16335 Nauticam Cinema Gear Set
for Laowa 24mm f/14 2x Macro Probe
&
16336 N120 Port daptor for Laowa 24mm
f/14 2x Macro Probe
Instruction Manual
F
OREWORD
Thank you for your purchase of a NAUTICAM product.
At NAUTICAM, we pride ourselves in the ability to recogni e the requirements
of professional as well as amateur underwater photographers and fulfill them
through the innovative designs of our products. We strive to achieve a high
level of user-friendliness by allowing stress-free installation and easy
operation of all important functions of the camera.
Please read this manual carefully before using the product, this will maximi e
its performance as well as its lifetime.
W
RR NTY
All NAUTICAM Products are warranted against any material and
manufacturing defects for two years from the date of purchase for consumer
use. This warranty only applies to products purchased from authori ed
NAUTICAM dealers and does not extend beyond the original retail purchaser.
To return your product for service, please contact your regional authori ed
service centre(s). Please note that this warranty only applies when the product
is purchased in the territory where the service centre is located.
NAUTICAM does not hold responsibility for damage, of any nature, to any
equipment used with and/or placed within our products.
NAUTICAM accepts no liability for any loss of captured images or the inability
to capture images even if it is due to the malfunctioning of our products.
Unauthori ed modifications and/or repairs of our products will automatically
invalidate the warranty.
P
RE
-
C UTIONS
· After installation of the port adaptor and extension ring, please make
sure the O-ring (s) are free from debris and uneven surface issues.
· A water-tight test without the camera inside the housing is highly
recommended after the changing of port and O-ring(s).
· Do not use lubricants from other brands with the silicone rubber O-ring
on this housing, only use the lubricant provided by NAUTICAM.
· Discontinue use immediately should you notice any leakage.
· Do not open the product in a wet or sandy environment. Protect the
interior from moisture and debris in order to prevent malfunction or
leakage.
· Defective products should be shipped to our distributors for service,
unauthori ed disassembling and/or modifications could result in
malfunction or leakage.
I
DENTIFIC TION OF
16335
P
RTS
I
DENTIFIC TION OF
16336
P
RTS
M
OUNTING THE
G
E R ON LENS
1. Insert the Focus c-ring and Iris C-ring in this order as
shown and place them over the lens
Iris gear
Iris C
-
ring
for Cine
Spare
Rubber grips
6x
Focus gear
Iris C
-
ring
for Standard
Focus C
-
ring
for Standard
Focus C
-
ring
for Cine
2. Insert the focus gear on the focus c-ring, then gently
push down the gear towards the bottom until it
cannot go any further.
**16335
Nauticam Cinema Gear Set for Laowa 24mm f/14 2x
Macro Probe is designed for both Laowa 24mm cine version
and standard version Lenses to use with N120 cinema
housing, such as RED DSMC2, C200, EVA1 etc.
It Includes a set of Iris and Focus gear (controlled by oom
and focus knob of the housing), and a set of Iris and Focus C-
Ring for cine version lens and another C-Ring set for standard
version as shown above.
Please use corresponding c
-
rings
Locknut
Alignment mark
Spare O
-
rings
**1633
6
N120 Port Adaptor for Laowa 24mm f/14 2x Macro
Probe is designed for Laowa 24mm Lenses to use with N120
DSLR housing and N120 cinema housing.
This N120 port adaptor is necessary to use with an extension
ring
70
, such as 21271 and 21170.

Current as of 2019-04-09
M
OUNTING N EXTENSION RING ND PORT ON THE HOUSING
3. Insert the Iris gear on the Iris c-ring, then gently
push down the gear towards the bottom until it
cannot go any further as focus gear
To remove the gear set, reverse the above steps.
The tightness between the gear set and the lens can
be adjusted by removing or adding rubber grips on
either sides of the plastic c-ring. Spare rubber grips
are included in the package.
1. Firstly mount the lens. Then plug a battery cable
before mounting an extension ring and a port.
2. Confirm that the Extension Ring is unlocked, with
the locking lever pointing upwards as shown.
3. Align the “o” mark on the port adaptor with the
“I” mark on the extension ring.
Gently push the port adaptor towards the
extension ring until it cannot go any further.
4. Turn the port adaptor clockwise until the “o” mark
on the port adaptor aligns with the “o” mark on
the extension ring.
.
5. Push the locking device inwards. Ensure that the
extension ring is securely locked with the port
6. Before mount the extension ring and port adaptor
on the housing, unscrew the locknut of the port
adaptor only halfway.
*
I
nside has a white o
-
ring

Current as of 2019-04-09
Remark: All Nauticam product manual will be changed to e-manual in end of
2018. Please download corresponding product manuals on Nauticam.com
website, or contact us for e-manuals.
8. Lock the extension ring into the place by turning the
port locking lever to the inward position.
To ensure that the extension ring is securely
mounted, confirm that the green line on the safety
button on the port locking lever is visible.
9. Fasten the locknut to squee e the inside O-ring as
well as grasp the lens for sealing
**The recommended depth rating of the lens is 30m.
7. Align the “o” mark on the extension ring with the
“o” mark on the housing.
Gently push the extension ring towards the housing
until it cannot go any further.
