NAVIGLOOPONTOONBOATPONTON2324

SUMMARY:KeyPointsofAssemblyInstructions/RÉSUMÉ:Pointsclésdel’assemblage
RÉSUMÉ
!
POINTSCLÉSDEL’ASSEMBLAGE
NAVIGLOOPONTON2324pi
SUMMARY
!
KEYPOINTSOFASSEMBLY
NAVIGLOOPONTOONBOAT2324ft



THE2VERTICALCONNECTORS
WITHOUTBASE
:front&back
LES2EMBRANCHEMENTSVERTICAUX
SANSBASE
:avant&arrière




[10’’24’’]


Leavea10to24inchmaximumoverhangpastthe2verticalsupportposts
withbase(front&back)
sothatthehorizontalbeamremainssecure.
Les2embranchementsverticauxsansbase(avant&arrière)doiventêtre
installésàchacunedesextrémitésdel’armatureàunedistancede10à24
poucesmaximumdespoteauxdesoutienavecbase(avantetarrière)afin
d’assurerlastabilitédelapoutrehorizontale.


Page9


Makesurethateachextremity(frontandback)endsata±90°angle
.
Les2embranchementsverticauxsansbase(avantetarrière)doiventformer
unanglede±90°aveclapoutrehorizontale.

Page10



THE5VERTICALSUPPORTPOSTS
LES5POTEAUXDESOUTIENVERTICAUX




Metalpins(K)mustONLYbeinstalledonthe5verticalsupportposts
.
Lesgoupillesdemétal(K)doiventêtreposéesUNIQUEMENTsurles5poteauxdesoutienverticaux.



Pages6,12



Carabiners(G1)ofthestrapsmustONLYbeinstalledontheCCLIPS(C)securingthe5verticalsupport
posts.
Lesmousquetons(G1)dessanglesdoiventêtresinstallésUNIQUEMENTsurlesCCLIPS(C)des5poteauxde
soutienverticaux.


Pages7,13



Itisimportantthatthehorizontalbeambelevelledasmuchaspossible.Adjusttheverticalposts
accordingly.
Ilestimportantquelapoutrehorizontalesoit,lepluspossible,deniveau.Ajusterlespoteauxverticauxen
conséquence.


Pages6,12


78’’


Theverticalsupportpostsrequireaheightof78inches.Itisrecommendedthatthisheightbemaintained
toensuregreaterframestabilityandachievetheproperpitchtoallowsnowtoslideoff.
Lespoteauxdesoutienverticauxdoiventavoirunehauteurde78pouces.Ilestrecommandédemaintenir
cettehauteurafind’assurerunmaximumderobustesseàl’armatureetd’obtenirlameilleurepente
possiblepourquelaneiges’écoule.


Pages6



Thedistancebetweenthe5verticalsupportpostsmustbemoreorlessequalinordertohavegreater
stability(theyarethe5pillarsoftheframe)
.
L’espaceentreles5poteauxdesoutienverticauxdoitêtrelepluséquilibrépossiblepourassurerunebonne
stabilité(puisqu’ils’agitdes5piliersdel’armature).


Pages12

1
2
[
10’’24’’
]

±90°
±
90°
78’’
K K K K
K
THE5VERTICALSUPPORTPOSTS:THEPILLARSOFTHEFRAME
LES5POTEAUXDESOUTIENVERTICAUX:LESPILIERSDEL’ARMATURE
4
5
3
1/3



©
NAVIGLOOPONTOONBOATPONTON2324

SUMMARY:KeyPointsofAssemblyInstructions/RÉSUMÉ:Pointsclésdel’assemblage
RÉSUMÉ
!
POINTSCLÉSDEL’ASSEMBLAGE
NAVIGLOOPONTON2324pi
SUMMARY
!
KEYPOINTSOFASSEMBLY
NAVIGLOOPONTOONBOAT2324ft
THE7SETSOFLATERALCONNECTORS
LES7PAIRESD’EMBRANCHEMENTSLATÉRAUX


THELATERALCONNECTORS:7SETS
LESEMBRANCHEMENTSLATÉRAUX:7PAIRES




Thespacebetweenthelateralpostsmustbeasequalaspossibletoensuregreaterstabilityandforabetter
weightdistributiononcethetarpaulinison.
L’espaceentrelesembranchementslatérauxdoitêtrelepluséquilibrépossibleafind’assurerunemeilleure
repartitiondeschargeslorsdel’installationdelatoile.


Page16




Foamprotectors(H)mustrestontheedgeofthewatercraftoverhangingtheedgebyabout3inches
.
Lesemboutsdeprotection(H)doivents’appuyersurlereborddel’embarcationetdépasserd’environ
3pouces.




Page17



Foamprotectors(H)mustoverhangtheABpostbyabout2inchesinordertoproperlyprotectthetarpaulin
.
Chaqueemboutdeprotection(H)doitdépasserd’environ2poucesl’embranchementlatéralABpourbien
protégerlatoile.


Page15




Ifallpreviousstepsaretakenintoaccount,theanglefortheslopeshouldbeapproximately50degrees.Itis
preferabletomaintainthisangletohavethebestslopepossibleallowingthesnowtoslideoff.

Enrespectantlesétapesprécédentes,l’angled’inclinaisondesembranchementslatérauxserad’environ
50degrés.Ilestpréférabledemaintenircetangled’inclinaisonafind’assurerlameilleurepentepossiblepour
quelaneiges’écoule.



Page17



OVERLAPINGoftheAandBtubes
CHEVAUCHEMENTdestubesAetB
























Foreachofthesesteps,itisimportanttohavea
minimum6inchoverlapoftheAandBtubesin
ordertohavethebestsecuritypossible.

Pourchacunedecesétapes,ilestimportant
d’appliquerunminimumde6poucesde
chevauchementdestubesAetBafind’avoirune
soliditéaccrue.

Pages6,12


Pages10,16  Page9

50°
3’’
K
J
A
A
B
B
J
A
B
2/3
50°
50
°




©
NAVIGLOOPONTOONBOATPONTON2324

SUMMARY:KeyPointsofAssemblyInstructions/RÉSUMÉ:Pointsclésdel’assemblage
RÉSUMÉ
!
POINTSCLÉSDEL’ASSEMBLAGE
NAVIGLOOPONTON2324pi
SUMMARY
!
KEYPOINTSOFASSEMBLY
NAVIGLOOPONTOONBOAT2324ft



EXTRAPROTECTION
PROTECTIONSSUPPLÉMENTAIRES




Werecommendusingextraprotectivemeasuresforfragilesurfacesthatmaycomeintocontactwiththe
bases,thepostsand/orthestraps.Forexample:placeaswatchofcarpetandapieceofplywoodunderthebases
(ortheposts)toprotectthewatercraft’supholstery.

Nousrecommandonsdeprotégertoutesurfacefragilequiseraencontactaveclesbases,lespoteaux
et/oulessangles.Parexemple:déposezunmorceaudetapisetuneplanchedeboissouslesbases(oulespoteaux)
afindebienprotégerlerevêtementdevotreembarcation.

Page5


Page11

DURINGINSTALLATIONOFTARPAULIN:

•ItisyourresponsibilitytopreventtheNaviglootarpaulinfromcomingintodirectcontactwithprotrudingcomponentsthatmay
createfriction,whichcouldpotentiallydamageorperforateit.(i.e.snapsforcanvasorBiminitopanchorpoints)*Damagecausedby
unpaddedcomponentsthatwearorperforatethetarpaulinisnotcoveredundertheconditionsofthelimitedwarranty.

•Takeextraprecautionstopreventthegrommetsonthetarpfromdamagingthehullofyourwatercraft.

LORSDEL’INSTALLATIONDELATOILE:

•Ilestdevotreresponsabilitédevousassurerquelatoilenepuisseêtreencontactavectoutecomposantequipourraitendommagerou
perforerlatoileparfrictioncauséeparleventouautre.(Exemples:lesboutonspressiond’unetoilerapide,lespointsd’ancraged’un
toitBimini,etc.)*Lagarantiesurlatoilenecouvrepaslesdommagescauséspartoutecomposantenonprotégéequipourrait
endommagerouperforerlatoile.

•Assurezvousquelesœilletsdelatoilen’abîmerontpasvotreembarcation.



Itisyourresponsibilitytoaddextraprotectiontoyourwatercraftwhennecessary(Example:motorcover,etc.)

_____ ____ ____________________ ____________________ ___ ____________________ _______________________ _______________

Ilestdevotreresponsabilitéd’apporterlesprotectionssupplémentairesquevousjugerezappropriéesàvotreembarcation.

(Exemple:houssedeprotectionpourmoteurhorsbord,etc.)




THESELFLOCKINGSTRAPS
LESSANGLESAUTOBLOQUANTES




Toensureproperassemblyofstraps:ThreadG2throughtheclipattheendofG1fromthe
bottom,thenpullhardfrombothends.G2shouldnotslip;ifitdoes,removeG2,turnthe
clipattheendofG1oversothattheteethofthecliparefacingupward,thenthreadG2
thoughtheclipfromthebottomagain.Testresistancebypullingstrapfrombothends.

WARNING:Asyoupullonbothendsof thestrap,makesurethatG2doesnotslip!Ifit
does,removeG2,turntheclipattheendofG1oversothattheteethoftheclipare
facingupward,thenthreadG2throughtheclipfromthebottomagain.(seeStep1)

S’assurerquelessanglessoientenfiléesdanslebonsens:lapartieG2 doitêtreenfiléedans
lapartieG1demanièreàcequ’ilyaitunerésistancelorsquevoustirezsurles2extrémités
delasangle(G1 etpartielibrede G2).
ATTENTION:Sivousn’arrivezpasàavoirunerésistanceetquelasangleglisse,enlevezla
partieG2,retournezlaetrecommencezdenouveau.(voirÉtape1)


Pages4,8,14



Thetensionintheselflockingstrapsoneachsideoftheverticalsupportpostsmustremaintightand
equaltoensuremaximumstability.
Latensiondessanglesdoitêtreajustéeuniformémentdechaquecôtédespoteauxdesoutienverticaux
afind’assurerunebonnestabilité.


Pages8,14





Ensurethatgatesonthecarabinersareproperlyclosed.

Assurezvousquelesmousquetonssoientbienenclenchés.




Pages8,14

G1
G2
