Nauticam NA-R7 User manual

NA - R7
For Canon EOS R7 Mirrorless Camera
User Manual
Housing
APS-C- MIL
PN 17338
Introduction 2
2
3
4
7
8
Package Contents
Important Instructions
Part Names and Functions
Housing Mount
Opening the housing
9Closing the housing
10
17
Preparation for Use
Optional Accessories
20
21
22
Care/Storage
Warranty
Specifications
Sep, 2022

2
INTRODUCTION
PACKAGE CONTENTS
Thank you for purchasing this Nauticam product.
Before using the product, please read this manual thoroughly to familiarize yourself with full scope of functions on the
product as well as ensuring that you will use the product correctly.
Make sure that you have all the included items listed below before using this product.
If some items are missing or damaged, contact your local Nauticam dealer.
After purchase, we suggest that
you reuse all packaging materials
for future travelling.
Panasonic CR2032 Battery
(pre-installed for Moisture Alarm)
Spare Main O-ring
Padded Travel Case Allen key set
O-ring Remover Manual Instruction Card
NA-R7
(2 x Handles with Mounting Balls, 1 x Housing Cap,
2 x Optical Fiber Mount Caps, 2 x Stainless Steel Handle Brackets)
Lubricant

3
IMPORTANT INSTRUCTIONS
A water-tight/vacuum test without the
camera inside the housing is highly
recommended when using the system for
the first time and after the changing of
port and O-ring(s).
Store the housing in a robust, shock-proof
container during transportation; avoid
transporting with any equipment, such as a
camera, inside the housing.
Care must be taken when opening the
housing, as pressure may build up inside
the housing which increases the opening
force.
Do not leave the housing and the monitor
in direct sunlight for prolonged periods.
Defective products should be shipped to
our distributors for service, unauthorized
disassembling and/or modifications
could result in malfunction or leakage.
Do not use lubricants from other brands
with the silicone rubber O-ring on this
housing, only use the lubricant provided by
NAUTICAM.
Discontinue use immediately should you
notice any leakage.
When travelling by air, do not travel with dome
port installed as this may lead to a pressure
difference between the atmosphere and
inside the housing.
This product is not intened for use by
children, or persons with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they
are supervised and/or given instruction by
a responsible person concerning use of
the product to ensure that they can use it
safely.
1
3
5
7
9
11
4
6
8
10
2
Do not open the product in a wet or sandy
environment. Protect the interior from
moisture and debris in order to prevent
malfunction or leakage.
Do not store the product in an environment
of high humidity.

4
PART NAMES AND FUNCTIONS
TTL Indicator window 0.66x Viewfinder
Menu button TTL on/off button
AE lock button
Right button Down button
Delete button
AF point selection/magnify/reduce button
Up button
Info button
Multi-controller
Left button
1 2
3 4
5
7
9
11
13
15
6
8
10
12
14
Rear View
3
1
2
6
4
5
7
9
11
10
A
Access lamp
Moisture alarm window Quick Control/Set buttonA
15
14
13
12
8

5
PART NAMES AND FUNCTIONS
M24 Accessory port
Multi-function lock button
Rear dial
Optical fiber cable connection
Lens release button
M14 Accessory port
ISO speed setting button
M14 Accessory port
Port index mark
1/4” Threaded holes
M10 Accessory port
Accessory mounting ball
Mode dial
Main switch
Focus mode switch
1
5
9
13
15
2
6
10
14
3
7
11
4
8
12
Top + Front Views
87
4
6
5
9
10
14
13
15
11
12
1
3
2

6
PART NAMES AND FUNCTIONS
Back + Side Views
Sacrificial zinc anodes
Port locking lever
REC lever
M-Fn lever
Front dial
1/4” Threaded tripod holes
Playback lever
AF-ON lever
Housing unlock button
Shutter release lever
Zoom/Focus knob
M5 Threaded holes
Port lock safety button
3
7
11
9
13
1
4
8
12
10
5
2
6
3
9
8
10
13
12
11
1
2
5
4
6
7

HOUSING MOUNT
M14 Accessory port
M14 Accessory port
1
2
Compatible accessoriesHousing mount
25624
17959
M14 Vacuum Valve II (Optional)
Housing Mounting ball with 1/4’’ screws
25221
25224
25033
25017
25020
M10 Strobe mounting ball
M10 Strobe mounting ball with hole
Standard HDMI bulkhead with M16 thread
M14 6 pin bulkhead for Canon system
Canon hotshoe plug to a M14 Nikonos
bulkhead (x and ground connection only)
1
M10 Accessory port
1/4” -20 mounting threads
M24 Accessory port
3
4
525086
25077
M24 adaptor for HDMI 2.0 cable
HDMI 2.0 cable
17954
17960
25218
Universal tripod plate
Universal Quadra-Pod Plate for Nauticam
Housings
Mounting ball set for tripod legs
1/4” -20 mounting threads
M5 Threaded holes
6
7
5
43
2
6
7
7

8
OPENING THE HOUSING
*
drawings as illustrations onl
y
1
2
3
depress housing unlock button
turn housing lock latch
anti-clockwise to open the
housing
flip open the back housing
when lock latch is aligned to
‘open’ position

9
CLOSING THE HOUSING
*
drawings as illustrations onl
y
1
2
3
before closing the housing, clean
and lubricate the main O-ring
make sure nothing is caught
between front and back housing
and that they are fully aligned
before locking
main O-ring
insert the housing shaft into the
shaft hole and then rotate the lock
latch clockwise until you hear and
feel it click into place
housing locked in place securely

10
PREPARATION FOR USE
Installing the Camera - housing tray attachment
1
4
2
3
unlock camera tray lever and
remove the tray from the housing
lock camera tray
* place the zoom/focus knob in
place and make sure it is engaged
with lens gear
*gently push the actuator of ON/OFF le-
ver downwards make sure it is engaged
with the lever on the camera
* pull out the actuator for focus
mode switch on the camera tray as
shown
attach the camera tray by tightening
the tray screw into the tripod socket
of the camera
place the actuator on the camera
tray in place and make sure it is en-
gaged with the focus mode swtich
on the camera
* pull out the zoom/focus knob if
installing the camera with lens and
gear attached
* lift up actuator of ON/OFF lever each
time before installing the camera
slide the camera tray back into the
housing along the tray rail
*
drawings as illustrations onl
y

11
PREPARATION FOR USE
Port Mounting
1
2
3
depress port lock safety button
and rotate anti-clockwise
lubricant the port O-ring before
mounting
align index mark
push port assembly straight in
rotate locking lever clockwise to
lock
*
drawings as illustrations onl
y

12
PREPARATION FOR USE
Coating housing O-ring
Main O-ring
remove the main O-ring using an O-ring remover
clean the O-ring groove with a cloth and ensure
that it is free from salt or other foreign materials
lightly coat it with provided lubricant
return the main O-ring by slowly pressing from
one corner to the whole perimeter
1
2
3
4
*
drawings as illustrations onl
y

13
PREPARATION FOR USE
Setting up moisture alarm
Alarm ON/OFF
CR2032
Battery
* drawings as illustrations onl
y
*please contact our authorized service centers if testing fails
*please refer to page 15 for complete vacuum system guidance
1
3
2
4
remove battery
insulation film
switch on the alarm
- the moisture alarm
window will flash in
BLUE when it is working
correctly
test the alarm
- connect the wires with a
dampened cotton bud; the
alarm will give a repeating
‘beep’ and the mositure alarm
window will flash RED
press the battery down until it
click into place

14
PREPARATION FOR USE
Changing lens/port without opening the housing
1
4
2
3
If using with vacuum valve :
remove the cap from the vacuum
valve and press the red button to
release pressure before unlocking
port lock
If using without vacuum valve,
please follow from step 2
unlock port lock and remove port
assembly
press the blue button to reset
vacuum alarm before replacing
port
replace port assembly
then reset vacuum valve system
using hand pump and close the
cap after
*please refer to page 15 on complete vacuum system guidance
*
drawings as illustrations onl
y

15
Vacuum valve system
remove the plug of M14 accessory
port from the housing
remove the cap from the vacuum
valve
slightly lubricate the o-ring and
make sure the o-ring is in place
then tighten the vacuum valve to
the housing with the tool provided
connect hand pump to the valve
and pump several times until it
reaches the target vacuum level
close vacuum valve cap
* It is recommended to leave the housing
for at least 20mins to ensure it is sealed.
If the LED light changes from steady
green light to rapidly flashing yellow light,
that means there is a leakage. Please
check every O-ring and then conduct the
vacuum test again.
hand pump
moisture alarm
window
accesory port
on housing
vacuum valve
1
2
Moisture alarm window colour indication :
Steady Blue
Flashing Blue
Steady Green
Steady Red
Flashing Yellow
Flashing Red
Alternating
Blue and Red
device is turned on
standby mode,
ready for pumpng
target vacuum level
is reached
out of battery
vacuum level
is dropping
vacuum is totally lost,
circuit stalled untill
device is switched off
vacuum is totally lost,
circuit stalled untill
device is switched off
*
drawings as illustrations onl
y
OPTIONAL ACCESSORIES
*please contact our authorized service centers if testing fails

1
5
2
6
43
firstly remove the pre-installed 0.66x viewfinder
from the housing by removing the retainer o-ring
inside rear housing
align the viewfinder alignment pins with the LCD
display window and push the viewfinder into the
housing until it cannot go in any further
gently push the 0.66x viewfinder from the inside of
the housing
lightly lubricate the retainer o-ring and place it back
from inside the housing
remove the retainer o-ring from the viewfinderto use with 32211/32213 viewfinder, exhchange a
collar of the viewfinder to 32215 collar adaptor.
(please refer to the 32215 adaptor manual.)
OPTIONAL ACCESSORIES
Installing Viewfinder
16

17
CARE/STORAGE
After each day of diving, it is advisable
to have both the housing main o-ring and
port o-ring removed from its groove with
the O-ring remover and inspected for dam-
age. Also check that the O-ring retains
its original circular shape; never stretch
the O-ring excessively or remove it with a
sharp object. The O-ring groove should be
cleaned to ensure it is free from any salt
deposit or foreign material; lightly coat the
O-ring with the provided lubricant before
reinstalling it in the groove.
It is recommended that you ship the
housing to our distributor for a complete
overhaul three years or after every 300
dives.
Do NOT travel with external 180/45
degree viewfinder installed, always pack
it separately with the housing.
If you will not use the housing for an
extended time, remove the O-rings for
storage to avoid deforming them.
Do not store the housing in an environment
of high humidity, extreme temperatures,
and direct sunlight.
Soak the housing system in fresh water
after each salt water use, during which all
control buttons/knobs should be operated
a few times to avoid the accumulation of
salt residue; wipe the housing with a towel
before opening. And do not dry your sys-
tem in the Sun after fresh water cleanning.
Store the housing in a robust, shock-proof
container during transportation; avoid
transporting with the camera inside the
housing.
When travelling by air, it is important that
the housing is not sealed. Either remove
the O-rings, the port, or leave the back of
the housing open.
A damaged O-ring should be discarded
immediately and replaced only with one
that is provided by NAUTICAM.
Place the O-rings in a small zip-lock plastic
bag and place it inside the housing.
1
3
5
5
4
4
4
44
2

18
WARRANTY
All NAUTICAM Housing Products and Viewfinders are
warranted against any material and manufacturing
defects for two years from the date of purchase for
consumer use. NAUTICAM Optical Accessories are
warranted against material and manufacturing defects
for a period of one year, and HDMI cables carry a year
warranty.
This warranty only applies to products purchased from
authorized NAUTICAM dealers and does not extend be-
yond the original retail purchaser.
To return your product for service, please contact your
regional authorized service center(s). Please note that
this warranty only applies when the product is pur-
chased in the territory where the service center is lo-
cated.
NAUTICAM accepts no liability for any damage to and
defects in the housing caused by improper use and/or
poor maintenance; it is the responsibility of the own-
er to carefully follow the instructions in our manuals.
NAUTICAM does not hold responsibility for damage, of
any nature, to any equipment used with and/or placed
within our products.
NAUTICAM accepts no liability for any loss of captured
images or the inability to capture images even if it is
due to the malfunctioning of our products.
Unauthorized modifications and/or repairs of our
products will automatically invalidate the warranty.

19
SPECIFICATIONS
HDMI CONNECTION, MONITOR & ETHERNET OPTIONS
Construction
Dimensions
Weight
Depth
Port specifications
Housing body
Width
In air
Rating
Port mount
Display window
Height
Buoyancy in water
Depth
Port accessories
Hard Anodized Aluminium Alloy
323 mm
2.3 kg
100 m
N 100 Port System
Abrasion Resistant Polycarbonate
173 mm
positive 0.1 kg (w/ camera & battery)
138 mm
1 x M24, 2 x M14, 1 x M10,
12x 1/4’’-20 threaded holes
Optional accessories
Buoyancy options
72216 Ø70x200mm Carbon Fibre Aluminium Float Arm (Buoyancy 370g)
72217 Ø70x250mm Carbon Fibre Aluminium Float Arm (Buoyancy 520g)
72218 Ø70x300mm Carbon Fibre Aluminium Float Arm (Buoyancy 670g)
72219 Ø90x170mm Carbon Fibre Aluminium Float Arm (Buoyancy 450g)
72220 Ø90x220mm Carbon Fibre Aluminium Float Arm (Buoyancy 720g)
72233 Single Bayonet Holder II for Ø70 Float Arm
72244 Double Bayonet Holder II for Ø90 Float Arm
72234 Double Bayonet Holder II for Ø70 Float Arm
83252 Single Bayonet Holder for Arms
72243 Single Bayonet Holder II for Ø90 Float Arm
83253 Double Bayonet Holder for Arms
83254 Bayonet Lens Holder for Inon Float Arms
87516 EMWL Bayonet Holder for Ø70 Float Arm
87517 EMWL Bayonet Holder for Ø90 Float Arm
25624 M14 Vacuum Valve II (Pushbutton Release)
32211 Nauticam Full Frame Straight Viewfinder 32°/ 1:1
26321 TTL Flash Trigger for Canon
32213 Nauticam Full Frame Angle Viewinder 32°/ 1:1
26305 Mini flash trigger for Panasonic/Fujifilm (from SN A534514)
32201 Nauticam 180˚straight viewfinder
26216 Universal Optical Fiber Cable
25020 Canon hotshoe plug to a M14 Nikonos bulkhead (x and ground connection only)
32203 Nauticam 45˚viewfinder
25017 M14 6 pin bulkhead for Canon system
90137 Housing o-ring (I.D.=170mm, C.S.=2.5mm)
HDMI connectivity required accessories ( 1.4 )
25033 Standard HDMI Bulkhead with M16 Thread
25081 M24 -16 Step Down Adaptor
Monitor options ( 1.4 )
Optional accessories for monitor mounting system
17923 NA-Shinobi-H Housing for Atomos Shinobi 5.2” 4K HDMI Monitor
17951 Nauticam Monitor Housing Mounting System
17952 Nauticam Monitor Housing Mounting Adaptor
17925 NA-503-H Housing for SmallHD 503 UltraBright On-Camera Monitor
17954 Tripof Plate
17960 Universal Quadra-pod Plate
25076 HDMI (D-D) 1.4 Cable in 200mm length
* 25033 is included in monitor housing packaging
HDMI connectivity required accessories ( 2.0 )
25086 M24 adaptor for HDMI 2.0 cable
25077 M24D1R205-M28A1R170 HDMI 2.0 cable
Monitor options ( 2.0 )
17922 Nauticam Atomos Ninja V Housing for Atomos Ninja V 5”

20
Macro
Macro to Wideangle
81301
81302
86201
Compact Macro Convertor 1
(CMC-1, 4.5x Magnification)
Compact Macro Convertor 2
(CMC-2, 2.8x Magnification)
Macro to Wideangle Lens 1
(MWL-1, 150 deg. FOV with full
frame 60mm macro lens)
Optional wet lens accessories
25101 M67 flip diopter holder for M67 macro ports
87512 Shade for 130° Objective Lens
25108 M67 Double Flip Holder for M67 Macro Ports
87518 Strobe Mounting Brackets for EMWL Relay Lens
87513 Shade for 100° Objective Lens
87515 M67 Mount to EMWL Focusing Unit
87517 EMWL Bayonet Holder for Ø90 Float Arm
87516 EMWL Bayonet Holder for Ø70 Float Arm
*please refer to Nauticam port charts for more setup information.
83250 M67 to Bayonet Mount Converter II
83214 Bayonet Mount Adaptor for SMC/CMC
87501 Flip Holder for EMWL
WET LENS COMPATIBILITY
FLASH TRIGGERING
Optical Manual
Optical TTL
Electronic Strobe Connection
26305 Mini flash trigger for Panasonic/Fujifilm (from SN A534514)
26321 TTL Flash Trigger for Canon
25017 M14 6-pin bulkhead for Canon System
25020 Canon Hotshoe plug to M14 Bulkhead (X and ground connection only)
87302
Wideangle
83202
85205
83201
EMWL Set#2
(incl. focusing unit #2, 150mm relay
lens & 3 objective lenses)
Wet Wide Lens 1 (WWL-1) 130 deg.
FOV with compatible 28mm Lenses
Wet Wide Lens 1B (WWL-1B) 130
deg. FOV with compatible 28mm
lenses (incl. float collar)
N100 0.36x Wide Angle Conversion
Port Compact (WACP-C)
83203
85203
Wet Wide Lens Compact (WWL-C)
130 Deg. FOV with Compatible
24mm Lenses (incl. float collar)
N100 0.36x Wide Angle Conversion
Port with Aluminium Float Collar
(incl. N100 Extension ring 35).
