USER MANUAL
SS-4 Stationary Shield
Patent Pending
Manufactured by:
Cellular Materials International, Inc.
1201 Five Springs Rd.
Charlottesville, VA 22902
[e-mail]
Distributor:
Nationwide Structures, Inc.
P.O. Box 55461
Virginia Beach, VA 23471
Ph: 888-430-0301 Fax: [phone]
[e-mail]

V 10262015A
2
Model ………………. SS-4
Protection level …..NIJ-IV
Steel…Astralloy, V2 armor plate, 0.5”thick
Glass …. Hawkins Glass, Laminated ballistic NIJ-4
Window area ….. 2 at 2 sq. ft. each
Weight 1100 lbs.
Max height…. 73”without awning
Max depth…. 41” without awning
Max width…. 36.5”
Window bolts ….. Grade 8 bolts
Awning material ….Astralloy V2 plate .25”
With a NIJ level III protection
Standard Color….. Powder Coat Black
Capability Chart:
Product Specifications:

V 10262015A
3
Moving the Shield:
To move the shield with a pallet
jack or fork lift, firmly lift and
remove the fork accesses doors on
both sides. Replace the fork access
doors once the shield is in
position.
Hoisting the Shield:
To hoist the shield, place an
appropriate hook or strap through
the eyelet.
Attaching the Awning (optional):
Align the through holes in the awning
with the through holes in the shield
roof plate. Insert (2x) the provided ½-
13 bolt with seated washer though the
aligned holes and fasten with a washer
and nut.

V 10262015A
4
Interior Cleaning Instructions for Ballistic Glass
1. Rinse with clean water or glass cleaner to remove abrasive dust and dirt.
2. Wash with soap or mild detergent using a soft cloth - DO NOT SCRUB. Rinse
and dry with a soft cloth.
3. To remove labels, stickers or grease, rub gently with a cloth wet thoroughly in
VM & P naphtha, kerosene or isopropyl alcohol. Wash and rinse. Do NOT allow
interior surface to come in contact with other solvents, razor blades, scrapers or
squeegees.
4. For repair or replacement contact Hawkins Glass.
Email: [e-mail], Phone: [phone].
Product Warranty
CMI will guarantee all workmanship to be free of defects for one year from date of shipment. This warranty covers
welding, assemblies and moving parts, such as wheels and castors, from manufacturing defects. This does not
cover damage from normal wear and tear, or misuse, abuse or damage caused by a hostile battle environment.
Any unauthorized changes made to the SS-4 will void this warranty. Paint is not covered by this warranty. Items
such as the glass will not be covered by CMI, but may be covered by the glass manufacturer’s own warranty.
DISCLAIMER AND PRODUCT USE AGREEMENT
THE PURPOSE OF MOBILE SHIELDS IS TO PROVIDE PROTECTION FROM SPECIFIC THREATS AND IT IS IMPOSSIBLE FOR CELLULAR MATERIALS INTERNATIONAL INC. (CMI)
TO PROVIDE PROTECTION AGAINST ALL SUCH THREATS OR UNKNOWN CONTINGENCIES. THESE SHIELDS ARE BUILT USING MATERIALS DESIGNED, MANUFACTURED
AND TESTED BY SUPPLIERS TO MEET A SPECIFIC THREAT, BASED UPON DATA THAT IS PROVIDED BY THE NATIONAL INSTITUTE OF JUSTICE (NIJ) PERFORMANCE
STANDARDS. THE PURCHASER AND THOSE USING MOBILE SHIELDS AGREE TO ASSUME ALL RISKS AND LIABILITIES WHEN USING MOBILE SHIELD SYSTEMS INCLUDING,
WITHOUT LIMITATION: RISKS AND LIABILITIES ARISING FROM INJURY OR DEATH OF ANY PERSON, AND RISKS AND LIABILITIES ARISING FROM DAMAGE TO, OR
DESTRUCTION OF, ANY PROPERTY. PURCHASERS AND USERS AGREE BY USE OF MOBILE SHIELDS TO INDEMNIFY AND HOLD HARMLESS CMI FROM CLAIMS, DEMANDS,
CAUSES OF ACTION, LOSSES, DAMAGES, PENALTIES, LIABILITIES, AND EXPENSES ARISING FROM, OR RELATING IN ANY WAY TO THE USE, TRANSPORTING AND
HANDLING OF MOBILE SHIELDS. CMI MAKES NO CLAIM OF A LEVEL OF PROTECTION OUTSIDE NIJ STANDARDS AND ONLY WHEN SUBJECTED TO NIJ TESTING
METHODS. CMI NEITHER ASSUMES NOR AUTHORIZES ANYONE TO ACCEPT ANY TYPE OF LIABILITY ON BEHALF OF CMI. MOBILE SHIELDS ARE DESIGNED TO PROVIDE
A LIMITED LEVEL OF PROTECTION IN VERY DANGEROUS SITUATIONS. PURCHASERS AND USERS AGREE, BY THEIR USE OF MOBILE SHIELDS, TO BEAR ALL
RESPONSIBILITY FOR THEIR OWN SAFETY.
CMI MAKES NO WARRANTY WHATSOEVER WITH RESPECT TO MOBILE SHIELDS, INCLUDING ANY (A) WARRANTY OF MERCHANTABILITY; OR (B) WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE WHETHER EXPRESS OR IMPLIED BY LAW, COURSE OF DEALING, COURSE OF PERFORMANCE, USAGE OF TRADE OR OTHERWISE.
IN NO EVENT SHALL CMI BE LIABLE TO ANY PARTY FOR ANY CONSEQUENTIAL, INCIDENTAL, INDIRECT, EXEMPLARY, SPECIAL OR PUNITIVE DAMAGES, INCLUDING ANY
DAMAGES FOR BUSINESS INTERRUPTION, LOSS OF USE, REVENUE OR PROFIT, WHETHER ARISING OUT OF BREACH OF CONTRACT, TORT OR OTHERWISE, REGARDLESS
OF WHETHER SUCH DAMAGES WERE FORESEEABLE AND WHETHER OR NOT ANY PURCHASER OR USER OF MOBILE SHIELDS WAS ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES.
IN NO EVENT SHALL CMI’S AGGREGATE LIABILITY ARISING OUT OF OR RELATED TO PURCHASE AND USE OF ANY PARTICULAR MOBILE SHIELD, WHETHER ARISING OUT
OF OR RELATED TO BREACH OF CONTRACT, TORT OR OTHERWISE, EXCEED THE TOTAL AMOUNT PAID TO CMI AS PAYMENT FOR THAT PARTICULAR MOBILE SHIELD.
THE FOREGOING LIMITATIONS SHALL APPLY EVEN IF THE REMEDIES UNDER THIS DISCLAIMER AND PRODUCT USE AGREEMENT FAIL OF THEIR ESSENTIAL PURPOSE.
