Nebula ART5003 User manual

ART5003
Assembly Instructions
Greene Galvanized Stairs

PARTS LIST
QTYDESCRIPTION
PART NUMBER
38
5/16"-18 x 3/4" Flange Bolt5/16-18x3/4FB
38
5/16"-18 Whiz Lock Nut5/16-18SFN
1
Easy Step Roof Stair Mount
ES-5015
1
Right Stair Post w/Guardrail
ART-1015
1
Left Stair Post w/Guardrail
ART-1016
1
Roof Stair Post Brace Right
ART-1004
1
Roof Stair Post Brace Left
ART-1007
2
Roof Stair Leveling Plate
ART-1011
4
3-Step Side Rail
ART-5003
3
30" x 11" Stair Step Tread
AS-00030
2Stair Stringer X-BraceART-1001
4
46" 1.5" Swaged Tubing 6" Swage
TR1504606
2
46" 1" Swaged Tubing 6" Swage
TR1004606
4
1.5" P-Clamp for Handrail
HRC1500
6
Self-Tapping ScrewFloor Screw
Parts List

Parts List
ES-5015
48.0
ART-1007 ART-1004
23.0
ART-1015ART-1016
45.25
ART-1011
10.0
ART-5003
AS00030
30.0
ART-1001
47.5
TR1504606
TR1004606
HRC1500
Floor Screw
5/16-18x3/4FB 5/16-18SFN
1:1 1:1 1:1
46.5
46.0
46.0

DETAIL A
PARTS USED IN STEP 1
QTYDESCRIPTION
PART NUMBER
1
Easy Step Roof Stair Mount
ES-5015
1
Roof Stair Post Brace Left
ART-1007
1
Roof Stair Post Brace Right
ART-1004
1
Right Stair Post
ART-1015
1
Left Stair Post
ART-1016
10
5/16"-18 x 3/4" Flange Bolt5/16-18x3/4FB
10
5/16"-18 Whiz Lock Nut5/16-18SFN
A
DRAWN
Marcus Wilmsmeyer
CHECKED
QA
MFG
APPROVED
1/17/2019 Greene Galvanized Stairs
East Lynn, IL 217.375.4244
www.greenebinstairs.com
TITLE
A-Series Roof Stairs - 3-Step
Assembly Instructions
SIZE
A
SCALE
DWG NO
IN-ART5003
REV
SHEET 4 OF 9
1/14
Step 1
Figure 1
Figure 2
A. Place the ART-1007 and ART-1004 braces against the ES-5015 Roof Mount as
shown in Figure 1. The braces' flanges will face up the roof run when installed.
B. Secure the braces to the roof mount using four (4) 5/16" Flange Bolts and four
(4) 5/16" Lock Nuts. See Detail A for bolt hole locations on the ES-5015 brace.
C. Place the ART-1015 and ART-1016 posts against the ART-1007 braces. The bolt
spacing shown in Figure 2 are in the lowest position; adjust the height to fit the
roof.
D. Secure each in place with three (3) 5/16" Flange Bolts and three (3) 5/16" Lock
Nuts.
ES-5015
ART-1007
ART-1004
ART-1016
ART-1015

PARTS USED IN STEP 2
QTYDESCRIPTION
PART NUMBER
4
5/16"-18 x 3/4" Flange Bolt5/16-18x3/4FB
4
5/16"-18 Whiz Lock Nut5/16-18SFN
2
Roof Stair Leveling Plate
ART-1011
DRAWN
Marcus Wilmsmeyer
CHECKED
QA
MFG
APPROVED
1/17/2019 Greene Galvanized Stairs
East Lynn, IL 217.375.4244
www.greenebinstairs.com
TITLE
A-Series Roof Stairs - 3-Step
Assembly Instructions
SIZE
A
SCALE
DWG NO
IN-ART5003
REV
SHEET 5 OF 9
1/9
ART-1011
Step 2
A. Take two (2) ART-1011 Levelling Brackets and attach
them to the ART-1015 and ART-1016 posts as shown
in Figure 3 and Figure 4.
B. Secure the brackets in place using four (4) 5/16"
Flange Bolts and four (4) 5/16" Lock Nuts.
Figure 3
Figure 4
ART-1007 ART-1004
ART-1016
ART-1015

PARTS USED IN STEP 3
QTYDESCRIPTION
PART NUMBER
4
3-Step Side Rail
ART-5003
3
30" x 11" Step Tread
AS00030
10
5/16"-18 x 3/4" Flange Bolt5/16-18x3/4FB
10
5/16"-18 Whiz Lock Nut5/16-18SFN
DRAWN
Marcus Wilmsmeyer
CHECKED
QA
MFG
APPROVED
1/17/2019 Greene Galvanized Stairs
East Lynn, IL 217.375.4244
www.greenebinstairs.com
TITLE
A-Series Roof Stairs - 3-Step
Assembly Instructions
SIZE
A
SCALE
DWG NO
IN-ART5003
REV
SHEET 6 OF 9
1/9
Step 3
A. Place three (3) AS00030 Step Treads in line with four (4)
ART-5003 Siderails as shown in Figure 5.
B. Using ten (10) 5/16" Flange Bolts and ten (10) 5/16" Lock Nuts,
secure the step treads to the siderails. On the second-lowest stair,
omit two of the bolts and nuts; they will be added on a later step.
Figure 5
Omit bolt here and on other side

DETAIL B
PARTS USED IN STEP 4
QTYDESCRIPTION
PART NUMBER
4
5/16"-18 x 3/4" Flange Bolt5/16-18x3/4FB
4
5/16"-18 Whiz Lock Nut5/16-18SFN
2
Roof Stair Cross Brace
ART-1001
B
DRAWN
Marcus Wilmsmeyer
CHECKED
QA
MFG
APPROVED
1/17/2019 Greene Galvanized Stairs
East Lynn, IL 217.375.4244
www.greenebinstairs.com
TITLE
A-Series Roof Stairs - 3-Step
Assembly Instructions
SIZE
A
SCALE
DWG NO
IN-ART5003
REV
SHEET 7 OF 9
1/10
Step 4
A. Take the two (2) Cross Braces and position them on the
bottom of the stair assembly as shown in Figure 6. On an
ART5003, these braces will line up with the second bolt from
the end on the siderails.
B. Secure in place with four (4) 5/16" Flange Bolts and four (4)
5/16" Lock Nuts.
Figure 6
ART-1001

PARTS USED IN STEP 5
QTYDESCRIPTION
PART NUMBER
6
5/16"-18 x 3/4" Flange Bolt5/16-18x3/4FB
6
5/16"-18 Whiz Lock Nut5/16-18SFN
DRAWN
Marcus Wilmsmeyer
CHECKED
QA
MFG
APPROVED
1/17/2019 Greene Galvanized Stairs
East Lynn, IL 217.375.4244
www.greenebinstairs.com
TITLE
A-Series Roof Stairs - 3-Step
Assembly Instructions
SIZE
A
SCALE
DWG NO
IN-ART5003
REV
SHEET 8 OF 9
1/7
Step 5
A. Using six (6) 5/16" Flange Bolts and six (6) 5/16" Lock Nuts,
bolt the siderails to the leveling bracket. Review Figures 7
and 8 for the bolt layout.
B. Tighten the bolts on the leveling plates after the final
placement on the roof.
Figure 7
Figure 8
1
2
3
4
5
6

DETAIL C DETAIL D
PARTS USED IN STEP 6
QTYDESCRIPTION
PART NUMBER
4
5/16"-18 x 3/4" Flange Bolt5/16-18x3/4FB
4
5/16"-18 Whiz Lock Nut5/16-18SFN
4
1.5" Handrail P-Clamp
HRC1500
6
Self-Tapping ScrewFloor Screw
4
1.5" Handrail, Swaged
TR1506006
2
1" Handrail, Swaged
TR1006006
C
D
DRAWN
Marcus Wilmsmeyer
CHECKED
QA
MFG
APPROVED
1/17/2019 Greene Galvanized Stairs
East Lynn, IL 217.375.4244
www.greenebinstairs.com
TITLE
A-Series Roof Stairs - 3-Step
Assembly Instructions
SIZE
A
SCALE
DWG NO
IN-ART5003
REV
SHEET 9 OF 9
1/22
Figure 9
Step 6
A. Taking the four (4) TR1506006 Swaged Pipes (1.5" dia.), position the pipes as
shown in Figure 9, Detail C. Secure the pipes to the posts using four (4) HRC1500
P-Clamps, four (4) 5/16" Flange Bolts, and four (4) 5/16" Lock Nuts.
B. After the four TR1506006 have been position to the desired location, use four (4)
Self-Tapping Screws and secure the 1.5" pipe to the P-Clamp. The screws should
be drilled through the bottom of the P-clamp, to minimize interference with
hands.
C. Take the two (2) TR1006006 Swaged Pipes (1" dia.), and position them as shown
in Figure 9, Detail D. Secure them to the posts by using two (2) Self-Tapping
Screws. There is a hole on the post to aid in starting the Self-Tapping Screw.
