Napoleon W415-1467 / A User manual

W415-1467 / A / 09.30.16
EN
FR
PG
43
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
This wood appliance needs periodic inspection and repair for proper operation. It is against United States federal
regulation to operate this wood appliance in a manner inconsistent with operating instructions in this manual.
INSTALLATION AND
OPERATING INSTRUCTIONS
1.27D
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.napoleonfireplaces.com • [email protected]
SAFETY INFORMATION
!WARNING
If the information in these instructions is not followed exactly, a
fire or explosion may result causing property damage, personal
injury or death. Improper installation, adjustment, alteration,
service or maintenance can cause injury or property damage,
bodily injury or even death. Please read entire manual before
you install and use your appliance.
This appliance has not been tested with an unvented gas log
set. To reduce risk of fire or injury, do not install an unvented
gas log set into the appliance.
- This appliance can be very hot when burning.
- Combustible materials such as firewood, wet clothing, etc. placed too close
can catch fire.
- Children and pets must be kept from touching the appliance when it is hot.
- The chimney must be sound and free of cracks. Before installing this unit,
contact the local building or fire authority and follow their guidelines.
- Operate only with the door tightly closed.
- Burn wood behind the log retainer directly on the firebricks.
- Do not use an elevated grate or otherwise raise the fire.
- At least 14 square inches (90.3 square centimeters) of outside air must be
admitted to the room or directly to the unit through a 4” (101.6mm) diameter
pipe.
- This appliance is designed to burn natural wood only. Higher efficiencies and
lower emissions generally result when burning air dried seasoned hardwoods,
as compared to softwoods or to green or freshly cut hardwoods.
- Do not start a fire with chemicals or fluids such as gasoline, engine oil, etc.
- Do not burn trash or garbage, lawn clippings / waste, rubber, waste petroleum
products, paints or paint thinners / solvents, plastic, materials containing
asbestos, construction debris, railroad ties or treated wood, manure or animal
remains, salt water driftwood or salted materials, unseasoned wood, coal,
charcoal, coloured paper, cardboard, plywood or particleboard.
- Do not let the appliance become hot enough for any part to glow red.
- KEEP THE STOVE TOP TEMPERATURE BELOW 700°F (371°C). Attempts to
achieve heat output rates that exceed design specifications can result in steel
distortion and damage.
$10.00
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
WARNING
1100ML, 1100C,
1400ML, 1400C
LEG MODELS
1400ML Illustrated
MODEL 1100ML, 1100C, 1400ML & 1400C MEET THE 2015 U.S ENVIRONMENTAL PROTECTION AGENCY (E.P.A) CRIB WOOD EMISSION LIMIT FOR WOOD
APPLIANCES SOLD AFTER MAY 15, 2015, 40 C.F. R. PART 60. THESE STOVES HAVE BEEN TESTED AND LISTED BY INTERTEK TESTING SERVICES TO
STANDARDS: CSA B366.2, ULC S627, UL 1482. MODEL 1100 HAS BEEN TESTED AND LISTED FOR INSTALLATION IN MOBILE HOMES.

EN
W415-1467 / A / 09.30.16
2
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 SPECIFICATIONS 5
2.3 GENERAL INSTRUCTIONS 6
2.4 GENERAL INFORMATION 7
2.5 RATING PLATE LOCATION 8
3.0 PRE-INSTALLATION PREPARATION 9
3.1 APPLIANCE PLACEMENT 9
3.2 CLEARANCE TO COMBUSTIBLES 9
3.3 ALCOVE INSTALLATION 9
3.4 FLOOR PROTECTION 10
3.5 OUTSIDE AIR 10
3.6 MOBILE HOME 11
4.0 INSTALLATION 12
4.1 CHIMNEY 13
4.1.1 CHIMNEY CONNECTION 14
4.1.2 ADDING SECTIONS 15
4.1.3 TYPICAL THROUGH THE CEILING 16
4.1.4 TYPICAL THROUGH THE WALL 17
4.1.5 TYPICAL EXISTING MASONRY 18
5.0 FINISHING 19
5.1 LEG INSTALLATION (1100ML / 1400ML) 19
5.2 DOOR REMOVAL / INSTALLATION (1100ML / 1400ML) 19
5.3 1100C/1400C DOOR REMOVAL /INSTALLATION 19
5.4 1400C CAST LID LEVELLING 20
5.5 DOOR HANDLE INSTALLATION 20
5.6 BRICKS AND BAFFLES INSTALLATION 21
6.0 OPTIONAL KIT INSTALLATIONS 22
6.1 OPTIONAL BLOWER INSTALLATION 22
6.2 OPTIONAL ASH DRAWER (1100ML/1400ML ONLY) 22
7.0 OPERATION 23
7.1 OPTIMUM BURN METHOD 24
7.2 AIR CONTROL 25
7.3 FIRE EXTINGUISHERS / SMOKE & CARBON MONOXIDE DETECTORS 25
7.4 FUEL 26
7.5 LIGHTING A FIRE 26
7.5.1 FLASH FIRE 26
7.5.2 EXTENDED FIRE 27
7.6 SMOKING 27
8.0 MAINTENANCE 27
8.1 ASH REMOVAL PROCEDURES 28
8.1.1 APPLIANCES WITH ASH PAN (1100C, 1400C) 28
8.1.2 APPLIANCES WITHOUT ASH PAN (1100ML,1450ML) 28
8.2 CREOSOTE FORMATION AND REMOVAL 28
8.3 RUNAWAY OR CHIMNEY FIRE 29
8.4 CHIMNEY CLEANING 29
8.5 GLASS REPLACEMENT 30
8.6 GASKET REPLACEMENT 30
8.7 SECONDARY AIR MANIFOLD REPLACEMENT 31
8.8 CARE OF GLASS 32
8.9 CARE OF PLATED PARTS 32
8.10 WOOD 33
9.0 REPLACEMENTS 34
9.1 1100ML OVERVIEW 35
9.2 1100C OVERVIEW 36
9.3 1400ML OVERVIEW 37
9.4 1400C OVERVIEW 38
10.0 ACCESSORIES 39
11.0 TROUBLESHOOTING 40
12.0 WARRANTY 41
NOTE: The camera icon indicates video tutorials are available as additional reference, visit
http://mynapoleon.napoleonproducts.com/download/index/44/1

EN
W415-1467 / A / 09.30.16
3
1.0 INSTALLATION OVERVIEW
Legs, see “LEG
INSTALLATION” section.
Blower, see “OPTIONAL
BLOWER KIT
INSTALLATION” section.
Ash drawer, see “OPTIONAL
ASH DRAWER” section.
Door, see “DOOR
REMOVAL /
INSTALLATION”
section.
Draft, see “AIR CONTROL”
section.
Rating Plate, see
“RATING PLATE
INFORMATION” section.
Brick and Baffles, see
“BRICK AND BAFFLES
INSTALLATION” section.
Handle, see “DOOR
AND HANDLE
INSTALLATION”
section.
1400PL ILLUSTRATED

EN
W415-1467 / A / 09.30.16
4
2.0 INTRODUCTION
3.17G
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS AND
IS PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance
according to operating instructions could cause fire or injury.
• Before installing this appliance, contact the local building or fire authority and follow their guidelines.
• This appliance must be installed by a qualified installer.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not operate without fully assembling all components.
• Do not let the appliance become hot enough for any part to glow red.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges may
be sharp.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid
burns or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance. Toddlers, young
children and others may be susceptible to accidental contact burns. A physical barrier is recommended if there
are at risk individuals in the house. To restrict access to an appliance or stove, install an adjustable safety gate to
keep toddlers, young children and other at risk individuals out of the room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance. Objects placed in front of the
appliance must be kept a minimum of 4 feet (1.2m) away from the front face of the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measures to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot
surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe servicing a separate solid fuel burning appliance.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should
be done by a licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• Only doors / optional fronts certified with the appliance are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all
plastic bags, these are not toys and should be kept away from children and infants.
• If the appliance is not properly installed, a house fire may result. Do not expose the appliance to the elements (ex.
rain, etc.) and keep the appliance dry at all times. Wet insulation will produce an odour when the appliance is used.
• The chimney must be sound and free of cracks. Clean your chimney a minimum of twice a year and as required.
• Do not start a fire with chemicals or fluids such as gasoline, engine oil, etc.
• Your appliance requires periodic maintenance and cleaning. Failure to maintain your appliance may lead to smoke
spillage in your home.
• Lower emissions generally result when burning air dried seasoned hardwoods, as compared to softwoods or too
green or freshly cut hardwoods. Burning wet unseasoned wood can cause excessive creosote accumulation.
When this is ignited it can cause a chimney fire that may result in a serious house fire.
• This appliance is designed to burn natural wood only. Do not burn trash or garbage, lawn clippings / waste,
rubber, waste petroleum products, paints or paint thinners / solvents, plastic, materials containing asbestos,
construction debris, railroad ties or treated wood, manure or animal remains, salt water driftwood or salted
materials, unseasoned wood, coal, charcoal, coloured paper, gift wrapping, cardboard, plywood or particleboard.
Burning these materials may result in release of toxic fumes or render the appliance ineffective and cause smoke.
• Burn wood directly on the firebricks. Do not elevate grate or otherwise raise the fire.
• Do not store wood within appliance installation clearances or within the space required for re-fueling and ash removal.
• Ashes must be disposed in a metal container with a tight lid and placed on a non-combustible surface well away
from the home or structure until completely cool.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance.
Elevated temperatures on the wall or in the air above the appliance can cause melting, discolouration or damage to
decorations, a T.V. or other electronic components.
• If equipped, the catalyst must be installed and in good working order. It is recommended that the catalyst is
inspected at least 3 times per heating season.

EN
W415-1467 / A / 09.30.16
5
* As tested using test method 28
** Figures will vary considerably with individual conditions.
*** Wolf Steel Ltd. estimated realistic BTU/hr with cordwood logs and regular refueling.
Specifications Ref 1100ML 1100C 1400ML 1400C
WIDTH A25 1/2”(64.8cm) 28” (71.1cm) 25 1/2”(64.8cm) 28” (71.1cm)
DEPTH B22 1/2” (57.2cm) 22 1/2” (57.2cm) 27” (68.6cm) 27” (68.6cm)
FLUE CENTER LINE
TO REAR C6 1/2” (165mm) 6 3/4” (171mm) 7 1/2” (191mm) 6 3/4” (171mm)
FLUE CENTER LINE
TO SIDE D12 3/4” (32.4cm) 14” (35.6cm) 12 3/4” (32.4cm) 14” (35.6cm)
HEIGHT LEG MODEL E32”(81.3cm) 28 1/2” (72.4cm) 32” (81.3cm) 28 1/2” (72.4cm)
CHAMBER (D.W.H) 13 1/2 x 18 x 12”
(34.3x45.7x30.5cm) 13 1/2 x 18 x 12” (34.3x45.7x30.5cm) 18 x 18 x 12” (45.7x45.7x30.5cm) 18 x 18 x 12” (45.7x45.7x30.5cm)
CAPACITY 1.7ft3 (0.5m3) 1.7ft3 (0.5m3) 2.25ft3 (0.7m3) 2.25ft3 (0.7m3)
APPROX. AREA HEATED** 600-1500 ft2600-1500 ft21000-2000 ft21000-2000 ft2
MAXIMUM HEAT OUTPUT
*** 55,000 BTU 55,000 BTU 70,000 BTU 70,000 BTU
HEAT OUTPUT * 11,700-42,200
BTU/Hr 11,700-42,200 BTU/Hr 11,400-41,300 BTU/Hr 11,400-41,300 BTU/Hr
DURATION LOW FIRE ** 7 Hours 7 Hours 9 Hours 9 Hours
WEIGHT w/o BRICKS 215 lbs (98kg) 215 lbs (98kg) 250 lbs (113kg) 305 lbs (138kg)
WEIGHT OF BRICKS 110 lbs (50kg) 110 lbs (50kg) 145 lbs (66kg) 145 lbs (66kg)
IDEAL WOOD LENGTH 12” (30.5cm) 12” (30.5cm) 16” (40.6cm) 16” (40.6cm)
2.1 DIMENSIONS
E
BC
D
A
6"
152mm
DIA.
1400ML ILLUSTRATED
2.2 SPECIFICATIONS

EN
W415-1467 / A / 09.30.16
6
2.3 GENERAL INSTRUCTIONS
4.7
ALL WIRING SHOULD BE DONE BY A QUALIFIED ELECTRICIAN AND SHALL BE IN COMPLIANCE WITH
LOCAL CODES. IN THE ABSENCE OF LOCAL CODES, USE THE CURRENT CSA22.1 CANADIAN
ELECTRIC CODE IN CANADA OR THE CURRENT NATIONAL ELECTRIC CODE ANSI/NFPA NO. 70 IN
THE UNITED STATES.
THIS APPLIANCE HAS NOT BEEN TESTED WITH ANY VENTED OR UNVENTED GAS LOG SET. TO
REDUCE RISK OF FIRE OR PREVENT INJURY, DO NOT INSTALL A VENTED OR UNVENTED GAS LOG
SET INTO THE APPLIANCE.
BURNING YOUR UNIT WITH THE ASH DUMP DOOR OPEN OR AJAR CREATES A FIRE HAZARD THAT
MAY RESULT IN DISCOLOURATION TO THE GOLD PLATED DOOR, INTERNAL DAMAGE TO THE
APPLIANCE OR A HOUSE CHIMNEY FIRE.
DO NOT CONNECT THIS APPLIANCE TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
THIS APPLIANCE AND IT’S COMPONENTS ARE DESIGNED TO BE INSTALLED AND OPERATED AS A
SYSTEM. ANY ALTERATION TO OR SUBSTITUTION FOR ITEMS IN THIS SYSTEM, UNLESS ALLOWED
BY THESE INSTALLATION INSTRUCTIONS, WILL VOID THE LISTING AND MAY VOID THE PRODUCT
WARRANTY. IT MAY ALSO CREATE A HAZARDOUS INSTALLATION. READ THROUGH THESE
INSTRUCTIONS THOROUGHLY BEFORE STARTING YOUR INSTALLATION AND FOLLOW THEM
CAREFULLY THROUGHOUT YOUR PROJECT.
!
WARNING
• Before beginning your installation, consult with your local building code agency or fire officials and
insurance representative to ensure compliance.
• Non-toxic smoke will be emitted during the paint curing process, to help dissipate the smoke open a
window near the appliance.
• Remove any dust or debris off the top of the appliance before firing the appliance as the paint will
become soft as the appliance heats up and will harden as the appliance cures. To cure the paint on
your appliance burn your appliance moderately hot during the first few fires.
• To keep the gasket from sticking to the appliance as the paint is curing, periodically open the door
every 5-10 minutes.
• For the first two weeks use generous amounts of fuel and burn the appliance with the damper wide
open for an hour as the appliance goes through a process of eliminating moisture in the steel and
firebricks. The initial heat output will be reduced while the moisture is being drawn from the appliance
and it will be necessary to build several hot fires to remove this moisture. DURING THIS PROCESS
DO NOT OVERFIRE THE APPLIANCE. REDUCE THE AMOUNT OF AIR COMING INTO THE
APPLIANCE IF THE APPLIANCE OR CHIMNEY BECOMES RED.

EN
W415-1467 / A / 09.30.16
7
Your appliance has been specifically designed to meet the 2015 U.S.A. EPA particulate emission standards and
has been extensively tested in Canadian and American laboratories. This system is the most efficient, simple and
trouble free we know and works as follows:
The chimney vent system used on your wood burning appliance should be designed with the least amount of
restriction possible to enable the exhaust products to easily flow through it. Chimney vent systems that are too
short or too long can also have an adverse affect on the flow of exhaust through it. The wood burning appliance
and chimney vent system also require a sufficient supply of combustion air not only to support the combustion in
the combustion chamber but to replace the exhaust leaving it so it can flow freely up through the vent system and
out into the atmosphere. It is the correct balance of combustion air and the chimney vent system that will ensure
the appliance provides you with its optimum performance.
Combustion air enters through two holes in the bottom
which can be adjusted by a single air control. Air from
the front hole goes up on either side of the door into
a preheating airwash located across the top and then
down the window to feed the fire and also to ensure that
the glass remains clean. Air from this hole also feeds
directly into the combustion chamber at hearth level.
Secondary air from the rear hole travels up the back in
the secondary air housing to the manifold located at the
top and shoots out laterally to oxidize the gases below
the smoke exit.
The combustion chamber is lined with high temperature
firebrick on both sides, the back and across the bottom,
with a layer of fibre baffles at the top to maintain a
high temperature in the combustion chamber so that
gases mixing with the preheated air from the secondary
air manifold tube are easily ignited and burned. The
appliance sides and back are shielded to direct the heat
upwards and forwards into the room.
Be sure to provide sufficient combustion air. There are many other appliances in your home competing for air such
as: a kitchen range hood, forced air heating devices or a bathroom exhaust fan.
Expansion / contraction noises during heating up and cooling down cycles are normal and to be expected.
After extended periods of non-operation such as following a vacation or a warm weather season, the appliance
may emit a slight odour for a few hours. This is caused by dust particles on the firebox burning off. Open a window
to sufficiently ventilate the room.
CALIFORNIA PROP 65 WARNING:
Use of this product may produce smoke which contains
chemicals known to the State of California to cause cancer,
birth defects, or other reproductive harm.
If optional ash drawer is purchased, ensure that the ash
dump door is tightly closed, allow the door to snap shut
dislodging anything (ashes or pieces of coal) that may be
stuck in the opening.
If outside air is utilized, you should never experience a shortage of combustion air. If you choose not to utilize
outside air and experience draft or smoking problems, you may need to open a door, a window or otherwise
provide some method of supplying combustion air to the appliance.
HOT SECONDARY AIR
FIBRE BRICKS
REFRACTORY
2 SIDES, BACK
& BOTTOM
SECONDARY AIR
PRIMARY AIR
FLUE GLASS
CERAMIC
GLASS
AIR CONTROL
COMBUSTION AIR
INTAKE
OPEN CLOSED
2.4 GENERAL INFORMATION
DO NOT OPERATE THIS APPLIANCE WITHOUT THE LEGS INSTALLED.
!
WARNING
We suggest that our woodburning hearth products
be installed and serviced by professionals who are
certified in the U.S. by the National Fireplace
Institute® (NFI) as NFI Woodburning Specialists or
who are certified in Canada by
Wood Energy Technical
Training (WETT).

EN
W415-1467 / A / 09.30.16
8
2.5 RATING PLATE LOCATION
For rating plate location, see
“INSTALLATION OVERVIEW”
This illustration is for reference
only. Refer to the rating plate on the
appliance for accurate information.
NOTE: The rating plate must remain
with the appliance at all times. It
must not be removed.
1400 SERIES RATING PLATE ILLUSTRATED
LISTEDSOLIDFUELBURNINGFIREPLACEINSERT/
ENCASTRÉ ÀCOMBUSTIBLESOLIDEHOMOLOGUÉ
TESTEDTO/TESTÉ SELON :
ULCS628 /UL1482
FROM HEATER / DU POÊLE
RESIDENTIAL/ RÉSIDENTIEL
S4
16IN/PO (406 mm)
12IN/PO (305 mm)
6IN/PO (152 mm)
USINGDOUBLE WALLCONNECTOR /
UTILISATIOND’UN CONDUIT DE
RACCORDEMENTÀ DOUBLE PAROI MAISON/ MOBILE HOME*
S4 1400
16IN/PO (406 mm) 10IN/PO (254 mm)
6IN/PO (152 mm) 6IN/PO (152 mm)
4IN/PO (102 mm) 4IN/PO (102 mm)
EPI1402
INSTALLAND USE ONLY IN
ACCORDANCE WITH THE
MANUFACTURER’S
INSTRUCTIONS AND LOCAL
BUILDING CODES.
MINIMUM CEILING HEIGHT:
7FT (2.13m)
HEARTH EXTENSION /
COMBUSTIBLE FLOOR
PROTECTION: IF INSTALLED
ON ACOMBUSTIBLE FLOOR,
UNIT MUST BE PLACED ON A
NON-COMBUSTIBLE FLOOR
PROTECTOR EXTENDING 18”
(455mm) IN FRONTAND 8”
(205mm) TO THE SIDES AND
BACK.
CHIMNEY TYPE: MINIMUM 6”
(152mm) DIAMETER
APPROVED RESIDENTIAL
TYPE FOR MOBILE HOME USE
A CHIMNEY LISTED TO ULC
S629 IN CANADA OR UL103HT
IN THE USA.
CHIMNEY CONNECTOR: 6”
(152mm) DIAMETER MINIMUM
24 GAUGE STEEL MINIMUM
CLEARANCE FROM
HORIZONTAL CONNECTOR
AND CEILING 18” (455mm).
DO NOT OBSTRUCT SPACE
UNDER HEATER.
SPECIAL METHODS ARE
REQUIRED WHEN PASSING A
CHIMNEY THROUGH A WALL
OR CEILING. SEE INSTRUC-
TIONS AND BUILDING CODES.
DO NOT CONNECT THIS UNIT
TOA CHIMNEY FLUE SERVING
ANOTHER APPLIANCE.
FUEL: FOR USE WITH WOOD
ONLY. DO NOT USE GRATE OR
ELEVATE FIRE. BUILD WOOD
FIRE DIRECTLY ON HEARTH.
WARNING: RISK OF SMOKE
SPILLAGE. OPERATE ONLY
WITH DOOR FULLY CLOSED.
REPLACE GLASS ONLY WITH
CERAMIC GLASS.
DO NOT OVERFIRE. IF
HEATER OR CHIMNEY
CONNECTORS GLOW, YOU
ARE OVERFIRING. INSPECT
AND CLEAN CHIMNEY
FREQUENTLY. UNDER
CERTAIN CONDITIONS OF
USE CREOSOTE BUILD-UP
MAY OCCUR RAPIDLY.
OPTIONAL BLOWER KIT:
EP-62, 115V, 60HZ, 0.82AMP.
ROUTE CORD AWAY FROM
UNIT.
DANGER: RISK OF
ELECTRICAL SHOCK.
DISCONNECT POWER
BEFORE SERVICING UNIT.
INSERT: INSTALL AND USE
ONLY IN SOLID FUEL
BURNING FIREPLACES. DO
NOT REMOVE BRICKS OR
MORTAR FROM SOLID FUEL
BURNING FIREPLACE.
INSTALL WITH A POSITIVE
FLUE CONNECTORAND
FACEPLATE.
POUR INSTALLATION ET
UTILISATION CONFORMÉMENT AUX
INSTRUCTIONS DU FABRICANTET
AUX CODES LOCAUX DU BÂTIMENT.
HAUTEUR DE PLAFOND MINIMAL
7PI (2,13m).
PROLONGEMENT
D’ÂTRE/PROTECTION DU
PLANCHER COMBUSTIBLE: SI
INSTALLÉ SUR UN PLANCHER
COMBUSTIBLE, L’APPAREIL DOIT
ÊTRE PLACÉ SUR UNE PLAQUE
PROTECTRICE INCOMBUSTIBLE
S’ÉTENDANT SUR 18” (455mm) À
L’AVANT ET 8” (205mm) À L’ARRIÈRE
ET SUR LES CÔTÉS.
TYPE DE CHIMNÉE: DIAMÈTRE
MINIMAL DE 6” (152mm)
APPROUVÉE POUR USAGE
RÉSIDENTIEL. MAISON MOBILE
EMPLOYEZ UNE CHEMINÉE
HOMOLOGUÉE ULC S629 AU
CANADA OU UL103HT AUX
ÉTATS-UNIS.
RACCORD DE CHEMINÉE:
DIAMÈTRE DE 6” (152mm) D’ACIER
DE CALIBRE 24 MINIMUM. 18”
(455mm) DE DÉGAGEMENT MINIMAL
ENTRE LE RACCORD HORIZONTAL
ET LE PLAFOND.
NE RIEN ENTREPOSER SOUS
L’APPAREIL.
DES MÉTHODES SPÉCIALES SONT
REQUISES LORSQU’UNE CHEMINÉE
TRAVERSE UN MUR OU UN
PLAFOND. VOIR LES INSTRUC-
TIONS ET LES CODES DU
BÂTIMENT.
NE PAS RACCORDER À LA
CHEMINÉE D’UN AUTRE APPAREIL.
COMBUSTIBLE: POUR USAGE AVEC
LE BOIS SEULEMENT. N’UTILISEZ
PAS DE CHENET OU NE
SURÉLEVEZ PAS LE BOIS.
PRÉPAREZ LE FEU DIRECTEMENT
SUR L’ÂTRE.
AVERTISSEMENT: RISQUE
D’ÉCHAPPEMENT DE FUMÉE. TENIR
LA PORTE FERMÉE LORSQUE LE
POÊLE FONCTIONNE. REMPLACEZ
LA VITRE PAR UNE VITRE EN
CÉRAMIQUE SEULEMENT.
NE SURCHAUFFEZ PAS L’APPAREIL.
SI L’APPAREIL OU LES RACCORDS
ROUGEOIENT, L’APPAREIL
SURCHAUFEE. INSPECTEZ ET
NETTOYEZ LACHEMINÉE
FRÉQUEMMENT. DANS CERTAINES
CONDITIONS, DES DÉPÔTS DE
CRÉOSOTE PEUVENT SE FORMER
RAPIDEMENT.
SOUFFLERIE OPTIONNELLE: EP-62,
115V, 60HZ, 0,82A. TENEZ LE
CORDON ÉLECTRIQUE LOIN DE
L’APPAREIL.
DANGER: RISQUE DE SECOUSSE
ÉLECTRIQUE. DÉBRANCHEZ AVANT
DE PROCÉDER À L’ENTRETIEN.
ENCASTRÉ: INSTALLEZ ET UTILISEZ
SEULEMENT DANS UN FOYER À
COMBUSTIBLE SOLIDE. NE RETIREZ
PAS DE MORTIER, NI BRIQUES DU
FOYER À COMBUSTIBLE SOLIDE.
INSTALLEZ AVEC UNE GAINE
CONFORME ET UNE PLAQUE DE
RECOUVREMENT.
CONTACT LOCAL BUILDING FIRE OFFICIALS ABOUTRESTRICTIONS AND
INSTALLATION INSPECTION IN YOURAREA. MODEL 1400 IS SUITABLE FOR USE
IN MOBILE HOMES WHEN USED WITH OUTSIDE AIR INSTALLATION KIT (111KT).
A MINIMUM CLEARANCE OF 18” (457mm)TO THE CHIMNEY CONNECTOR MAY
BE REQUIRED BY THEAUTHORITY HAVING JURISDICTION.
RENSEIGNEZ-VOUS AUPR
ÈS DES AUTORITÉS LOCALES DU BÂTIMENT ET DU
SERVICE DES INCENDIESAU SUJET DES RESTRICTIONS ET DES INSPECTIONS
D’INSTALLATION DANS VOTRE RÉGION. LES MODÈLES 1400 PEUVENT ÊTRE
INSTALLÉS DANS UNE MAISON MOBILE SI INSTALLÉS CONJOINTEMENTAVEC UNE
PRISE D’AIR EXTÉRIEUR (111KT). UN DÉGAGEMENT MINIMALDE 18” (457mm)
JUSQU’AU RACCORD DE LA CHEMINÉE PEUTÊTRE EXIGÉ PAR L’AUTORITÉ AYANT
JURIDICTION.
8" 8"
18"
8"
ALCOVE
A"
B"
C
BACK WALL (M/A)
45°
SIDE WALL (M/L)
BACK WALL (M/A)
SIDE WALL (M/L)
B
A
IF THE STOVE IS TO BE INSTALLED ONA COMBUSTIBLE FLOOR, IT MUST BE
PLACED ON ANAPPROVED NON-COMBUSTIBLE HEARTH PAD, THAT
EXTENDS 8” (200mm) BEYOND THE STOVE SIDESAND BACK, AND 18”
(455mm) TO THE FRONT.
SI LE POÊLE EST INSTALLÉ SUR UN PLANCHER COMBUSTIBLE, ILDOIT ÊTREPLACÉ
SUR UNE BASE DE PROTECTION INCOMBUSTIBLE CERTIFÉE QUI DOIT DÉPASSER
LES CÔTÉS ET L’AMÉRE DU POÊLE DE 8” (200mm) ET SE PROLONGER DE 18”
(455mm) SUR LE DEVANT.
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALWITH SINGLE WALL
CHIMNEY CONNECTOR / D ÉGAGEMENTS MINIMAUX AUX MATÉRIAUX
COMBUSTIBLES AVEC RACCORD DE CHEMINÉE À PAROI SIMPLE:
*MODELS 1400 AND S4 MAY BE INSTALLED INTO AMOBILE HOME IN THE
UNITED STATES ONLY.
* LE MODÈLES 1400 ET S4 NE PEUT ÊTRE INSTALLÉ QUE DANS UNE MAISON
MOBILE AUX ÉTATS-UNIS SEULEMENT.
HOTWHILE IN OPERATION. DONOTTOUCH. KEEPCHILDREN,
CLOTHINGANDFURNITUREAWAY. CONTACTMAYCAUSE
SKINBURNS.
QUAND L’APPAREIL FONCTIONNE, LA SURFACE DEVIENT
CHAUDE. NE PAS TOUCHER. TENIR LES ENFANTS, LES
VÊTEMENTS ET LES MEUBLES À L’ÉCART. LE CONTACT PEUT
CAUSER DES BRÛLURES À LA PEAU.
CAUTION:
ATTENTION:
W385-2031 / A
EPA1400
1400 1400L 1402 1450 S4
WOLF STEEL LTD.
24NAPOLEON ROAD, BARRIE,ON, L4M 0G8 CANADA
1400C
9700539 (WSL)
4001657 (NGZ)
4001658 (NAC)
4001659 (WUSA)
LISTED SOLID FUEL BURNING SPACE HEATER / POÊLE À COMBUSTIBLE SOLIDE
HOMOLOGUÉ TESTED TO: / TESTÉ SELON : UL1482 / ULC S627
MODEL / MODÈLE - EPA 1400
U.S. ENVIRONMENTAL PROTECTION AGENCY
U.S.ENVIRONMENTAL PROTECTIONAGENCY
Certified to comply with 2015 particulate emissions standards. Not approved for sale
Certifiedtocom
ply with 2015particulate emissions standards. Not approved forsale
after May 15, 2020. Certifié conforme à la norme d’ émanation de particles de 2020. Non approuvé pour la vente après le 15 mai, 2020.
after May 15, 2020. Certifié conformeàla normed’ émanation dep
articles de 2020. Non approuvé pourla vente après le1
5 mai, 2020.
40 CFR Part 60,Subpart AAA.
40 CFR Part 60,SubpartAA
A.
1400
12IN/PO (305 mm)
12IN/PO (305 mm)
6IN/PO (152 mm)
1400
10IN/PO (254 mm)
6IN/PO (152 mm)
4IN/PO (102 mm)
S4
16IN/PO (406 mm)
6IN/PO (152 mm)
4IN/PO (102mm)
CEILING / PLAFOND
C
DBA
FLOOR / PLANCHER
CLEARANCES TO COMBUSTIBLE CONSTRUCTION /
D ÉGAGEMENTS AUX MATÉRIAUX COMBUSTIBLES:
(MEASURED TO UNIT / ÀPARTIR DE L’APPAREIL)
A SIDE FACING / CÔTÉ 1 IN/PO (25mm) *
B TOP FACING / DESSUS 28 IN/PO (710mm)
C MANTEL / TABLETTE 28 IN/PO (710mm)
D SIDE WALL / MUR LATÉRAL 17 IN/PO (430mm)
* CLEARANCE TO EDGE OF FLASHING / DÉGAGEMENTAU
BORD DE LA FAÇADE
3.5 Grams Per Hour / 2015 Crib Wood / 3.5 Grammes par heure / Crib Wood 2015
3.5 Grams Per Hour / 2015 Crib Wood / 3.5 Grammes par heure/Crib Wood 2015
MANUFACTURE DATE: / DATE DE FABRICATION:
YEAR: 2016 2017 2018
MONTH: 2019 2020
2436
58
710
91211
1
THIS WOOD APPLIANCE NEEDS PERIODIC INSPECTIONAND REPAIR FOR
PROPER OPERATION. CONSULT THE OWNER'S MANUALFOR FURTHER
INFORMATION. IT ISAGAINST UNITED STATES FEDERAL REGULATIONSTO
OPERATE THIS WOODAPPLIANCE IN A MANNER INCONSISTENT WITH THE
OPERATING INSTRUCTIONS IN THE OWNER'S MANUAL.
CETAPPAREILAU BOIS DOIT FAIRE L'OBJECTD'UNE INSPECTION ET D'UN
ENTRETIEN PÉRIODIQUES POUR UN FONCTIONNEMENTADÉQUAT. CONSULTEZ
LE MANUEL D'INSTRUCTIONS POUR PLUS D'INFORMATION. LES RÈGLEMENTS
FÉDÉRAUX DE L'ÉTATS-UNIS INTERDISENT D'UTILISER CETAPPAREILDE
CHAUFFAGE D'UNE MANIÈREALLANT À L'ENCONTRE DES INSTRUCTIONS DE
FONCTIONNEMENT CONTENUES DANS CE MANUEL.
SAMPLE
FROM HEATE
P
RESIDENT
P
USINGDOUBLE WALLUSINGDOUBLE WALL
MP
UTILISATIOND’UTILISATIO
M
RACCORDEMENTRACCORDEME
M
Y
SED.
LY WITH
RE. IFRE. IF
HIMNEYHIMNEY
ORS GLOW,YOU
RS GLOW, YO
ERFIRING. INSPECT
IRING. INSPECT
EAN CHIMNEY
CHIMNEY
NTLY. UNDER
LY. UNDER
ONDITIONS OFNDITIONS OF
TE BUILD-UPBUI
IDLY.
R KIT:KIT:
S
2AMP.
2AMP.
OM
SONTONT
HEMINÉEMINÉE
UN
NSTRUC-
ES DUS
ORDER À LAORDER À LA
D’UN AUTRE APPAREIL.UN AUTRE APPAREIL.
STIBLE:
P
OU
R
US
A
G
E AVE
C
POUR USAGE AVEC
AM
IS SEULEMENT. N’UTILISEZNT. N’UTILISEZ
S DE CHENET OU NEDE CHENET OU NE
SURÉLEVEZ PAS LE BOIS.URÉLEVEZ PAS LE BOIS.
PRÉPAREZ LE FEU DIRECTEMENTPRÉPAREZ LE FEU DIRECTEMENT
SU
R L’ÂTRE.
SUR L’ÂTRE.
AVERTISSEMENT:
VERTISSEMENT:
R
I
SQ
U
ERISQUE
AM
D’ÉCHAPPEMENT DE FUMÉE. TENIRCHAPPEMENT DE FUMÉE. TEN
LA PORTE FERMÉE LORSQUE LEORTE FERMÉE LORSQUE L
POÊLE FONCTIONNE. REMPLAE FONCTIONNE. REMPL
LA VITRE PAR UNE VITRE ERE PAR UN
CÉRAMIQUE SEULEMENTQUE SE
NE SURCHAUFFEZ PANE SURCHAUFFE
SI L’APPAREIL OU LSI L’APPAREIL OU
ROUGEOIENT, L’AROUGEOIENT, L
SURCHAUFEERCHAU
NETTOYEZETTOYE
FRÉQUEMFRÉQUE
CONDCOND
CRÉCRÉ
R
RE EX
RE EX
E
E
LE
LE
E
E
E
AL
CO
V
EALCO
A
"A"
B"
E
E
E
E
E
E
E
LE
E
L
LE
E
LE
L
CC
SIDE WALL (M/LSIDE WALL (M
MPLE
E INSTALLED ON A COMBUSTIBLE FLOOR,OMBUSTIBLE FLOOR
ROVED NON-COMBUSTIBLE HEARTH PADROVED NON-COMBUSTIBLE HEARTH PAD
mm) BEYOND THE STOVE SIDESAND BACm) BEYOND THE STOVE SIDESAND BAC
E FRONT.RONT.
EST INSTALLTALL
É SUR UN PLANCHER COMBUSTIÉ SUR UN PLANCHER COMBUST
ASE DE PROTECTION INCOMBUSTIBLE CERTIFSE DE PROTECTION INCOMBUSTIBLE CERT
ÉS ET L’AMÉRE DUS ET L’AMÉRE
P
OPO
ÊÊ
LE DE 8” (200mm) ETLE DE 8” (200mm) ET
m) SUR LE DEVANT.m) SUR LE DEVANT.
NIMUM CLEARANCE TO COMBUSTIBLE MAMUM CLEARANCE TO COMBUSTIBLE MA
PL
CHIMNEY CONNECTOR / DHIMNEY CONNECTOR /
ÉGAGEMENTS MEMENTS
PL
PL
COMBUSTIBLES AVEC RACCORD DE CHEMCOMBUSTIBLES AVEC RACCORD DE CHE
P
*
MODOD
UNI
*
14
00
12IN/PO (30
12IN/PO12I
6IN/P6IN/
14
000
10IN/PO (25410IN/PO (254
6IN/PO (156IN/PO
4IN/PO4IN/PO

EN
W415-1467 / A / 09.30.16
9
3.0 PRE-INSTALLATION PREPARATION
Have an authorized dealer install the appliance. If you install the appliance yourself, have your dealer review
your installation plans and/or installation.
Draw out a detailed plan of the installation including dimensions and verify the dimensions with the
requirements listed in this manual.
You may wish to adjust the appliance position slightly to ensure the vent does not intersect with a framing
member. Appliance must be positioned so that no combustibles are within, or can swing within (e.g. drapes,
doors), 4 feet (1.2m) of the front of the appliance. 67.1B
3.1 APPLIANCE PLACEMENT
3.2 CLEARANCE TO COMBUSTIBLES
BACK WALL
B
SIDE WALL
A
BACK WALL
C
SIDE WALL
F
D
E
E
PARALLEL & CORNER SINGLE WALL CONNECTOR DOUBLE WALL CONNECTOR
1100ML / 1100C 1400ML /
1400C
1100ML / 1100C 1400ML / 1400C
SIDEWALL (A) 12" (30.5cm) 12" (30.5cm) 10" (254mm) 10" (254mm)
SIDEWALL TO FLUE (B) 21 3/4" (55.2cm) 21 3/4" (55.2cm) 19 3/4" (50.2cm) 19 3/4" (50.2cm)
BACKWALL (C) 10" (254mm) 12" (30.5cm) 6"(152mm) 6" (152mm)
BACKWALL TO FLUE (D) 13 1/2" (34.3cm) 16 1/2" (41.9cm) 9 1/2" (241mm) 10 1/2" (267mm)
CORNER (E) 6" (152mm) 6" (152mm) 2" (51mm) 4" (102mm)
CEILING (F) 7 feet (2.1m) 7 feet (2.1m) 7 feet (2.1m) 7 feet (2.1m)
Clearances can be reduced with shielding acceptable to local authorities. Reduced installation must comply
with NFPA 211 or CAN/CSA-B365.
14"
23"
ALCOVE
4 FOOT
MAX
9” 6”
1100 series only may be installed, using a listed double wall connector,
such as Security DL6 in Canada, the Simpson Duravent Plus DVL in
the USA or an equivalent double wall connector, into an alcove having
a depth of no more than 4 feet and a height of at least 7 feet.
The minimum clearances are as shown.
3.3 ALCOVE INSTALLATION
DO NOT INSTALL INTO ANY AREA HAVING A HEIGHT LESS THAN 7 FEET (2.1m)
(CEILING OF ENCLOSURE TO APPLIANCE BOTTOM, EXCLUDING HEARTH HEIGHT)
!
WARNING

EN
W415-1467 / A / 09.30.16
10
3.4 FLOOR PROTECTION
3.5 OUTSIDE AIR
The following are signs that a outside air kit may be required:
• When there is combustion present: Wood burns poorly, smoke spills, back-draft takes place and your
chimney does not draw steadily.
• In the winter there is too much condensation on the windows.
• Opening a window seems to alleviate the above symptoms.
• A ventilation system is installed in the house.
• Other devices are present that exhaust house air.
• The house has tight fitting windows and/or is equipped with a
well-sealed vapour barrier.
A. Connection from the appliance’s air intake to the outside is
mandatory in mobile homes only, either through a hole in the
wall or through the hole in the floor to line up with the knock out
in the leg model or the hole in the pedestal base.
B. Use a fresh air kit. Secure the aluminum liner by flaring the end once it is inserted through the hole
in the base of the leg or pedestal model. If the air intake is through the floor, the hole in the pedestal
back must be covered with sheet metal to avoid cold air spillage into the room. A cover plate is
available from your Wolf Steel Ltd. dealer. Avoid cutting away floor joists, wall studs, electrical wires
or plumbing. Seal around the outside pipe with insulation to prevent drafts.
C. Attach the rear knockout plate (located inside the ash pan for shipping purposes).
!
WARNING
IF ROOM AIR STARVATION OCCURS BECAUSE THE FRESH AIR INTAKE IS BLOCKED WITH ICE,
LEAVES, ETC., OR BECAUSE THE APPLIANCE DOOR WAS LEFT OPEN, OR DUE TO A STRONG
EXHAUST FAN OPERATING ETC., DANGEROUS FUMES AND SMOKE FROM THE OPERATING
APPLIANCE COULD BE DRAWN INTO THE ROOM.
99.1B
EMBER PROTECTOR:
This appliance must be installed on a non-combustible protector that extends to the front, sides and back of the
appliance as per the minimum requirements below.
NOTE: Ember protection is required for spark and ash shielding, not for limiting floor temperatures
from the radiant heat of the appliance. The appliance was designed and safety tested so that without
any protection, the floor will not overheat.
J
J
I
L
K
MINIMUM FLOOR PROTECTION
FRONT (I) SIDES (J) BACK (K) VENT (L)
CANADA 18” (45.7cm) 8” (203.2mm) 8” (203.2mm) N/A
USA 16” (40.6cm) 8” (203.2mm) 8” (203.2mm) 2” (50.8mm)

EN
W415-1467 / A / 09.30.16
11
3.6 MOBILE HOME
MODEL 1100ML, 1100C ARE APPROVED FOR INSTALLATION IN MOBILE HOMES IN THE UNITED
STATES & CANADA.
MODEL 1400ML, 1400C ARE APPROVED FOR INSTALLATION IN MOBILE HOMES IN THE UNITED
STATES ONLY.
NOTE: All mobile home approved appliances
must be secured to the floor of the mobile home.
For specific clearances, see “MINIMUM
CLEARANCES TO COMBUSTIBLES” section.
The appliance must be installed between ceiling
joists, with radiation shield and roof flashing, so that
the structural strength, insulation and waterproof
qualities of the home are not lessened. Seal with
silicone to maintain a vapour barrier at the chimney
and outside air pipe penetrations.
This model is equipped with holes so that the
appliance can be bolted securely to the floor.
RAIN CAP REMOVE TO
ALLOW FOR
TRANSPORATION
MOBILE HOME
ROOF FLASHING
RADIATION SHIELD
CEILING SUPPORT
TRIM COLLAR
APPLIANCE
BOLTED TO FLOOR
HEARTH PAD
OUTSIDE AIR CONNECTION
THROUGH WALL OR FLOOR
!
WARNING
DO NOT INSTALL IN SLEEPING ROOM.
THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND CEILING/ROOF MUST BE
MAINTAINED.
THE APPLIANCE MUST BE PROVIDED WITH OUTSIDE COMBUSTION AIR.
THE APPLIANCE MUST BE BOLTED TO THE FLOOR.
INSTALL ACCORDING TO 24 CFR, PART 3280 (HUD).
USE A CHIMNEY CERTIFIED FOR WOOD BURNING UL 103 S629, TYPE HT (2100°F).

EN
W415-1467 / A / 09.30.16
12
4.0 INSTALLATION
68.3C
!
WARNING
WEAR GLOVES AND SAFETY GLASSES FOR PROTECTION.
CAREFULLY FOLLOW THE INSTRUCTIONS FOR ASSEMBLY OF THE PIPE AND OTHER PARTS
NEEDED TO INSTALL THE APPLIANCE. FAILURE TO DO SO MAY RESULT IN A FIRE, ESPECIALLY IF
COMBUSTIBLES ARE TOO CLOSE TO THE APPLIANCE OR CHIMNEY AND AIR SPACES ARE
BLOCKED, PREVENTING THE FREE MOVEMENT OF COOLING AIR.
DO NOT DRAW OUTSIDE AIR FROM GARAGE SPACES. EXHAUST PRODUCTS OF GASOLINE ENGINES
ARE HAZARDOUS. DO NOT INSTALL OUTSIDE AIR DUCTS SUCH THAT THE AIR MAY BE DRAWN
FROM ATTIC SPACES, BASEMENTS OR ABOVE THE ROOFING WHERE OTHER HEATING APPLIANCES
OR FANS AND CHIMNEYS EXHAUST OR UTILIZE AIR. THESE PRECAUTIONS WILL REDUCE THE
POSSIBILITY OF APPLIANCE SMOKING OR AIR FLOW REVERSAL. THE OUTSIDE AIR INLET MUST
REMAIN CLEAR OF LEAVES, DEBRIS ICE AND/OR SNOW. IT MUST BE UNRESTRICTED WHILE
APPLIANCE IS IN USE TO PREVENT ROOM AIR STARVATION WHICH CAN CAUSE SMOKE SPILLAGE
AND AN INABILITY TO MAINTAIN A FIRE. SMOKE SPILLAGE CAN ALSO SET OFF SMOKE ALARMS.
NEGATIVE PRESSURE WITHIN YOUR HOME MAY INADVERTENTLY AFFECT YOUR APPLIANCE.
TO PREVENT CONTACT WITH SAGGING OR LOOSE INSULATION, THE APPLIANCE MUST NOT BE
INSTALLED AGAINST VAPOUR BARRIERS OR EXPOSED INSULATION. LOCALIZED OVERHEATING
COULD OCCUR AND A FIRE COULD RESULT.
DO NOT USE MAKESHIFT COMPROMISES DURING INSTALLATION. DO NOT BLOCK OR RESTRICT
AIR, GRILLE OR LOUVRE OPENINGS. DO NOT ADD A HOOD.
TO PREVENT PERSONAL INJURY KEEP HAND TOOLS IN GOOD CONDITION, SHARPEN CUTTING
EDGES AND MAKE SURE TOOL HANDLES ARE SECURE.
ALWAYS MAINTAIN THE MINIMUM AIR SPACE REQUIRED TO THE ENCLOSURE TO PREVENT FIRES.

EN
W415-1467 / A / 09.30.16
13
4.1 CHIMNEY
!
WARNING
NEVER INSTALL A SINGLE WALL SLIP SECTION OR SMOKE PIPE IN A CHASE STRUCTURE.
THE HIGHER TEMPERATURE OF THIS SINGLE WALL PIPE MAY RADIATE SUFFICIENT HEAT TO
COMBUSTIBLE CHASE MATERIALS TO CAUSE FIRE.
DO NOT CONNECT THIS APPLIANCE TO A CHIMNEY SYSTEM SERVING ANOTHER APPLIANCE.
TO AVOID DANGER OF FIRE, ALL INSTRUCTIONS MUST BE STRICTLY FOLLOWED, INCLUDING
THE PROVISIONS OF AIR SPACE CLEARANCE BETWEEN CHIMNEY SYSTEM AND ENCLOSURE.
TO PROTECT AGAINST THE EFFECTS OF CORROSION ON THOSE PARTS EXPOSED TO THE
WEATHER, WE RECOMMEND THAT THE CHASE TOP BE PAINTED WITH A RUST RESISTANT PAINT.
DO NOT FILL ANY FRAMED SPACE AROUND THE CHIMNEY WITH INSULATION OR ANY OTHER
MATERIAL. INSULATION PLACED IN THIS AREA COULD CAUSE ADJACENT COMBUSTIBLES TO
OVERHEAT.
MAINTAIN A MINIMUM 2” (50.8mm) AIR CLEARANCE TO ALL PARTS OF THE CHIMNEY SYSTEM AT
ALL TIMES (EXCLUDING THE CHIMNEY CONNECTOR). FAILURE TO MAINTAIN THIS 2” (50.8mm) AIR
CLEARANCE WILL CAUSE A STRUCTURE FIRE. NEVER FILL THIS SPACE WITH ANY TYPE OF MATERIAL.
DETAILED INSTRUCTIONS FOR INSTALLATION OF THE CHASE TOP, STORM COLLAR AND
TERMINATION CAP ARE PACKAGED WITH THESE PARTS. MINIMUM CLEARANCE TO
COMBUSTIBLES WILL VARY DEPENDING ON THEIR DESIGN.
DO NOT CUT RAFTERS OR CEILING JOISTS WITHOUT FIRST CONSULTING A BUILDING OFFICIAL
TO ENSURE STRUCTURAL INTEGRITY IS NOT COMPROMISED.
FIRESTOP SPACERS MUST BE USED WHENEVER THE CHIMNEY PENETRATES A CEILING/FLOOR AREA.
THE TOTAL HORIZONTAL VENT LENGTH SHOULD NOT EXCEED 40% OF THE CHIMNEY HEIGHT
ABOVE THE APPLIANCE. ALL HORIZONTAL SMOKE PIPE MUST SLOPE SLIGHTLY UPWARDS A
MINIMUM OF 1/4” (21.2mm) PER FOOT (METER) AND ALL CONNECTIONS MUST BE TIGHT AND
SECURED BY THREE SHEET METAL SCREWS EQUALLY SPACED. AN UNINSULATED SMOKE PIPE
SHALL NOT PASS THROUGH AN ATTIC, ROOF SPACE, CLOSET, OR SIMILAR CONCEALED SPACE,
OR THROUGH A FLOOR, CEILING, WALL OR PARTITION, OR ANY COMBUSTIBLE CONSTRUCTION.
DO NOT USE ANY MAKESHIFT MATERIALS DURING INSTALLATION.
63.8A
Your appliance may be connected to a factory built or masonry chimney. If you are using a factory built
chimney, it must comply with ULCS629 (Canada) or UL103 HT (USA) standards. It must therefore be a 6"
(152mm) HT Type (2100°F / 1149°C ) chimney. Use only specified components with no substitutions. It is
extremely important that it be installed according to the manufacturer's specifications. The manufacturer's
installation instructions and specified clearances should always be followed in accordance with local and
national codes. In Canada the CSA B365 and the CSA C22.1 installation codes are to be followed. In the
USA the ANSI NFPA 70 and ANSI NFPA 211 installation codes are to be followed.
Chimney and chimney connector must be in good condition and kept clean.

EN
W415-1467 / A / 09.30.16
14
4.1.1 CHIMNEY CONNECTION
Your chimney connector and chimney must have the same diameter as the appliance’s exhaust flue outlet.
The appliance pipe must be made of aluminized or cold roll steel with a minimum 24 gauge thickness. It is
strictly forbidden to use galvanized steel.
A 6” (152mm) diameter single wall chimney connector, used to connect the appliance to the chimney, must be
installed with the crimped end toward the appliance. This will ensure that the moisture which condenses from the
burning wood will flow back into the fire chamber. Each joint in the chimney connector must be secured with at
least three sheet metal screws.
For installation of your chimney connector, the following recommendations may be useful.
• The chimney connector must be short and straight. For optimum performance it is recommended that
all horizontal runs have a minimum 1/4” (6mm) rise per foot, with the upper end of the section toward
the chimney. For safe and proper operation of the appliance, see “INSTALLATION” instructions.
• To insure a good draft, the total horizontal vent length should not exceed 40% of the chimney height
above the appliance. All horizontal smoke pipe must slope slightly upwards a minimum of 1/4”
(6.4mm) per foot (meter) and all connections must be tight. In the case of vertical installation, the total
length of the connector can be longer and connected without problem to the chimney at the ceiling
level.
• There should never be more than two 90° elbows in the entire connector and chimney system. Never
start with a 90° elbow. Always go up vertically for at least 24 inches (61cm) from the flue collar before
using a 90° elbow.
• The connector must not pass through any combustible material, nor may it pass through a concealed
space (such as an attic, roof space, or closet). If passing through a wall, ceiling, or into a masonry
chimney, use either chimney components listed for that specific use, or means acceptable to local
authorities having jurisdiction over the installation.
This appliance must be connected to:
A. A chimney complying with the requirements for
Type HT chimneys in the Standard for Chimneys,
Factory-Built, Residential Type and Building Heating
Appliance, or
B. A code-approved masonry chimney with a flue
liner. Vent the stove into a masonry chimney or an
approved, insulated solid-fuel stainless-steel chimney
with as short and straight a length of 6” (152.4mm)
diameter chimney connector as possible. Connection
to a masonry chimney must be by a metal or masonry
thimble cemented in place.
TOWARD
APPLIANCE
FLUE GAS
DIRECTION
MALE END OF
CONNECTOR
OR CHIMNEY
PIPE
58.1B

EN
W415-1467 / A / 09.30.16
15
4.1.2 ADDING SECTIONS
A
dd chimney sections, according to the manufacturers installation instructions. The chimney must extend at
least, 3 feet (1m) above its point of contact with the roof and at least 24 inches (61cm) higher than any wall,
roof, building or obstacle within 10 feet (3m) horizontally.
59.1B
3 FT
(1m)
MIN
3 FT (1m)
MIN
10 FT (3m)
OR MORE
FLAT ROOF WALL
10 FT (3m)
TO NEAREST
ROOFLINE
RIDGE
LESS THAN
10 FEET
(3m)
24” (61cm) MIN 3 FT (1m)
MIN
24” (61cm)
MIN
LESS THAN
10 FEET
(3m)
3 FT (1m)
MIN 24” (61cm)
MIN

EN
W415-1467 / A / 09.30.16
16
4.1.3 TYPICAL THROUGH THE CEILING
A. Move the stove into position with the flue centered, midpoint between two
joists to prevent having to cut them. Use a plumb bob to line up the center.
B. Cut and frame an opening in the ceiling to provide a 2” (50.8mm) clearance
between the outside of the chimney and any combustible material. DO NOT
FILL THIS SPACE WITH ANY TYPE OF MATERIAL.
Nail headers between the joist for extra support.
Firestop spacers must be placed on the
bottom of each framed opening in any floor
or ceiling that the chimney passes through.
If your chimney system is enclosed within
the attic area, a rafter radiation shield is
required.
C. Hold a plumb bob from the underside of
the roof to determine where the opening in
the roof should be. Cut and frame the roof
opening to maintain proper 2” (50.8mm) clearances.
NOTE: The chimney must be supported at the ceiling or roof so that it’s
weight does not rest on the appliance and must comply with it’s
manufacturer’s instructions.
60.1B
HEADERS
FIRESTOP SPACER -
UNDERSIDE OF JOIST
FLOOR
PROTECTOR
ROOF
FLASHING
STORM
COLLAR
TERMINAL
COMBUSTIBLE
WALL
MAINTAIN
2” (50.8mm)
CLEARANCE
CHIMNEY
CONNECTOR
CHIMNEY
SUPPORT
LISTED CHIMNEY INSULATION
CEILING
SUPPORT
LISTED
CHIMNEY
SPECIFIED
CLEARANCE
TO STOVE

EN
W415-1467 / A / 09.30.16
17
4.1.4 TYPICAL THROUGH THE WALL
If possible, design the installation so that the connector does not pass through a combustible wall. If during
your installation you must pass through a combustible wall, check with your building inspector before you
begin. Also check with the chimney connector manufacturer for any specific requirements.
Consult with your dealer regarding special connection components available for use for wall pass-throughs.
Use only parts that have been tested and listed for use in a wall pass-through.
61.1A
FLOOR
PROTECTOR
ROOF
FLASHING
STORM
COLLAR
TERMINAL
COMBUSTIBLE
WALL
MAINTAIN 2”
(50.8mm) CLEARANCE
THROUGH EAVE
COMBUSTIBLE
CEILING
LISTED
CHIMNEY
COMBUSTIBLE
OUTSIDE WALL
TO
STOVE
2” (50.8mm)
CLEARANCE
INSULATED
“T”
WALL
SUPPORT
WALL SPACER
FOR OUTSIDE
WALL
SECTION
LISTED
CHIMNEY
PIPE
THIMBLE
CHIMNEY
CONNECTOR

EN
W415-1467 / A / 09.30.16
18
4.1.5 TYPICAL EXISTING MASONRY
You can also install your appliance using your existing
masonry chimney. To do so, follow the guidelines
below. Use a factory-built thimble, or construct
your own brick thimble. If you are using a masonry
chimney, it is important that it be built in compliance
with the specifications of the Building Code in
your region. It must normally be lined with fire clay
bricks, metal or clay tiles sealed together with fire
cement. (Round flues are the most efficient). The
maximum flue size is 8” (203.2mm) x 8” (203.2mm)
square or 6” (152.4mm) round. For greater diameters
it is necessary to install a 6” stainless steel liner.
62.1A
FLOOR
PROTECTOR
CHIMNEY
CONNECTOR
COMBUSTIBLE
WALL
CLEARANCE
EAVE
RAFTER
CLEARANCE WITH FIRESTOP
CEILING JOIST
THIMBLE

EN
W415-1467 / A / 09.30.16
19
To avoid being damaged during shipping, the appliance has been bolted to the
pallet and must be unbolted before the appliance can be installed.
A. Remove the four nuts and washers
from the underside of the pallet.
B. Lift the appliance up and away from
the pallet to clear the threaded studs
sticking through the pallet. Place
the appliance on its back onto a
protective surface such as a carpet or
blanket to avoid scratches during leg
installation.
C. Remove the four additional nuts from each of the four studs.
D. Use four of the nuts and washers removed above to install the legs as illustrated.
E. Lift the appliance up and gently set down on all four legs. Do not pivot appliance up on its legs, as
this could result in damage to the legs.
5.0 FINISHING
PINS
A. Pivot the door open and lift up to clear the
bushings. Do not pivot the door any further than
necessary.
B. Carefully set the door aside and pull the pins out
from the door bushings. Repeat in reverse order to
install the door.
C. Install the door in reverse order.
A. 1400C only: Remove the cast lid.
B. Remove cast top.
C. Pull pin from top door hinge. It is important to hold the door while
removing the pin. Pivot the door to clear the top door hinge. Lift the door
off of the lower pin. Do not pivot the door any further than necessary.
Repeat in reverse order to install the door.
D. Install the door in reverse order.
DOOR ADJUSTMENT: Loosen screws of top door bracket and slide side to side
to adjust the door hinge. Close door against paper seal to ensure proper door
seal.
5.1 LEG INSTALLATION (1100ML / 1400ML)
5.2 DOOR REMOVAL / INSTALLATION (1100ML / 1400ML)
5.3 1100C/1400C DOOR REMOVAL /INSTALLATION

EN
W415-1467 / A / 09.30.16
20
5.4 1400C CAST LID LEVELLING
A. Loosen the clinching nut. (4 places)
B. Tighten or loosen the levelling
screw in the adjusting nut.
C. Tighten the clinching nut.
LEVELLING
SCREW
ADJUSTING
NUT
CLINCHING
NUT
HINGE
BRACKET
CAST TOP
5.5 DOOR HANDLE INSTALLATION
DOOR
HANDLE
DOOR HANDLE
LATCH LOCK
NUT
DOOR
SPACER
FRONT VIEW
NOTE: Position of
door handle latch.
98.1
NOTE: DOOR MAY NOT BE AS
ILLUSTRATED
SPRING
WASHER
!
WARNING
BURNING YOUR APPLIANCE WITH THE DOORS OPEN OR AJAR CREATES A FIRE HAZARD THAT
MAY RESULT IN A HOUSE AND OR CHIMNEY FIRE.
DO NOT STRIKE OR SLAM DOOR.
NEVER REMOVE THE DOOR WHEN THE APPLIANCE IS HOT.
