Naxa NAS-3061A User manual

Portable Bluetooth®Stereo Speakers
Entertainment Pack
NAS-3061A
Instruction Manual
Please read carefully before use and keep for future reference.

Page 2 Naxa Electronics
Thank You
We know you have many choices when it comes to
technology; thank you for choosing us here at Naxa
Electronics. Established in 2001 in Los Angeles, Califor-
nia, we are dedicated to delivering products that en-
tertain and delight.
We trust that you will be happy with your purchase.
Please read this manual carefully and save it for refer-
ence. You may also nd the latest FAQ, documentation,
and other product material at our website. Come visit
us on the web at www.naxa.com and see all that we
have to offer!
In the Box
Please take a moment to make sure that you have ev-
erything in the list below. Although we make every ef-
fort to ensure that each Naxa device is securely packed
and sealed, we know a lot can happen in between us
and you. If anything is missing, check back with your
local retailer to get immediate assistance. If they can-
not help you, please contact our Naxa Support team at
www.naxa.com/naxa_support.
•Bluetooth®speaker unit
•USB battery pack
•Headphones
•Earphones
•USB charge cable
•3.5mm AUX cable

www.naxa.com Page 3
Bluetooth®Speaker
Connecting Power
Your speaker can be powered bythe included recharge-
able battery. Upon initial use, the battery should be
charged fully to ensure optimal performance and bat-
tery life.
Installing the Battery:
1. Remove the cover of the battery compartment on
the speaker.
2. Place the rechargeable battery (BL-5C) in the bat-
tery compartment, taking care to match the +/–
poles of the battery with the markings in the com-
partment.
3. Replace the cover of the battery compartment.
Charging the Battery
Use the included USB cable to connect the speaker to a
USB power source to charge the battery.
•Connect the small end of the cable to the USB
charge port of the unit.
•Connect the large end of the cable to a high-power
USB port of a computer. The computer should be
powered on.
 The round DC 5V power input requires an
optional power adapter and is not used.
⚠The battery used in this device may pres-
ent a re or chemical burn if mistreated.
Do not disassemble, incinerate, or heat
the battery. Do not leave the battery in a
place subject to direct sunlight, or in a car
with its windows closed.
Do not connect the unit to a power source
other than that which is indicated here or
on the label as this may result in the risk
of re or electric shock.

Page 4 Naxa Electronics
Turning the Speaker On/O
To turn the speaker on, set the ON/OFF switch to the
“ON” position. The LED will light up red.
To turn the speaker off, set the ON/OFF switch to the
“Off” position.
Pairing a Device with Bluetooth®
A device must be paired with the speaker before using
them together for the rst time.
When you turn on the speaker, it will automatically
search for a paired device. If it does not detect a paired
device, it will switch to Pairing mode. Then:
1. Make sure Bluetooth®is enabled on your device.
Enable it if it hasn’t.
2. Use your device to search for available Bluetooth
devices. (This function is usually in the Bluetooth
settings menu; refer to your device’s instruction
manual to learn more.)
3. The speaker will announce itself as NAXA NAS-
3061A. Select it from the list of devices.
4. If your device asks for a passcode, use “0000” to
complete the pairing process.
 If the speaker fails to pair with your de-
vice: 1) Turn the speaker off; 2) Make sure
Bluetooth has been enabled on your de-
vice; 3) Turn the speaker on again; 4) Use
your Bluetooth device to search for and
pair with the speaker.
The speaker cannot be paired with more
than one device at a time.
When the speaker is connected to a Bluetooth®device,
use the connected device to control playback and to ad-
just the volume to a comfortable level.
Using the AUX Input Connector
Connect devices without Bluetooth®by using the AUX
connection. A 3.5mm stereo patch cable is required to
make this connection.
1. Use the included AUX cable to connect the device’s
headphone or line-out jack to the LINE IN (AUX)
connector on the speaker.

www.naxa.com Page 5
2. Turn on the device and the speaker.
3. Adjust the device volume to a comfortable level
and then start playback.
 Use the connected AUX device to control
all functions in AUX mode. The speaker
can only be used to adjust the volume.

Page 6 Naxa Electronics
USB Battery Pack
At a Glance
1 Micro USB
port
Power input. Use this port to charge the bat-
tery pack with the included USB charge cable.
2 USB port Power output. Use this port to charge other
devices with the USB cable provided by the
device’s manufacturer .
3 Status LED Lights up to show the current status of the
battery pack.
4USB charge
cable
Use the USB charge cable to connect the bat-
tery pack to a USB power source.
Charging the Battery Pack
Use the included USB cable to connect the speaker to a
USB power source to charge the battery.
•Connect the small end of the cable to the micro
USB charge port of the unit.
•Connect the large end of the cable to a high-power
USB port of a computer or other USB power source.

www.naxa.com Page 7
The Status LED will light red while the battery pack is
charging; the LED will turn off when the battery pack is
fully charged.
 Fully charge the battery pack for at least
5 hours when using the battery pack for
the rst time.
⚠The battery used in this device may pres-
ent a re or chemical burn if mistreated.
Do not disassemble, incinerate, or heat
the battery. Do not leave the battery in a
place subject to direct sunlight, or in a car
with its windows closed.
Do not connect the unit to a power source
other than that which is indicated here or
on the label as this may result in the risk
of re or electric shock.
Using the Battery Pack to Charge
Your Devices
Use the cable included with your device to charge it.
•Connect the end that goes into your device as usual.
•Connect the large end of the cable to the large USB
port of the battery pack.
 For optimal performance, fully charge the
battery pack before using it to charge an-
other device.
Care and Maintenance
Please read and follow the recommendations below
when using the Portable USB Battery Pack.
•Do not expose the device to liquid, moisture, or hu-
midity. This may adversely affect the device’s in-
ternal circuit.
•Do not use abrasives or solvents to clean the de-
vice.

Page 8 Naxa Electronics
•Do not expose the device to extremely high or low
temperatures as it may damage the device or de-
form the plastic parts of the device.
•Do not incinerate the device to dispose of it as it
may cause an explosion.
•Do not allow the device to come into contact with
sharp objects to prevent scratches or other dam-
age.
•Do not drop the device or subject it to any strong
shocks or other impact. This may damage the in-
ternal circuit of the device.
•Do not attempt to disassemble the device. There
are no user-serviceable parts inside.
Troubleshooting Guide
This guide lists common problems and their solutions.
Please refer to this guide before requesting service.
If you need further assistance, please contact Naxa
Technical Support (www.naxa.com/naxa_support/).
Bluetooth®Speaker
Symptom Possible Cause Possible Solution
There is no
power.
The battery is
exhausted.
Connect the unit to a
USB power source to
charge it.
The speaker hasn’t
been turned on.
Set the ON/OFF switch
on the speaker to the
“ON” position.
The device
is unable to
connect to the
speaker.
The speaker is not
in pairing mode.
Reset the speaker
(turn it off and then
on again.) Wait for the
status indicator to ash
quickly.
Bluetooth may be
disabled on your
device.
Make sure Bluetooth is
enabled on your device.
Turn it on if it isn’t.

www.naxa.com Page 9
Symptom Possible Cause Possible Solution
The device is
connected but
there is no
sound.
The AUX connector
may be in use.
Disconnect all cables
from the AUX in-
put connector of the
speaker.
Your device may be
beyond the effec-
tive range of the
speaker.
Move closer to the
speaker. Range may
be affected adversely
by environmental
conditions.
Your device may
not be in playback
mode.
Ensure that your device
is operating correctly.
Start playback on your
device.
USB Battery Pack
Symptom Possible Solution
The status
LED does not
light up while
charging the
battery pack.
Ensure that the battery pack is securely con-
nected to a power source with the included
USB charge cable.
If the power source is a computer, make sure
the computer is turned on.
Symptom Possible Solution
The battery
pack is not
charging a
connected
device.
Ensure that the USB cable is connected se-
curely to the battery pack and to the device.
Make sure the battery pack is fully charged
before attempting to charge another device.

Page 10 Naxa Electronics
Warnings and Precautions
The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of unin-
sulated “dangerous voltage” within the product’s enclosure that
may be of signicant magnitude to constitute risk of electric
shock
The exclamation point within an equilateral triangle is intended
to alert the userto the presence of important operation and ser-
vicing instructions in the literature accompanying the appliance.
CAUTION
• Do not block the ventilation openings or holes.
• Do not place any naked ames (such as lighted candles) on the ap-
paratus.
• When discarding batteries, follow all local rules and laws governing the
disposal of batteries. Consider the environmental impact of your actions!
• To prevent re or shock hazard, do not expose this appliance to rain
or moisture.
Important Safety Information
1. Read Instructions: All the safety and operating instructions should be
read before the product is operated.
2. Retain Instructions: The safety and operating instruction should be
retained for future reference.
3. Heed Warnings: All warnings on the product and in the operating in-
structions should be adhered to.
4. Follow Instructions: All operating and usage instructions should be
followed.
5. Cleaning: Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6. Attachments: Use only attachments recommended by the manufac-
turer. Use of other attachments may be hazardous.
7. Water and Moisture: Do not use this product near water (e.g., near a
bathtub, washbowl, kitchen sink, laundry tub, in wet basements, or
near a swimming pool and the like).
8. Accessories: Do not place this product on an unstable
cart, stand, tripod, bracket, or table. Use only with
carts, stands, tripods, brackets, or tables recom-
mended by the manufacturer or sold with the
product. Any mounting of the product should fol-
low the manufacturer’s instructions and should use
a mounting accessory recommended by the manu-
facturer. A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
product and cart combination to overturn.

www.naxa.com Page 11
9. Ventilation: Slots and openings in the cabinet are provided for ven-
tilation to ensure reliable operation of the product and to protect it
from overheating. These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer in-
structions have been adhered to.
10. Power Sources: This product should be operated only from the type of
power source indicated on the rating label. If you are not sure of the
type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
11. Grounding or Polarization: This product may be equipped with a po-
larized alternating-current line plug that has one blade wider than
the other. This plug will only t into the power outlet in one direction.
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the direction of the plug. If the plug should
still fail to t, contact an electrician to replace the obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
12. Power-Cord Protection: Power supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, conve-
nience receptacles, and at the point which they exit from the product.
13. Protective Attachment Plug: The product may be equipped with an at-
tachment plug with overload protection. This is a safety feature. See
the operating instructions for replacement or directions to reset the
protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same over-
load protection as the original plug as specied by the manufacturer.
14. Outdoor Antenna Grounding: If an outside antenna is connected to
the product, be sure the antenna system is grounded so as to provide
some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANS/NFPA 70 provides in-
formation with regard to proper grounding of the mast and support-
ing structure,grounding of the lead-in wire to an antenna-discharge
unit, size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for the
grounding electrode (see gure).
15. Lightning: For added protection for this product, unplug it from the
wall outlet and disconnect the antenna or cable system during a
lightning storm or when it is left unattended and unused for long pe-
riods of time. This will prevent damage to the product due to lightning
or power-line surges.
16. Power Lines: An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power cir-
cuits, or where it can fall into such power lines or circuits. When in-
stalling an outside antenna system, extreme care should be taken to

Page 12 Naxa Electronics
keep from touching such power lines or circuits, as contact with them
might be fatal.
17. Overloading: Do not overload wall outlets, extension cords, or inte-
gral convenience receptacles as this can result in a risk of re or elec-
tric shock.
18. Object and Liquid Entry: Never push objects of any kind into this prod-
uct through openings as they may touch dangerous voltage points or
short-out parts that could result in a re or electric shock. Never spill
liquid of any kind on the product.
19. Servicing: Do not attempt to service this product yourself as open-
ing or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualied service personnel.
20. Damage Requiring Service: Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the follow-
ing conditions: a) when the power-supply or plug is damaged; b) if
liquid has been spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if the product does
not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as
improper adjustment of other controls may result in damage and will
often require extensive work by a qualied technician to restore the
product to its normal operation; e) if the product has been dropped or
damaged in any way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
21. Replacement Parts: When replacement parts are required, be sure
that your service technician has used replacement parts specied
by the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in re, electric shock, or
other hazards.
22. Safety Check: Upon completion of any service or repairs to this
product,ask the service technician to perform safety checks to ensure
that the product is in proper operating condition.
23. Wall or Ceiling Mounting: The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
24. Heat: The product should be situated away from heat sources such as
radiators,heat registers, stoves, or other products (including ampli-
ers) that produce heat.
WARNING:
This product contains lead, a chemical known to the State of California to
cause cancer and birth defects or other reproductive harm. Wash hands
after handling.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the lim-
its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be de-
termined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:

www.naxa.com Page 13
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION ON MODIFICATIONS
Any changes or modications not expressly approved by the grantee of
this device may void the authority granted by the FCC to operate the
equipment.
Trademark & Regulatory Statements
Bluetooth®is a registered trademark of Bluetooth SIG, Inc. Other trade-
marks and names are those of their respective owners.

Page 14 Naxa Electronics
Specications
Portable Bluetooth® Stereo Speakers
Speakers Two 50mm full-range drivers
Frequency Response 100-20,000 Hz
Input Bluetooth®
3.5mm AUX line-in
Power Rechargeable battery (500 mAh)
USB charge port (DC 5V, 1A)
Battery Life* 1.33 hours
* Estimated time based on Bluetooth use at 100% volume; battery life will
vary depending on use conditions.
Headphones
Drivers 40 mm neodymium
Type Dynamic, closed
Frequency Response 20-20,000 Hz
Impedance 32 Ω
Sensitivity 108 dB
Cord 1.5 m
Plug 3.5mm stereo
Earphones
Drivers 15 mm
Type Dynamic, In-ear
Frequency Response 20-20,000 Hz
Impedance 32 Ω
Sensitivity 102 dB
Cord 1.0 m
Plug 3.5mm stereo
Portable USB Battery Pack
Capacity 2,200 mAh
Charge connector USB
Power Output: DC 5V, 1A
Input: DC 5V, 1A
Note: Product are improved continuously. We reserve the right to modify
the product and specications without prior notice.

www.naxa.com Page 15
Support
If you have problems with your device, please consult
the instructions in this manual. Please also visit us
on the web at www.naxa.com to get up to the minute
news, alerts, and documentation for your device. For
additional assistance, please contact Naxa Technical
Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
