Instruction Manual for
M67/M77 Flip Diopter Holders
PN# 25101, 25103, 25108, 25109
F
OREWORD
Thank you for your purchase of a NAUTICAM pro uct.
At NAUTICAM, we pri e ourselves in the ability to recognise the requirements
of professional as well as amateur un erwater photographers an fulfill them
through the innovative esigns of our pro ucts. We strive to achieve a high
level of user-frien liness by allowing stress-free installation an easy
operation of all important functions of the camera.
Please rea this manual carefully before using the pro uct, this will maximise
its performance as well as its lifetime.
W
ARRANTY
All NAUTICAM Pro ucts are warrante against any material an
manufacturing efects for two years from the ate of purchase for consumer
use. This warranty only applies to pro ucts purchase from authorise
NAUTICAM ealers an oes not exten beyon the original retail purchaser.
To return your pro uct for service, please contact your regional authorize
service centre(s). Please note that this warranty only applies when the pro uct
is purchase in the territory where the service centre is locate .
NAUTICAM oes not hol responsibility for amage, of any nature, to any
equipment use with an /or place within our pro ucts.
NAUTICAM accepts no liability for any loss of capture images or the inability
to capture images even if it is ue to the malfunctioning of our pro ucts.
Unauthorise mo ifications an /or repairs of our pro ucts will automatically
invali ate the warranty.
I
DENTIFI ATION OF
P
ARTS
*There are two alignment pins at the bottom of the hol er, by relocating the
two screws to the threa e holes aroun the hol er, the position of the
hol er can be change .
#25101 M67 Flip diopter holder is used as an example in this instruction
manual, #2510 will be slightly different in term of appearance.
M
OUNTING THE
F
LIP
H
OLDER ON A
P
ORT
Press the lever an flip the iopter hol er to the si e then remove the locking
ring from the flip iopter hol er.
Align the two positioning screws on the back of the hol er with the slots on
the front of the port.
The position of the flip iopter hol er can be change by relocating the two
screws in the threa e holes aroun hol er.
M67 threa
Release lever
Locking ring
Alignment pins
*
Press Flip out
1
2

Current as of 2021-6-24
Fasten the hol er by screwing the locking ring into the threa on the front of
the port.
To un-mount the flip iopter hol er from the port, reverse the above steps.
S
PE IFI ATIONS
Threa size for
iopter:
M67
Threa size for ports:
25101: M67
25103: M77
25108: M67
25109: M77
