Napoleon XIR4-1N User manual

EN
W415-1194 / 03.04.13
FR
PG
37
$10.00
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.napoleonfireplaces.com • [email protected]
1.36B
CERTIFIED FOR CANADAAND UNITED STATES USING ANSI/CSAMETHODS.
SAFETY INFORMATION
!WARNING
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by a
qualified installer, service agency or the supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
WARNING
CERTIFIED
CERTIFIED UNDER CANADIANAND AMERICAN NATIONAL STANDARDS: CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS.
XIR4-1N
NATURAL GAS
XIR4-1P
PROPANE

TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 MINIMUM CLEARANCE TO COMBUSTIBLES 5
2.3 GENERAL INSTRUCTIONS 5
2.4 GENERAL INFORMATION 6
2.5 RATING PLATE INFORMATION 7
3.0 INSTALLATION 8
3.1 LEVELLING THE APPLIANCE 8
3.2 CHIMNEY CONNECTION 9
3.3 GAS INSTALLATION 10
4.0 FINISHING 11
4.1 MINIMUM MANTEL CLEARANCES 11
4.2 DOOR REMOVALAND INSTALLATION 12
4.3 LOG PLACEMENT 13
4.4 BATTERY INSTALLATION 14
4.5 OPTIONAL ROCK PLACEMENT 15
4.6 GLOWING EMBERS 15
4.7 LOGO PLACEMENT 15
5.0 ELECTRICAL INFORMATION 16
5.1 WIRING DIAGRAM 16
6.0 OPERATION 17
6.1 OPERATING AND LIGHTING INSTRUCTIONS 17
6.2 GENERAL TRANSMITTER LAYOUT 18
6.3 APPLIANCE OPERATION 18
6.4 HAND HELD REMOTE OPERATIONS 18
6.5 TEMPERATURE DISPLAY 19
6.6 ROOM THERMOSTAT 19
6.7 SMART THERMOSTAT 19
6.8 FLAME HEIGHT 20
6.9 CHILD PROOF FUNCTION 20
6.10 NIGHT LIGHT 20
6.11 LOW BATTERY / MANUALBYPASS 21
6.12 IN THE EVENT OFA POWER FAILURE 21
6.13 CONTROL MODULE 21
6.14 SPLIT FLOW VALVE 21
6.15 ANTI CONDENSATION CONTROL SWITCH (OPTIONAL) 22
6.16 TIMED BLOWER 22
7.0 ADJUSTMENTS 22
7.1 PILOT BURNER ADJUSTMENT 22
7.2 VENTURI ADJUSTMENT 23
7.3 FLAME CHARACTERISTICS 23
8.0 MAINTENANCE 24
8.1 CARE OF GLASS 24
8.2 CARE OF PLATED PARTS 24
8.3 DOOR GLASS REPLACEMENT 25
8.4 BURNER REMOVAL 26
8.5 FCM REPLACEMENT 26
8.6 NIGHT LIGHT™ REPLACEMENT 27
8.7 VALVE TRAIN REPLACEMENT 27
9.0 REPLACEMENTS 28
10.0 TROUBLESHOOTING 32
11.0 WARRANTY 35
12.0 SERVICE HISTORY 36
W415-1194 / 03.04.13
2
EN
NOTE: changes, other than editorial, are denoted by a vertical line in the margin.

W415-1194 / 03.04.13
3
EN
1.0 INSTALLATION OVERVIEW
Venting, see “INSTALLATION
- CHIMNEY CONNECTION”
section.
Rating Plate, see “RATING
PLATE INFORMATION”
section.
Logs, see “FINISHING - LOG
PLACEMENT” section.

W415-1194 / 03.04.13
4
EN
2.0 INTRODUCTION
3.2B
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS
AND IS PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate
appliance according to operating instructions could cause fire or injury.
• Risk of fire or asphyxiation do not operate appliance with fixed glass removed.
• Do not connect 110 volts to the control valve.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges
may be sharp.
• Do not burn wood or other materials in this appliance.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to
avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance. Toddlers,
young children and others may be susceptible to accidental contact burns. A physical barrier is recommended
if there are at risk individuals in the house. To restrict access to an appliance, install an adjustable safety gate
to keep toddlers, young children and other at risk individuals out of the room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot
surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
• The appliance is a vented gas-fired appliance. Do not burn wood or other materials in the appliance
• It is imperative that the control compartments, burners and circulating blower and its passageway in the
appliance and venting system are kept clean. The appliance and its venting system should be inspected
before use and at least annually by a qualified service person. More frequent cleaning may be required due
to excessive lint from carpeting, bedding material, etc. The appliance area must be kept clear and free from
combustible materials, gasoline and other flammable vapors and liquids.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this appliance if any part has been under water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the control system and any gas control which has been under
water.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass
should be done by a licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• When equipped with pressure relief doors, they must be kept closed while the appliance is operating to
prevent exhaust fumes containing carbon monoxide, from entering into the home. Temperatures of the exhaust
escaping through these openings can also cause the surrounding combustible materials to overheat and catch
fire.
• Only doors / optional fronts certified with the appliance are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all
plastic bags, these are not toys and should be kept away from children and infants.
• As with any combustion appliance, we recommend having your appliance regularly inspected and serviced as
well as having a Carbon Monoxide Detector installed in the same area to defend you and your family against
Carbon Monoxide.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance.
Elevated temperatures on the wall or in the air above the appliance can cause melting, discolouration or
damage of decorations, a T.V. or other electronic components.

W415-1194 / 03.04.13
5
EN
2.1 DIMENSIONS
THIS GAS APPLIANCE SHOULD BE INSTALLED AND SERVICED BY A QUALIFIED INSTALLER to
conform with local codes. Installation practices vary from region to region and it is important to know the
specifics that apply to your area, for example in Massachusetts State:
• This product must be installed by a licensed plumber or gas fitter when installed within the commonwealth
of Massachusetts.
• The appliance damper must be removed or welded in the open position prior to installation of a appliance
insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches (914.4mm).
• ACarbon Monoxide detector is required in all rooms containing gas fired appliances.
• The appliance is not approved for installation in a bedroom or bathroom unless the unit is a direct vent
sealed combustion product.
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT,
WITH THE GLASS DOOR OPENED OR REMOVED.
PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE.
PROVIDE ADEQUATE VENTILATION.
NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.
OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48” (1219.2mm)
FROM THE FRONT FACE OF THE APPLIANCE.
SURFACES AROUND AND ESPECIALLY ABOVE THE APPLIANCE CAN BECOME HOT. AVOID CONTACT
WHEN THE APPLIANCE IS OPERATING.
FIRE RISK. EXPLOSION HAZARD.
HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE PRESSURE TESTING GAS
LINE AT TEST PRESSURES ABOVE 1/2 PSIG. CLOSE THE MANUAL SHUT-OFF VALVE BEFORE PRESSURE
TESTING GAS LINE AT TEST PRESSURES EQUAL TO OR LESS THAN 1/2 PSIG (35 mb).
USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE.
USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENTING
COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION.
!
WARNING
Thisappliance mustbe recessed into a vented noncombustible wood-burning appliance (prefabricated or masonry)
only. The minimum appliance opening size in which the appliance is to be installed is:
HEIGHT 25" (635mm) WIDTH 34.25" (870mm) DEPTH 17" (431.8mm)
The minimum allowable chimney flue size is 7" (177.8mm) round.
The minimum distance, from the bottom of a combustible mantel projecting 3" (76.2mm) maximum from the
wall to the top of the appliance, is 14" (355.6mm) (see "MINIMUM MANTEL CLEARANCES" section).
2.2 MINIMUM CLEARANCE TO COMBUSTIBLES
2.3 GENERAL INSTRUCTIONS
335/8” (854.1mm)
343/4” (882.7mm)
251/4” (641.4mm)
165/8”
(422.3mm)
121/2”
(317.5mm)
213/8”
(542.9mm)
11
1/2
”
(292.1mm)
11”
(279.4mm)
241/4”
(616mm)
241/2”
(622.3mm)
16
5/8
”
(422.3mm)

W415-1194 / 03.04.13
6
EN
2.4 GENERAL INFORMATION
4.12A
sealed combustion product.
The installation must conform with local codes or, in
absence of local codes, the National Gas and Propane
Installation Code CSA B149.1 in Canada, or the National
Fuel Gas Code, ANSI Z223.1 / NFPA 54 in the United
States. Suitable for mobile home installation if installed in
accordance with the current standard CAN/CSA Z240MH
Series, for gas equipped mobile homes, in Canada or
ANSI Z223.1 and NFPA 54 in the United States.
Some appliances have optional fans or blowers. If an optional fan or blower is installed, the junction box must
be electrically connected and grounded in accordance with local codes, use the current CSA C22.1 Canadian
Electrical Code in Canada or the ANSI/NFPA 70 National Electrical code in the United States.
We suggest that our gas
hearth products be installed
and serviced by professionals
who are certied in the U.S.
by the National Fireplace
Institute
® (NFI) as NFI Gas
Specialists
www.ncertied.org
FOR YOUR SATISFACTION, THIS APPLIANCE HAS BEEN TEST-FIRED TOASSURE ITS OPERATION AND
QUALITY!
XIR4-1
NG LP
Altitude (FT) 0-4,500 0-4,500
Max. Input (BTU/HR) 40,000 40,000
Max. Output (BTU/HR) 33,200 33,200
Efficiency (w/the fan on) 83% 83%
A.F.U.E. (maximum value) 79% 79%
Min. Inlet Gas Supply Pressure 4.5" Water Column
(11.2mb) 11" Water Column (27.4mb)
Max. Inlet Gas Supply Pressure 7" Water Column
(17.4mb) 13" Water Column (32.4mb)
Manifold Pressure (Under Flow Conditions) 3.5" Water Column
(8.7mb) 10" Water Column (24.9mb)

W415-1194 / 03.04.13
7
EN
When the appliance is installed at elevations above 4,500ft (1371.6m), and in the absence of specific
recommendations from the local authority having jurisdiction, the certified high altitude input rating shall be
reduced at the rate of 4% for each additional 1,000ft (304.8m). Expansion / contraction noises during heating
up and cooling down cycles are normal and to be expected.
This appliance is not approved for closet or recessed installations. It is approved for bathroom, bedroom and
bed-sitting room installations and is suitable for mobile homes. The natural gas model is suitable for installation
in a mobile home that is permanently positioned on its site and fuelled with natural gas.
2.5 RATING PLATE INFORMATION
INSTALLER: It is your responsibility to check off the appropriate box on the rating plate according to
the model, venting and gas type of the appliance.
For rating plate location, see “INSTALLATION OVERVIEW” section.
This illustration is for reference only. Refer to the rating plate on the appliance for accurate information.
SERIAL NUMBER/NO. DE SERIE: XIR4/CXIR4
WARNING: DO NOTADDANY MATERIAL TOTHE APPLIANCE THAT WILLCOME IN
CONTACT WITHTHE FLAMES, OTHER THAN THAT SUPPLIED BY THE MANUFACTURER
WITH THE APPLIANCE.
AVERTISSEMENT: N'A JOUTEZ PASA CET APPAREIL AUCUN MATERIAU DEVANT
ENTRER ENCONTACTAVECLES FLAMMESAUTRE QUECELUI QUIEST FOURNIAVECCET
APPAREIL PAR LE FABRICANT.
W385-0662
CERTIFIED FOR
CERTIFIEE POUR CANADA USA
XIR4N XIR4PCXIR4N CXIR4P
MODEL
CERTIFIED
REFERENCE #161746
Natural Gas/Gaz Naturel Propane
CE FOYER À GAZ VENTILÉS NE DOIT PAS ÊTRE UTILISÉ
CONJOINTEMENT AVEC DES FILTRES À AIR. UTILISER AVEC LES
PORTES VITRÉES HOMOLOGUÉES AVEC CETTE UNITÉ SEULE-
MENT. UN COMBUSTIBLE SOLIDE NE DOIT PAS ETRE UTILISE
AVEC CET APPAREIL.
CERTIFIED UNDER / HOMOLOGUÉ SELON LES NORMES: ANSI Z21.88b-2009, CSA2.22b-2009 VENTED GAS FIREPLACE / APPAREIL À GAZVENTILÉS.
WOLF STEEL LTD.
24 NAPOLEON ROAD, BARRIE. ONTARIO L4M 4Y8 CANADA
ELECTRICAL RATING: 115V 1.5AMP 60HZ
THE APPLIANCE MUSTBE VENTED USING THEAPPROPRIATE WOLF STEELVENT KITS. SEE
OWNER’S INSTALLATION MANUAL FOR VENTING SPECIFICS. PROPER REINSTALLATIONAND
RESEALING IS NECESSARYAFTER SERVICING THE VENT-AIR INTAKE SYSTEM.
WARNING: FOR INSTALLATION INTO AVENTED NON-COMBUSTIBLE FIREPLACE ONLY. THE
MINIMUM FIREPLACE SIZE IS: HEIGHT 24 1/2”, DEPTH 17”, WIDTH 34”. THE MINIMUM INSIDE
FLUE SIZE IS 6”. THE MINIMUM DISTANCE FROM THE BOTTOM OF ACOMBUSTIBLE MANTEL
PROJECTING AMAXIMUM 3” FROM THE WALLTO THE TOP OF THE UNIT IS 12”. SEE OWNER’S
MANUAL FOR GREATER EXTENSIONS.
OPTIONAL FAN KIT - GZ550-KT, GD65.
CLASS : 115V, 1.5AMP, 60HZ
L’APPAREIL DOIT EVACUER SES GAZ EN UTILISANT L’ENSEMBLE D’EVACUATION PROPRE A WOLF STEEL. REFERER
AU MANUEL D’INSTALLATION DE PROPRIETAIRE POUR L’EVACUATION PRECISE. IL EST IMPORTANT DE BIEN
REINSTALLER ET RESCELLER L’EVENT APRES AVOIR ASSURE LE MAINTIEN DU SYSTEME DE PRISE D’AIR.
ATTENTION : POUR INSTALLATION DANS UN FOYER VENTILE EN MACONNERIE. LES DIMENSIONS MINIMUMS SONT:
HAUTER 24
1/2
”, PROFONDEUR 17”, LARGEUR 34”. LE DIAMETRE INTERIEUR MINIMUM DE CONDUIT D’EVACUATION
EST DE 6”. LA DISTANCE MINIMALE, DU BAS DU MANTEAU COMBUSTIBLE FORMANT UNE PROJECTION MAXIMALE DE
3” DU MUR AU DESSUS DE LA GARNITURE NORMALE EST 12”. REFERER AU MANUEL D’INSTALLATION POUR DES
EXTENSIONS PLUS GRANDES.
SOUFFLERIE OPTIONELLE
GZ550-KT, GD65.
4500FT (0-1370m) ALTITUDE/ELEVATION 4500FT (0-1370m)
40,000 BTU/h INPUT/ALIMENTATION 40,000 BTU/h
16,000 BTU/h REDUCED INPUT/ALIMENTATION REDUITE 15,000 BTU/h
MANIFOLD PRESSURE: 3.5” WATER COLUMN
PRESSION AU COLLECTEUR: 3.5” D’UNE COLONNE D’EAU
MINIMUM SUPPLY PRESSURE: 4.5” WATER COLUMN
PRESSION D’ALIMENTATION MINIMALE: 4.5” D’UNE COLONNE D’EAU
MAXIMUM SUPPLY PRESSURE: 7.0” WATER COLUMN
PERSSION D’ALIMENTATION MAXIMALE: 7.0” D’UNE COLONNE D’EAU
AFUE: 72.4%
MANIFOLD PRESSURE: 10” WATER COLUMN
PRESSION AU COLLECTEUR: 10” D’UNE COLONNE D’EAU
MINIMUM SUPPLY PRESSURE: 11” WATER COLUMN
PRESSION D’ALIMENTATION MINIMALE: 11” D’UNE COLONNE D’EAU
MAXIMUM SUPPLY PRESSURE: 13” WATER COLUMN
PERSSION D’ALIMENTATION MAXIMALE: 13” D’UNE COLONNE D’EAU
AFUE: 72.4%
THIS VENTED GAS FIREPLACE HEATER IS NOT FOR USE
WITH AIR FILTERS. FOR USE WITH GLASS DOORS CERTIFIED
FOR THIS UNIT ONLY. NOT FOR USE WITH SOLID FUEL.
NE PAS ALLUMER SI DES ENFANTS OU D’AUTRES INDIVIDUS À RISQUE
SONT À PROXIMITÉ DU FOYER.APPAREIL DE CHAUFFAGE À ÉVACUATION
DIRECTE. HOMOLOGUÉ POUR INSTALLATION DANS UNE CHAMBRE À
COUCHER, UNE SALLE DE BAIN ET UN STUDIO.APPROPRIÉ POUR
INSTALLATION DANS UNE MAISON MOBILE SI SON INSTALLATION EST
CONFORME AUX EXIGENCES DE LA NORME CAN/CSAZ240MH SÉRIE DE
MAISONS MOBILES ÉQUIPÉES AU GAZ, EN VIGUEUR AU CANADA, OUAUX
ÉTATS-UNIS, SELON LANORME DE SÉCURITÉ ET DE CONSTRUCTION DE
MAISONS MANUFACTURÉES, TITRE 24 CFR, SECTION 3280. DANS LE CAS
OÙ CETTE NORME DES ÉTATS-UNIS NE PEUT ÊTREAPPLIQUÉE, SE
RÉFÉRER À LA NORME RELATIVE AU CRITÈRE DE MESURES DE SÉCURITÉ
CONTRE L'INCENDIE POUR LES INSTALLATIONS DANS LES MAISONS
MANUFACTURÉES, LES SITES ET LES COMMUNAUTÉS,ANSI/NFPA 501A.
DO NOT TURN ON IF CHILDREN OR OTHERAT RISK INDIVIDUALS
ARE NEAR THE FIREPLACE. DIRECT VENT GAS FIREPLACE
HEATER. SUITABLE FOR BEDROOM, BATHROOM AND BED-SITTING
ROOM INSTALLATION. SUITABLE FOR MOBILE HOME INSTALLATION
IF INSTALLED IN ACCORDANCE WITH THE CURRENT STANDARD
CAN/CSA Z240MH SERIES GAS EQUIPPED MOBILE HOMES, IN
CANADA OR IN THE UNITED STATES THE MANUFACTURED HOME
CONTRUCTION AND SAFETY STANDARD, TITLE 24 CFR, PART 3280.
WHEN THIS US STANDARD IS NOT APPLICABLE USETHE
STANDARD FOR FIRE SAFETY CRITERIA FOR MANUFACTURED
HOME INSTALLATIONS, SITESAND COMMUNITIES,ANSI / NFPA
501A.
SAMPLE
APPLIANCEAPPLIANC
THA
T
WI
LL
LL
CO
M
ECOME
I
NIN
TT
SUPPLIED BSUPPLIED B
Y
Y
THE MAN
UTHE MANU
FF
ACTURERACTURE
FFF
PL
X
IR
4
P
XIR4P
ELEL
S
ProPr
CE FOYCE F
CONCON
P
C
RIE. ONTA
RIE. ONTA
HE APPROPRIATE WOLF STEEL VENT KPRIATE WOLF STEEL VENT K
ENTING SPECIFICS. PROPER REINSTALLICS. PROPER REINSTAL
RVICING THE VENT-AIR INTAKE SYSTEMVICING THE VENT-AIR INTAKE SY
A VENTED NON-COMBUSTIBLE FIREPLAA VENTED NON-COMBUSTIBLE F
GHT 24GHT 24
11
//
22
”, DEPTH 17”, WIDTH 34”. THE M”, DEPTH 17”, WIDTH 34”. T
DISTANCE FROM THE BOTTOM OF ACO
ISTANCE FROM THE BOTTOM OF ACO
FROM THE WALL TO THE TOP OF THE UN
OM THE WALL TO THE TOP OF THE U
TENSIONS.
SIONS.
T, GD65.
GD65.
ELEVATIONLEVATION
45004500
MENTATIONMENTATIO
/ALIMENTATION REDUITEALIMENTATION REDUI
LUMN
E D’EAUE D’EA
R COLUMNR COLUMN
LONNE D’EAUONNE D’EAU
WATER COLUMNR COLUMN
E COLONNE D’EAUCOLONNE D’EAU
AFUE
:AFUE:
72.4
%72.4%
M
ANIFOLD PRESSURE
:MANIFOLD P
10
PRESSION AU COLLECPRESSION
MINIMUM SUPPLY PRMINIMUM SU
PRESSION D’ALIMRESSION D’A
MAXIMUM SUPPIMUM SUP
PERSSION D’PERSSION D
AFUE
:AFUE
72.44
NOT FOR USENOT FOR USE
S DOORS CERTIFIEDOORS CERTIFIED
WITH SOLID FUEL.D FUEL.
SI DESDES
TÉ DU FOYTÉ DU FO
MOLOGUÉ POUROLOGUÉ POU
UNE SALLE DE BAIN EUNE SALLE DE BAIN
TION DANS UNE MAISONTION DANS UNE MAISO
RME AUX EXIGENCES DE LA NRME AUX EXIGENCES DE LA N
SONS MOBILES ÉQUIPÉES AU GAZ,
S MOBILES ÉQUIPÉES AU GAZ,
TATS-UNIS, SELON LANORME DE SÉCS, SELON LA NORME DE SÉC
MAISONS MANUFACTURÉES, TITRE 2NUFACTURÉES, TITRE 2
OÙ CETTE NORME DES ÉTATS-UNIME DES ÉTATS-UN
RÉFÉRER À LA NORME RELATIVRME RELATIV
CONTRE L'INCENDIE POUR LECONTRE L'INCENDIE POUR L
MANUFACTURÉES, LES SITMANUFACTURÉES, LES SIT
68.9%
XIR4-1

W415-1194 / 03.04.13
8
EN
3.0 INSTALLATION
3.1 LEVELLING THE APPLIANCE
68.4B
Clean out ashes from the inside of the wood-burning appliance. Make sure that the chimney and wood-burning
appliance are in a clean and sound condition and constructed of non-combustible materials. If necessary have
any repair work done by a qualified person before installing the insert. Remove the existing appliance damper
or lock into an open position.
Using screws, attach the appliance warning tag
to the inside of the firebox of the appliance into
which the insert is being installed.
The sheet-metal parts of the appliance, in which
the gas appliance insert is to be installed, must
not be cut.
If the wood-burning factory-built appliance has
no gas access hole(s) provided, an access hole of 1½ inch (38.1mm) or less may be drilled through the lower
sides or bottom of the appliance in a proper workman like manner. This access hole must be plugged with non
-
combustible insulation after the gas supply line has been installed.
Ensure that existing chimney cleanouts fit properly.
The refractory, glass doors, screen rails, screen mesh and log grates may be removed from the existing
appliance before installing the gas appliance insert.
Smoke shelves, shields and baffles may be removed if attached by mechanical fasteners.
The ventilation openings in the existing appliance may be obstructed by the backer plates, aluminium trim etc.
but these parts are not to be applied so as to have an airtight seal.
!
WARNING
RISK OF FIRE, MAINTAIN SPECIFIED AIR SPACE CLEARANCES TO VENT PIPE AND APPLIANCE.
W385-0199_B
WARNING: THIS FIREPLACE HAS BEEN CONVERTED FOR USE WITHA GAS FIREPLACE
INSERT ONLYAND CANNOT BE USED FOR BURNING WOOD OR SOLID FUELS UNLESSALL ORIGINAL
PARTS HAVE BEEN REPLACED ANDTHE FIREPLACE IS RE-APPROVED BY THEAUTHORITY HAVING
JURISDICTION.
ATTENTION: CE FOYER AETE CONVERTIAFIN D’ETRE UTILISE SEULEMENT
COMME FOYER ENCASTRE AU GAZ ET NE PEUT ETRE UTILSE POUR BRULER DU BOIS OU
TOUTAUTRE COMBUSTIBLE SOLIDE, SANS QUE TOUTES LES PIECES ORIGINALESAIENT
ETE REMPLACEES ET QUE LE FOYER SOITAPPROUVE DE NOUVEAU PAR LES AUTORITES
AYANT JURIDICTION.
ADVERTENCIA: ESTA CHIMENEASE REMODELÓ PARA USARSE SOLO CON UNA
INSERCIÓN DE CHIMENEAA GAS Y NO PUEDE USARSE PARA QUEMAR MADERANI COMBUSTIBLES
SÓLIDOS, A MENOS QUE SE HAYAN REEMPLAZADO TODAS LAS PIEZAS ORIGINALES, Y LAAUTORI-
DAD JURISDICCIONAL LA HAYA VUELTO A APROBAR.
Move the appliance close to its final position. This appliance is equipped with levelling screws located on the
base. Level using the levelling screws. Levelling the appliance will eliminate rocking or excessive noise when
the fan is in operation. Once the appliance is level, move it partially into place to allow for all connections to be
made. It is not practical to level the appliance once it has been installed. Determine the required depth prior to
installing the appliance and adjust the levelling screws accordingly. 67.2

W415-1194 / 03.04.13
9
EN
While the liners must be continuous from the appliance to the chimney cap, to
achieve the needed length, they may be coupled, using an approved coupler
and sealant.
We recommend that exhaust vents that pass through unheated spaces,
such as tall exterior chimneys, be wrapped in a protective sleeve to minimize
condensation and reverse flow symptoms. See Trouble Shooting for details.
This appliance is approved for use with a 3" (76.2mm) exhaust and air intake.
A. OUTSIDE: Slip the one end of a liner a minimum of 2" (50.8mm)
over the sleeve of the air terminal. Secure using 3 screws. Then
seal the joint and screw heads with high temperature sealant. Repeat with the other liner.
NOTE: We recommend that the other end of the exhaust liner be marked to eliminate the
exhaust liner being connected to the intake collar at the appliance.
B. Gently stretch the liners to the
required lengths and insert into
the chimney. Trim and fit the
flashing plate to suit the chimney
termination. Place the air terminal
onto the top of the chimney.
Make weather tight by sealing
with caulking (not supplied).
Fasten to the chimney with
screws and plugs (not supplied).
C. INSIDE: Remove the securing
screw from the front of the vent
mounting plate. Pull the vent
mounting plate only, back into
the track, to the front stop. Start
the slider back into position. Re-
secure the screw. The appliance
may now be pushed into its
final position inside the wood
burning appliance, and the screw
tightened until the slider has
been pulled tight to the front stop.
D. Route the flex liners through
the slider. Attach and secure
the liners to the vent mounting plate using the same procedure as before, ensuring that the marked
exhaust liner is attached to the exhaust collar.
FLASHING
PLATE
2” (50.8mm)
OVERLAP
SEALANT
HI-TEMP
INTAKE
EXHAUST
SECURING
SCREW
SLIDER
MOUNTING
PLATE
HIGH TEMP
SEALANT
2” (50.8mm)
OVERLAP
3” (76.2mm)
LINERS
EXHAUST
INTAKE
VENT MOUNT
ASSEMBLY
3.2 CHIMNEY CONNECTION
Chimney installation must conform to both national and local code requirements. The chimney must be lined
with one 3" (76.2mm) diameter liner for intake and one 3" (76.2mm) diameter liner for exhaust. The minimum
and maximum vent lengths are 10 feet (3.1m) and 35 feet (10.7m) respectively.
Recommended kits come in 3 lengths:
2-3" DOUBLE PLY ALUMINUM LINER-INLET AND EXHAUST:
GDI-320KT VENT KIT 20FT (6.1m)
GDI-325KT VENT KIT 25 FT (7.6m)
GDI-335KT VENT KIT 35 FT (10.7m)

W415-1194 / 03.04.13
10
EN
3.3 GAS INSTALLATION
30.1
Installation and servicing to be done by a qualified installer. Do not use open flame.
• Move the appliance into position and secure.
• If equipped with a flex connector the appliance is designed to accept a 1/2” gas supply. Without the
connector it is designed to accept a 3/8” gas supply. The appliance is equipped with a manual shut off
valve to turn off the gas supply to the appliance.
• Connect the gas supply in accordance to local codes. In the absence of local codes, install to the
current CAN/CSA-B149.1 Installation Code in Canada or to the current National Fuel Gas Code, ANSI
Z223.1 / NFPA 54 in the United States.
• When flexing any gas line, support the gas valve so that the lines are not bent or kinked.
• Check for gas leaks by brushing on a soap and water solution.
!
WARNING
RISK OF FIRE, EXPLOSION OR ASPHYXIATION. ENSURE THERE ARE NO IGNITION SOURCES SUCH AS
SPARKS OR OPEN FLAMES.
SUPPORT GAS CONTROL WHEN ATTACHING GAS SUPPLY PIPE TO PREVENT DAMAGING GAS LINE.
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT
WITH THE GLASS DOOR OPENED OR REMOVED. PURGING OF THE GAS SUPPLY LINE SHOULD BE
PERFORMED BY A QUALIFIED SERVICE TECHNICIAN. ASSURE THAT A CONTINUOUS GAS FLOW IS AT
THE BURNER BEFORE CLOSING THE DOOR. ENSURE ADEQUATE VENTILATION. FOR GAS AND
ELECTRICAL LOCATIONS, SEE “DIMENSION” SECTION.
ALL GAS CONNECTIONS MUST BE CONTAINED WITHIN THE APPLIANCE WHEN COMPLETE.
HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE TESTING GAS
LINE AT TEST PRESSURES ABOVE 1/2 PSIG.
VALVE SETTINGS HAVE BEEN FACTORY SET, DO NOT CHANGE.

W415-1194 / 03.04.13
11
EN
4.0 FINISHING
Combustible mantel clearance can vary according to the mantel depth. Use the graph to help evaluate the
clearance needed. These same requirements apply to any combustibles protruding on either side of the
appliance.
H
DF
G
MANTEL DEPTH
0” (mm)
+
(
,
*
+
7
0
$
1
7
(
/
E
C
B
A
!
WARNING
RISK OF FIRE, MAINTAIN ALL SPECIFIED AIR SPACE CLEARANCES TO COMBUSTIBLES. FAILURE
TO COMPLY WITH THESE INSTRUCTIONS MAY CAUSE A FIRE OR CAUSE THE APPLIANCE TO
OVERHEAT. ENSURE ALL CLEARANCES (I.E. BACK, SIDE, TOP, VENT, MANTEL, FRONT, ETC.) ARE
CLEARLY MAINTAINED.
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE
HEAT RESISTANT TO PREVENT DISCOLOURATION. 73.1
!
WARNING
RISK OF FIRE!
NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.
THE FRONT OF THE APPLIANCE MUST BE FINISHED WITH ANY NON-COMBUSTIBLE MATERIALS
SUCH AS BRICK, MARBLE, GRANITE, ETC., PROVIDED THAT THESE MATERIALS DO NOT GO
BELOW THE SPECIFIED DIMENSION AS ILLUSTRATED.
DO NOT STRIKE, SLAM OR SCRATCH GLASS. DO NOT OPERATE APPLIANCE WITH GLASS
REMOVED, CRACKED, BROKEN OR SCRATCHED.
FACING AND/OR FINISHING MATERIAL MUST NEVER OVERHANG INTO THE APPLIANCE OPENING.
72.1A
4.1 MINIMUM MANTEL CLEARANCES
D
ABC
6” (152.4mm) MANTEL
F
H
G
241/4” (616mm)
MANTEL DIMENSIONS
Ref
A17" (431.8mm)
B16" (406.4mm)
C15" (381mm)
D14" (355.6mm)
E6" (152.4mm)
F5" (127mm)
G4" (101.6mm)
H3" (76.2mm)

W415-1194 / 03.04.13
12
EN
The optional front, if installed, must be
removed to allow the glass door to be
opened or closed.
The glass door is secured to the top front
edge of the firebox with two latches. Pull the
handles of the latches forward, then lift the
latches out from the door frame to release
the top of the door. Next, pivot the door
forward until the top edge clears the front of
the appliance. Carefully grip the sides of the
door lifting it out from the retainer along the
bottom of the door.
NOTE: The protective wrap on plated
parts is best removed when the assembly is at room temperature but this can be improved if the
assembly is warmed, using a hair dryer or similar heat source.
4.2 DOOR REMOVAL AND INSTALLATION
!
WARNING
GLASS MAY BE HOT, DO NOT TOUCH GLASS UNTIL COOLED.
THE DOOR LATCHES ARE PART OF A SAFETY SYSTEM AND MUST BE PROPERLY ENGAGED. DO
NOT OPERATE THE APPLIANCE WITH LATCHES DISENGAGED.
FACING AND/OR FINISHING MATERIALS MUST NOT INTERFERE WITH AIR FLOW THROUGH AIR
OPENINGS, LOUVRES OPENINGS, OPERATION OF LOUVRES OR DOORS OR ACCESS FOR
SERVICE. OBSERVE ALL CLEARANCES WHEN APPLYING COMBUSTIBLE MATERIALS.
BEFORE DOOR IS REMOVED TURN THE APPLIANCE OFF AND WAIT UNTIL APPLIANCE IS COOL TO
THE TOUCH. DOORS ARE HEAVY AND FRAGILE SO HANDLE WITH CARE.
75.1
HANDLES

W415-1194 / 03.04.13
13
EN
4.3 LOG PLACEMENT
!
WARNING
FAILURE TO POSITION THE LOGS IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE
ONLY LOGS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY
DAMAGE OR PERSONAL INJURY.
LOGS MUST BE PLACED IN THEIR EXACT LOCATION IN THE APPLIANCE. DO NOT MODIFY THE
PROPER LOG POSITIONS, SINCE APPLIANCE MAY NOT FUNCTION PROPERLY AND DELAYED
IGNITION MAY OCCUR.
THE LOGS ARE FRAGILE AND SHOULD BE HANDLED WITH CARE.
76.1A
PHAZERTM logs and glowing embers exclusive to Napoleon, provide a unique and realistic glowing effect that is
different in every installation. Take the time to carefully position the glowing embers for a maximum glowing effect.
Log colours may vary. During the initial use of the appliance, the colours will become more uniform as colour
pigments burn in during the heat activated curing process.
PINS
4. Place the centre charcoal
piece* into position, lining up the
hole in the bottom with the stud in
the front centre of the log support.
6. Place the rear log against the
back panel, lining up the holes
with the studs at the back of the
firebox. Locate 3 pins (supplied)
into the top of the log.
5. Place the right front charcoal
piece* into position, lining up the
holes in the bottom with the studs
in the front right corner.
1. Place the right charcoal piece
into position, lining up the holes
in the bottom with the studs in the
right side of the burner.
3. Place the left front charcoal
piece* into position, lining up the
holes in the bottom with the studs
in the left front corner.
2. Place the left charcoal piece
into position, lining up the bottom
holes with the studs to the left side
of the burner.
* These front pieces have a lip to distinguish them from the other charcoal pieces.

W415-1194 / 03.04.13
14
EN PINS
PIN
7. Position the middle log behind
the burner pan, lining up the holes
with the 4 studs, ensuring the log
is flat against the base. Place
2 pins into the left and right top
holes.
8. Position the left crossover log
over the pins in the left side of the
middle and rear logs.
9. Position the middle crossover
log onto the middle pin of the rear
log. Rest the end of the log into
the notch of the middle log.
10. Position the right crossover log
over the pins in the right side of
the middle and rear logs. Place a
pin in the top of the log.
11. Position the small middle
crossover log on the right cross-
over log pin. Resting the other end
on the middle log as shown.
4.4 BATTERY INSTALLATION
4 AA batteries must be installed into the receiver before operation
is possible. The receiver is located in the bottom left corner of the
appliance.
If receiver removal is necessary, remove the left access panel from the front
of the appliance. Remove the 2 screws holding the receiver in place. Pull
the receiver through the access hole and replace.
RECEIVER
RECEIVER PLATE
SCREWS

W415-1194 / 03.04.13
15
EN
Tear the embers into pieces and place along the front row of ports covering all of the burner area in front of
the small logs. Care should be taken to shred the embers into thin, small irregular pieces as only the exposed
edges of the fibre hairs will glow. The ember material will only glow when exposed to direct flame; how-
ever, care should be taken to not block the burner ports.
Blocked burner ports can cause an incorrect flame pattern, carbon deposits and delayed ignition. PHAZERTM
logs glow when exposed to direct flame. Use only certified "glowing embers" and PHAZERTM logs available
from your authorized dealer / distributor.
97.1A
Remove the backing o
f
the logo supplied and place on the glass viewing door,
as indicated. ½"(12.7mm)
LOGO
½"(12.7mm)
Before beginning with the installation, remove the door and all burner media from the appliance including logs
and charcoal strips. Retain the glowing embers.
D. Reinstall the glowing embers over the burner.
E. Reinstall the door.
4.5 OPTIONAL ROCK PLACEMENT
!
WARNING
REAL ROCKS MUST NOT BE USED IN THIS APPLIANCE. HEAT WILL CAUSE THEM TO EXPLODE
A. Sit the four rock clusters on top of the rear log support and behind the front burner pan. Ensure the clusters
are sitting flat.
B. Place the large notched rocks along the step behind the front burner as desired.
C. Place the remaining rocks around the burner as desired making sure not to cover any burner ports
(there are no set locations).
4.6 GLOWING EMBERS
4.7 LOGO PLACEMENT

W415-1194 / 03.04.13
16
EN
5.0 ELECTRICAL INFORMATION
5.1 WIRING DIAGRAM
!
WARNING
DO NOT USE THIS APPLIANCE IF ANY PART HAS BEEN UNDER WATER. CALL A QUALIFIED
SERVICE TECHNICIAN IMMEDIATELY TO HAVE THE APPLIANCE INSPECTED FOR DAMAGE TO THE
ELECTRICAL CIRCUIT.
RISK OF ELECTRICAL SHOCK OR EXPLOSION. DO NOT WIRE 110V TO THE VALVE OR TO THE
APPLIANCE WALL SWITCH. INCORRECT WIRING WILL DAMAGE CONTROLS.
ALL WIRING SHOULD BE DONE BY A QUALIFIED ELECTRICIAN AND SHALL BE IN COMPLIANCE
WITH LOCAL CODES. IN THE ABSENCE OF LOCAL CODES, USE THE CURRENT CSA22.1 CANADIAN
ELECTRIC CODE IN CANADA OR THE CURRENT NATIONAL ELECTRIC CODE ANSI/NFPA NO. 70 IN
THE UNITED STATES.
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT,
WITH THE GLASS DOOR OPENED OR REMOVED.
69.2
Wire Harness Assembly
IPI Board
Pilot
Ground
Wire
EI
Pilot
Spark Electrode Flame
Sensor
Valve
Electronic Modulation
120V OUT FAN AUX OUT
COM
POWER
ACS/IPI Switch
(OPTIONAL)
Receiver
Wire Harness
Control Module
Night Lights
Fan
(OPTIONAL)
Wire
Harness
Plug
This appliance comes equipped with a battery back-up. If this back-up is used, install 4 AA batteries (not
supplied) into the receiver.

W415-1194 / 03.04.13
17
EN
6.0 OPERATION
When lit for the first time, the appliance will emit a slight odour for a few hours. This is a normal temporary con-
dition caused by the "burn-in" of internal paints and lubricants used in the manufacturing process and will not
occur again. Simply open a window to sufficiently ventilate the room. After extended periods of non-operation
such as following a vacation or a warm weather season, the appliance may emit a slight odour for a few hours.
This is caused by dust particles in the heat exchanger burning off. Open a window to sufficiently ventilate the
room.
IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT
CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT WITH
THE GLASS DOOR OPENED OR REMOVED.
!
WARNING
6.1 OPERATING AND LIGHTING INSTRUCTIONS
OPERATING INSTRUCTIONS / INSTRUCTIONS D’OPERATION
FOR YOUR SAFETY READ BEFORE OPERATING / POUR VOTRE SÉCURITÉ LIRE AVANT DE FAIRE FONCTIONNER
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUC-
TIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT
CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR
LOSS OF LIFE.
INITIAL LIGHTING OF THE PILOT AND MAIN BURNERS
MUST BE DONE WITH THE GLASS DOOR OFF.
DO NOT CONNECT VALVE OR WALL SWITCH TO ELEC-
TRICITY. SEE INSTALLATION INSTRUCTIONS.
A. THIS FIREPLACE IS EQUIPPED WITH AN IGNITION DEVICE WHICH AUTOMATI-
CALLY LIGHTS THE PILOT. DO NOT TRY TO LIGHT BY HAND.
B. BEFORE OPERATING SMELL ALL AROUND THE FIREPLACE AREA FOR GAS
AND NEXT TO THE FLOOR BECAUSE SOME GAS IS HEAVIER THAN AIR AND WILL
SETTLE ON THE FLOOR.
WHAT TO DO IF YOU SMELL GAS:
TURN OFF ALL GAS TO THE FIREPLACE.
OPEN WINDOWS.
DO NOT TRY TO LIGHT ANY APPLIANCE.
DO NOT TOUCH ANY ELECTRIC SWITCHDO NOT USE ANY PHONE IN YOUR
BUILDING.
IMMEDIATELY CALL YOUR GAS SUPPLIER FROM A NEIGHBOUR¶S PHONE.
FOLLOW THE GAS SUPPLIER¶S INSTRUCTIONS.
IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE DEPARTMENT.
C. DO NOT TRY TO REPAIR ANY PART OF THIS ASSEMBLY. CALL A QUALIFIED
SERVICE TECHNICIAN. FORCE OR ATTEMPTED REPAIR MAY RESULT IN A FIRE
OR EXPLOSION.
D. DO NOT USE THIS FIREPLACE IF ANY PART HAS BEEN UNDER WATER.
IMMEDIATELY CALL A QUALIFIED SERVICE TECHNICIAN TO INSPECT THE
FIREPLACE AND REPLACE ANY PART OF THE CONTROL SYSTEM AND ANY GAS
CONTROL WHICH HAS BEEN UNDER WATER.
ATTENTION: SI CES INSTRUCTIONS NE SONT PAS OBSERVÉES A LA
LETTRE, UN FEU OU UNE EXPLOSION POURRAIT S¶ENSUIVRE
CAUSANT DES DOMMAGES A LA PROPRIETE, DES BLESSURES
CORPORELLES OU PERTE DE VIE.
L¶ALLUMAGE INITIAL DE LA VEITLLEUSE ET DU BRULEUR PRINCIPAL
DOIT SE FAIRE AVEC LA PORTE VITREE ENLEVEE.
NE RACCORDE=PAS LA SOUPAPE OU L¶INTERRUPTEUR MURALA
L¶ELECTRICITE.
CONSULTE=LES INSTRUCTIONS D¶INSTALLATION.
A. CET APPAREIL EST MUNI D¶UN DISPOSITIF D¶ALLUMAGE QUI ALLUME LA VEILLEUSE
AUTOMATIQUEMENT.
N¶ESSAYE=PAS D¶ALLUMER LA VEILLEUSE MANUELLEMENT.
B. AVANT D¶ALLUMER SENTE=L¶AIR AUTOUR DE L¶APPAREIL ET PRÊS DU PLANCHER (CERTAINS
GA=SONT PLUS LOURDS QUE L¶AIR ET SE DÉPOSERONT AU NIVEAU DU PLANCHER) POUR
DÉTECTER UNE FUITE POSSIBLE.
QUE FAIRE SI VOUS DÉTECTEZ UNE ODEUR DE GAZ:
COUPEZ L¶ALIMENTATION DE GAZ PRINCIPALE.
OUVREZ LES FENETRES.
N¶ALLUMEZ AUCUN APPAREIL.
NE TOUCHEZ PAS ¬AUCUN INTERRUPTEUR ÉLECTRIQUEN¶UTILISEZ AUCUN TÉLÉPHONE
DANS VOTRE IMMEUBLE.
APPELEZ IMMÉDIATEMENT VOTRE FOURNISSEUR DE GAZ D¶UN TÉLÉPHONE VOISIN ET SUIVEZ
SES INSTRUCTIONS.
SI VOUS NE POUVEZ PAS REJOINDRE VOTRE FOURNISSEUR DE GAZ, APPELEZ LE SERVICE
DES
INCENDIES.
C. N¶ESSAYEZ PAS DE RÉPARER AUCUNE PIÊCE DE CET ASSEMBLAGE. APPELEZ UN
TECHNICIEN QUALIFIÉ. FORCER OU TENTER DE RÉPARER L¶ASSEMBLAGE POURRAIT CAUSER
UN FEU OU UNE EXPLOSION.
D. N¶UTILISEZ PAS CET APPAREIL SI UN DE SES COMPOSANTS ¬ÉTÉ SUBMERGÉ. CONTACTEZ
IMMÉDIATEMENT UN TECHNICIEN DE SERVICE QUALIFIÉ POUR INSPECTER L¶APPAREIL ET
REMPLACER TOUT SYSTÊME DE CONTRÐLE DE GAZ TOUCHÉ PAR L¶EAU. W385-0460
LIGHTING INSTRUCTIONS / INSTRUCTIONS D’ALLUMAGE
1. STOP! READALL INFORMATION OF OPERATING AND LIGHTING
INSTRUCTIONS BEFORE PROCEEDING.
2. TURN OFF ELECTRIC POWER TO THE FIREPLACE.
3. THIS FIREPLACE IS EQUIPPED WITH AN IGNITION DEVICE WHICH
AUTOMATICALLY LIGHTS THE PILOT. DO NOT TRYTO LIGHT THE PILOT
BY HAND.
4. OPEN THE GLASS DOOR.
5. TURN MANUAL SHUTOFF VALVE CLOCKWISE TO OFF.
6. WAIT FIVE (5) MINUTES TO CLEAR OUTANY GAS. IF YOU SMELLGAS
INCLUDING NEAR THE FLOOR, STOP! FOLLOW “B” OF THE OPERATING
INSTRUCTIONS. IF YOU DON’T SMELLGAS GO TO THE NEXT STEP.
7. TURN MANUAL SHUTOFF VALVE COUNTER-CLOCKWISE TO ON.
8. CLOSE THE GLASS DOOR.
9. TURN ON ALL ELECTRIC POWER TO THE FIREPLACE.
10. TURN ON MAIN BURNER.
1. ARRÊTEZ! LISEZ TOUTES LES INSTRUCTIONS DE FONCTIONNEMENT
ET D’ALLUMAGE AVANT DE CONTINUER.
2. COUPEZ L’ALIMENTATION ÉLECTRIQUE À L’APPAREIL.
3. CETAPPAREIL EST MUNI D’UN DISPOSITIF D’ALLUMAGE QUIALLUME
LA VEILLEUSE AUTOMATIQUEMENT, N’ESSAYEZ PAS D’ALLUMER LA
VEILLEUSE MANUELLEMENT.
4. OUVREZ LA PORTE VITRÉE.
5. TOURNEZ LASOUPAPE DE SECTIONNEMENT MANUELLE VERS LA
DROITE A “OFF”.
6. ATTENDEZ CINQ (5) MINUTES POUR QUE LE GAZ PUISSE
S’ÉCHAPPER. SI VOUS DÉTECTEZ UNE ODEUR DE GAZ, ARRÊTEZ!
SUIVEZ « B » DANS LES INSTRUCTIONS DE FONCTIONNEMENT. S’IL
N’YA PAS D’ODEUR DE GAZ, PASSEZ À L’ÉTAPE SUIVANTE.
7. TOURNEZ LASOUPAPE DE SECTIONNEMENT MANUELLE VERS LA
GAUCHE A “ON”.
8. FERMEZ LA PORTE VITRÉE.
9. RÉTABLISSEZ L’ALIMENTATION ÉLECTRIQUE AU FOYER.
10. ALLUMEZ LE BRÛLEUR PRINCIPAL.
1. TURN OFF ALL ELECTRICAL POWERTO THE FIREPLACE IF SERVICE IS
TO BE PERFORMED.
2. TURN MANUAL SHUTOFF VALVE CLOCKWISE TO OFF. DO NOT
FORCE.
1. COUPEZ L’ALIMENTATION ÉLECTRIQUEAU FOYER SI UN TRAVAIL
D’ENTRETIEN DOIT SE FAIRE.
2. TOURNEZ LASOUPAPE D’ARRÉT MANUELLE VERS LA DROITE
À “OFF” NE FORCEZ PAS.
TO TURN OFF GAS / INSTRUCTIONS POUR COUPER LE GAZ

W415-1194 / 03.04.13
18
EN THERMOSTAT
OFF/ON/SMART
ROOM
TEMPERATURE
LOW BATTERY
ALARM
CHILD SAFETY
LOCK OUT
TRANSMISSION
AUX. OUTPUT
FANFLAME
TEMPERATURE SET POINT/ LEVEL/ STATUS
SPLIT VALVE
35.18
6.2 GENERAL TRANSMITTER LAYOUT
6.3 APPLIANCE OPERATION
A
. Install 4 AA batteries into the receiver battery bay as indicated on the battery cover
(
+
/
-
)
.
(O
nly required
as back up to household electricity).
While there is a provision to connect a 6V battery pack (do not use a 9 volt battery), it must not be
used when using the remote control receiver.
B. Place the 3 position slider switch of the receiver in the “Remote” position.
C. Using the end of a paper clip, or other similar object, insert the end of the paper clip into the hole
marked “PRG” on the receiver front cover. The receiver will “beep” three (3) times to indicate that it is
ready to synchronize with the transmitter.
D. Install the 3 AAA batteries in the transmitter battery bay, located on the base of the transmitter.
With the batteries already installed in the transmitter, push the “ON” button. The receiver will “beep”
four times to indicate the transmitter’s command is accepted and set to the particular code of that
transmitter. The system is now initialized. 35.3
6.4 HAND HELD REMOTE OPERATIONS
A
. Press the
O
N
/O
FF key on the transmitter. The transmitter
display will show all active icons on the screen. A single
“beep” from the receiver will confirm reception of the
command.
35.4
3
BLUE LCD DISPLAY
ON/OFF KEY
UP/DOWN
ARROW KEY
MODE KEY
TEMPERATURE KEY
THERMOSTAT KEY

W415-1194 / 03.04.13
19
EN
The remote transmitter can operate as a room thermostat.
The thermostat can be set to a desired temperature to control the
comfort level in the room.
A. Press the Thermostat Key. The LCD display on the
Transmitter will show that the room is “ON” and the set
temperature is now displayed.
B. To adjust the set temperature, press the Up/Down Arrow
Keys until the desired set temperature is displayed on the
LCD screen of the Transmitter.
35.6
76°F
ON
68
ROOM TEMPERATURE
SET TEMPERATURE
6.5 TEMPERATURE DISPLAY
6.6 ROOM THERMOSTAT
A
. With the system in the “
O
FF” position, press the
Thermostat Key and the Mode Key at the same
time to change from degrees F to C.
B. Look at the LCD screen on the Transmitter to
verify that a C or F is visible to the right of the
Room Temperature display.
35.5
73°F 23°C
The
S
mart Thermostat
f
unction adjusts the
fl
ame height according to the di
ff
erence
between the set temperature and the actual room temperatures. As the room
temperature gets closer to the set point the Smart Function will automatically adjust
the flame down.
A
. Press the thermostat key until the word “SMART” appears to the right of the
temperature bulb graphic.
B. To adjust the set temperature, press the Up/Down arrow keys until the
desired set temperature is displayed on the LCD screen at the Transmitter.
35.7
76°F
ON
68
SMART
MAX
6.7 SMART THERMOSTAT

W415-1194 / 03.04.13
20
EN
The remote control has six (6) flame levels. With the
system on and the flame level at the maximum, press
the Down Arrow Key once and it will reduce the flame
height by one step until the flame is turned off.
The Up Arrow Key will increase the flame height each
time it is pressed. If the Up Arrow Key is pressed while
the system is on but the flame is off, the flame will
come on the high position. A single “beep” will confirm
reception of the command.
35.8
76°F
OFF
76°F
76°F
76°F
Hi
FLAME OFF FLAME AT LEVEL 1
FLAME AT LEVEL 5 FLAME AT “HI” LEVEL 6
6.8 FLAME HEIGHT
This function will lock the keys to avoid unsupervised operation.
A. Press the MODE and UP keys at the same time.
B. To de-activate this function, press the MODE and UP keys at the same time.
35.10
76°F
6.9 CHILD PROOF FUNCTION
The auxiliary function controls the AUX power outlet on
the Control Module which controls the NIGHT LIGHT™.
A. Use the Mode Key to guide you to the AUX icon.
B. Pressing the Up Arrow Key will activate the
NIGHT LIGHT™.
C. Pressing the Down Arrow Key will turn the
NIGHT LIGHT™ off. A single “beep” will confirm
the reception of the command.
35.12
76°F
OFF
76°F
ON
6.10 NIGHT LIGHT
