National Cycle Quantum hardcoated N30216 Quick start guide

Thank you for purchasing a National Cycle product. Read these instructions carefully and thoroughly before beginning work. Dealers, if installing this
windshield for a customer, please give them this manual upon completion. It contains information needed to properly maintain and use this product.
N30216 PARTS LIST
ITEM PART NO. DESCRIPTION QUANTITY
A20-290464-000 Full Size Windscreen 1
B44-447165-000 Grommets for Mount Holes (pre-installed) 4
Bag#1135
C44-449370-000 Clamp, Wraparound 4
D44-449380-000 Retaining Pin 4
E55-563131-000 Machine Screw, Phillips, #12 x 1.25 4
F49-490355-000 Washer, Flat, Black 4
TOOLS REQUIRED FOR ASSEMBLY
#2 or #3 Phillips Screwdriver
National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA P: 708-343-0400 / F: 708-343-0625 / E: [email protected] www.nationalcycle.com
©2021 National Cycle, Inc. Page 1 of 3 10-118608-000 Rev B 01/21
Description: Quantum® Hardcoated Polycarbonate; 3D
UTV Windshield; Full Size
Model: Polaris® RZR 900/1000 XP
Part Number: N30216 Installation Time: 30 min.
Quantum® is a registered trade-
mark of National Cycle Inc.
Assembly Instructions
and Owner’s Manual
A
C(x4)
D(x4)
F(x4)
E(x4)
B(x4)
BAG#1135
ATTENTION: Special notes and cautionary measures
which can prevent damage to the accessory or vehicle.
NOTE: Tips for facilitation of operation, control
and adjustment, as well as maintenance work.
Grommets, Gasket and Top Bracket are pre-installed on
Windshield.

WINDSHIELD INSTALLATION
Place all fasteners within reach of windshield
installation procedure.
Figure 1
Place Windshield on vehicle hood and against the front frame of
the vehicle. Then install and align the Wraparound Clamps (C).
Orient the clamps so that the male half (with embossed part
number) is toward the front of the vehicle.
Illustration A
Slide the Windshield up to engage
the visor or roof, with the top gas-
ket outside and the Windshield’s
top metal bracket inside the visor
or roof. The gasket should fully
engage the visor/roof surface.
Illustration B
Loosely install the following parts
to the Windshield and the four
Wraparound Clamps as shown in
illustration B.
(Phillips Screwdriver)
• Retainer Pins (D)
• Flat Black Washers (F)
• Machine Screws (E)
Note the hex shape of the
Retainer Pins and male
Clamp halves.
CHECK ALIGNMENT AND FINAL TIGHTENING
Figure 2
Check the alignment and position of the Windshield and make
sure it is even and symmetrical. Snug up the bottom seal
against the hood.
Securely tighten the Machine Screws in the four Wraparound
Clamps. (Phillips Screwdriver)
Your new Quantum® Hardcoated Polycarbonate Windshield
is now fully assembled.
Test ride for function and performance, and enjoy your new
National Cycle UTV Windshield!
National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA P: 708-343-0400 / F: 708-343-0625 / E: [email protected] www.nationalcycle.com
©2021 National Cycle, Inc. Page 2 of 3 10-118608-000 Rev B 01/21
PREPARATION
Carefully unpack your new windshield, sort the parts, and make sure you have everything required to complete the assembly.
Figure 1
Illustration B
Figure 2
Illustration A

CLEANING AND MAINTENANCE
To clean your windshield, wash with a clean soft cloth and plenty of warm water and,
if necessary, a non-abrasive soap such as dishwashing liquid. Flannel or soft cham-
ois make good cleaning cloths. Paint, glue residue or grease removal: Moisten
cotton wad with naphtha or turpentine followed by a wash as above.
National Cycle Shield Wash™ (N1401-01) makes a good daily cleaner and comes
with a handy travel-size bottle. Shield Wash is safe for all windshields and helmet
visors.
Do not clean polycarbonate in hot sun or high temperatures. Do not clean the screen
with household glass cleaners.
Do not allow brake fluid, alcohol, or strong solvents to contact the windshield.
RAIN REPELLENT
Do not use rain protective products made for glass. We recommend National Cycle’s
RainZip® (N1410-01) to keep your windshield clear in rainy weather.
National Cycle 3-Year Limited Warranty
Register Your Windshield Online at www.nationalcycle.com
National Cycle hereby warrants to the original registered owner of a National Cycle polycarbonate windshield for a period of three years
from the date of purchase against breakage. This limited warranty is expressly limited to the replacement of the polycarbonate windscreen.
This limited warranty does not include scratches, coating failure, cosmetic wear and tear, replacement of hardware, or any consequential
damages or expenses including labor cost of installation, removal and/or replacement, inconvenience, inbound freight expenses or damage
to any other component of the vehicle or any other accessories. Certain chemicals, generally known as acidic hydrocarbons, are known to
cause polycarbonate damage and will not be covered under this limited warranty. Please refer to the cleaning instructions supplied with all
National Cycle windshields. Visit www.nationalcycle.com for further details or call or write National Cycle Inc.
Ask for Shield Wash™ and RainZip® at your local dealer or visit
www.nationalcycle.com.
National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA P: 708-343-0400 / F: 708-343-0625 / E: [email protected] www.nationalcycle.com
©2021 National Cycle, Inc. Page 3 of 3 10-118608-000 Rev B 01/21
Never operate your vehicle with loose accessory mounting hardware. Check the hardware for tightness regularly.
UTVs are built with enough frame rigidity to withstand the moderate loads imposed on them by the foreseeable addition of an accessory(ies). If an accessory(ies)
adversely affects your vehicle’s stability, immediately remove the accessory(ies). Do not operate a vehicle that exhibits unsafe handling traits.
Have experienced service personnel correct any problem before driving with the accessory(ies) installed. For further questions concerning handling problems associat-
ed with an accessory(ies), contact your dealer, UTV manufacturer, or accessory manufacturer.
Caution: Do not clean polycarbonate in hot sun or high temperatures. Do not clean the screen with glass cleaners. Certain chemicals, generally known as acidic hydro-
carbons, are known to cause polycarbonate damage. Do not allow brake fluid, alcohol, or strong solvents to contact the screen.
Caution: Do not use rain protective products made for glass. We recommend National Cycle’s rainZip® (N1410-01) to help shed water in rainy weather.
Caution: Always face windshield forward (in direction of travel) while carrying on truck or trailer.
WARNING
WASH'N'WIPE™ WIPER KITS
This windshield is pre-drilled and prepped for the installation of National Cycle’s optional Wash'n'Wipe Wiper Kit.
Part No. N30216-WK
