Napoleon Park Avenue Series User manual

EN
FR
PG
61
tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE
INSTALLATION AND
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.napoleon¿replaces.com • [email protected]
1.28E
$10.00
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
WARNING
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with the appliance and
shall be installed.
SAFETY INFORMATION
!WARNING
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by a
qualified installer, service agency or the supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
CERTIFIED FOR CANADAAND UNITED STATES USING ANSI/CSAMETHODS.
Decorative Product: Not for use as a heating appliance.
BARRIER
CONFORMS TO AMERICAN NATIONAL STANDARDS: ANSI Z21.50, CERTIFIED TO CANADIAN CSA 2.22 FOR VENTED GAS FIREPLACES.
SAFETY BARRIER
GD82NT-PAE
NATURAL GAS
GD82PT-PAE
PROPANE

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
2
EN
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 GENERAL INSTRUCTIONS 5
2.3 GENERAL INFORMATION 7
2.4 RATING PLATE INFORMATION 7
3.0 VENTING 8
3.1 VENTING LENGTHS AND COMPONENTS 9
3.2 TYPICAL VENT INSTALLATION 10
3.3 SPECIAL VENT INSTALLATIONS 11
3.3.1 PERISCOPE TERMINATION 11
3.4 MINIMUM AIR TERMINAL LOCATION CLEARANCES 12
3.5 VENTING APPLICATION FLOW CHART 13
3.6 DEFINITIONS 13
3.7 ELBOW VENT LENGTH VALUES 13
3.8 HORIZONTAL TERMINATION 14
3.9 VERTICAL TERMINATION 16
4.0 INSTALLATION 18
4.1 WALLAND CEILING PROTECTION 18
4.1.1 HORIZONTAL INSTALLATION 19
4.1.2 VERTICAL INSTALLATION 19
4.2 USING FLEXIBLE VENTING COMPONENTS 20
4.2.1 HORIZONTALAIR TERMINAL INSTALLATION 20
4.2.2 VERTICALAIR TERMINAL INSTALLATION 21
4.2.3 APPLIANCE VENT CONNECTION 22
4.3 USING RIGID VENT COMPONENTS 22
4.3.1 HORIZONTALAIR TERMINAL INSTALLATION 22
4.3.2 EXTENDED HORIZONTALAIR TERMINAL INSTALLATION 22
4.3.3 VERTICALAIR TERMINAL INSTALLATION 23
4.4 GAS INSTALLATION 24
4.5 MOBILE HOME INSTALLATION 24
5.0 FRAMING 25
5.1 MINIMUM CLEARANCE TO COMBUSTIBLES 27
5.2 MINIMUM CLEARANCE TO COMBUSTIBLE ENCLOSURES 28
5.3 ALCOVE CLEARANCES 30
5.4 MINIMUM MANTEL CLEARANCES 31
6.0 FINISHING 32
6.1 SAFETY SCREEN REMOVAL / INSTALLATION 32
6.2 DOOR REMOVAL / INSTALLATION 33
6.3 LOG SHIPPING BRACKET 34
6.4 DECORATIVE BRICK PANEL INSTALLATION 34
6.5 LOG PLACEMENT 35
6.6 GLOWING EMBERS 35
6.7 AFK82/RFK82 FACING KIT INSTALLATION 36
7.0 WIRING DIAGRAM / ELECTRICAL INFORMATION 37
7.1 ELECTRICAL CONNECTION 37
7.1.1 HARD WIRING CONNECTION 37
7.1.2 SCHEMATIC 37
8.0 OPERATION 38
8.1 GENERAL TRANSMITTER LAYOUT 38
8.2 APPLIANCE OPERATION 38
8.3 HAND HELD REMOTE OPERATIONS 39
8.4 TEMPERATURE DISPLAY 39
8.5 FLAME HEIGHT 39
8.6 CHILD PROOF FUNCTION 40
8.7 REMOTE AUXILIARY OUTLET 40
8.8 FAN SPEED 40
8.9 LOW BATTERY / MANUALBYPASS 41
8.10 IN THE EVENT OF A POWER FAILURE 41
8.11 FAN CONTROL MODULE 41
8.12 TIMED BLOWER 41
9.0 OPERATING INSTRUCTIONS 42
10.0 ADJUSTMENTS 43
10.1 RESTRICTING VERTICAL VENTS 43
10.2 PILOT BURNER ADJUSTMENT 43
10.3 VENTURI ADJUSTMENT 44
10.4 FLAME CHARACTERISTICS 44
11.0 MAINTENANCE 45
11.1 BURNER AND VALVE REPLACEMENT 46
11.2 SPARK MODULE BATTERY INSTALLATION 46
11.3 BLOWER REPLACEMENT 47
11.4 NIGHT LIGHT™ REPLACEMENT 47
11.5 GLASS / DOOR REPLACEMENT 48
11.6 CARE OF GLASS 48
11.7 CARE OF PLATED PARTS 48
12.0 REPLACEMENT PARTS 49
13.0 OVERVIEW 50
14.0 NIGHT LIGHT ASSEMBLY 51
15.0 VALVE TRAIN ASSEMBLY 52
16.0 ACCESSORIES 53
17.0 TROUBLESHOOTING GUIDE 55
18.0 WARRANTY 58
19.0 SERVICE HISTORY 59
TABLE OF CONTENTS
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
3
EN
1.0 INSTALLATION OVERVIEW
See the section
“MINIMUM MANTEL
AND ENCLOSURE
CLEARANCES”
See the section
“FRAMING”
See the section
“VENTING” and
“INSTALLATION”
Side
Wall
See the section
“FRAMING”
See the section
“FRAMING” and
“MINIMUM
MANTELAND
ENCLOSURE
CLEARANCES”
for Drywall (or
other combustible
material)
See the section
“FRAMING” for
Non-combustible
material
Rating plate, See “RATING
PLATE INFORMATION” section
SAFETY BARRIER
SAFETY BARRIER
Batteries must be disposed of according to the local laws and regulations. Some batteries may be recycled,
and may be accepted for disposal at your local recycling center. Check with your municipality for recycling
instructions.

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
4
EN
2.0 INTRODUCTION
3.1D
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES TO THIS APPLIANCE OR IT’S CONTROLS CAN BE DANGEROUS AND IS PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to
operating instructions could cause ¿re or injury.
• Risk of ¿re or asphyxiation do not operate appliance with ¿xed glass removed.
• Do not connect 110 volts to the control valve.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges may be sharp.
• Do not burn wood or other materials in this appliance.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns
or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance.
Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the house. To restrict access to an appliance or stove, install an
adjustable safety gate to keep toddlers, young children and other at risk individuals out of the room and away from hot
surfaces.
• Clothing or other flammable material should not be placed on or near the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These
screens and guards must be fastened to the Àoor.
• Any safety screen, guard or barrier removed for servicing the appliance, must be replaced prior to operating the
appliance.
• The appliance is a vented gas-¿red appliance. Do not burn wood or other materials in the appliance.
• The appliance area must be kept clear and free from combustible materials, gasoline and other Àammable vapors and liquids.
• Under no circumstances should this appliance be modi¿ed.
• This appliance must not be connected to a chimney Àue pipe serving a separate solid fuel burning appliance.
• Do not use this appliance if any part has been under water. Immediately call a quali¿ed service technician to inspect the appliance
and to replace any part of the control system and any gas control which has been under water.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should be done by a
licensed or quali¿ed service person.
• Do not strike or slam shut the appliance glass door.
• When equipped with pressure relief doors, they must be kept closed while the appliance is operating to prevent exhaust fumes
containing carbon monoxide, from entering into the home. Temperatures of the exhaust escaping through these openings can also
cause the surrounding combustible materials to overheat and catch ¿re.Only doors / optional fronts certi¿ed with the unit are to be
installed on the appliance.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all plastic bags, these
are not toys and should be kept away from children and infants.
• As with any combustion appliance, we recommend having your appliance regularly inspected and serviced as well as having a
Carbon Monoxide Detector installed in the same area to defend you and your family against Carbon Monoxide.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance. Elevated temperatures
on the wall or in the air above the appliance can cause melting, discolouration or damage to decorations, a T.V. or other electronic
components.
• A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance and shall be
installed.
• If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance.
• Installation and repair should be done by a qualified service person. The appliance should be inspected before use and
at least annually by a professional service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. It is imperative that control compartments, burners and circulating air passageways of
the appliance be kept clean.
• This appliance uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple supplied by Wolf Steel
Ltd.

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
5
EN
2.1 DIMENSIONS
2.2 GENERAL INSTRUCTIONS
THIS GAS APPLIANCE SHOULD BE INSTALLED AND SERVICED BY A QUALIFIED INSTALLER to
conform with local codes. Installation practices vary from region to region and it is important to know the
speci¿cs that apply to your area, for example in Massachusetts State:
• This product must be installed by a licensed plumber or gas ¿tter when installed within the commonwealth
of Massachusetts.
• The appliance damper must be removed or welded in the open position prior to installation of an appliance
insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The Àexible connector must not be longer than 36 inches (914mm).
• A Carbon Monoxide detector is required in all rooms containing gas ¿red appliances.
• The appliance is not approved for installation in a bedroom or bathroom unless the unit is a direct vent
sealed combustion product.
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT,
WITH THE GLASS DOOR OPENED OR REMOVED.
PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE.
PROVIDE ADEQUATE VENTILATION.
NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.
OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48” (1219mm) FROM
THE FRONT FACE OF THE APPLIANCE.
SURFACES AROUND AND ESPECIALLY ABOVE THE APPLIANCE CAN BECOME HOT. AVOID CONTACT
WHEN THE APPLIANCE IS OPERATING.
FIRE RISK. EXPLOSION HAZARD.
HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE PRESSURE TESTING GAS
LINE AT TEST PRESSURES ABOVE 1/2 PSIG. CLOSE THE MANUAL SHUT-OFF VALVE BEFORE PRESSURE
TESTING GAS LINE AT TEST PRESSURES EQUAL TO OR LESS THAN 1/2 PSIG (35 mb).
USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE.
USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENTING
COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION.
!
WARNING
37 5/8"
956mm
46"
1168mm
58"
1473mm
24" 610mm
28" 711mm
2"
51mm
13 7/8"
352mm
GAS
INLET
8 7/8"
225mm
21" 533mm
22 1/8" 562mm
14"
356mm
17 3/4" 451mm
7/8"
22mm
7" 178mm DIA.
4" 102mm DIA.

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
6
EN
4.1B
The installation must conform with local codes or, in
absence of local codes, the National Gas and Propane
Installation Code CSA B149.1 in Canada, or the National
Fuel Gas Code, ANSI Z223.1 / NFPA 54 in the United
States. Suitable for mobile home installation if installed in
accordance with the current standard CAN/CSA Z240MH
Series, for gas equipped mobile homes, in Canada or
A
NSI Z223.1 and NFPA 54 in the United States.
A
s long as the required clearance to combustibles is
maintained, the most desirable and bene¿cial location
for an appliance is in the center of a building, thereby
allowing the most ef¿cient use of the heat created. The location of windows, doors and the traf¿c Àow in the
room where the appliance is to be located should be considered. If possible, you should choose a location
where the vent will pass through the house without cutting a Àoor or roof joist.
If the appliance is installed directly on carpeting, vinyl tile or other combustible material other than wood
Àooring, the appliance shall be installed on a metal or wood panel extending the full width and depth.
Some appliances have optional fans or blowers. If an optional fan or blower is installed, the junction box must
be electrically connected and grounded in accordance with local codes, use the current CSA C22.1 Canadian
Electrical Code in Canada or the ANSI/NFPA 70 National Electrical code in the United States.
We suggest that our gas
hearth products be installed
and serviced by professionals
who are certied in the U.S.
by the National Fireplace
Institute
® (NFI) as NFI Gas
Specialists
www.ncertied.org

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
7
EN
2.3 GENERAL INFORMATION
FOR YOUR SATISFACTION, THIS APPLIANCE HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION AND
QUALITY!
RATES AND EFFCIENCIES
NG LP
Altitude (FT) 0 - 4,500 0 - 4,500
Max. Input (BTU/HR) 26,000 26,000
Max. Output Steady State (BTU/HR) 16,150 16,150
Ef¿ciency (w/the fan on) 62% 62%
Min. Inlet Gas Supply Pressure 4.5" Water Column (11mb) 11" Water Column (27mb)
Max. Inlet Gas Supply Pressure 7" Water Column (17mb) 13" Water Column (32mb)
Manifold Pressure (Under Flow Conditions) 3.5" Water Column (9mb) 10" Water Column (25mb)
When the appliance is installed at elevations above 4,500ft (1371m), and in the absence of speci¿c
recommendations from the local authority having jurisdiction, the certi¿ed high altitude input rating shall be
reduced at the rate of 4% for each additional 1,000ft (305m).
This appliance is certi¿ed to be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certi¿ed kit is used. No external electricity (110 volts or 24 volts)
is required for the gas system operation.
Expansion / contraction noises during heating up and cooling down cycles are normal and are to be expected.
Change in Àame appearance from “HI” to “LO” is more evident in natural gas than in propane.
NOTE: The protective wrap on plated parts is best removed when the assembly is at room temperature
but this can be improved if the assembly is warmed, using a hair dryer or similar heat source.
2.4 RATING PLATE INFORMATION
INSTALLER: It is your responsibility to check off the appropriate box on the rating plate according to
the model, venting and gas type of the appliance.
For rating plate location, see “INSTALLATION OVERVIEW” section.
This illustration is for reference only. Refer to the rating plate on the appliance for accurate information.
NOTE: The rating plate must remain with the appliance at all times. It must not be removed.
THE APPLIANCE MUST BE VENTED USINGTHE APPROPRIATE WOLF STEEL
VENT KITS. SEE OWNERS INSTALLATION MANUAL FOR VENTING
SPECIFICS. PROPER REINSTALLATION AND RESEALING IS NECESSARY
AFTER SERVICING THE VENT-AIR INTAKE SYSTEM.
L'APPAREILDOIT EVACUER SES GAZ EN UTILISANT L'ENSEMBLE
D'EVACUATION PROPREA WOLF STEEL. POUR LES SPÉCIFICATIONS
D'ÉVACUATION, SE REFERERAU MANUEL D'INSTRUCTIONS.. IL EST
IMPORTANT DE BIEN REINSTALLER ET RESCELLER LE SYSTEME DE
PRISE D'AIR ET D'EVACUATION APRESAVOIR EFFECTUE LE SERVICE.
W385-1990
WOLF STEEL LTD.
24 NAPOLEON RD. BARRIE, ONTARIO L4M 0G8 CANADA
9700539 (WSL) 4001657 (NGZ)
4001658 (NAC) 4001659 (WUSA)
GD82NT-PAE
TOP, SIDES & BACK: PER STAND OFF SPACERS FOR FRAMING
MATERIALS. FOR FINISHING MATERIALS SEE OWNERS MANUAL.
*MAXIMUM HORIZONTAL EXTENSION 2”. SEE INSTRUCTION MANUAL
FOR GREATER EXTENSIONS. SEE OWNER’S INSTRUCTION MANUAL
FOR MIMIMUM AND MAXIMUM VENT LENGTHS.
THIS VENTED GAS FIREPLACE IS NOT FOR USE WITH AIR FILTERS.
FOR USE WITH GLASS DOORS CERTIFIED WITH THIS
APPLIANCE ONLY.
WARNING: DO NOTADD ANY MATERIAL TO THE
APPLIANCE WHICH WILL COME IN CONTACT WITH
THE FLAMES OTHER THAN THAT SUPPLIED BY THE
MANUFACTURER WITH THEAPPLIANCE.
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALS:
TOP 0 RECESSED DEPTH 22 1/2"
FLOOR 0 VENT 2"
SIDES 0 MANTEL 8" *
BACK 0
0-45000FT (0-1370M) ALTITUDE / ELEVATION 0-4500FT (0-1370M)
26,000 BTU/H INPUT / ALIMENTATION 26,000 BTU/H
16,000 BTU/H REDUCED INPUT / ALIMENTATION REDUITE 16,000 BTU/H
3.5" WATER COLUMN / D’UNE COLONNE D’EAU MANIFOLD PRESSURE / PRESSION AU COLLECTEUR 10" WATER COLUMN / D’UNE COLONNE D’EAU
4.5" WATER COLUMN / D’UNE COLONNE D’EAU MINIMUM SUPPLY PRESSURE / 11" WATER COLUMN / D’UNE COLONNE D’EAU
PRESSION D’ALIMENTATION MINIMALE
7.0" WATER COLUMN / D’UNE COLONNE D’EAU MAXIMUM SUPPLY PRESSURE / 13" WATER COLUMN / D’UNE COLONNE D’EAU
PRESSION D’ALIMENTATION MAXIMALE
P4 55%
PROPANE MODELNATURAL MODEL
POUR UTILISATION UNIQUEMENTAVEC LES PORTES EN VERRE
CERTIFIÉES AVEC L’APPAREIL.
AVERTISSEMENT: N’AJOUTEZ PAS ACET APPAREIL
AUCUN MATERIAU DEVANT ENTRER EN CONTACT AVEC
LES FLAMMES AUTRE QUE CELUI QUI EST FOURNIAVEC
CET APPAREIL PAR LE FABRICANT.
DEGAGEMENTS MINIMAUX DES MATERIAUX COMBUSTIBLES:
DESSUS 0 PROFONDEUR D’ENCASTRE 22 1/2"
PLANCHER 0 EVENT 2"
COTES 0 MANTEAU 8" *
ARRIERE 0
DESSUS, COTES & ARRIERE: SELON LES ESPACEURS CONSULTER
POUR LES MATERIAUX D’OSSATURE. CONSULTER LE MANUEL DE
D'INSTRUCTIONS POUR LES MATERIAUX DE FINITION.
* L’EXTENSION HORIZONTALE MAXIMALE: 2”. SE REFERER AU
MANUEL D’INSTRUCTION POUR DES EXTENSIONS PLUS GRANDE. SE
REFERER AU MANUELD'INSTRUCTIONS POUR LES LONGUEURS
D'ÉVENT MINIMALE ET MAXIMALE.
NOT FOR USE WITH SOLID FUEL. NE PAS UTILISER AVEC DU COMBUSTIBLE SOLIDE.
VENTED GAS FIREPLACE. APPROVED FOR BEDROOM, BATHROOM AND BED-SITTING ROOM INSTALLATION. SUITABLE FOR MOBILE HOME INSTALLATION IF INSTALLED IN ACCORDANCE WITHTHE CURRENT STANDARD CAN/CSA Z240MH SERIES GAS EQUIPPED MOBILE HOMES, IN CANADAOR IN THE UNITED
STATES THE MANUFACTURED HOME CONSTRUCTIONAND SAFETY STANDARD, TITLE 24 CFR, PART 3280. WHEN THIS US STANDARD IS NOTAPPLICABLE USE THE STANDARD FOR FIRE SAFETY CRITERIA FOR MANUFACTURED HOME INSTALLATIONS, SITES AND COMMUNITIES,ANSI / NFPA501A. FOR USE ONLY
WITH BARRIER W565-0184 OR W565-0186. FOLLOW THE INSTALLATION INSTRUCTIONS LOCATED IN THE INSTALLATION MANUAL. APPAREIL AGAZ VENTILES. HOMOLOGUE POUR INSTALLATION DANS UNE CHAMBRE A COUCHER, UNE SALLE DE BAIN ET UN STUDIO.APPROPRIE POUR INSTALLATION DANS
UNE MAISON MOBILE SI SON INSTALLATION POUR LES CONFORME AUX EXIGENCES DE LANORME CAN/CSA Z240MH POUR LES MAISONS MOBILES EQUIPEES AU GAZ, EN VIGUEURAU CANADA OU AUX ETATS-UNIS L'INCENDIE POUR LA NORME DE SECURITE ET DE CONSTRUCTION POUR LES MAISONS
MANUFACTUREES, TITRE 24 CFR, SECTION 3280. DANS LE CAS OU CETTE NORME D'ETATS-UNIS NE PEUT ETREAPPLIQUEE, SE REFERER A LANORME RELATIVEAU CRITERE DE MESURES DE SECURITE CONTRE L'INCENDIEPOUR LES INSTALLATIONS DANS LES MAISONS MANUFACTURES, LES SITES ET LES
COMMUNAUTES, ANSI/NFPA 501A. POUR UNE UTILISER SEULMENT AVEC BARRIÈRE W565-0184 OU W565-0186. SUIVEZ LES INSTRUCTIONS D'INSTALLATION SE TROUVENT DANS LE MANUEL D'INSTALLATION.
CLASSIFICATION:115V 0 82AMP60HZ CE FOYER À GAZ VENTILÉS NE DOIT PAS ÊTRE UTILISÉ CONJOINTEMENT
AVEC DES FILTRES À AIR.
GD82NT-TE CDV82NT-PAE CDV82NT-TE GD82PT-PAE GD82PT-TE CDV82PT-PAE CDV82PT-TE
CONFORMS TO / CONFORME AUX:ANSI Z21.50-2014, CERTIFIED TO / CERTIFIE CSA 2.22-2014 VENTED GAS FIREPLACE / FOYER À GAZ VENTILÉ
PRODUIT DÉCORATIF: NE PAS UTILISER COMME APPAREIL DE CHAUFFAGE
DECORATIVE PRODUCT: NOT FOR USE AS AHEATING
APPLIANCE.
SAMPLE
ENTED USING THE APPROPRIATE WOLF STEELED USING THE APPROPRIATE WOLF STEEL
S. SEE OWNERS INSTALLATION MANUALFOR VENTINGERS INSTALLATION MANUALFOR VENTING
CS. PROPER REINSTALLATION AND RESEALING IS NECESSARYTALLATION AND RESEALING IS NECESSARY
AFTER
S
ERVI
C
IN
G
THE VENT-AIR INTAKE
S
Y
S
TEM.
SERVICING THE VENT-AIR INTAKE SYSTEM.
L'APPAREILDOIT EVACL'APPAREILDOIT EVA
D'EVACUATION PRD'EVACUATION P
D'ÉVACUATIOD'ÉVA
IMPOIMPO
E
SAM
WOLF STEEL LTD
.WOLF STEEL LTD.
2
4 NAP
O
LE
O
N RD. BARRIE,
O
NTARI
O
L4M 0
G
8
C
ANAD
A24 NAPOLEON RD. BARRIE, ONTARIO L4M 0G8 CANA
UALUAL
MANUALMANUAL
IR FILTERS.
LTERS.
E / ELEVATION/ ELEVATION
0
-4500FT
(
0-1370M
)500FT (0-137
PUT / ALIMENTATIONALIMENTATION
2
6,000 BTU
/
H
26,000 BTU/H
CED INPUT /ALIMENTATION REDUITE 16,000 BTU/HED INPUT /ALIMENTATION REDUITE 16,000 BTU/H
FOLD PRESSURE / PRESSION AU COLLECTEUR 10" WATER COLUMN / D’UNE COLONNE D’OLD PRESSURE / PRESSION AU COLLECTEUR 10" WATER COLUMN / D’UNE COLONNE D
M
INIM
U
M
SU
PPLY PRE
SSU
RE
/MINIMUM SUPPLY PRESSURE
11" WATER COLUMN / D’UNE COLON11" WATER COLUMN / D’UNE COLO
PRESSION D’ALIMENTATION MINIMALEPRESSION D’ALIMENTATION MINIM
NE D’EAU MAXIMUM SUPPLY PRESSURE /MAXIMUM SUPPLY PRESSURE /
13" WATER COLUMN / D13" W
PRE
SS
I
O
N D’ALIMENTATI
O
N MAXIMALE
PRESSION D’ALIMENTATION MAXIMA
P4 55%P4 55%
ED USING THE APPROPRIATE WOLF STEELD USING THE APPROPRIATE WOLF STEE
P
ROPANE MODEL
PROPANE M
POUR UTILISATION UNIQPOUR UTILISATION UNIQ
CERTIFIÉES AVEC L’APPA
CERTIFIÉES AVEC L’APPA
AVERTISSEMENAVERTISSEMEN
AUCUN MAAUCUN M
LES FLES
C
C DU COMBUSTIBLE SOLIDE.DU COMBUSTIBLE
RENT STANDARD CAN/CSA Z240MH SERIES GAS EQUCAN/CSA Z240MH SERIES GAS EQ
CRITERIA FOR MANUFACTURED HOME INSTALLATIONS, SITERITERIA FOR MANUFACTURED HOME INSTALLATIONS, SI
ATION DANS UNE CHAMBREA COUCHER, UNE SALLE DE BAIN ET UTION DANS UNE CHAMBRE ACOUCHER, UNE SALLE DE BAIN
AU CANADA OUAUX ETATS-UNIS L'INCENDIE POUR LA NORME DE SECURITCANADA OUAUX ETATS-UNIS L'INCENDIE POUR LA NORME
DE MESURES DE SECURITE CONTRE L'INCENDIEPOUR LES INSTALLATIONS DANSES DE SECURITE CONTRE L'INCENDIEPOUR LES INSTALLATIONS DANS
NT DANS LE MANUEL D'INSTALLATION.T DANS LE MANUEL D'INSTAL
C
LA
SS
IFI
C
ATI
O
N:11
5
V
08
2AMP
60
HZ
CLASSIFICATION:115V 0 82AMP60HZ
GD82PT-PAEGD82PT-PAE
G
D82PT-T
EGD82PT-TE
CDV82PT-PA
EDV82PT-PA
CDV82PT-T
EDV82PT-TE
M
P
PL
L
A barrier designed to reduce the risk of burns from the hot viewing glass is provided for the appliance
and shall be installed

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
8
EN
3.0 VENTING
7.1C
THIS APPLIANCE USES A 4” (102mm) EXHAUST / 7” (178mm) AIR INTAKE VENT PIPE SYSTEM.
Refer to the section applicable to your installation.
For safe and proper operation of the appliance follow the venting instruction exactly. Deviation from the
minimum vertical vent length can create dif¿culty in burner start-up and/or carboning. Under extreme
vent con¿gurations, allow several minutes (5-15) for the Àame to stabilize after ignition. Although not a
requirement, it is recommended for vent lengths that pass through unheated spaces (attics, garages, crawl
spaces) be insulated with the insulation wrapped in a protective sleeve to minimize condensation. Provide
a means for visually checking the vent connection to the appliance after the appliance is installed. Use a
¿restop, vent pipe shield or attic insulation shield when penetrating interior walls, Àoor or ceiling.
NOTE: If for any reason the vent air intake system is disassembled; reinstall per the instructions
provided for the initial installation.
!
WARNING
RISK OF FIRE, MAINTAIN SPECIFIED AIR SPACE CLEARANCES TO VENT PIPE AND APPLIANCE.
IF VENTING IS INCLUDED WITH SPACERS THE VENT SYSTEM MUST BE SUPPORTED EVERY 3FT
(0.9m) FOR BOTH VERTICAL AND HORIZONTAL RUNS. USE SUPPORTS OR EQUIVALENT
NON-COMBUSTIBLE STRAPPING TO MAINTAIN THE REQUIRED CLEARANCE FROM
COMBUSTIBLES. USE WOLF STEEL LTD. SUPPORT RING ASSEMBLY W010-0370 OR EQUIVALENT
NON-COMBUSTIBLE STRAPPING TO MAINTAIN THE MINIMUM CLEARANCE TO COMBUSTIBLES
FOR BOTH VERTICAL AND HORIZONTAL RUNS. SPACERS ARE ATTACHED TO THE INNER PIPE AT
PREDETERMINED INTERVALS TO MAINTAIN AN EVEN AIR GAP TO THE OUTER PIPE. THIS GAP IS
REQUIRED FOR SAFE OPERATION. A SPACER IS REQUIRED AT THE START, MIDDLE AND END OF
EACH ELBOW TO ENSURE THIS GAP IS MAINTAINED. THESE SPACERS MUST NOT BE REMOVED.

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
9
EN
3.1 VENTING LENGTHS AND COMPONENTS
Use only Wolf Steel, Simpson Dura-Vent, Selkirk Direct Temp,American MetalAmerivent or Metal-Fab venting
components. Minimum and maximum vent lengths, for both horizontal and vertical installations, and air terminal
locations for either system are set out in this manual and must be adhered to. For Simpson Dura-Vent, Selkirk Direct
Temp,American MetalAmerivent and Metal-Fab follow the installation procedure provided with the venting components.
Astarter adaptor must be used with the following vent systems and may be purchased from the corresponding supplier:
For Simpson Dura-Vent, Selkirk Direct Temp,American Metal Amerivent and Metal-Fab follow the installation
procedure found on the website for your venting supplier.
For vent systems that provide seals on the inner exhaust Àue, only the outer air intake joints must be sealed using a red
high temperature silicone (RTV).This same sealant may be used on both the inner exhaust and outer intake vent pipe
joints of all other approved vent systems except for the exhaust vent pipe connection to the appliance Àue collar which must
be sealed using the black high temperature sealant Mill Pac. High temperature sealant must be ordered separately.
When using Wolf Steel venting components, use only approved Wolf Steel rigid / Àexible components with the following
termination kits: wall terminal kit GD222, GD222R, or 1/12 to 7/12 pitch roof terminal kit GD110, 8/12 to 12/12 roof terminal
kit GD111, Àat roof terminal kit GD112 or periscope kit GD201 (for wall penetration below grade). With Àexible venting, in
conjunction with the various terminations, use either the 5 foot (1.5m) vent kit GD220 or the 10 foot (3.1m) vent kit GD330.
For optimum flame appearance and appliance performance, keep the vent length and number of elbows to a minimum.
The air terminal must remain unobstructed at all times. Examine the air terminal at least once a year to verify that
it is unobstructed and undamaged.
Rigid and flexible venting systems must not be combined. Different venting manufacturer components must not
be combined.
These vent kits allow for either horizontal or vertical venting of the appliance. The maximum allowable horizontal run is
20 feet (6.1m). The maximum allowable vertical vent length is 40 feet (12.2m).The maximum number of vent connections
is two horizontally or three vertically (excluding the appliance and the air terminal connections) when using Àexible venting.
Horizontal runs may have a 0” (0mm) rise per foot/meter however for optimum performance it is recommended
that all horizontal runs have a minimum 1” (25.4mm) rise per foot/meter using Àexible venting. For safe and proper
operation of the appliance, follow the venting instructions exactly.
Aterminal shall not terminate directly above a sidewalk or paved driveway which is located between two single family
dwellings and serves both dwellings. Local codes or regulations may require different clearances.
Do not allow the inside liner to bunch up on horizontal or vertical runs and elbows. Keep it pulled tight.A1¼”
(31.8mm) air gap all around between the inner liner and outer liner is required for safe operation.
PART 4”/7” SUPPLIER WEBSITE
Duravent W175-0053 Wolf Steel www.duravent.com
Amerivent 4DSC-N2 American Metal www.americanmetalproducts.com
Direct Temp 4DT-AAN Selkirk www.selkirkcorp.com
SuperSeal 4DNA Metal-Fab www.mtlfab.com
8.7A

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
10
EN !
WARNING
THE FIRST 2 FEET OF OUTER 7" (178MM) DIAMETER VENT PIPE FROM THE APPLIANCE MUST
BE WRAPPED IN THE 1" (25MM) THICK INSULATION SLEEVE (SUPPLIED). MAKE SURE THE
INSULATION IS PULLED DOWN TIGHT TO THE APPLIANCE WHEN INSTALLED. THERE AFTER, A
2" (51MM) CLEARANCE ALL AROUND THE VENT PIPE FROM COMBUSTIBLE MATERIALS ON ALL
HORIZONTAL VENT SECTIONS IS REQUIRED.
45.6
10" (254mm)
MINIMUM
24" (610mm)
MAXIMUM
56"
(1422mm)
PLUS RISE
46"
(1168mm)
16" (406mm)
MINIMUM
3 FEET (1m)
MINIMUM
40 FEET (12m)
MAXIMUM
When venting, the horizontal run must be kept to a maximum of 20 feet (6m). If a 20 foot (6m) horizontal run
is required, the appliance must have a minimum vertical rise immediately off the appliance of 57" (1448mm).
When terminating vertically, the vertical rise is a minimum 3 feet (1m) and a maximum 40 feet (12m) above the
appliance.
* FIRST TWO
FEET
REQUIRES
INSULATION
SLEEVE
3.2 TYPICAL VENT INSTALLATION
46"
(1168mm)
* First two feet (0.6m) requires insulation sleeve

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
11
EN
Use the periscope kit to locate the air termination above grade. The periscope
must be installed so that when ¿nal grading is completed, the bottom air slot is
located a minimum 12” (305m) above grade. The maximum allowable vent length
(including both rise and run) is 10’ (3m).
9.3B
3.3 SPECIAL VENT INSTALLATIONS
3.3.1 PERISCOPE TERMINATION
30" (762mm)
MINIMUM*
12" (305mm)
MINIMUM
ABOVE
GRADE
46"
(1168mm)

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
12
EN
3.4 MINIMUM AIR TERMINAL LOCATION CLEARANCES
INSTALLATIONS
CANADA U.S.A.
A12” (304.8mm) 12” (304.8mm) Clearance above grade, veranda porch, deck or balcony.
B12” (304.8mm) ǻ9” (228.6mm) ǻClearance to windows or doors that open.
C12” (304.8mm)* 12” (304.8mm)* Clearance to permanently closed windows.
D18”
(457.2mm)** 18” (457.2mm)** Vertical clearance to ventilated sof¿ts located above the terminal within a horizontal distance of 2’ (0.6m) from the centerline of the terminal.
E12”
(304.8mm)** 12” (304.8mm)** Clearance to unventilated sof¿t.
F0” (0mm) 0” (0mm) Clearance to an outside corner wall.
G0” (0mm)*** 0” (0mm)*** Clearance to an inside non-combustible corner wall or protruding non-combustible obstructions (chim-
ney, etc.).
2” (50.8mm)*** 2” (50.8mm)*** Clearance to an inside combustible corner wall or protruding combustible obstructions (vent
chase, etc.).
H3’ (0.9m) 3’ (0.9m)**** Clearance to each side of the centerline extended above the meter / regulator assembly to a
maximum vertical distance of 15’ (4.6m).
I3’ (0.9m) 3’ (0.9m)**** Clearance to a service regulator vent outlet.
J12” (304.8mm) 9” (228.6mm) Clearance to a non-mechanical air supply inlet to the building or a combustion air inlet to any other
appliance.
K6’ (1.8m) 3’ (0.9m) Clearance to a mechanical air supply inlet.
L7’ (2.1m)‡ 7’ (2.1m)**** Clearance above a paved sidewalk or paved driveway located on public property.
M12”
(304.8mm)†† 12” (304.8mm)**** Clearance under a veranda, porch, deck or balcony.
N16” (406.4mm) 16” (406.4mm) Clearance above the roof.
O2’ (0.61m)†* 2’ (0.61m)†* Clearance from an adjacent wall including neighbouring buildings.
P8’ (2.4m) 8’ (2.4m) Roof must be non-combustible without openings.
Q3’ (0.9m) 3’ (0.9m) See chart for wider wall dimensions.
R6’ (1.8m) 6’ (1.8m) See chart for deeper wall dimensions. The terminal shall not be installed on any wall that has
an opening between the terminal and the open side of the structure.
ǻThe terminal shall not be located less than 6 feet (1.8m) under a window that opens on a horizontal plane in a structure with three walls and a roof.
* Recommended to prevent condensation on windows and thermal breakage
** It is recommended to maximize the distance to vinyl clad sof¿ts.
*** The periscope requires a minimum 18” (457.2mm) clearance from an inside corner.
**** This is a recommended distance. For additional requirements check local codes.
† 3 feet (0.91m) above if within 10 feet (3.1m) horizontally.
‡ A vent shall not terminate where it may cause hazardous frost or ice accumulations on adjacent property surfaces.
†† Permitted only if the veranda, porch, or deck is fully open on a minimum of two sides beneath the Àoor.
†* Recommended to prevent recirculation of exhaust products. For additional requirements check local codes. 12.3C
R
QM
GP
COVERED BALCONY APPLICATIONS
QMIN RMAX MAX
R
= 3 feet
(0.9m) = 2 x IHHW
(4.6m)
QACTUAL

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
13
EN
3.5 VENTING APPLICATION FLOW CHART
14.1
For the following symbols used in the venting calculations and examples are:
> - greater than
> - equal to or greater than
< - less than
< - equal to or less than
HT- total of both horizontal vent lengths (Hr) and offsets (Ho) in feet
HR- combined horizontal vent lengths in feet
HO- offset factor: .03 (total degrees of offset - 90°*) in feet
VT- combined vertical vent lengths in feet
3.6 DEFINITIONS
15.1A
FEET INCHES MILLIMETERS
1° 0.03 0.5 12.7
15° 0.45 6.0 152.4
30° 0.9 11.0 279.4
45° 1.35 16.0 406.4
90°* 2.7 32.0 812.8
* The ¿rst 90° offset has a zero value and is shown in the formula as - 90°
13.1A
TOP EXIT
Horizontal Termination Vertical Termination
Vertical rise is equal
to or greater than
the horizontal run
Vertical rise is less
than horizontal run
Vertical rise is equal
to or greater than
the horizontal run
Vertical rise is less
than horizontal run
Horizontal run +
vertical rise to
maximum of 40 feet
(12m)
Horizontal run +
vertical rise to
maximum of
24.75 feet (7.5m)
Horizontal run +
vertical rise to Horizontal run +
vertical rise to
4.2 times the
vertical rise equal to
or greater than the
horizontal run
3 times the vertical
rise equal to or
greater than the
horizontal run
maximum of 40 feet
(12m) maximum of 40 feet
(12m)
3.7 ELBOW VENT LENGTH VALUES

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
14
EN
3.8 HORIZONTAL TERMINATION
16.1B
Simple venting configuration (only one 90° elbow)
(HT) < (VT)
For vent configurations requiring more than one 90° elbow, the following formulas apply:
Formula 1: HT< VT
Formula 2: HT+ VT< 40 feet (12.2m)
Example:
V1= 3 FT (0.9m)
V2= 8 FT (2.4m)
VT= V1+ V2= 3 FT (0.9m ) + 8 FT (2.4m) = 11 FT (3.4m)
H1= 2.5 FT (0.8m)
H2= 2 FT (0.6m)
HR= H1+ H2= 2.5 FT (0.8m) + 2 FT (0.6m) = 4.5 FT (1.4m)
HO= .03 (three 90° elbows - 90°) = .03 (270° - 90°) = 5.4 FT (1.7m)
HT= HR+ HO= 4.5 FT (1.4m) + 5.4 FT (1.6m)= 9.9 FT (3m)
HT+ VT= 9.9 FT (3m) + 11 FT (3.4m) = 20.9 FT (6.4m)
Formula 1: HT< VT
9.9 FT (3m) <11 FT (3.4m)
Formula 2: HT+ VT< 40 FT (12.2m)
20.9 FT (6.4m) < 40 FT (12.2m)
Since both formulas are met, this vent con¿guration is acceptable.
See graph to determine the required vertical
rise VTfor the required horizontal run HT.
The shaded area within the lines represents
acceptable values for HTand VT
02.5
(0.8) 5 (1.5) 7.5 (2.3) 10 (3.1) 12.5 (3.8) 15 (4.6)
40 (12.2)
10 (3.1)
20 (6.1)
30 (9.1)
17.5
(5.3) 20 (6.1)
39 (11.9)
REQUIRED
VERTICAL
RISE IN FEET
(METERS)VT
HORIZONTAL VENT RUN PLUS OFFSET IN
FEET (METERS) HT
90°
90°
90°
V1
V2
H1
H2

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
15
EN
(HT) > (VT)
Simple venting configuration (only one 90° elbow) See graph to determine the required vertical rise VTfor the
required horizontal run HT.
REQUIRED
VERTICAL RISE
IN INCHES
(MILLIMETERS)
VT
HORIZONTAL VENT RUN PLUS OFFSET IN FEET (METERES) HT
For vent configurations requiring more than one 90° elbow, the following formulas apply:
Formula 1: HT< 4.2 VT
Formula 2: HT+ VT< 24.75 feet (7.5m)
Example:
V
1=VT= 6 FT (1.8m)
H1= 3 FT (0.9m)
H2= 5 FT (1.5m)
HR=H1+ H2= 3FT (0.9m) + 5FT (1.5m) = 8 FT (2.4m)
HO= .03 (two 90° elbows - 90°) = .03 (180° - 90°) = 2.7FT (0.8m)
HT=HR+ HO= 8FT (2.4m) + 2.7FT (0.8m) = 10.7FT (3.3m)
HT+ VT= 10.7FT (3.3m) + 6FT (1.8m) = 16.7FT (5.1m)
Formula 1: HT< 4.2 VT
4.2 VT= 4.2FT (1.3m) x 6FT (1.8m) = 25.2FT (7.7m)
10.7FT (3.3m) < 25.2FT (7.7m)
Formula 2: HT+ VT< 24.75 FT (7.5m)
16.7FT (5.1m) < 24.75 (7.5m)
Since both formulas are met, this vent configuration is acceptable.
05
(1.5) 15 (4.6) 20 (6.1)
100 (2540)
50 (1270)
150 (3810)
12.5
(3.8)
19 1/2
(495.3)
57 (1447.8)
147
(3733.8)
2
(0.6)
The shaded area within the lines represents acceptable
values for HTand VT
90°
V1
H1H2
90°
Example:
V
1= 4 FT (1.2m)
V
2= 1.5 FT (0.5m)
V
T=V1+ V2= 4FT (1.2m) + 1.5FT (0.5m) = 5.5 FT (1.7m)
H1= 2 FT (0.6m)
H2= 1 FT (0.3m)
H3= 1 FT (0.3m)
H4= 1.5 FT (0.5m)
HR=H1+ H2+ H3+ H4= 2FT (0.6m) + 1FT (0.3m) + 1FT (0.3m) + 1.5FT (0.5m) = 5.5 FT (1.7m)
HO= .03 (four 90° elbows - 90°) = .03 (360° - 90°) = 8.1 FT (2.5m)
HT=HR+ HO= 5.5 FT (1.7m) + 8.1 FT (2.5m) = 13.6 FT (4.2m)
HT+ VT= 13.6 FT (4.2m) + 5.5 FT (1.7m) = 19.1 FT (5.8m)
Formula 1: HT< 4.2 VT
4.2 VT= 4.2 FT (1.3m) x 5.5 FT(1.7m) = 23.1 FT (7m)
13.6 FT (4.2m) < 23.1 FT (7m)
Formula 2: HT+ VT< 24.75 FT (7.5m)
19.1FT (5.8m) < 24.75 FT (7.5m)
Since both formulas are met, this vent configuration is acceptable.
90°
90°
90° 90°
H1
H2
V1
V2
H3
H4
10
(3.1) 19.5
(5.9)
16.1_2A
05
(1.5) 15 (4.6) 20 (6.1)
100 (2540)
50 (1270)
150 (3810)
12.5
(3.8)
19 1/2
(495.3)
57 (1447.8)
147
(3733.8)
2
(0.6)
10
(3.1) 19.5
(5.9)
10" (254mm) MIN. RISE IF
MAX 42" (1067mm)
WITH MIN RISE. HT

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
16
EN
3.9 VERTICAL TERMINATION
(HT) < (VT)
Simple venting configurations. See graph to determine the required vertical rise VTfor the
required horizontal run HT.
REQUIRED
VERTICAL
RISE IN FEET
(METERS) VT
HORIZONTAL VENT RUN PLUS OFFSET IN FEET (METERS) HT
For vent configurations requiring one or more 90° elbows the following formulas apply:
Formula 1: HT< VT
Formula 2: HT+ VT< 40 feet (12.2m)
Example:
V1= 5 FT (1.5m)
V2= 6 FT (1.8m)
V3= 10 FT (3.1m)
VT=V1+ V2+ V3= 5FT (1.5m) + 6FT (1.8m) + 10FT (3.1m) = 21FT (6.4m)
H1= 8 FT (2.4m)
H2= 2.5 FT (0.8m)
HR=H1+ H2= 8FT (2.4m) + 2.5FT (0.8m) = 10.5 FT (3.2m)
HO= .03 (four 90° elbows - 90°)
= .03 (360° - 90°) = 8.1 FT (2.5m)
HT=HR+ HO= 10.5FT (3.2m) + 8.1FT (2.5m) = 18.6FT (5.7m)
HT+ VT= 18.6FT (5.7m) + 21FT (6.4m) = 39.6FT (12.1m)
Formula 1: HT< VT
18.6FT (5.7m) < 21FT (6.4m)
Formula 2: HT+ VT< 40 FT (12.19m)
39.6FT (12.1m) < 40FT (12.2m)
Since both formulas are met, this vent configuration is acceptable.
90°
V1
V2
H1
H2
The shaded area within the lines represents acceptable
values for HTand VT
90°
90°
90°
05
(1.5) 10 (3.1) 15 (4.6) 20 (6.1)
40 (12.2)
10 (3.1)
20 (6.1)
30 (9.1)
3 (0.9)
V3
18.1A

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
17
EN
(HT) > (VT)
Simple venting configurations. See graph to determine the required vertical rise VTfor the
required horizontal run HT.
REQUIRED
VERTICAL
RISE IN FEET
(METERS) VT
HORIZONTAL VENT RUN PLUS OFFSET IN FEET (METERS) HT
For vent configurations requiring more than two 90° elbows the following formulas apply:
Formula 1: HT< 3VT
Formula 2: HT+ VT< 40 feet (12.2m)
Example:
V1= 2 FT (0.6m)
V2= 1 FT (0.3m)
V3= 1.5 FT (0.5m)
VT=V1+V2+V3= 2FT (0.6m) + 1FT (0.3m) + 1.5FT (0.5m) = 4.5FT (1.4m)
H1= 6 FT (1.8m)
H2= 2 FT (0.6m)
HR=H1+ H2= 6FT (1.8m) + 2FT (0.6m) = 8 FT (2.4m)
HO= .03 (four 90° elbows - 90°)
= .03 (360° - 90°) = 8.1 FT (2.5m)
HT=HR+ HO= 8FT (2.4m) + 8.1FT (2.5m) = 16.1FT (4.9m)
HT+ VT= 16.1FT (4.9m) + 4.5FT (1.4m) = 20.6 FT (6.3m)
Formula 1: HT< 3VT
3VT= 3FT (0.9m) x 4.5FT (1.4m) = 13.5FT (4.1m)
16.1FT (4.9m) > 13.5FT (4.1m)
Since this formula is not met, this vent configuration is unacceptable.
Formula 2: HT+ VT< 40 feet (12.2m)
20.6FT (6.3m) < 40 (12.2m)
Since only formula 2 is met, this vent configuration is unacceptable and a new appliance location or vent configuration will
need to be established to satisfy both formulas.
The shaded area within the lines represents acceptable
values for HTand VT
05
(1.5) 10 (3.1) 15 (4.6) 20 (6.1)
10 (3.1)
20 (6.1)
3 (0.9)
25
(7.6) 30 (9.1)
19 (5.8)
90°
V1V2
H1
H2
90°
90°
90°
V3
18.1_2B
05
(1.5) 10 (3.1) 15 (4.6) 20 (6.1)
10 (3.1)
20 (6.1)
3 (0.9)
25
(7.6) 30 (9.1)
19 (5.8)
3
(0.9)

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
18
EN
4.0 INSTALLATION
4.1 WALL AND CEILING PROTECTION
Horizontal runs may have a 0" (0mm) rise per foot in all cases using Wolf Steel, Simpson Dura-Vent, Selkirk
Direct Temp or American Metal Amerivent rigid vent components and Wolf Steel Àexible vent components. For
optimum performance it is recommended that all horizontal runs have a minimum 1/4" (6.3mm) rise per foot
using Àexible or rigid venting. For safe and proper operation of the appliance, follow the venting instructions
exactly.
!
WARNING
ENSURE TO UNPACK ALL LOOSE MATERIALS FROM INSIDE THE FIREBOX PRIOR TO HOOKING UP
THE GAS AND ELECTRICAL SUPPLY.
IF YOUR APPLIANCE IS SUPPLIED WITH A REMOTE ENSURE THE REMOTE RECEIVER IS IN THE
“OFF” POSITION PRIOR TO HOOKING UP THE GAS AND ELECTRICAL SUPPLY TO THE APPLIANCE.
FOR SAFE AND PROPER OPERATION OF THE APPLIANCE, FOLLOW THE VENTING INSTRUCTIONS
EXACTLY.
ALL INNER EXHAUST AND OUTER INTAKE VENT PIPE JOINTS MAY BE SEALED USING EITHER RED
RTV HIGH TEMP SILICONE SEALANT W573-0002 (NOT SUPPLIED) OR BLACK HIGH TEMP MILL PAC
W573-0007 (NOT SUPPLIED) WITH THE EXCEPTION OF THE APPLIANCE EXHAUST FLUE COLLAR
WHICH MUST BE SEALED USING MILL PAC.
IF USING PIPE CLAMPS TO CONNECT VENT COMPONENTS, 3 SCREWS MUST ALSO BE USED TO
ENSURE THE CONNECTION CANNOT SLIP OFF.
DO NOT CLAMP THE FLEXIBLE VENT PIPE.
RISK OF FIRE, EXPLOSION OR ASPHYXIATION. IMPROPER SUPPORT OF THE ENTIRE VENTING
SYSTEM MAY ALLOW VENT TO SAG AND SEPARATE. USE VENT RUN SUPPORTS AND CONNECT
VENT SECTIONS PER INSTALLATION INSTRUCTIONS.
RISK OF FIRE, DO NOT ALLOW LOOSE MATERIALS OR INSULATION TO TOUCH THE VENT PIPE.
REMOVE INSULATION TO ALLOW FOR THE INSTALLATION OF THE ATTIC SHIELD AND TO
MAINTAIN CLEARANCES TO COMBUSTIBLES.
68.2B
!
WARNING
DO NOT FILL THE SPACE BETWEEN THE VENT PIPE AND ENCLOSURE WITH ANY TYPE OF
MATERIAL. DO NOT PACK INSULATION OR COMBUSTIBLES BETWEEN CEILING FIRESTOPS.
ALWAYS MAINTAIN SPECIFIED CLEARANCES AROUND VENTING AND FIRESTOP SYSTEMS.
INSTALL WALL SHIELDS AND FIRESTOPS AS SPECIFIED. FAILURE TO KEEP INSULATION OR
OTHER MATERIALS AWAY FROM VENT PIPE MAY CAUSE FIRE.
70.1

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
19
EN
This application occurs when venting through an exterior wall.
Having determined the correct height for the air terminal
location, cut and frame a hole in the exterior wall as
illustrated to accommodate the ¿restop assembly.
Dry ¿t the ¿restop assembly before proceeding to
ensure the brackets on the rear surface ¿t to the
inside surface of the horizontal framing.
The length of the vent shield may be cut shorter
for combustible walls that are less than 8 1/2”
(215.9mm) thick but the vent shield must extend
the full depth of the combustible wall.
A. Apply a bead of caulking (not supplied) around the corner edge of
the inside surface of the ¿restop assembly, ¿t the ¿restop
assembly to the hole and secure using the 4 screws (supplied in your
manual baggie).
B. Once the vent pipe is installed in its ¿nal position, apply high temperature sealant W573-0007 (not
supplied) between the pipe and the ¿restop.
DETERMINE
THE
CORRECT
HEIGHT
CAULKING
FIRESTOP
SPACER
VENT
SHIELD
FINISHING
MATERIAL
20.2A
!
WARNING
THE FIRESTOP ASSEMBLY MUST BE INSTALLED WITH THE VENT SHIELD TO THE TOP.
TERMINALS MUST NOT BE RECESSED INTO A WALL OR SIDING MORE THAN THE DEPTH OF THE
RETURN FLANGE OF THE MOUNTING PLATE.
4.1.1 HORIZONTAL INSTALLATION
4.1.2 VERTICAL INSTALLATION
This application occurs when venting through a roof. Installation kits for
various roof pitches are available from your authorized dealer / distributor. See
accessories to order speci¿c kits required.
A. Determine the air terminal location, cut and frame a square opening as
illustrated in the ceiling and the roof to provide the minimum 1“ (25mm)
clearance between the vent pipe and any combustible material. Try to center
the vent pipe location midway between two joists to prevent having to cut
them. Use a plumb bob to line up the center of the openings.Avent pipe
shield will prevent any materials such as insulation, from ¿lling up the 1”
(25mm) air space around the pipe. Nail headers between the joist for
extra support.
B. Apply a bead of caulking (not supplied) to the framework or to the Wolf
Steel vent pipe shield plate or equivalent (in the case of a ¿nished ceiling),
and secure over the opening in the ceiling.A¿restop must be placed on the
bottom of each framed opening in a roof or ceiling that the venting system passes
through.Apply a bead of caulking all around and place a ¿restop spacer over
the vent shield to restrict cold air from being drawn into the room or around the
¿replace. Ensure that both spacer and shield maintain the required clearance to
combustibles. Once the vent pipe is installed in its ¿nal position, apply sealant between the
pipe and the ¿restop assembly.
C. In the attic, slide the vent pipe collar down to cover up the open end of the shield and
tighten. This will prevent any materials, such as insulation, from ¿lling up the 1” (25mm) air
space around the pipe. 21.1
CAULKING
VENT PIPE
SHIELD
FIRESTOP
UNDERSIDE OF
JOIST
VENT
PIPE
COLLAR
VENT
PIPE
SHIELD

tϰϭϱͲϭϰϬϳϬϴϮϵϭϴ
20
EN
4.2 USING FLEXIBLE VENTING COMPONENTS
For safe and proper operation of the appliance, follow the venting
instructions exactly.
All inner Àex pipe and outer Àex pipe joints may be sealed using high
temperature sealant W573-0002 (not supplied) or the high temperature
sealant W573-0007 Mill Pac (not supplied). However, the high temperature
sealant W573-0007 Mill Pac (not supplied) must be used on the joint
connecting the inner Àex pipe and the exhaust Àue collar.
Use only approved flexible vent pipe kits marked:
“Wolf Steel Approved Venting” as identified
by the stamp only on the outer flex pipe.
22.1
ELBOW
SPACERS
DO NOT ALLOW THE INNER FLEX PIPE TO BUNCH UP ON HORIZONTAL OR VERTICAL RUNS AND ELBOWS.
KEEP IT PULLED TIGHT.
SPACERS ARE ATTACHED TO THE INNER FLEX PIPE AT PREDETERMINED INTERVALS TO MAINTAIN AN EVEN
AIR GAP TO THE OUTER FLEX PIPE. THIS GAP IS REQUIRED FOR SAFE OPERATION. A SPACER IS REQUIRED
AT THE START, MIDDLE AND END OF EACH ELBOW TO ENSURE THIS GAP IS MAINTAINED. THESE SPACERS
MUST NOT BE REMOVED.
!
WARNING
4.2.1 HORIZONTAL AIR TERMINAL INSTALLATION
A. Stretch the inner Àex pipe to the required
length needed for the ¿nished wall surface.
Apply a heavy bead of high temperature
sealant W573-0007 Mill Pac (not supplied) to
the inner sleeve of the air terminal. Slip the
vent pipe a minimum of 2” (50.8mm) over the
inner sleeve of the air terminal and secure
with 3 #8 screws.
B. Using the outer Àex pipe, slide over the outer
combustion air sleeve of the air terminal
and secure with 3 #8 screws. Seal using
high temperature sealant W573-0002 (not
supplied).
C. Insert the vent pipes through the ¿restop
maintaining the required clearance to
combustibles. Holding the air terminal (lettering
in an upright, readable position), secure to the
exterior wall and make weather tight by sealing
with caulking (not supplied).
D. If more vent pipe needs to be used to
reach the ¿replace, couple them together
as illustrated. The vent system must be
supported approximately every 3 feet (0.9mm)
for both vertical and horizontal runs. Use
noncombustible strapping to maintain the
minimum 1” (25.4mm) clearance to combustibles.
The air terminal mounting plate may be recessed into the exterior wall or siding no greater than the depth
of its return flange. 23.3B
HI-TEMP
SEALANT
#8 X 1/2” SELF DRILLING
SCREWS
INNER COUPLER
OUTER COUPLER
OUTER
FLEX PIPE INNER
FLEX PIPE
OUTER
FLEX PIPE
CAULKING
SCREWS
#10x2" PIPE
OUTER FLEX
SEALANT
2" (50.8mm) OVERLAP
HI-TEMP
INNER FLEX
PIPE
