Preface
This manual contains technical information necessary for servicing and repairing the NEC
PowerMateEnterprise computer from NEC Computer Systems Division, Packard Bell
NEC, Inc. It contains hardware and interface information for users who need an overview
of system design. The manual also includes system setup information, procedures for
installing options, and illustrated parts lists. The manual is written for NECCSD-trained
customer engineers, system analysts, service center personnel, and dealers.
The manual is organized as follows:
Section 1 — Technical Information provides an overview of computer features and
options, hardware design, interface ports, and internal devices. System specifications are
listed including dimensions, weight, environment, safety compliance, power consumption,
and memory.
Section 2 — Setup and Operation includes unpacking, setup, and operation information.
Procedures are also included for configuring the system with the BIOS Setup utility, setting
passwords, using power management and security features, reinstalling the operating system
or software, and using the BIOS Update utility.
Section 3 — Option Installation provides installation procedures for adding optional
expansion boards, additional storage devices, system memory, or a processor upgrade.
Section 4 — Maintenance and Troubleshooting includes recommended maintenance
information, along with possible computer problems and their solutions, and the procedures
for battery replacement. NECCSD telephone numbers are provided for obtaining service,
accessing the NECCSD Bulletin Board System, and accessing the NECCSD FaxFlashSM
service.
Section 5 — Repair includes computer disassembly and reassembly procedures. Also
included are an exploded view diagram (Illustrated Parts Breakdown) and a parts list for
field-replaceable parts.
Appendix A — Connector Pin Assignments provides a list of system, riser, and option
board internal connector pin assignments and a list of external pin assignments for the
keyboard, mouse, serial ports, parallel port, network ports, and video port.
Appendix B —Jumper Settings provides jumper settings for the system board and hard
disk drive, and for options that may ship with the computer, including the CD-ROM reader,
the fax/modem board, the Zip drive, and the tape backup unit.
