Nature Power Solar Security Light 1600 User manual

SAVE THESE INSTRUCTIONS
Solar Security Light 1600
User Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #22245
V1.1-M 1Nov2019

Page 2 of 8
⚠WARNING
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the
product was designed.
Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. It
will be a safer experience and do the job better at the capacity for which it was intended. DO
NOT use this equipment for a purpose for which it was not intended.
Industrial or commercial applications must follow OSHA requirements.
Important Safety Information
Thank you for choosing a Nature Power Product.
Save the receipt and these instructions. It is important that you read the entire manual to become
familiar with this product before you begin using it.
This product is designed for certain applications only. the distributor cannot be responsible for
issues arising from modification. We strongly recommend this product not be modified and/or used
for any application other than that for which it was designed. If you have any question relative to a
particular application, Do not use the product until you have first contacted the distributor to
determine if it can or should be performed on the product.
For technical question please call 1800-588-0590
WARNING
This product can expose you to chemicals, including Di (2-ethylhexyl) phthalate (DEHP)
which is known to the State of California to cause cancer, birth defects or other reproductive
harm. For more information, go to www.p65warnings.ca.gov
ATTENTION
ce produit peut vous exposer aux produits chimiques, y compris les di (2 - éthylhexyl)
phthalate (dehp) qui est connu de l'État de californie pour causer le cancer, les
malformations congénitales ou d'autres dommages de reproduction.pour de plus amples
renseignements, aller à www.p65warnings.ca.gov
harm. For more information, go to www.p65warnings.ca.gov

Parts List
Reference Part Description Quantity
1 Lamp 1
2 Solar Panel 1
3 Screws and Anchors (pack) 1
4 Light Mounting Bracket（Removable）1
5 Manual 1
Page 3 of 8
1
345
2
Intended Use
The 205-LED Solar-Powered Motion Security Light delivers twice the illumination and versatility. With
the included mounting plate, you have the option of positioning on a flat wall to illuminate a large area
or on a corner to light two separate areas. Each light head adjusts to suit your needs. Motion detection
automatically activates the lights when motion is detected from up to 40 feet.
Technical Specifications
Property Specification
Lumen 1600 Lumens Max / 10 Lumens at night light mode
LEDs 205 LEDs (6000K / 3000K)
Motion Sensor Distance and Range 40 feet and 120 degrees

1. Lamp Unit Installation
• Mounting your light requires a screwdriver, pencil, and (in some
circumstances) a power drill.
• Slide the bracket off from the light housing (as picture shown) then
place the mounting bracket on the surface you wish to mount to.
• Mark with a pencil the position of the mounting bracket screw holes.
This will enable you to pre-drill your screw holes.
• Once the mounting bracket is installed, ensuring all screws are tight, you are ready to position
your light.
• Carefully route the wire from the solar panel to the lamp and plug it into the power socket.
• Adjust the motion sensor to your desired position. Your light is now installed and ready to charge.
Assembly Instructions
Note: The lamp unit should be mounted 6.5-9 feet (2-3 meters), from the ground to ensure motion
detection is optimized.
 Secure the bracket to the solar panel with the screw provided
 Set the bracket on the surface and secure in place with larger screws provided.
 Adjust the angle of the solar panel to ensure it receives optimum sunlight.
Note: The Solar Panel is equipped with a length of wire. Ensure that the wire will reach the desired
position of the lamp before making the final installation.
Before Each Use
Solar lights require sunlight to function properly. Extended periods of cloudy weather will cause
shorter runtimes. Shade on the solar panel is to be avoided. The solar panel may be cleaned with a
clean damp cloth. Do not use soap, solvents, or abrasives. A regular visual inspection is
recommended. Ensure the solar panel is free from debris and in a location where it will receive
several hours of sunlight each day. Ensure the light is facing the desired direction and that there are
no nearby alternate light sources that may interfere with the motion sensor.
Page 4 of 8
3，Location of the Solar Light
Solar powered lights require sunlight to recharge the internal batteries. For best results, locate the Solar
Panel in a position where it will receive direct sunlight, and is generally free from cover and shade.
2，Wall or deck mounting of solar panel

Page 5 of 8
Located at the back of the light housing, push the button to
switch light color, 3000K Warm white or 6000K White.
4，How to Use Control Dials
The Solar Motion Light has 3 dials which control the light’s duration,
sensitivity to light, and sensitivity to motion.
LUX (Light Level)
The LUX dial adjusts the sensitivity to darkness. If set to the maximum
level, the light will go on in daylight. If set to the minimum level,
the sensor will only trigger the light to turn on at dusk or when it is dark
out. This is the ideal position for general use. Please note that ambient
light will affect the sensor.
Time
The time dial sets the duration the light will stay on when triggered.
The duration is adjustable from 8 seconds to 2 minutes. Rotating the
dial clockwise will increase the duration the light will stay on.
SENS (Sensitivity)
The SENS dial adjusts the sensitivity of motion detection:
1. Minimum position – Low Range: large movement
is required to trigger the light to turn on.
2. Mid Position - Medium setting.
3. Maximum position - Maximum range: the smaller movements will trigger the light to turn on.
Operating Instructions
1，Before the Solar Motion Light can operate to its full capacity, allow the unit to charge in sunlight for
2 days with the solar panel wire connected to the light. Charging should be done with the unit in the
“OFF” position.
2，Located at the bottom of the Battery Housing there is a OFF/AUTO/ON switch:
“AUTO” position, the light will turn on automatically when motion is detected. then both light head
turns on after the motion detect, Red warning will be flashing all the time at night.
“OFF” position, the light will remain off and will not detect any movement
"ON" Position, all the three light head on and maximum brightness.
3，Light Color switch




Page 6 of 8
Maintenance
Maintain the solar powered light by adopting a program of conscientious repair and maintenance in
accordance with the following recommended procedures
Maintenance Interval Maintenance Point
First Use
Allow the solar panel to charge the light for 2 sunny days.
Observe the solar panel once installed for one day. Ensure
that it is not shaded at any time during daylight.
Observe the light once installed during the evening. Ensure
there is no alternate light source that will interfere with the
light’s sensors.
Seasonally
Visually inspect the solar panel and light to ensure both are
clear of debris and dirt.
Observe the solar panel during one sunny day to ensure that
as the suns position has changed in the sky, the solar panel is
still receiving optimal sunlight throughout the day.
During the Winter
Check the solar panel. Ice should not be allowed to form on
the solar panel as the freezing can damage waterproof seals.
Adjust the angle of the solar panel to the sun’s lower position
in the sky. This will maximize the amount of sunlight received
and help allow any water or snow that accumulates on the
panel to slide off.
Troubleshooting
Use the table below to troubleshoot problems before contacting service personnel or your local
dealer. If the problem continues after troubleshooting, call your local dealer for assistance.
Failure Possible Cause Corrective Action
Light does not
stay on as long
as it did
previously or it
flashes.
Batteries are not fully charged.
Ensure the solar panel is in a location
where it will receive maximum sunlight
during daytime hours.
Turn the light to the OFF position and
allow the solar panel to charge the
batteries for 2 sunny days
Solar panel is not receiving enough
sunlight and not able to recharge
batteries.
Clean the solar panel with a clean,
damp cloth.
It is winter and there is not as much
sunlight as during summer, and the
solar panel is not able to recharge the
batteries.
Ensure the solar panel is located in a
place where it will receive the
maximum amount of sunlight during
the day. Remove any object that
throws shade on the solar panel. Tilt
the solar panel so that it is
perpendicular to the sun.

Page 7 of 8
Failure Possible Cause Corrective Action
Light does not
turn on.
Batteries are not charged.
Ensure the solar panel is in a location
where it will receive maximum sunlight
during daytime hours.
Turn the light to the OFF position and
allow the solar panel to charge the
batteries for 2 sunny days.
Clean the solar panel with a clean,
damp cloth.
Switch is in wrong position Move the switch to the AUTO position.
Rechargeable batteries are at the end
of their life.
Replace the batteries with new
rechargeable batteries of the same
type and size.
Battery Replacement:
1. Batteries are located in the battery
housing located at the back of the
lamp.
2. Remove Screws from front of the
battery housing to access
batteries.
3. Replace batteries with
rechargeable batteries of the
same type and rating
4. Reassemble battery housing.
Sensor is malfunctioning.
Reset the Sensor:
1.
2.
Take the light into a dark room and
then switch to the Auto.
Activate the motion sensor in the
dark.
3. Once the light turns on, the
sensors are reset.
4. Wait until the light turns off before
returning the product to a lit room
or area.

Nature Power warrants our products to the original purchaser that this product is free from defects in
materials and workmanship for the period of one year from date of purchase. In the case of product
defect, contact Nature Power customer service to receive troubleshooting. If defective part or unit
should be returned, a Return Authorization Number must be issued by Nature Power and the defective
part or unit should be returned to the authorized location at the purchasers’ expense. A dated proof of
purchase is required to receive warranty service. Once received at authorized location and defect
proves to be the result of defective material and workmanship, the defective part or unit will be replaced
at warrantors’ option and returned to the original purchaser at warrantors’ expense. No refunds will be
granted by the warrantor, in the event of buyer’s remorse please contact your point of purchase within
and in adherence to their return policy. Refunds are granted at the retailers’ discretions.
Limited Warranty
!"#$%#&'()*$'*&+$*,-#&!(.#-&!-(/,'*%&*(&$'0,1-#&2(-#&1)3(-2$*1()4!
"#$%%#&$$#%&'%
()*+,)-./012+31020+4/5.675+8!
3337)-./012+31020+4/5.675+8!
Made in China
