Navitar 370MCZ125 User manual

Installation of Navitar NuView Series 370 lenses on Christie LX65 &
LX100, LX120, L6 Roadrunner & L8 Roadrunner projectors.
TOOLS REQUIRED: PHILLIPS HEAD SCREWDRIVER
1. Ensure projector power cord is disconnected.
2. Remove front cover by taking 2 Phillips screws from top cover then lifting up while
applying pressure to front of cover.
3. Insert the keyed portion of the adapter ring into the projector and rotate the lens lock lever
downward while squeezing together.
4. Replace the front cover of the projector removed in step 1, above.
5. To focus, gently twist the front of lens. To zoom, loosen thumbscrew and twist knurled
ring (zoom lenses only, of course). Re-tighten thumbscrew. CAUTION: Do not twist entire
lens out of adapter!
