Natural Ozone Multipurpose Ozonator User manual
3
www.naturalozone.co.nz
Multipurpose Ozonator User Manual
About the Multipupose Ozonator .......................................................... 4
Specications ....................................................................................... 5
What’s included .................................................................................... 6
Before Operating .................................................................................. 7
Operating instructions .......................................................................... 8
Ozonated water .................................................................................... 11
Applications .......................................................................................... 13
Warranty ............................................................................................... 15
content
4Multipurpose Ozonator User Manual
About Your Natural
Ozone Multipurpose
Ozonator
The Natural Ozone Multipurpose Ozonator is specially designed for
household and car use.
It delivers ozone for various purposes to help keep your family safe and healthy including
but not limited to:
• Make immune-boosting ozonated drinking water.
• Make ozonated water for washing vegetables to remove harmful pathogens and pesticides,
also handy for washing benchtops.
• Use ozonated water to condition your skin and for dental and gum hygiene.
• Treat small spaces such as the car, fridge or cupboards with air ozone to remove
pathogens, mould, unwanted odours and harmful chemicals.
It runs on 240V AC or 12V DC which makes it perfect for car, caravan and mobile home use.
why ozone?
Ozone is a powerful oxidant which is the most effective disinfectant known. When ozone
(O3) comes into contact with viruses, bacteria, mould it quickly attacks their protective layer,
rendering them unviable. Likewise, it strips residual agricultural chemicals away from food,
improving food safety and shelf life.
Important: Please make sure you read these instructions carefully before use
5
www.naturalozone.co.nz
Multipurpose Ozonator User Manual
sPECIFICATIONS
Model Natural Ozone Multipurpose Ozonator
Electrical Input: AC100-240V, 50/60Hz (mains power)
DC 12V Power rating 12 watts
Ozone Output 300 mg/H at 2.5L/min dry air (RH 30%)
230 mg/H at 2.8L/min ambient air of RH85%
Operating Temperature 0℃~60℃
Product Dimension 223*162.5*54.5mm
Net weight 0.96 Kgs
Air sanitisation Up to 20m³
Accessories Power adaptor, silicon tube, stone diffuser, user
manual
Certication CE
6Multipurpose Ozonator User Manual
Power switch
Silicon tube
Ozone outlet
Stone diuser
Car adapter
mounting screws
Suction caps
for mounting
Timer indicator
Timer setting
what’s included
7
www.naturalozone.co.nz
Multipurpose Ozonator User Manual
caution before
operating
Read the User’s Manual carefully before
operating.
Human and pets must leave the car or
small room when ozone gas is being
used as an air purier, it is safe to enter
area 30 minutes after ozonation time has
been completed.
Mount the unit to the wall out of reach
of children using the screws or suction
cups provided.
Do not let any water enter the unit. It
should be mounted so that it is above
the height of the water you wish to
ozonate.
Use the power supply which comes with
the product. For use in the car, use the
12 V cigarette lighter option.
Avoid being in a conned space with
ozone gas.
Disconnect ALL power before
maintenance.
Make sure the air inlet at the back
side and other ventilation holes are
unimpeded.
Do not insert any metal objects into the
unit.
Moisten a soft cloth with water for
cleaning. Do not clean this appliance
with harsh chemicals, abrasives or
cleansers.
8Multipurpose Ozonator User Manual
1. Remove from the package and make sure
all components are present.
2. Select a location on a wall out of children’s
reach, adjacent to a power source. If using
in the kitchen or bathroom, make it higher
than the water faucet.
3. Connect the power cable to the power inlet
at the back. Tidy up the cables with the
cable slots in the product, and then plug
it to the mains. The unit will emit a beep
and the LED panel will display 4 lights to
indicate that power is connected.
4. When injecting ozone into the water,
connect the silicon tubing to the ozone
outlet, and another end to the stone
diffuser. Ensure good ventilation to avoid
breathing any excess ozone.
5. When using as an air purier, direct the
hose without stone diffuser to the area you
wish to treat and seal off that area as best
as possible.
6. If treating a vehicle or caravan, plug into
a 12V socket, and seal up. Ensure that no
humans or animals are inside the car or
van while operating.
7. There are two modes of operation:
1. Mode A - manual operation mode.
2. Mode B - automatic operation mode.
This option should be used if you wish
to run a regular cycle, for example 15
minutes per day. Please ensure that
no humans or animals will be subject
to breathing ozone gas if the unit is on
automatic mode.
OPERATING INSTRUCTIONS
9
www.naturalozone.co.nz
Multipurpose Ozonator User Manual
To set up manual operation (Mode A)
ACTION DIAGRAM ACTUAL
PICTURE DISPLAY
Plug product to the mains, four dots
should appear on the screen
Four dots
Press to enter Mode A
00:00
Press to start setting. The 4 digits start
ashing, then press again to increase
the operation time (5 minutes for every
press, up to 30 minutes), and press
to decrease the operation time (1 minute
for every press, down to 0 minute)
MM:SS
Press again to conrm the setting.
Product will start automatically.
MM: SS
(Counting
down)
When the timer counts down to zero,
product goes to standby. Press again
to stop at any time during operation
00:00
standby
10 Multipurpose Ozonator User Manual
To set up automatic operation mode (Mode B)
ACTION DIAGRAM ACTUAL
PICTURE DISPLAY
Plug product to the mains
Four dots
Press and buttons at the same time to
enter Mode B
OF:ON
Press to start setting. The last 2 digits
“ON” start ashing. This is to set the length
of operation time for the cycle.
Press to increase the operation time (5
minutes for every press, up to 30 minutes),
and press to decrease the operation
time (1 minute for every press, down to 0
minute.)
OF:MM
(MM means
operation
time to
be set in
minutes)
Press again to set the interval between
cycles. The rst 2 digits “OF” start ashing.
Press to increase the interval time (0.5
hours for every press, up to 24 hours), and
press to decrease the interval time (0.1
hours for every press, down to 0 hours)
H.H:MM (H.H
for interval
time, MM for
operation
time )
Press again, and product should start
running. When MM (ON) counts down to
zero, product stops making ozone, and the
last two digits show the next operation time
(MM), and the H.H (OF) starts counting
down. When H.H (OF) counts down to zero,
the machine starts again. This is how cycles
are formed. Eg, if you wish your machine
to run for 15 minutes per day, the display
should read 24:15
H.H: MM
(H.H for
interval
time, MM for
operation
time)
If you wish to reset the operation and
interval time, just press again to reset
OF:ON
If you wish to enter Mode A, press and
buttons at the same time to quit Mode B
Four dots
11
www.naturalozone.co.nz
Multipurpose Ozonator User Manual
The process of ozonating water can
produce two results:
1. Pure water free of bacteria, viruses,
spores, parasites, and chemicals.
Wonderful for drinking, or using in pools
and hot tubs.
2. If done properly, ozonated water can
actually ‘hold’ ozone for a short period of
time. With the proper use of a high purity,
high output corona discharge ozone
generator, and if the ozone is bubbled
through the water long enough, this
ozonated water can contain signicant
levels of ozone. This ozonated water, is
beyond pure. Full of ozone and oxygen,
this ozonated water is used topically as
a healing and antibacterial / antifungal
agent, on burns, scrapes, bruises,
in dentistry, surgery, and many other
applications. If you drink this water, you
are actually drinking ozone.
Ozonated water is considered by many
advocates to be highly benecial, regardless
of one’s health condition.
The effectiveness of ozonated water has to do
with the strength of Ozone in it.
The major potential benets of Ozone in
water include the following:
•It kills viruses, bacteria, fungi and algae on
contact.
• It breaks down harmful synthetic
chemicals into less dangerous molecules.
• It puries the blood of microorganisms by
rupturing their cell walls.
• It kills some cancer cells, slowstumour
growth, and may stop the spread of
cancer.
• It provides more oxygen to the brain.
• It boosts the immune system.
Your Multipurpose Ozonator is wall
mountable. Attach the air diffuser stone to
the silicon tube and insert it into a tall, thin
glass to ozonate drinking water. Plug in the
Multipurpose Ozonator and set the timer.
Ozonated water
12 Multipurpose Ozonator User Manual
Some further points to consider:
It is best to start off drinking 1 glass a day
and then you can slowly build up to drinking
8 glasses of water a day. Following this
procedure will minimise any detox reactions.
Wait at least 3 hours after your last meal
before drinking ozonated water.
After having ingested ozonated water, wait
at least 15 minutes before you eat or drink
anything.
Do not put anything else in the water. Just
use pure water. Preferably mineral or reverse
osmosis ltered water. Distilled water is ne
as long as you supplement with minerals
afterwards.
Drink ozonated water within 20 minutes, since
ozone will lose its strength and effectiveness
after that.
The container that the ozone will be bubbled
into must be made of glass, ceramic or
stainless steel. Ozone will cause plastic to be
dissolved into the water.
Take zinc, selenium, and vitamin E
supplements when drinking ozonated water in
order to support the detoxication process.
Since ozonated water can signicantly
accelerate detoxication, some people
experience cleansing symptoms, such as
nausea, headaches, and stomach or bowel
disturbances.
Duration
Depends on the amount and desired
concentration.
The following times should allow for a
maximum saturation of the water, however
you cannot over ozonate water, once it is fully
saturated you will just get ozone off gassing.
Best to leave a window open so you don’t
breathe in excess ozone.
- 1 glass (200-300 ml)
- a minimum of 5 to 7 min
- 500 ml - a minimum of 10-15 min
- 1 Litre - a minimum of 20 to 30 min
Ozone dissipates quickly so you need to drink
right away or within 20 minutes Alternatively
you can leave a bottle in the fridge and drink
slowly over 12 hrs. A stainless steel or silicon
cork in a wine bottle works well.
13
www.naturalozone.co.nz
Multipurpose Ozonator User Manual
applications
APPLICTIONS BENEFITS OPERATION NOTES
Purify air in
a small room
such as small
bedroom,
kitchen,
toilet, ofce,
smokers area.
Inactivate pathogens
(including bacteria
and viruses) in the
air and sufaces.
Oxidise strong smells
like kitchen cooking
smells, smoke or pet
smells.
Deliver ozone to
air directly for 30
minutes for every
10 m3, of space or
a little longer time if
necessary.
Remove the stone
diffuser. Keep the
window and door
closed. Keep people
and animals out of
the room until 30
mins after ozone
operation time stops
and then air out.
Car
sanitisation
Remove pathogens
in the air and
surfaces. Also
remove strong
odours.
Deliver ozone to the
air directly for 20
minutes. The timing
can be set up a little
longer as needed.
Keep the window
and door closed.
User should not stay
in while ozonating.
Open doors and
windows to air out
30 minutes after
operation has
ceased.
Pet house
sanitisation
Kill pathogens,
disrupt breading
cycle of eas,
remove odours.
Deliver ozone to pet
house for 5 minutes.
The timing can be
set up a little longer
based on need.
Remove pets, and
then seal windows
and doors. Allow
30 minutes after
ozonation before
reintroducing the
pets.
Wash fruit,
vegetables,
meat,
seafood, etc.
Remove chemical
residues on fruit &
vegetables, remove
hormone residues in
meat and seafood.
Kill bacteria, attain
longer shelf-life.
Wash the food, then
soak in water inside
a container, eg
kitchen sink; Bubble
ozone 10-20 minutes
via the stone diffuser.
Sink or container
should be glass,
ceramic or stainless
steel. Do not use
plastic vessels for
this job.
Disinfect
baby
products and
toys
Clean and sterilise
baby bottles,
dishware and toys.
Soak in water inside
a container, eg
kitchen sink; Bubble
ozone 10-20 minutes
via the stone diffuser.
Do not use hot water
or >35℃. Sink or
container should be
glass, or stainless
steel. Do not use
plastic vessels for
this job.
14 Multipurpose Ozonator User Manual
Skin
protection
and beauty
treatment
Ozonated water can
remove bacteria
in pores. Excellent
for acne cleanse.
Remove makeup
remains on skin.
Ozonate the water
for 10 minutes via
stone diffuser, use
as you would normal
water.
Ozonate directly
into bathroom sink.
Or use only glass,
ceramic or good
quality stainless steel
for ozonating water
in.
Drink
ozonated
water
Supports healthy
cell function, super-
oxygenates your
blood, all round
health tonic.
Ozonate the water
for 10 minutes using
stone diffuser and
then drink on an
empty stomach.
Use only glass
or good quality
stainless steel for
ozonating water.
Drink straight away
or keep in fridge for
up to 12 hours.
Brush teeth/
gum hygiene
Remove bacteria in
the mouth, care of
gums. Remove bad
breath.
Leave in mouth
and swish for 30
seconds. Brush
teeth and gums with
ozonated water.
Floss with ozonated
water.
Good support for a
tooth abscess also.
Athlete’s foot
treatment
Sanitise and
deodorise, may
support healing of
fungal and bacterial
infections.
Ozonate cold water
for 20 minutes and
then soak feet in
water.
Do not use hot water.
Keep ozonating
if treatment is
in ventilated
environment and you
do not risk breathing
ozone off gassing.
Disinfect
wash cloths,
toothbrushes,
dentures etc
Sanitise and remove
viruses and bacteria.
Can also clean with
freshly ozonated
water.
Soak item for 5 to 10
minutes in ozonated
water.
Always use ozone
resistant container
such as glass,
stainless steel or
ceramic.
For more ideas on application & uses, see the video
‘Sanitise, Deodorise, Revitalise!’ on the Natural Ozone
YouTube channel: youtu.be/fOyuIK17Z_I
For detailed instructions of how to make your own rapid
decontamination chamber to disinfect household items,
medical or fermenting equipment etc see the video
‘How to Decontaminate Your Shopping’ on the Natural
Ozone YouTube channel: youtu.be/InHuDQmZp8c
15
www.naturalozone.co.nz
Multipurpose Ozonator User Manual
The ozone generator comes with a one-year
limited warranty.
This device is warranted to be free from
all defects in material in normal use for a
period of 1 year from date of purchasing.
The warranty is granted only to the original
purchaser. This warranty provides for
the repair or replacement of the unit,
replacement product or parts may include
re-manufactured or refurbished parts or
components.
This warranty does not cover parts of the
unit that require replacement under normal
use. Any damage or malfunctions caused by
negligence, abuse, or use not in accordance
with the owner’s manual, including water
damage are not covered by this warranty.
Likewise, any defects or damage caused by
unauthorized service.
The right of nal interpretation on after-sales
services and instructions is owned by the
manufacturer.
warranty
Table of contents
Other Natural Ozone Medical Equipment manuals
