NatComm EASY-TRANSFER User manual

Easy-Transfer
Two Extension Transfer Device
For Technical Assistance
Ph: 07 5596 5128
(9AM to 5PM QLD Time)
or email : i[email protected]

Page 2 Natcomm
DESCRIPTION
Our EASY-TRANSFER Line Sharer is designed to connect to ANY
TELEPHONE SOCKET and then allow TWO standard telephones
that are connected direct to it, to operate as extensions of your
ordinary single telephone line.
You can then transfer a call, from one of the telephone extensions
connected to EASY-TRANSFER, to the other telephone extension,
by dialing *.
When transferring a call, you will be able to privately communicate
with the other extension while the call is silently on hold. The party
on hold will be connected to either EASY-TRANSFER extension, as
soon as the other extension hangs up.
You can also make an intercom call, from one of the telephone
extensions to the other at any time, by simply dialing *. EASY-
TRANSFER will then ring the other telephone extension and once
the other party answers, you will be able to communicate just as if
you had made a telephone call.
EASY-TRANSFER is designed to work with all standard residential
telephones and cordless telephones.
NOTE - In the event of a power cut, only the
Telephones connected to Port EXT B will ring.
EASY-TRANSFER is supplied with a 12VAC/500mA Power Adaptor

Natcomm Page 3
PACKING LIST
Before commencing installation, please check that you have the
following items:
Description Quantity
EASY-TRANSFER Line Sharer 1
Power Supply 1
Telephone Cable 3
For technical assistance, please contact National Communications
on [phone], 9AM to 5PM Monday - Friday (QLD TIME).

Page 4 Natcomm
INSTALLATION PROCEDURE
1. Unplug all equipment from the telephone socket to be used.
2. Connect the TELEPHONE LINE port of EASY-TRANSFER to
ANY Telephone socket on your Telephone Line, using the
supplied Telephone Cable.
3. CONNECT your MAIN Telephone to the port of EASY-
TRANSFER labelled EXT B, using the cable currently used
with this device, or using one of our supplied cables.
(Note – Only this phone will ring if power is lost or disconnected from
Easy-Transfer).
4. CONNECT your OTHER Telephone or Telephone Device to
the port of EASY-TRANSFER labelled EXT A, using the cable
currently used with this device, or using one of our supplied
cables.
5. Connect the supplied 12VAC Telephone Adaptor, which is
supplied with EASY-TRANSFER and switch it ON.
6. Set your Dip Switch Settings as required – See Page 8.

Natcomm Page 5
INSTALLATION DIAGRAM

Page 6 Natcomm
OPERATION
Once your EASY-TRANSFER device has been installed as per our
instructions, you will be able to transfer an incoming or outgoing call
from any telephone connected to your line (including those
telephones not connected direct to an EASY-TRANSFER), to either
telephone connected to the EASY-TRANSFER.
INTERCOM CALLS BETWEEN TELEPHONES
CONNECTED TO EASY-TRANSFER
You can make an intercom call between telephone extensions
connected to the same EASY-TRANSFER by dialing *. You can
transfer a call, at any time, between telephone extensions connected
to the same EASY-TRANSFER, by dialing *. When transferring calls,
you will be able to privately communicate with the other extension
while the call is silently on hold. The party on hold will be connected
to either EASY-TRANSFER extension, as soon as the other EASY-
TRANSFER extension hangs up.
TRANSFERRING CALLS TO THE OTHER
TELEPHONE CONNECTED TO EASY-TRANSFER
To TRANSFER a call from 1 telephone connected to your EASY-
TRANSFER to the other, just press *. EASY-TRANSFER will RING
the Other Telephone until it is answered, or up to a maximum of 7
rings. Note: When the other Telephone Answers, you can
communicate in private while the Telephone Call is on Silent Hold.
To return to the Telephone Call, 1 party should hang up and the other
party will then have the call.

Natcomm Page 7
USER OPTIONS
PRIVATE MODE or PARTY MODE
You can set telephones connected to EASY-TRANSFER to operate
in either PRIVATE MODE or PARTY MODE :
PRIVATE MODE - When EASY-TRANSFER is set in PRIVATE
MODE, only ONE telephone connected to EASY-TRANSFER can
participate in a telephone conversation at the same time. Only the
first device to answer (or make a call) can access the telephone
conversation. The Other phone will not be able to hear or participate
in a conversation.
Note - Telephones NOT connected to EASY-TRANSFER cannot be blocked from the
line.
PARTY MODE - When EASY-TRANSFER are set in PARTY
MODE, Both telephones connected to the line can participate in a
telephone conversation at the same time.
TELEPHONES TO RING
It is possible to set ONE telephone connected to EASY-
TRANSFER to NOT RING whenever there is an incoming call.
NOTE - In the event of a power cut, ONLY THE TELEPHONES CONNECTED TO EXT
B WILL RING.
All Settings are selected by setting the Dip Switches located
on the underside of the unit (see page 8 for further details) to
the desired position.

Page 8 Natcomm
DIP SWITCH SETTINGS
SWITCH 1
If set to ON, the telephones connected to this unit will operate in
PARTY mode.
If set to OFF, the telephones connected to this unit will operate in
PRIVATE mode.
SWITCH 2
If set to ON, both telephones attached to this unit will RING with an
incoming telephone call.
If set to OFF, only the telephone connected to port B or this unit
will RING with an incoming telephone call.
SWITCHES 3 & 4 - Are not used

Natcomm Page 9
ACMA (Australia)
FCC (USA) and IC (Canada) COMPLIANCE
This product has been tested by an authorized independent laboratory to
comply with all Telephone Line and Electromagnetic Compliance
requirements for Australia, USA and Canada.
The Power adaptor supplied with this product complies with Australian, UL
(USA) and cUL (Canada) specifications.

Page 10 Natcomm
SPECIFICATIONS
Dimensions (mm) : 106 (W) x 106 (D) x 43
(H)Dimensions (inches) : 4.2 (W) x 4.2 (D) x 1.7 (H)
Weight : 6 ounce or 170g
Power Supply : 12V AC or 12V DC Power
Power Consumption : Idle - 0.5 W; Call – 0.75W
Line IN Connector : RJ 11 6 pin (2 center)
Line OUT Connector : RJ 11 6 pin (2 center)
Power Connector : 2.5mm barrel connector
ACMA, FCC & IC COMPLIANT : Supplier Number NC
Ringer Equivalence Number : 0.1 REN

Natcomm Page 11
NOTES

Page 12 Natcomm
WARRANTY
This device is guaranteed against defects from workmanship
for a period of two years (24 months) from the date of
purchase.
In the event of a problem, please call ph 07 55965 128 for
assistance and if necessary, a Return Authorization. You
should then return your unit, along with the proof of purchase
date, and a written statement about the nature of the
problem.
The Manufacturers obligation is solely to repair or the
product. The product may be replaced at the discretion of
the Manufacturer. The warrantor is not liable for any
incidental or consequential damages due to such defects.
This Warranty shall not apply to any unit which has been
subject to alteration, modification, abuse, negligence,
accident, external voltage/ lightning surge or used in any
manner contrary to these instructions.
The user is responsible for freight costs to the repair point.
The warrantor will be responsible for freight costs in
returning this unit back to the user.
Damage caused to this device or attached equipment by
lightning strikes or over voltage surge is not covered under
this warranty.
THE CASE IS SEALED AT THE FACTORY.
OPENING THE CASE WILL VOID THE WARRANTY.
