Instruction Manual
EPU-100-W5-R60
Wireless Positioning Units
・Lock Adapter (EPL-48-D6-D6) (Option)

1
Introduction
Thank you very much for purchasing this Wireless Positioning Unit (EPU-
100-W5-R60) from Nabeya Bi-tech Kaisha.
Read the "Wireless Positioning Unit (EPU-100-W5-R60) Simple Guide"
or the "Wireless Positioning Unit (EPU-100-W5-R60) Instruction Manual"
for this product carefully prior to use. Only use once the correct usage
method of this product is understood.
The contents of "1 Cautionary Notes Regarding Safety" in particular, must
be read and understood prior to use.
This manual should be stored in a manner that enables it to be viewed
whenever a user may require it.
■About Applications of this Product
This product is designed for general industrial applications, such as feed
screw drives.
Do not use in applications where incorrect operation or failure may lead
to death or personal injury, or in applications where failure could cause
serious social damage or adverse impact.
・ Contact us when considering use for special applications.
・ Always install the fail-safe function if using for applications involving
equipment that may cause serious accident or loss.
■About Disposal
When disposing this product, follow the rules and regulations of each local
government and dispose of it as industrial waste.
© 2019- Nabeya Bi-tech Kaisha Co., Ltd.
Copying or reprinting all or part of this document without permission in any way is
strictly prohibited.
Due to product improvements, some of the specications described in this document
are subject to change without notice.

2
Contents
Introduction ............................................................................. 1
1 Cautionary Notes Regarding Safety ................................. 3
1.1 Cautionary Notes Regarding Installation and Wiring .............4
1.2 Cautionary Notes Regarding Operation and Maintenance ......6
2 Overview ............................................................................. 7
2.1 Product Overview ...........................................................................7
2.2 Part Names and Functions ...........................................................8
2.3 Button and Switch Operation ................................................... 10
2.4 Block Diagram .............................................................................. 12
3 Specications ...................................................................13
4 Installation and Connection ............................................15
4.1 Installation ..................................................................................... 15
4.2 Connection .................................................................................... 21
5 Maintenance .....................................................................25
5.1 Requests for Inspections ............................................................ 25
5.2 Inspection Items ........................................................................... 25
6 Troubleshooting ...............................................................26
7 Dimension Figure .............................................................27
8 Warranty ...........................................................................28
9 Notes About Electromagnetic Radiation .......................29
Revision History .....................................................................30

3
Take care to understand the following precautions before using the
product in order to ensure safe operation.
Improper handling or use may cause an unexpected accident or
shorten the life of the product.
We do not take any responsibility in the case of failure due to
improper use, modication, of for not following the precautions.
In this manual, safety precautions are classied as either a
"Warning" or "Caution".
■Description of Markers
The specic contents will be indicated in sentences near the
Warning/Caution marker.
Warning
This indicates a situation where improper handling
could result in a dangerous situation that could cause
death or serious injury.
Caution
This indicates that incorrect handling may cause minor
injury or damage to the product and surrounding
equipment.
■Explanation of Figure Marker
The specic contents will be indicated in sentences near the gure
marker.
Figure
Marker Description
Indicates something is prohibited.
Never perform any prohibited work.
Indicates something is mandatory.
Always perform any mandatory work as instructed.
1 Cautionary Notes Regarding Safety

4
1 Cautionary Notes Regarding Safety
1.1 Cautionary Notes Regarding Installation
and Wiring
Warning
・ Be sure to perform wiring after installation is complete. Not doing so may
result in an electric shock.
・ Wiring should be done in a place that is free from dust and water or oil. This
may result in an electric shock, re, or a fault.
・ Do not allow conductive foreign matter, such as screws and metal pieces, or
ammable foreign substances, such as oil, to enter the internals. This may
result in an electric shock, re, or a fault.
・ Be sure to install the unit in such a way that re or personal injury does not
occur during an earthquake.
・ Insulate the power supply terminals connections. Not doing so may result in
an electric shock.
Warning
・ Do not wire or operate with wet hands. It may result in electric shock or
failure.
・ Do not use this product near water, corrosive atmosphere, ammable gas or
harmful gas, or near combustible materials. Not doing so may result in an
electric shock, re, or a fault.
・ Do not damage, apply excessive stress, place heavy objects on, pinch, or
bend the cables repeatedly. This may result in an electric shock, re, or a
fault.
・ Do not use in locations subject to severe vibration or impacts. This may
result in an electric shock, injury, re, or a fault.

5
1 Cautionary Notes Regarding Safety
Caution
・ Perform wiring correctly and securely. Not doing so may result in an electric
shock, re, or a fault.
・ Install according to the specied mounting method and mounting direction.
Not doing so may result in injury or a fault.
・ Consider each of the specications, such as the main unit weight and rated
output, when installing and install in an appropriate environment. Not doing
so may result in injury or a fault.
・ Install the unit where the ambient temperature is -5°C to 55°C (non-freezing)
and the ambient humidity is 20%RH to 85%RH (non-condensing). Not doing
so may result in a re or a fault.
・ Take measures regarding peripheral devices that are a󱐯ected by noise as
noise may be generated by the PWM switching control. Also consider the
installation environment as the unit itself may be a󱐯ected by external noise.
・ Adjust the alignment between the output shaft and the partner device
accurately. Not doing so may result in a fault.
・ When installing the unit vertically, install the unit with the output shaft facing
down, as failing to do so may result in grease owing into the unit. This may
result in a fault.
・ Check and adjust each setting before operation to avoid unexpected
operation. This may result in injury or a fault.
Caution
・ Do not apply any voltage other than the specied voltage. This may result in
a fault.
・ Do not stack the units. This may result in a fault.
・ Do not hold the cables or output shaft during transportation. This may result
in a fault.
・ Do not step on the unit or place heavy objects on it. This may result in a fault.
・ Do not subject the unit to strong impacts such as those caused by dropping
or falling from something. This may result in a fault.
・ Do not use outdoors or under exposure to direct sunlight. This may result in
a re or a fault.
・ Do not use in places where static electricity is generated. This may result in
a re or a fault.
・ Do not subject the output shaft to strong impacts. This may result in a fault.
・ Do not subject the output shaft to loads in excess of the allowable load.
This may result in a fault.
・ Do not connect directly to AC power. This may result in a re or a fault.

6
1 Cautionary Notes Regarding Safety
1.2 Cautionary Notes Regarding Operation and Maintenance
Warning
・ Wiring, maintenance and inspection should be performed by a specialized
technician. This may result in an electric shock, injury, or a fault.
・ If an error occurs, stop operation immediately and install an external
emergency stop circuit so that the power can be shut o󱐯. Not doing so may
result in an electric shock, injury, re, or a fault.
Warning
・ Do not move, connect wiring, or inspect while the power is on. It may result
in electric shock or failure.
・ In case of a fault, shut o󱐯 the power immediately at the power supply and
do not reapply power. This may result in a re or a fault.
・ Do not touch the unit while the power is on or for a while after the power is
turned o󱐯, as it may be hot. This may result in burns.
・ Never touch the output shaft during operation. This may result in injury.
・ Do not disassemble, repair or modify. This may result in an electric shock,
injury, re, or a fault.
Caution
・ Securely x to the device so that it will not come loose during operation. Not
doing so may result in injury or a fault.
・ If a dangerous situation may occur while stopped or if the product fails, install
an external holding brake. Not doing so may result in injury or a fault.
・ If an error occurs, x the cause and ensure safety before restarting operation.
Not doing so may result in a fault.
・ Turn o󱐯 the power if not using the product for extended periods of time. Not
doing so may result in a fault.
Caution
・ Do not use a unit while damaged. This may result in injury, re, or a fault.
・ Do not make extreme adjustments or changes. Such changes may cause
unstable operation.
・ After power is restored in the event of a power outage, do not approach the
equipment because operation may restart all of a sudden. This may result in injury.
・ Do not turn the power on or o󱐯 excessively frequently. This may result in a
re or a fault.
・ Do not perform continuous operation for extended periods of time. This may
result in a re or a fault.

7
2.1 Product Overview
Wireless Positioning Unit (EPU-100-W5-R60)
・ These units automate positioning mechanisms
with a feed screw. By replacing the feed screw
operating handle with this unit, equipment
and device positioning mechanisms can be
automated.
Lock Adapter (EPL-48-D6-D6)(Option)
・ Position retention (locking) components are
parts used in combination with Wireless
Positioning Units.
・ The torque from the input side (unit side) is
transmitted to the output side, but the torque
load from the output side is not transmitted to
the input side.
2 Overview

8
2 Overview
2.2 Part Names and Functions
SET RUN
232C
RF
AB
Output Shaft
Rotational Direction
CW Direction (Button A)
CCW Direction (Button B)
Output
Shaft
1
2
3
4
7
5
8910
1234
5
67
6

9
2 Overview
No. Name Function Reference
1Antenna Antenna for wireless communication.
> P.16
2Display LED
Regular: Green (Standby: Illuminated,
Moving: Blinking)
-Error: Red (Error occurred: Illuminated,
Fault: Blinking)
Setting: Orange (Network settings: Illuminated)
3External I/F
connector
High-density D-sub 15-pin male connector.
Used for wired communication, limit sensor
connection, or for connecting a forced travel switch.
> P.22
4Power Cable Cable for making connections to power.
24 V (Wiring color: Red), 0 V (Wiring color: Black)
> P.21
5Nameplate
1Rated Voltage 5Part No.
-
2Rated Current 6Serial No.
3Rated Torque 7QR Code
4
Rated Rotational Frequency -
6Rubber cover Remove to access the buttons and switches
on the PCB. -
7A button (CW) Output shaft rotates clockwise as seen from
the output shaft side.
> P.10
8B button (CCW) Output shaft rotates counter-clockwise as
seen from the output shaft side.
9RF/232C
Switch
RF: Controls the unit via wireless
communication.
> P.11
232C: Controls the unit via wired
communication.
10 RUN/SET
Switch
RUN:
Puts the unit into regular operation
mode, enabling operation. The switch
should be switched to regular mode.
SET: Puts the unit into wireless unit
search standby state for wireless
unit registration mode. Contact
us if communication or operation
is interrupted after changing the
network settings.

10
2 Overview
2.3 Button and Switch Operation
Remove the rubber cover on the top of the unit and operate using
the buttons and switches on the board to rotate the output shaft,
switch between wired and wireless communication, and make
other network settings.
■A button (CW), B button (CCW) operation
The output shaft will rotate while the button is pressed.
Warning
Do not wire or operate with wet hands. It may result in electric shock or
failure.
・ Never touch the other components on the PCB. This may result in a fault.
・ Do not use in places where static electricity is generated. This may result in
a re or a fault.
Unit Top
Output Shaft
Rotational Direction
CW Direction (Button A)
CCW Direction (Button B)
Output
Shaft
RUN
232C
RF
AB
Caution

11
2 Overview
■RF/232C Switch, RUN/SET Switch Operation
Use the switches on the board to switch between wired and
wireless communication, and make other network settings. Use a
thin screwdriver, such as a precision screwdriver or a ballpoint pen,
to perform the switching.
RF/232C
Switch
RF: Controls the
unit via wireless
communication.
232C: Controls
the unit via wired
communication.
RUN/
SET
Switch
RUN: Puts the
unit into regular
operation mode,
enabling operation.
The switch should
be switched to
regular mode.
SET: Puts the unit
into wireless unit
search standby
state for wireless
unit registration
mode. Contact us
if communication
or operation is
interrupted after
changing the
network settings.
※ Change the switches prior to applying power. The signal
indicating the new switch status is sent only when the unit is
started.
※ Default factory settings are "RF" and "SET".
Warning
Do not wire or operate with wet hands. It may result in electric shock or
failure.
・ Never touch the other components on the PCB. This may result in a fault.
・ Do not use in places where static electricity is generated. This may result in
a re or a fault.
Unit Top
SET RUN
232C
RF
AB
Caution

12
2 Overview
2.4 Block Diagram
Wireless Position㏌g Unit
(EPU-100-W5-R60)
Wireless
Co㎜unication
Module
RS-232C
Limit
Se㎱or 1
Limit
Se㎱or 2
CPU
RF/232C
Switch
Low
Voltage
Detection
Circuit
Memory
A
button
B
button
RUN/SET
Switch
Encoder
Driver
Motor

13
■Wireless Positioning Unit (EPU-100-W5-R60)
Power Source Voltage 24 VDC ± 10%
Current
Consumption
Standby 20 mA
Rated 0.65 A
Maximum 1 A
Rated Output 4.98 W
Rated Rotational Frequency 62 ±10 rpm
Rated Torque 0.765 N·m*1
Max. Allowable
Load
Radial Load 29.4 N
Thrust Load 24.5 N
Stop Accuracy ±5°
*2
Input
Wireless
Communication
2.4 GHz Band Wireless
Communication
Wired
Communication
RS-232C (3-wire type)
Input Circuit 2ch*3
Wireless Reach
Distance
(Reference
Value)
Indoors 60 m
Outdoors 1200 m
External Size
(Output Shaft/Power Cable)
/Not including antenna)
42 mm x 70 mm x 115 mm
Weight 520 g
*1: When attaching the lock adapter the output torque is
0.715 N·m.
*2: When attaching the lock adapter, about 10° of backlash is
generated.
To compensate for the backlash, refer to the Dedicated
Software (EPU-COM) Instruction Manual.
*3: For limit sensor detection
3 Specications

14
3 Specications
■Lock Adapter (EPL-48-D6-D6)(Option)
Retention Torque *1 5 N·m
Loss Torque *2 0.05 N·m
Reduction Ratio Constant Velocity (1:1)
External Size (Excluding
Output Shaft) 42 mm x 42 mm x 23 mm
Weight 135 g
*1 Load torque from output side which the lock adapter can hold
*2 Torque lost when torque is transmitted from input side to
output side
■Operating Environment
Operating
Environment
Temperature -5°C to 55°C
(non-freezing)
Humidity 20%RH to 85%RH
(non-condensing)

15
4 Installation and Connection
4.1 Installation
The following environmental conditions are required for installation.
Install in an appropriate environment.
・ Install indoors.
・ Install in a place that is not exposed to direct sunlight.
・ Install where there is no continuous vibration.
・ Install in a place that is free from dust and water or oil.
・ Install in an environment where heat is easily dissipated.
・ Install in a place where inspection and cleaning are easy.
・ Install the unit where the ambient temperature is -5°C to 55°C
(non-freezing) and the ambient humidity is 20%RH to 85%RH
(non-condensing).
・ Be sure to install the unit in such a way that re or personal
injury does not occur during an earthquake.
・ Do not install this product near water, corrosive atmosphere,
ammable gas or harmful gas, or near combustible materials.
・ Take measures regarding peripheral devices that are a󱐯ected
by noise as noise may be generated by the PWM switching
control. Also consider the installation environment as the unit
itself may be a󱐯ected by external noise.
※ Contact us individually if installing in a special environment.
> P.28

16
4 Installation and Connection
■Unit Installation
1. Connect the antenna.
Radio waves are radiated vertically from the antenna axis as
shown below. After connecting the antenna, adjust the angle of
the antenna while considering the directivity of the radio waves.
Wireless communication distance varies depending on the
installation / connection conditions.
The communication distance may be shorter under the following
conditions, and should be considered when determining the
installation location and connection method.
・ There is an obstacle in the transmission path. (Rebar,
reinforced concrete, etc.)
・ There is a height di󱐯erence in the transmission path.
・ The installed position is close to the ground.
・ There is metal around.
・ There is a lot of radio noise in the vicinity.
※ Antenna connection is not necessary for wired
communication.

17
4 Installation and Connection
2. Mount at the install location.
Use the spigot to align the unit with the mating device and
secure it using a hex socket head cap screw.
※ Hex socket head cap screws and couplings are not
provided.
<Equipment side mounting part recommended machining dimensions>
3. After tightening the screws, make sure that there is no gap
between the unit and the partner device.
・ Do not hold the cables or output shaft during transportation. This may result
in a fault.
・ Do not subject the output shaft to strong impacts. This may result in a fault.
・ When installing the unit vertically, install the unit with the output shaft facing
down, as failing to do so may result in grease owing into the unit. This may
result in a fault.
Couplings Couplings
Equipment side
mounting part
Mounting hole
(M4)
Spigot receiver
Hex socket head cap screw (M4)
Hex socket head cap screw (M3)
Mounting hole (M4)
Spigot receiver
Equipment side
mounting part
Unit
Unit
32H7
48
45°
When fixing from equipment side: 4×Φ4.5
When fixing from the unit side: 4×M3
Caution

18
4 Installation and Connection
■If installing the unit-using the lock adapter (optional)
Assemble the unit with a lock adapter enables positioning
misalignment due to equipment vibration, external force, or dead
weight in vertical use to be prevented.
1. Connect the antenna.
> P.16
2. Mount the lock adapter to the unit.
Align the output shaft of the unit with phase of the D-cut surface
hole on the input side of the lock adapter and insert. Match
each spigot part and assembly the unit and lock adapter in
parallel with each other.
3. Mount at the install location.
Hold the unit with the lock adapter in place and secure the unit
to the partner device using hex socket head bolts.
※ Hex socket head cap screws and couplings are not provided.
Output Shaft
Input side D-cut
surface
Spigot receiver
Unit
Lock Adapter
Couplings
Equipment side
mounting part
Equipment side
mounting part
Mounting hole
(M4)
Spigot receiver
Hex socket head cap screw (M4)
Hex socket head cap screw (M3)
Mounting hole (M4)
Spigot receiver
Unit
Unit
Couplings
Lock Adapter
Lock Adapter

19
4 Installation and Connection
<Equipment side mounting part recommended machining dimensions>
4. After tightening the screws, make sure that there is no gap
between the unit and the lock adapter, or the lock adapter
and the partner device.
※ When attaching the lock adapter, about 10° of backlash is
generated.
To compensate for the backlash, refer to the Dedicated
Software (EPU-COM) Instruction Manual.
・ Do not forcibly assemble the unit and the lock adapter. This may result in a
fault.
・ Make sure that no foreign objects, such as metal fragments, enter the lock
adapter. This may result in a fault.
・ Do not hold the cables or output shaft during transportation. This may result
in a fault.
・ Do not subject the output shaft to strong impacts. This may result in a fault.
・ When installing the unit vertically, install the unit with the output shaft facing
down, as failing to do so may result in grease owing into the unit. This may
result in a fault.
32H7
48
45°
When fixing from equipment side: 4×Φ4.5
When fixing from the unit side: 4×M3
Caution
