Nautilus Sport Series T514 User manual

003–3273–012510D

ParaobtenerestemanualenEspañolLatinoAmericanovayaa:
http://support.nautilus.com.
TableofContents
ImportantSafetyInstructions—Assembly3ImportantSafetyInstructions—Operation14
Specifications4Features17
BeforeAssembly5Operations25
Tools6Maintenance31
Hardware6Troubleshooting36
Parts7Contacts38
Assembly8GuidedeMontageetduPropriétaire39
LevelingtheMachine13
PatentInformationThisproductmaybecoveredbyUSandForeignPatentsandPatentsPending.
©2010Nautilus,Inc.,Allrightsreserved
™and®indicateatrademarkorregisteredtrademark.Nautilus,Inc.(www.nautilus.com)trademarksinclude
NAUTILUS®,BOWFLEX®,SCHWINN®andUNIVERSAL®andrespectivelogos.
Othertrademarksarethepropertyoftheirrespectiveowners.
2 2
2

ImportantSafetyInstructions
Indicatesapotentiallyhazardoussituationwhich,ifnotavoided,couldresultindeathorseriousinjury.
Obeythefollowingwarnings:
Readandunderstandallwarningsonthismachine.
CarefullyreadandunderstandtheAssemblyManual.
• •
•Keepbystandersandchildrenawayfromtheproductyouareassemblingatalltimes.
• •
•Donotconnectpowersupplytothemachineuntilinstructedtodoso.
• •
•Donotassemblethismachineoutdoorsorinawetormoistlocation.
• •
•Makesureassemblyisdoneinanappropriateworkspaceawayfromfoottrafficandexposuretobystanders.
• •
•Somecomponentsofthemachinecanbeheavyorawkward.Useasecondpersonwhendoingtheassemblystepsinvolving
theseparts.Donotdostepsthatinvolveheavyliftingorawkwardmovementsonyourown.
• •
•Setupthismachineonasolid,level,horizontalsurface.
• •
•Donottrytochangethedesignorfunctionalityofthismachine.Thiscouldcompromisethesafetyandcanvoidthewarranty.
• •
•IfreplacementpartsarenecessaryuseonlygenuineNautilus®replacementpartsandhardware.Failuretousegenuine
replacementpartscancausearisktousers,keepthemachinefromoperatingcorrectlyorvoidthewarranty.
• •
•Donotuseorputthemachineintoserviceuntilthemachinehasbeenfullyassembledandinspectedforcorrect
performanceinaccordancewiththeOwner’sManual.
• •
•ReadandunderstandthecompleteOwner’sManualsuppliedwiththismachinebeforefirstuse.KeeptheOwner’sand
AssemblyManualsforfuturereference.
3 3
3

Specifications
Nautilus®T514Treadmill
DimensionsCapacities
Length74"/188cmMaximumUserWeight350lb/158kg
Width32"/81cmWorkoutPrograms16
Height54"/137cmSpeedRange0.5–12mph/0.8–19.3
km/h
AssembledUnitWeight205lb/93kgElevationRange0–12%
Folded39"X32"X60"/99X81X
152cm
ShippingWeight233.7lb/106kgComponentSpecifications
Frame,FoldingSteel
RegulatoryApprovalsMotor2.75CHPDC
IntertekETLlisted.ConformstoANSI/UL1647.4thED.
CertifiedtoCAN/CSA-C22.2No.68-92.DeckSize20"x55"/51x140cm
RoHSBelt2ply
PowerRequirementsHeartRateMonitorContact,Telemetry
120VAC15A60HzNon-GFI
groundedoutlet(dedicated
circuit)
HeartRateChestStrapPolar®
DisplayBacklitLCD
Built-InFan3–speed
Nautilus®T516Treadmill
DimensionsCapacities
Length78"/198cmMaximumUserWeight350lb/158kg
Width34"/86cmWorkoutPrograms21
Height54"/137cmSpeedRange0.5–15mph/0.8–24.1
km/h
AssembledUnitWeight220.5lb/100kgElevationRange0–15%
Folded41"X34"X651/2"/104X
86X166cm
ShippingWeight253.5lb/115kgComponentSpecifications
Frame,FoldingSteel
RegulatoryApprovalsMotor3.2CHPDC
IntertekETLlisted.ConformstoANSI/UL1647.4thED.
CertifiedtoCAN/CSA-C22.2No.68-92.DeckSize20"x58"/51x147cm
RoHSBelt2ply
PowerRequirementsHeartRateMonitorContact,Telemetry
4 4
4
120VAC15A60HzNon-GFI
groundedoutlet(dedicated
circuit)
HeartRateChestStrapPolar®
DisplayBacklitLCD
Built-InFan3–speed

BeforeAssembly
Selecttheareawhereyouaregoingtosetupandoperateyourmachine.Forsafeoperation,thelocationmustbeonahard,level
surface.Allowaworkoutareaofminimum201”x71”(5.1mx1.8m).
Followthesebasicpointswhenyouassembleyourmachine:
1.Readandunderstandthe“ImportantSafetyInstructions”beforeassembly.
2.Collectallthepiecesnecessaryforeachassemblystep.
3.Usingtherecommendedwrenches,turntheboltsandnutstotheright(clockwise)totighten,andtheleft
(counterclockwise)toloosen,unlessinstructedotherwise.
4.Whenattaching2pieces,lightlyliftandlookthroughtheboltholestohelpinserttheboltthrough
theholes.
5.Theassemblyrequires2people.
Note:Thetreadmillisdesignedtoplugintoagrounded,non-GFIoutletonly.DonotconnectthetreadmilltoaGFI
outlet.TodetermineifyouroutletorcircuitbreakerisGFI,lookforatestandresetbuttononthem.Ifthey
havethetestandresetbutton,itisaGFIoutletorcircuitbreaker.
5 5
5

Tools
IncludedNotIncluded
6mm
5mm
Hardware
ItemQtyDescription
A2M10x60LButtonHeadHexScrews,pre-installed
B2M10NylockNuts,pre-installed
C2M8x70LFlatheadHexScrews
4M4x10PhillipsHeadScrews,pre-installed(modelT514)
D
6M4x10PhillipsHeadScrews,pre-installed(modelT516)
E2#8x1/2LPhillipsHeadBolts,pre-installed
F4M8x15LButtonHeadHexScrews,2pre-installed
G4M8washer,2pre-installed
6 6
6

Parts
ItemQtyDescription
11Frame
22ConsoleSidePanels
32SideCovers(modelT516only)
41PowerCord
51RearEndCap(modelT516only)
7 7
7

Assembly
1.UnfoldFrame
Note:HoldoneUpright(1A)andtheErgoBar(1B)whenyouliftthefoldeduprightsintoposition.Keepyour
handsclearoftheareabetweentheErgoBarandtheUpright.
8 8
8

2.InstallScrewsandAdjustHandlebars
Note:Tightenpivotscrews(A1).
9 9
9

3.InstallScrewsinHandlebars
10 10
10

4.AdjustConsole/ErgoBarandInstallConsoleSidePanels
11 11
11

5.AttachSideCoversandRearEndCap(modelT516only)
12 12
12

6.ConnectPowerCord
FinalInspection
Inspectyourmachinetoensurethatallfastenersaretightandcomponentsareproperlyassembled.
Donotuseorputthemachineintoserviceuntilthemachinehasbeenfullyassembledandinspectedforcorrect
performanceinaccordancewiththeOwner’sManual.
LevelingtheMachine
Tostabilizethetreadmill,adjustthe2feetbelowthefrontofthebaseframe.
• •
•Liftonesideofthemachineandturnthefoot—clockwisetoshortenorcounterclockwisetolengthen.
• •
•Adjustthefootontheothersideifnecessary.
13 13
13

ImportantSafetyInstructions
Indicatesapotentiallyhazardoussituationwhich,ifnotavoided,couldresultindeathorseriousinjury.
Beforeusingthisequipment,obeythefollowingwarnings:
Todecreasetheriskofburns,electricshock,orinjurytopersons,readandunderstandthecompleteOwner’sManual.
Failuretofollowtheseguidelinescancauseaseriousorpossiblyfatalelectricalshockorotherseriousinjury.Keep
Owner’sManualforfuturereference.
Readandunderstandallwarningsonthismachine.IfatanytimetheWarningstickersbecomeloose,unreadableor
dislodged,contactNautilus®CustomerServiceforreplacementstickers.
• •
•
Toreducetheriskofelectricalshock,alwaysunplugthepowercordandwait5minutesbeforecleaning,
maintainingorrepairingthismachine.
• •
•Childrenmustnotbeletonorneartothismachine.Movingpartsandotherfeaturesofthemachinecanbedangerous
tochildren.
• •
•Consultaphysicianbeforeyoustartanexerciseprogram.Stopexercisingifyoufeelpainortightnessinyourchest,become
shortofbreath,orfeelfaint.Contactyourdoctorbeforeyouusethemachineagain.Usethevaluescalculatedormeasured
bythemachine’scomputerforreferencepurposesonly.
• •
•Beforeeachuse,examinethismachinefordamagetopowercord,powerreceptacle,loosepartsorsignsofwear.Donot
useiffoundinthiscondition.ContactNautilus®CustomerServiceforrepairinformation.
• •
•Maximumuserweightlimit:350lbs.(158kg).Donotuseifyouareoverthisweight.
• •
•Thismachineisforhomeuseonly.
• •
•Donotwearlooseclothingorjewelry.Thismachinecontainsmovingparts.Donotputfingersorotherobjectsintomoving
partsoftheexerciseequipment.
• •
•Alwayswearrubbersoledathleticshoeswhenyouusethismachine.Donotusethemachinewithbarefeetoronly
wearingsocks.
• •
•Setupandoperatethismachineonasolid,level,horizontalsurface.
• •
•Usecautionwhenyousteponandoffthemachine.Usethesuppliedfootsupportplatformsforstabilitybeforewalking
onthemovingbelt.
• •
•Donotoperatethismachineoutdoorsorinmoistorwetlocations.
• •
•Keepatleast19.5"(0.5m)oneachsideofthemachineand79”(2m)behindthemachineclear.Thisistherecommended
safedistanceforaccess,movementandemergencydismountsfromthemachine.Keepthirdpartiesoutofthisspace
whenthemachineisinoperation.
• •
•Donotoverexertyourselfduringexercise.Operatethemachineinthemannerdescribedinthismanual.
• •
•Read,understand,andtesttheEmergencyStopProcedurebeforeuse.
• •
•Keepthewalkingbeltcleananddry.
• •
•Donotstandonmachinemotorcoverorfronttrimcover
• •
•Keeppowercordawayfromheatsourceandhotsurfaces.
• •
•Donotdroporputobjectsintoanyopeningofthemachine.
• •
•Connectthismachinetoacorrectlygroundedoutlet;consultalicensedelectricianforassistance.
• •
•Donotoperatewhereaerosolproductsarebeingused.
14 14
14

• •
•Donotletliquidstouchtheelectroniccontroller.Ifitdoes,thecontrollermustbeinspectedandtestedforsafetybyan
approvedtechnicianbeforeitcanbeusedagain.
• •
•Donotremovethemachinemotorcover,dangerousvoltagesarepresent.Thecomponentsareserviceableonlyby
approvedservicepersonnel.
• •
•Theelectricalwiringfortheresidenceinwhichthemachinewillbeusedmustobeytheapplicablelocalandprovincial
requirements.
SafetyWarningLabelsandSerialNumber
TypeDescription
WARNINGFailuretoobeythesesafeguardscancauseseriousinjuryorhealthproblems.
1.Keepchildrenandpetsawayfromthismachineatalltimes.
2.Whenthismachineisnotinoperation,removetheSafetyKeyandkeepoutofthereach
ofchildren.
3.UseCautionwhenyouoperatethisequipmentorseriousinjurycanoccur.
4.Priortouse,readandunderstandtheOwner’sManual,includingallWarnings.
5.Topreventinjury,standontheFootPlatformsbeforeyoustartthemachine.
6.ThismachineisforResidentialuseonly.
7.TheMaximumuserWeightforthismachineis350lbs/158kg
1
8.ReplaceanyWarninglabelthatbecomesdamaged,illegibleorisremoved.
15 15
15

AVERTISSEMENTLenon-respectdecesmesuresdeprotectionpourraitentraînerdesblessuresoudegraves
problèmesdesanté
1.Gardezlesenfantsetlesanimauxdecompagnieéloignésdecettemachineentouttemps.
2.Lorsquecettemachinen’estpasutilisée,retirezlecordondesécuritéetgardez-lehorsdela
portéedesentants.
3.Soyezprudentlorsquevousutilisezcetéquipementpournepasvousinfligerdegraves
blessures.
4.Lisezetfamiliarisez-vousavecleManueldupropriétaireetavectouslesavertissementsavant
d’utilisercettemachine.
5.Pouréviterlesblessures,mettez-vousdeboutsurlesrepose-piedsavantdemettrelamachine
enmarche.
6.Cettemachineestàusagedomestiqueuniquement.
7.Cettemachinesupporteunpoidsmaximalde(158kg).
8.Remplaceztouteétiquetted’avertissementendommagée,illisibleoumanquante.
WARNINGDonotliftormovefromthisend—rotatingpartscanpinchorcrush
2
AVERTISSEMENTNepassouleveroudéplacerdepuiscetteextrémité—lesélémentspivotantspeuventpincer
ouécraser
3SerialNumberRecordserialnumberonContactspageatendofthismanual.
GroundingInstructions
Thisproductmustbegrounded.Ifitshouldmalfunctionorbreakdown,groundinggivesapathofleastresistanceforelectrical
current,todecreasetheriskofelectricshock.ThepowercordisequippedwithanEquipment-groundingConductoranda
groundingplug.Theplugmustbeconnectedtoanoutletthatiscorrectlyinstalledandgrounded.Theelectricalwiringmustobey
theapplicablelocalandprovincialrequirements.
Incorrectconnectionoftheequipment-groundingconductorcanresultinariskofelectricshock.
Consultalicensedelectricianifyouarenotsureifthemachineiscorrectlygrounded.Donotchange
theplugonthemachine–ifitdoesnotfittheoutlet,haveacorrectoutletinstalledbyalicensed
electrician.
Itisrecommendedtouseadedicatedcircuitforthismachine.Thismeansthatnootherequipmentisconnectedtothesameoutlet.
DonotuseaGFIoutlet,surgeprotectororextensioncordforthismachine.
EmergencyStopProcedures
ThetreadmillisequippedwithaSafetyKeythatcanpreventseriousinjury,aswellas
preventchildrenfromplayingwithand/orbeinginjuredonthemachine.IftheSafety
KeyisnotfullyputintotheSafetyKeyPort,thebeltwillnotoperate.
TopreventunsupervisedoperationofthemachinealwaysremovetheSafetyKey
anddisconnectthepowercordfromthewalloutletormachineACinput.
AlwaysattachtheSafetyKeyCliptoyourclothingduringyourworkout.
Whenyouusethemachine,onlyremovetheSafetyKeyinanemergency.When
thekeyisremovedwhilethemachineisinoperation,itwillstopquickly,which
couldcausethelossofbalanceandpossibleinjury.
BesuretoremovetheSafetyKeyforsafestoragewhennotinoperation.
16 16
16

Features
AConsoleLWalkingBelt
BWaterBottleHolderMSideFootSupportRails
CMagazineRackNSupportBar
DHandlebarsOHydraulicLift
ERemoteSpeedControlPTransportWheels
FContactHeartRate(CHR)SensorsQBase
GSafetyKeyPortRAdjustableFeet
HUprightsSRemoteInclineControl
IMotorCoverTErgoBar
JPowerSwitchUFan
KPowerCordVHeartRate(HR)ChestStrap
17 17
17

ConsoleFeatures
AADualLCD—BacklitDisplayFFFanButton
BBPresetSpeedKeysGGStop
CCSpeedUp/DownHHProfiles/Courses
DDEnter/ResetIIInclineUp/Down
EEQuickStart(Start)JJPresetInclineKeys
LCDDisplayData
Themulti-function,backlitLCDshowsyourworkoutmeasurements(duringtheworkout),results,usersetupdataandconsole
diagnostics.
18 18
18

AA1ProgramDisplayAA5PULSE
AA2TOTALTIMEAA6CALORIES
AA3DISTANCE(km/miles)AA7SPEED/PACETIME
AA4INCLINE
Note:TochangethemeasurementunitstoEnglishImperialormetric,refertothe“ChangingUnitMeasures
(English/Metric)”sectioninthismanual.
ProgramDisplay
TheProgramDisplayshowsthenameoftheprogramselectionandthedot-matrixareashowsthecourseprofilefortheprogram.
Eachcolumnintheprofileshowsoneinterval(1/12ofthetotalprogramtime).Thehigherthecolumn,thehighertheinclineand/or
speedforthatinterval.Theflashingcolumnshowsyourcurrentinterval.
TotalTime
TheTOTALTIMEdisplayfieldshowsthetimecountintheworkout.Ifapresettimeisnotsetupforthecurrentworkoutprogram,
thedisplayvaluestartsatzeroandcountsforwarduntiltheendoftheworkout.Themaximumtimeis99:59.
Iftheworkouthasapresettime,thedisplaystartsatthepresetvalueandcountsdowntozero.Thedisplayshowsthetotaltime
count for the workout, then the time count for the current interval.
19 19
19

Distance
TheDISTANCEdisplayfieldshowsthedistancecount(milesorkm)intheworkout.Ifnodistancegoalissetupforthecurrent
workoutprogram,thedisplayvaluestartsatzeroandcountsforwarduntiltheendoftheworkout.Iftheworkouthasadistance
goal,thedisplaystartsatthepresetvalueandcountsdowntozero.
Incline
TheINCLINEdisplayfieldshowsthetreadmillinclineinpercentageofelevation.
Pulse
ThePulsedisplayfieldshowstheheartrateinbeatsperminute(BPM)fromtheheartratemonitor(HRM).
Consultaphysicianbeforeyoustartanexerciseprogram.Stopexercisingifyoufeelpainortightnessinyourchest,
becomeshortofbreath,orfeelfaint.Contactyourdoctorbeforeyouusethemachineagain.Usethevaluescalculatedor
measuredbythemachine’scomputerforreferencepurposesonly.
Calories
TheCALORIESdisplayfieldshowstheestimatedcaloriesthatyouhaveburnedduringtheexercise.Ifnocaloriegoalissetup
forthecurrentworkoutprogram,thedisplayvaluestartsatzeroandcountsforwarduntiltheendoftheworkout.Iftheworkout
hasacaloriegoal,thedisplaystartsatthepresetvalueandcountsdowntozero.
Speed/PaceTime
TheSPEED/PACETIMEdisplayfieldshowsthemachinespeedinkilometersperhour(km/h)ormilesperhour(mph)for10seconds,
thenthepaceinminutespermile(orminutesperkm)for10seconds.
KeyFunctions
Themulti-functionconsolekeysletyouadjustthemachinesettings,makeexerciseprogramselections,andenterusersetupdata
fortheconsoletocalculateyourworkoutdata.TheOperationssectionofthismanualgivestheproceduresforusingthekeys
ineachOperationsmode.
INCLINE▲/▼Pushthe▲(Up)or▼(Down)keysto:
• •
•AdjusttheInclineinincrementsof1%.
• •
•Adjustthedatavaluesforusersetup.
COURSES/PROFILESPushtheCOURSES/PROFILESkeytogototheProgramSelectionmenu.
STOP
• •
•PushtheSTOPkeytopauseyourworkout.
• •
•PushandholdtheSTOPkeyfor3secondstostoptheworkoutandgobacktoReadyMode
(workoutdatanotsaved).
[Fan]PushtheFanbutton1timeforLowspeed.PushagainforHighspeed.Push1moretimetoturnthe
fanoff.
20 20
20
