Accessories
OPS-PCAFQ-PH
Integrated and removable single board computer
with Quad Core AMD processor for
the most demanding content playback
Enjoy seamless integration with this internal
AMD Quad Core Fusion-based PC that
adheres to the Open Pluggable Specification
(OPS) and increases the operational flexibility
of a compatible NEC display for any digital
signage application. With a Windows 7 Professional
license and 4GB of integrated RAM, this PC is perfect for
applications requiring external human interface devices or
extra memory.
Highlights
•No external connections required. DVI video, stereo
audio, RS232 control and power are all passed internally
from display to OPS device, allowing for seamless,
hidden integration and simplified installation
•Powerful 1.5 GHz Quad Core AMD Fusion APU provides
enough horsepower to process high-end digital signage
content
•Durable and protected with an all-stainless steel chassis
and integrated redundant cooling fans to protect the
unit during installation, operation and service
•4GB DDR3 RAM of memory ensures the playback of
high-taxing content
•DisplayPort output allows for multi-display support
through ATI graphics
•Four USB ports allow you to connect compatible devices
•Full networking capabilities through the integrated
Ethernet connection
•3-year warranty matches that of the display
Key Markets
• Quick-Service Restaurants
• Digital Signage
• Education
• Retail
Compatible Displays
With SB-02AM Adaptor:
NEC P Series, V422, V462, V551, V651, X463UN, X551UN
Without SB-02AM Adaptor:
X401S, X461S, X551S, V322, V552, V652
• Corporate
• Medical
• Touchscreen
• Video Conferencing
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
Product specifications subject to change.
©2012 NEC Display Solutions of America, Inc.
All rights reserved. 25.NEC.80.GL.UN.130 rev. 10113
Ethernet DisplayPort USB USB
Operating System Windows 7 Professional
CPU 1.5 GHz AMD Quad Core Fusion
(A8-3500M)
GPU Integrated HD 6620G
RAM 4GB DDR3
Hard Drive 250GB HDD
Video Output Internal DVI, External DisplayPort
Audio Output Internal Stereo, External DisplayPort
Network Connections Gigabit Ethernet
Control I/O USB 2.0 (4)
Video Format Support 1080p video playback, MPEG/2, H.264,
WM9
Power 16VDC Input Voltage, Power Dissipation
(60W)
Operating Temperature 32° - 104°F / 0° - 40°C
Operating Humidity 80% maximum relative humidity,
non-condensing
Dimensions (W x H x D) 7.1 x 1.2 x 4.6 in. / 180 x 30 x 118mm
Weight 2.5 lbs. / 1.2 kg
Gross Weight 3 lbs.
Certifications CE, FCC Section 15
