draft in your chimney depends on
the length of the chimney, local geography, nearby obstruc-
tions and other forces. Adjusting the draft control regulates
the temperature. The draft can be adjusted from a low burn
rate with the handle at the bottom setting to a fast burn rate
with the handle at the top setting. Inadequate draft may
causeback-pufngintotheroomandmaycauseplugging
of the chimney. Too much draft may cause an excessive
temperatureinthereplace,glowing redreplacepartsor
anuncontrollableburnwhichcanallleadtoachimneyre
or a permanent damage to the unit. Do not operate your
replace for longer than 30 minutes with the draft control
on 'HIGH' (fully open).
CONTROLLING COMBUSTION AIR AChIEVING PROPER DRAFT
FIGURES 37

W415-0585 / B / 11.28.06
16
For maximum efciency, when the replace is thoroughly
hot, load it fully to the top of the door opening and burn at a
medium low setting. The bricks will be nearly all white and
the glass mostly clear. The whiteness of the bricks and the
cleanness of the glass are good indicators of your operating
efciency.
Not enough heat is produced when only one or two pieces of
wood are burned. A minimum of three pieces are needed to
encaseabedofcoalsthatsustainsthere.Looselystacked
wood burns quicker than a tightly packed load.
Wood burns in cycles rather than giving a steady output of
heat. It is best to plan these cycles around your household
routine so that only enough coals are left to start the next
load.Intheevening,loadyourreplace,atleast,ahalf-hour
beforebedtoensurethereishotenoughtoclosethedraft
control for an overnight burn.
Burn only dry seasoned wood. It produces more heat and
less soot or creosote. Do not burn ocean beach wood. Its
salt content can produce a metal eating acid. When refueling
open the door slowly to prevent smoke spillage. Use a pair
oflongreplacegloveswhenfeedingthere.Keepasmall
steel shovel nearby to use as a poker and to remove ashes.
Donotstorewoodwithin3feet(1m)ofthereplace.
FLASH FIRES: Aashreisasmallreburnedquicklywhen
youdon'tneedmuchheat.Afteryourkindlinghas"caught",
load at least 3 pieces of wood, stacked loosely. Burn with the
draft control fully open or closed only slightly.
EXTENDED FIRE: Load your larger pieces of wood com-
pactly, packed close enough to prevent the ames from
penetrating it completely. After approximately 30 minutes,
depending on the size of the load, close the draft control
completelymakingsurethatthereisnotextinguished.
DO NOT OVERFIRE THE FIREPLACE!Overringcanoccur
by: a) burning large amounts of smaller wood pieces such as
furniture scraps, skids or treated wood; b) vigorously burning
large loads of wood with the draft control on "HIGH" (fully
open) for long periods of time (one or two hours).
FUEL LOADING AND BURN CYCLE
Remove all source of gasoline or other ammable
vapours and liquids in the vicinity of this or other
appliances prior to lighting. Ensure that the top
rebricks and bre bafes are in place and not
lifted up.
Whenrstinstalled,thereplaceandthesteelarecoldand
mustbecomehotbeforethereplacewillfunctionwell.During
thebreak-inperiod(therst2or3res)createonlysmall,hot
resusingkindling;thiswillallowtherebricktocure.Donot
bealarmedifsmallhairlinecracksdevelopintherebrick.
This is a normal occurrence and does not pose a safety
hazard.Thepaintmayalsosmellalittlefortherstfewres
as it cures and you may wish to open a door or window to
alleviate the smell.
Tostart,abriskreisrequired.Placelooselycrumpledpaper
ontheoorofthereplacebehindthelogretainerandcover
with dry kindling. Open the draft control fully by moving the
lever to "HIGH". Light the paper and leave the door slightly
ajar (one inch) until all kindling is burning. To maintain a brisk
re,ahotcoalbedmustbeestablishedandmaintained.
Slowly add larger wood (2x4 size pieces). Lay the pieces
lengthwise from side to side in the hot coal bed with a shallow
trenchbetween,sothattheprimaryaircanowdirectlyinto
thistrenchandignitethefuelabove.Whenthereseemsto
be at its peak, medium sized logs may be added. Once these
logshavecaughtre,carefullyclosethedoor.
Closing the door too quickly after refueling will reduce
the rebox temperature and result in an unsatisfactory
burn.
Rememberitismoreefcienttoburnmediumsizedwood,
briskly,andrefuelfrequentlythantoloadthereplacewith
large logs that result in a smouldering, inefcient re and
dirty glass.
As soon as the door is closed, you will observe a change in the
amepattern.Theameswillgetsmallerandlazierbecause
less oxygen is getting into the combustion chamber. The
ames,however,aremoreefcient.Theameswillremain
lazybutbecomelargeragainassoonastherebrickshave
been heated thoroughly and the chimney becomes heated
andprovidesagooddraft.Atthispoint,theroaringrethat
you see when the door is opened is wastefully drawing heated
room air up the chimney -- certainly not desirable. So always
operate with the door fully closed once the medium sized logs
havecaughtre.
Youcannowaddlargerpiecesofwoodandoperatethere-
placenormally.Oncethereplaceisentirelyhot,itwillburn
veryefcientlywithlittlesmokefromthechimney.Therewill
beabedoforangecoalsinthereboxandsecondaryames
ickeringjustbelowthetopoftherebox.Youcansafelyll
thereboxwithwoodtothetopofthedoor.
Can't get the stove operating? Use more kindling and pa-
per. Assuming the chimney and vent are sized correctly and
thereissufcientcombustionair,thelackofsufciently
quantities of kindling is the problem.  is a
good gauge for small kindling diameter.
OPERATING INSTRUCTIONS
Can't get heat out of the stove? One of two things may
havehappened.Thereplacedoormayhavebeenclosed
prematurelyandthereplaceitselfhasnotreachedoptimum
temperature. Re-open the door and/or draft control to re-
establishabriskre.Theotherproblemmayhavebeenwet
wood. The typical symptom is sizzling wood and moisture
being driven from the wood.

W415-0585 / B / 11.28.06
17
A bed of ashes approximately 1 inch deep should be left on the
reboxbottomtohelpmaintainahotcharcoalbed.Whenthe
rehasburneddownandcooled,removeanyexcessashes.
To use your ash pan, pull the ash dump handle forward to an
open position. Rake the excess ashes over the grate and into
the ash pan. Close the ash well.
3. Burningyourreplacewiththeashdumpdooropen.
4. Improperly installed or worn gaskets.
SOLUTIONS:
1. Do not burn treated or processed wood, coal, charcoal,
coloured paper or cardboard.
2. Becarefulnottooverretheunitbyleavingthedooropen
too long after the initial start-up.
3. Alwaysoperatethereplacewiththeashwellinaclosed
position.
4. Replaceworn,driedout(inexible)gaskets.
WHAT TO DO IF A RUN-AWAY OR CHIMNEY FIRE
STARTS:
1. Close the draft fully (lowest position).
2. Callthelocalredepartment.
3. Examine the chimney, attic and roof of the house, to see if
anyparthasbecomehotenoughtocatchre.Ifnecessary
spraywithareextinguisherorwaterfromagardenhose.
4. Do not operate the stove again until you are certain the
chimney has not been damaged.
Allhomeswithasolidfuelburningreplaceshouldhaveat
leastonereextinguisherinacentrallocation,known to all,
and at least one smoke detector in the room containing the
replace.Ifitsoundsanalarm,correctthecausebutdonot
de-activate or relocate the smoke detector.
Burn only dry, clean unpainted wood that has been seasoned.
It produces more heat and less soot or creosote. Freshly cut
wood contains about 50% moisture while after proper season-
ing only about 20% of the water remains. As wood is burned,
this water boils off consuming energy that should be used in
heating. The wetter the wood, the less heat is given off and
the more creosote is produced.
Bothhardwoodandsoftwoodburnequallywellinthisre-
place but hardwood, which is denser, will weigh more per
cord and burn a little slower and longer. Firewood should be
split, stacked in a manner that air can get to all parts of it and
covered in early spring to be ready for burning that fall. Dry
rewoodhascracksintheendgrain.
Attheendofeachburningseasoninspectthebafelocated
above the secondary air tubes for deterioration. Replace if nec-
essary. At this time also check that the door gasket is not worn
orloose.Replacewith1/2"breglassropeifnecessary.
To remove the door, open and lift out; remove the screws and
brackets holding the glass in place. Remove all broken glass.
WraptheedgesofthenewglasswithaU-shapedstripofber-
glass gasket, covering 1/4" on each side. Place this gasketed
glass in position and replace the brackets and screws. When
nished,youshouldbeabletomovetheglassslightly,horizon-
tally and vertically.
To remove the door, open and lift out; remove the screws and
brackets holding the glass in place. Remove all broken glass.
WraptheedgesofthenewglasswithaU-shapedstripofber-
glass gasket, covering 1/4" on each side. Place this gasketed
glass in position and replace the brackets and screws. When
nished,youshouldbeabletomovetheglassslightly,horizon-
tally and vertically.
When wood is burned slowly, it produces tar and other organic
vapours which combine with expelled moisture to form creo-
sote. These vapours condense in the relatively cooler chimney
ueofaslowburningreandwhenignited,makeanextremely
hotre.So,thechimneyshouldbeinspectedmonthlyduring
the heating season to determine if a build-up has occurred.
If creosote has accumulated it should be removed to reduce
theriskofachimneyre.
Run-awayrescanbetheresultofFOUR major factors:
1. Using incorrect fuel, or small fuel pieces which would nor-
mally be used as kindling.
2. Leaving the door ajar too long and creating extreme tem-
peratures as the air rushes in the open door.
ASh REMOVAL PROCEDURES
MAINTENANCE
Never operate your replace with the ash well in an open
position!
Thiscreatesarehazardthatmayresultinahouse/chim-
ney re, internal damage to the stove or discoloration to
thegoldplateddoor(platednishesarenotcoveredbythe
warranty). To ensure that the ash well is fully closed, allow
the door to snap shut, dislodging anything that may be stuck
at the opening.
Flip the cover up onto the ash pan when transporting the
ashestoaclosedcontainerwithatightttinglidforstorage.
Carry the ash pan using the front and back handles. Keep
theclosedcontaineronanon-combustibleoororground,
well away from all combustible materials. The ashes should
be retained in the closed container until all cinders have
thoroughly cooled. Cold wood ashes can be used on the
garden or compost.
GASkET / BAFFLE REPLACEMENT
Nz-26 DOOR GLASS REPLACEMENT
CREOSOTE FORMATION &
REMOVAL
RUN-AWAY OR ChIMNEY FIRE
WOODPILE MAINTENANCE
FIRE EXTINGUIShERS AND SMOkE
DETECTORS
FIGURE 39
Nz-26WI DOOR GLASS REPLACEMENT

W415-0585 / B / 11.28.06
18
# PART NO. DESCRIPTION
1 W010-0243 ASH PAN WITH LID
2 W325-0028 ASH PAN HANDLE
3* W690-0001 MILLIVOLT THERMOSTAT
4* W690-0005 120V THERMOSTAT
5 NZM 218-B HOT AIR GRILL 13" X 13" - polished brass
6 W090-0044 RIGHT FRONT FIREBRICK
7 W090-0045 LEFT FRONT FIREBRICK
8 W090-0039 REAR FIREBRICK - 2 REQUIRED
9 W090-0042 BOTTOM RIGHT FIREBRICK
10 W090-0043 BOTTOM LEFT FIREBRICK
11 W090-0041 RIGHT SIDE FIREBRICK
12 W090-0040 LEFT SIDE FIREBRICK
13 W090-0037 LEFT UPPER FIREBRICK
14 W090-0038 RIGHT UPPER FIREBRICK
15 W018-0063 RIGHT FIBRE BAFFLE
16 W018-0064 LEFT FIBRE BAFFLE
17 GZ552 REPLACEMENT BLOWER
18* W062-0006 BLOWER - central heating kit
19 KB35 VARIABLE SPEED CONTROL incl knob
20 W690-0002 HEAT SENSOR
21 W018-0060 BAFFLE SUPPORT
Contact your dealer for questions concerning prices and avail-
ability of replacement parts. Normally all parts can be ordered
through your Napoleon dealer or distributor.
When ordering replacement parts always give the following
information:
1. Model & serial nuMber of fireplace
2. installation date of fireplace
3. part nuMber
4. description of part
5. finish
for warranty replacement parts, aphoto-
copy of the original invoice will be required
to honour the claim.
* identifies items which are not illustrated.
for further information, contact your
napoleon dealer.
REPLACEMENTS
# PART NO. DESCRIPTION
33 111KT OUTSIDE AIR KIT
34 NZ 690KT THERMOSTATIC AIR CONTROL KIT
35 NZ 62 CH* CENTRAL HEATING KIT
36 NZ62* BLOWER KIT
37 NZ 220 HOT AIR GRAVITY VENT KIT - 5 FT.
38 GA-566 HOT AIR DISTRIBUTION KIT
39 GA-70 EXTENSION KIT - 5 ft
40 W175-0002* FLEXIBLE PIPE COUPLER - 8" DIA.
41 W010-0067* FLEXIBLE VENT SUPPORT ASSEMBLY
42 NZ-FTS* FLUE TILE SUPPORT ASSEMBLY
43 NZ 220-2* HOT AIR GRAVITY VENT EXTENSION KIT - 5 FT.
c/winsulation sleeve
44 W410-0005* 10FT FLEXIBLE ALUMINUM AIR VENT - 8" DIA.
(for use with nz62ch)
COMMON REPLACEMENT PARTS COMMON ACCESSORIES
# PART NO. DESCRIPTION
45 H333 ARCHED BLACK DOOR c/whandle & gasket
45 H333G ARCHED GOLD PLATED DOOR c/whandle & gasket
46 H334 WEBBED BLACK DOOR c/whandle & gasket
46 H334G WEBBED GOLD PLATED DOOR c/whandle & gasket
47 NZLPB UPPER & LOWER LOUVRE ASSEMBLY- polished brass
47 NZLK UPPER & LOWER LOUVRE ASSEMBLY - black
47 NZLG UPPER & LOWER LOUVRE ASSEMBLY - gold plated
Nz-26 ACCESSORIES
# PART NO. DESCRIPTION
22 W010-1072 DOOR C/w GLASS & GASKET
23 W562-0010 DOOR GASKET
24 W562-0016 GLASS GASKET
25 W325-0007 LARGE SPRING HANDLE
26 W325-0002 SMALL SPRING HANDLE
Nz-26 REPLACEMENT PARTS
# PART NO. DESCRIPTION
27 W010-1512 DOOR C/W GLASS & GASKET (LEFT)
28 W010-1513 DOOR C/W GLASS & GASKET (RIGHT)
29* W562-0041 DOOR GASKET
30* W562-0042 GLASS GASKET
31* W325-0029 DOOR HANDLE
32* W020-0365 DOOR HARDWARE
Nz-26WI REPLACEMENT PARTS

W415-0585 / B / 11.28.06
19

W415-0585 / B / 11.28.06
20
BUILD YOUR FIRE ON THE FLOOR OF THE FIRE-
BOX AND BEHIND THE LOG RETAINER ONLY.
Do not block or restrict the hot air outlets or air
inlets. This will cause the replace to overheat.
Keep res away from the door.
1. Build a hot re.
2. Use only dry wood
3. Several pieces of medium sized wood are better
than a few big pieces.
4. Clean the chimney regularly.
5. Refuel frequently using medium sized wood.
6. "Fine Tune" the air settings for optimum
performance.
1. Take ash out immediately. Let it accumulate to
a depth of at least one inch. A good ash layer
provides for a longer lasting and better burning
re.
2. Burn wet wood.
3. Close the door too soon or damper down too
quickly.
4. Burn one large log rather than two or three
smaller, more reasonably sized logs.
5. Burn at continually 'low setting', if the glass door
is constantly blackened. This means the rebox
temperature is too low.
Expansion / contraction noises during heating up and cooling
downcyclesarenormalandtobeexpected.Whenrstlight-
ingare,ifthesmokeisnotquicklydrawnintothechimney,
there may be a downdraft or cold air in the chimney. Roll up
somenewspaper,lightitandplaceitnearthereplaceue
untilthechimneybeginstodraw.Duringaring,openthe
draftcontrolbeforeopeningthereplacedoor.Openthedoor
slowly to avoid drawing smoke into the room.
AproperlyinstalledNapoleonreplaceshouldnotsmoke.If
yours does, check the following: Has the chimney had time
to get hot? Is the smoke passage blocked anywhere in the
replaceorchimney?Istheroomtooairtightandtheairintake
not connected to the outside? Check with a window partly
open.Isthesmokeowimpededbytoolongahorizontalpipe
or too many bends? Is it a weak draft perhaps caused by a
leaky chimney, a cold outside chimney, too short a chimney,
or a chimney too close to trees or a higher roof?
Check your chimney for creosote and soot build-up monthly
until a safe frequency for cleaning is established. If accumu-
lation is excessive, clean the chimney. You may want to call
a professional chimney sweep to clean it. Both the chimney
andthereplacehavetobecleanedatleastonceayearor
as often as necessary. See the Section on Creosote Forma-
tion and Removal.
TROUBLE ShOOTING GUIDE
MAINTENANCE
DOs:
DON'Ts:
